Thor Broadcast F-RF-TX-MN-2Mw User manual

User Manua l
Optical Mini CATV RF
Transmitter & Receiver 45-1000Mhz
F-RF-TX-MN-2Mw
F-RF-RX-MN-2
TRANSMITTER RECEIVER

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
A Note from Thor Broadcast about this Manual
Intended Audience
This user manual has been written to help people who have to use, integrate and to install the product. Some
chapters require some prerequisite knowledge in electronics and especially in broadcast technologies and
standards.
Disclaimer
No part of this document may be reproduced in any form without the written permission of Thor Broadcast.
The contents of this document are subject to revision without notice due to continued progress in
methodology, design and manufacturing. Thor shall have no liability for any error or damage of any kind
resulting from the use of this document.
Copy Warning
This document includes some confidential information. Its usage is limited to the owners of the product that
it is relevant to. It cannot be copied, modified, or translated in another language without prior written
authorization from Thor Broadcast.

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
Table of Contents
CHAPTER 1 - INTRODUCTION....................................................................................................................... 1
1.1 PRODUCT OVERVIEW ..................................................................................................................................... 1
1.3 SPECIFICATIONS ............................................................................................................................................ 3
1.4 APPLICATION DRAWING.................................................................................................................................. 5
1.5 QUICK INSTALLATION GUIDE .......................................................................................................................... 4

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
Tel: [phone] Email: [e-mail] http://www.thorbroadcast.com
Chapter 1 - Introduction
1.1 Product Overview
TRANSMITTER:
The Thor Fiber Optical Mini CATV RF 45-900Mhz Transmitter is mainly used for transmitting
long distance optical fiber transmission of CATV RF - Analog or digital QAM or ATSC Television Digital
TV, telephone and data transmission. It's application for digital signal transmission of video and data in the
cable television and communications industry. The transmission range can vary from 5km to 30km. It comes
equipped with an advanced DFB laser that readily provides exceptionally high performance and RF power,
as well as automatic processing technology developed by our company. Finally it has a built-in
micro-computer that automatically monitors the control system and guarantees excellent performance of the
equipment.
RECEIVER:
The Thor Fiber Mini FTTH optical receiver F-RF-RFMN-2 is specifically designed for FTTH
networks. These ultra compact Fiber-To-The-Home optical receivers were designed and engineered to
ensure compatibility for any type of FTTH network structure in mind. It has small compact housing,
mini-internal circuit structure that still remains a high performance, low cost receiver that is economical for
any project. It can be used for any application of HFC network fiber to the home (FTTH) because of it's
form factor and output power. These units have a wide range for receiving optical power, high output level
and low power consumption. They are the ideal pieces for any optical fiber network which can provide
a highly reliable, digital video frequency and data bi-directional transmission for the HFC network. It could
be use to send CATV RF point to point or point to multipoint.
This unit comes in a kit: part of the Thor Fiber MIni Transmitter / Receiver kit with F-RF-TX-MN-2Mw

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
2
1.2 Key features
TRANSMITTER:
45-1000MHz working bandwidth
High performance DFB coaxial laser that has a great linking performance and stable output
Advanced CPU processing and with an auto monitoring system to supervise the operational status
which leads to a longer life of the laser
Low power loss design(less than 8W) which creates a very low operational temperature
RECEIVER:
Designed for FTTH (Fiber To The Home) Networks
Excellent linearity and flatness
Converts Optical signal to electrical RF 45-10000Mhz
Analog NTSC/PAL, Digital QAM, ATSC, DVB-T ,
20dBmV RF output power at Optical Input: -0 dBm
Dual Coaxial output for easy deployment for multiple devices
Wide range of optical input power
Single-mode fiber
Ultra low noise technology
Smaller size and easy to install
Red-LED for power indication
Color-LED for optical power indication
Built-in filter

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
Tel: [phone] Email: [e-mail] http://www.thorbroadcast.com
1.3 Specifications
TRANSMITTER:
Item
Unit
Technical specification
Wavelength
nm
1310nm ± 20
Laser type
DFB laser
Optical
modulation type
Direct optical strength modulation
Optical
connector type
SC/APC
IMPORTANT NOTE*** (it is very important to interface our unit with
SC/APC - Angle Polished Connector to avoid any light reflections.
If your fiber is terminated with the SC, ST, FC /PC flat connector, you
need to use an optical jumper from PC type to SC/APC for proper
conversion.
Frequency range
MHz
45-862/1000
RF input level
dBuV
72~82
Flatness in band
dB
±0.75
Rf input
resistance
75
Input reflection
loss
dB
≥16
Link C/N
dB
≥51
Link C/CSO
dB
≥60
Link C/CTB
dB
≥65
AGC controlling
range
dB
±5
MGC controlling
dB
0~10
Power Supply
V
DC 12 V/1 A
Power Loss
W
≤ 8
Dimension
mm
140 x 90 x 26

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
Tel: [phone] Email: [e-mail] http://www.thorbroadcast.com
RECEIVER:
Technical Parameters
Light wavelength
1100 ~1600nm
Operating Wavelength
1550 nm ± 20nm ,built-in for filtering 1490 nm signal and remain 1550 nm signal to
photo-diode
Optical input power
range
0dBm to ~-15dBm (digital) & 0dBm to ~-10dBm (analog)
Frequency range
45MHz-1GHz
Output level
Output range: 65-75dBμV (Optical Input: -6 dBm)
Output range: 70-80dBμV (Optical Input: -2 dBm)
Flatness
±1dB
Slope
5dB ± 2dB
Return loss
16dB
Noise figure
47.5dB
CTB
≥65dB
CSO
≥65dB
MER
38
Power Consumption
≥0.6W
Test Conditions
60 CH (PAL-D), Pin -6dBm, 1 EDFA with noise figure 5dB, 25Km, Composite OMI
18.5%
Output impedance
75 Ω
Output port number
1
RF connector
F (female)
Responsibility
≥ 0.9 A/W @ 1550nm
Optical return loss
≥ 55 dB
LED indicator
Alarm LED:
Green on: receive power in range (about -6 to 0 dBm)
Red: low (<-8dBm) or lost signal
Power LED: Red = Power on
Power Adapter
Input Voltage: 90-250V AC@50-60Hz
Output Voltage uncertainty ≤ 3% without load
Output Voltage: Continuous current ≥ 90% nominal current;
±5% nominal DC Voltage; Ripple Voltage (Vpp) ≤150mV
Voltage surge arrester equipment’s integrated.
Housing material
Stainless Metal with wall-mount Flange
Working environment
Operating temperature -20 + 55 °C
Size (W)*(D)*(H)
36*76.5*23mm

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
Tel: [phone] Email: [e-mail] http://www.thorbroadcast.com
1.4 Principle Chart
1.5 Quick Installation guide
The Mini Transmitter and Mini Receiver set are plug and play devices if
the RF input power to the TX and optical power Input to the RX are in the specified range.
TX RF INPUT 15-25dBmV (75-85dBuV)
RX Optical INPUT should be +2 - 6dBm
TRANSMITTER:
1) Connect Power Supply to the Transmitter
2) Connect CATV RF Input to the F port connector - Please note, the RF Power should be
Between 15-25dBmV (75-85 dBµV)
3) Connect fiber optic cable to the Mini Transmitter Output - The Connector type MUST be
SC/APC, never use SC/PC (Blue flat connector)
NEVER LOOK DIRECTLY INTO THE UNITS OPTICAL OUTPUT (you could burn your eye)
4 ) For short distance, point to point transmission, please plug 5db fiber optic attenuator,
included in the box. (if the transmitter is used with a fiber optic splitter, the attenuator is not
needed due to splitters insertion loss).
The fiber loss is about 0.35db/km in 1310nm wavelength there is also some slight loss in path panel
junctions typically 0.1 -0.5db per junction
5) The TX should show "ON" on the LCD, meaning it is transmitting and outputting an optical signal.

F-RF-TX-MN-2Mw & F-RF-RX-MN-2
Tel: [phone] Email: [e-mail] http://www.thorbroadcast.com
RECEIVER:
1) Connect POWER Supply to the Receiver, "No Light Input" or "Level too Low" the LED will be RED
2) Connect CATV RF cable to the F port connector - RF Output, the output will be about 22dBmV (82 dBuV)
3) Connect fiber optic cable to the Mini Receiver INPUT –The Connector type MUSTbe SC/APC, never use SC/PC
(Blue flat connector)
NEVER LOOK DIRECTLY TO THE FIBER JUMPER. (You will burn your eye)
4) The Optical level by the receiver should be about +2 to -6dBm
The Light turns Red when RF Signal Input is Lower then 80dBµV (>20dBmV)
5) The LED should turn from RED to GREEN when RF Signal Input is Between 60~80dBµV (0-20dBmV)
5a) The RED LED means no Link Light detector RF Signal Input is larger than 60dBµV (>0dBmV)
5b) The red light mightalsomean saturation, LEVELTOO HIGH, itis easyto determine when you plug in the optical
jumper the unit will go from RED to GREEN to RED again, it means the optical level is higher
than +2dbm , the receiver will still work correctly if this levelwill be not higher than +5dbm, If higher then +5, please
add 5db attenuator included with your purchase.
Optical Output SC/APC or
FC/APC
Power SupplyAdapter
(DC 12V 1.5A)
RF Input Port
