THOR T2161XBIN Quick start guide

Cod:0103087104-00.03
T2161XBIN
Extractors
Installation, use and maintenance

2
Important
The manufacturer cannot be held responsible for injuries or losses caused by incorrect use or installation of this product.
Please note that the manufacturer reserves the right to invalidate the guarantee supplied with this product following
incorrect installation or misuse of the appliance or use in a commercial environment.
This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental
capacity, or who lack experience or knowledge about it, unless they have had supervision or instructions on how to use
the appliance by someone who is responsible for their safety.
Under no circumstances should any external covers be removed for servicing or maintenance except by suitably qualified
personnel.
Appliance information:
Please enter the details on the appliance rating plate below for reference, to assist THOR Customer Care in the event of a
fault with your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity:
This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Gas
safety, Electrical safety (LVD) and Electromagnetic interference compatibility (EMC).
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE
2002/96/EC.
At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer
providing appliance recycling services.
Disposing of a household appliance separately avoids possible negative consequences for the environment and health. It
also enables the constituent materials to be recovered, saving both energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin.
Please note:
•Under no circumstances should the extractor be connected to any gas ventilation system, flue system or hot air
ducting system.
•Do not vent the extractor into an attic or loft space.
•Only house the extractor in rooms with adequate ventilation. Remember that the extractor is powerful and
whatever air is extracted needs to be replaced.
•Do not tile the extractor in. It should be removable for service or maintenance.
•Do not use silicone sealant to secure the hood to the wall.
•You must be able to isolate the extractor from the mains electrical supply after installation.
•This extractor has been designed to be used in a room with a volume of less than 36 m3.
•Steam cleaners must not be used when cleaning this appliance.
•The performance of your extractor will vary depending on a number of factors. These include: type of extraction,
length of ducting, room volume, ventilation available and cleanliness of the filters.

4
Care and Maintenance
IMPORTANT : DO NOT PERFORM MAINTENANCE OR CLEANING OF THE EXTRACTOR WITHOUT FIRST
SWITCHING OFF THE ELECTRICITY SUPPLY.
Cleaning
You should use a nonabrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the
control panel markings.
shine with a clean cloth.
Cleaning the (rectangular) grease filter
The grease filter captures grease particles in the air, so is therefore subject to clogging depending on the frequency of
use of the appliance.
In order to prevent fire hazard it is recommended to clean the grease filter at a maximum of 2 month intervals by
carrying out these instructions:
Depending on model, you may have either acrylic or aluminium grease filter(s).
Acrylic grease filter:
1. Remove the cover panel by pushing the fixing clips up and then lifting the panel forwards.
2. Remove the filter retaining wires from the cover panel.
3. Remove the grease filter and wash by hand in a lukewarm solution of water and mild detergent. Once clean
squeeze the grease filter but DO NOT wring it out. Clean the filter holder using a dilute solution of water and mild
detergent or with a damp cloth. Allow the grease filter to dry completely before reassembling the extractor.
4. Replace the grease filter in the cover panel and reattach the filter retaining wires.
5. Replace the cover panel by inserting the lugs on the upper side in the extractor, and then refasten the fixing clips
on the lower side.
Aluminium grease filters:
1. Remove the filters from the cooker hood and wash in a solution of warm water and neutral liquid detergent, leaving
to soak.
2. Rinse thoroughly with warm water and leave to dry.
3. The filters may alternatively be washed in the dishwasher. The aluminium panels may alter in colour after several
washes in a dishwasher. This is not a fault and is not cause for replacing the panels.

5
Changing the (circular) charcoal filter (re-circulating only):
To ensure best performance of your extractor, you should replace the charcoal filters every four to six months,
depending on use.
Please note the charcoal filter cannot be washed.
To attach a new charcoal filter, follow the steps below:
1. Remove the cover panel (acrylic filter model) or grease filter (aluminium filter model) as described above.
2. Place the charcoal filter on the centre of the motor support, and once firmly located turn the charcoal
filter clockwise 90º until the charcoal filter locks into position.
3. Replace the cover panel or grease filter that has been removed.
Changing the Light
DO NOT CHANGE THE LIGHT BULB IMMEDIATELY AFTER USE AS THE BULB WILL BE HOT. ALLOW IT TO
COOL BEFORE REMOVING IT.
Remove the cover panel as described above, unscrew the light bulb and replace the light with the required
light bulb as shown in the table below. Finally, replace the cover panel.
Do not touch bulbs or adjacent areas during or straight after prolonged use of the lights.
The light is designed for use during cooking and not for general room illumination. Extended use of the light
can reduce the life span of the bulb.
Bulb replacement is not covered by the guarantee.
Only use bulbs recommended for your extractor. Do not fit bulbs of a higher power rating. Bulbs of a lower
power rating may be adequate for use, generally last longer and use less energy.
Spare bulbs are available from THOR Customer Care or from your local DIY shop.
T2161XBIN E14 LED 4Wx1 DR-4-H-E14-37
Table 1

FUSE 3A
PROTECTION LINE
3A Fuse is installed inside the plug to protection line.
49W
230-240V ac, 50Hz

7
Selection of outlet mode
Back vent mode
Top vent mode
1. Remove the knock-out plate from the back of the unit.
2. Do not remove the knock-out plate on top. If removed, a cover plate must be used.
3. Fit the ducting adaptor on the outlet.
4. Attach the ducting hose to the adaptor.
1. Remove the knock-out plate from the top of the unit.
2. Do not remove the back knock-out plate. If removed, a cover plate must be used.
3. Fit the ducting adaptor on the outlet.
4. Attach the ducting hose to the adaptor.
Vertical installation is the most common. If your kitchen has an attic space above, the ducting may be run up through
the cupboard and attic to a roof cap.

10
In re-circulating mode, air is vented back into the kitchen through the
opening in the cooker hood.
This method is advised if you are not using your hob intensively.
Re-circulated air requires the use of charcoal filters to remove odours.
Charcoal filter installation
Care and Maintenance
IMPORTANT: DO NOT ATTEMPT TO MAINTAIN OR CLEAN THE
EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY
SUPPLY.
Fig. 6-I
To ensure the best performance from your cooker hood, the charcoal
filter should be replaced every 3-6 months, dependent on use.
Check with your local retailer or dealer for information on how to obtain
replacement charcoal filters.
1. Using both hands, grasp as far to the edges of the front screen as
possible and carefully open it forwards (do not pull in the middle as
this might bend the panel!).
2. Using both grips “a”, push the filter flap upwards ①, pull it forwards ②
and remove the filter flap downwards ③.
3. Install the carbon filter “b” (not in the scope of delivery) on the motor
as shown and rotate 90 degrees to attach.
Fig. 6-II a
Fig. 6-III
b

INT60SS
26.6
1.7
8.6
69.1
99.2
120
193.2
38.2
4
55
---
0.0
62
70.0 (D)
14 (D
THOR
)

12
