THORLABS PDA07P2 User manual

PDA07P2
InAsSb Amplified Fixed
Gain Detector
User Guide

InAsSb Amplified Fixed Gain Detector
Table of Contents
Chapter 1 Warning Symbol Definitions ...........................................1
Chapter 2 Description........................................................................2
Chapter 3 Setup..................................................................................3
Chapter 4 Operation...........................................................................4
4.1. Theory of Operation......................................................4
4.2. Responsivity .................................................................4
4.3. Dark Current .................................................................4
4.4. Bandwidth and Response ..............................................5
4.5. Terminating Resistance.................................................5
Chapter 5 Troubleshooting...............................................................6
Chapter 6 Specifications...................................................................7
6.1. Response Curve.............................................................9
6.2. Mechanical Drawing ...................................................10
Chapter 7 Certificate of Conformance ...........................................11
Chapter 8 Regulatory.......................................................................12
Chapter 9 Thorlabs Worldwide Contacts.......................................13

InAsSb Amplified Fixed Gain Detector Chapter 1: Warning Symbol Definitions
Rev C, January 3, 2019 Page 1
Chapter 1 Warning Symbol Definitions
Below is a list of warning symbols you may encounter in this manual or on your
device.
Symbol
Description
Direct Current
Alternating Current
Both Direct and Alternating Current
Earth Ground Terminal
Protective Conductor Terminal
Frame or chassis Terminal
Equipotentiality
On (Supply)
Off (Supply)
In Position of a Bi-Stable Push Control
Out Position of a Bi-Stable Push Control
Caution, Risk of Electric Shock
Caution, Hot Surface
Caution, Risk of Danger
Warning, Laser Radiation
Caution: ESD Sensitive Components

InAsSb Amplified Fixed Gain Detector Chapter 2: Description
Page 2 TTN161140-D02
Chapter 2 Description
The PDA07P2 is an amplified Indium Arsenide Antimonide (InAsSb) detector
designed for detection of light ranging from 2.7 to 5.3 µm. A buffered output drives
50 Ωload impedances up to 5 V. The PDA07P2 housing includes a removable
threaded coupler (SM1T1) and retaining ring (SM1RR) that is compatible with any
number of Thorlabs’1" threaded accessories. This allows for convenient mounting
of external optics, light filters, and apertures as well as an easy mounting
mechanism using Thorlabs’cage assembly accessories.
ESD Caution
The components inside this instrument are ESD sensitive. Take all
appropriate precautions to discharge personnel and equipment before
making any electrical connections to the unit.

InAsSb Amplified Fixed Gain Detector Chapter 3: Setup
Rev C, January 3, 2019 Page 3
Chapter 3 Setup
The detector can be set up in many different ways using our extensive line of
adapters. However, the detector should always be mounted and secured for best
operation.
1. Unpack the optical head, install either an imperial or metric optical post
into one of the mounting holes located on the bottom and side of the
sensor, and mount using a post holder. Note that these detectors feature
tapped holes that accept both 8-32 and M4 threads, so using either
imperial or metric TR posts is possible.
2. Connect the power supply 3-pin plug into the power receptacle on the
PDA07P2.
3. Plug the power supply into a 50 to 60 Hz, 100 V / 120 V / 230 V power
outlet.
4. Attach a 50 Ωcoax cable (i.e. RG-58U) to the output of the PDA. When
running cable lengths longer than 12", we recommend terminating the
opposite end of the coax with a 50 Ωresistor (Thorlabs p/n T4119) for
maximum performance. Connect the remaining end to a measurement
device such as an oscilloscope or high-speed DAQ card.
Caution: Many high-speed oscilloscopes have input impedances of
50 Ω. In this case, do not install a 50 Ωterminator. The combined loads
will equal 25 Ω, which could allow ~135 mA of output current, damaging
the output driver of the PDA07P2.
5. Power the PDA07P2 on using the power switch located on the top side
of the unit.
Caution!
The PDA07P2 was designed to allow maximum accessibility to the
photodetector by having the active area surface of the diode flush with the
outside of the PDA housing. When using fiber adapters, make sure that the
fiber ferrule does not crash into the detector. Failure to do so may cause
damage to the diode and or the fiber.
6. Install any desired filters, optics, adapters, or fiber adapters to the input
aperture.
7. During alignment, take appropriate precautions, such as using reduced
radiation power, or other precautions, and use proper eye and/or skin
protection as recommended by the radiation source manufacturer.
8. Apply a light source to the detector.

InAsSb Amplified Fixed Gain Detector Chapter 4: Operation
Page 4 TTN161140-D02
Chapter 4 Operation
4.1. Theory of Operation
Thorlabs’PDA series of detectors are ideal for measuring both pulsed and CW
light sources. The PDA07P2 includes a reverse-biased PIN photo diode, mated to
a fixed gain transimpedance amplifier, and is packaged in a rugged housing.
4.2. Responsivity
The responsivity of a photodiode can be defined as a ratio of generated
photocurrent (IPD) to the incident light power (P) at a given wavelength:
󰇛󰇜

4.3. Dark Current
Dark current is leakage current which flows when a bias voltage is applied to a
photodiode. PDA detectors with a transimpedance amplifier control the dark
current flowing out. Looking at the figure above, it can be noted that point B is held
at ground, and the amplifier will try to hold point A at “virtual ground”. This
minimizes the effects of dark current present in the system.
The dark current is also affected by the photodiode material and the size of the
active area. Silicon devices generally produce low dark current compared to
germanium devices, which have high dark currents. The table below lists several
photodiode materials and their relative dark currents, speeds, sensitivity, and
costs. Please note that sensitivity values in the table are typical values; Thorlabs
offers photodetectors with sensitivity ranges that vary from those shown below.

InAsSb Amplified Fixed Gain Detector Chapter 4: Operation
Rev C, January 3, 2019 Page 5
Material
Dark
Current
Speed
Sensitivity1
(nm)
Cost
RoHS
Compliant
Silicon (Si)
Low
High
400 –1000
Low
Yes
Germanium (Ge)
High
Low
900 –1600
Low
Yes
Gallium Phosphide
(GaP)
Low
High
150 –550
Med
Yes
Indium Gallium
Arsenide (InGaAs)
Low
High
800 –1800
Med
Yes
Extended Range:
Indium Gallium
Arsenide (InGaAs)
High
High
1200 –2600
High
Yes
Lead sulfide (PbS)
or Lead selenide
(PbSe)
N/A2
Low
1000 - 2900
(PbS) or 1500
- 4800 (PbSe)
Med
No
Indium Arsenide
Antimonide (InAsSb)
N/A3
High
1000 –53004
Med
Yes
4.4. Bandwidth and Response
For the PDA detectors, the gain of the detector is dependent on the feedback
element (Rf). The bandwidth of the detector can be calculated using the following:
󰇛󰇜

Where GBP is the amplifier gain bandwidth product and CDis the sum of the
photodiode junction capacitance and the amplifier capacitance.
4.5. Terminating Resistance
The maximum output of the PDA07P2 is 10 V for high impedance loads (i.e.,
RLoad > 5 kΩ) and 5 V for 50 Ω loads. Ensure the signal level is below 10 V to avoid
saturation.
For low terminating resistors, <5 kΩ or 1% error, an additional factor needs to be
considered. The output of the PDA includes a 50 Ω series resistor (Rs). The output
load creates a voltage divider with the 50 Ω series resistor as follows:
 

 
󰇛󰇜󰇛󰇜
Note that we already include the scale factor in our specification for the gain at 50
Ω. Refer to the table in Chapter 6 for additional performance specifications.
1
Approximate values; actual wavelength values will vary.
2
These are photoconductive detectors, normally AC coupled.
3
Photovoltaic detectors, generally unbiased.
4
At 25 °C. The lower end cut-off wavelength can be determined by the front window material.

InAsSb Amplified Fixed Gain Detector Chapter 5: Troubleshooting
Page 6 TTN161140-D02
Chapter 5 Troubleshooting
Problem
Suggested Solutions
There is no signal response.
Verify that the power is switched on and all
connections are secure.
Verify the proper terminating resistor is installed if
using a Voltage measurement device.
Verify that the optical signal wavelength is within
the specified wavelength range.
Verify that the optical signal is illuminating the
detector active area.
Output Voltage will not increase.
Detector Output is skewed.
Check to make sure the detector is not saturated.
Refer to the Output Voltage spec. in the
Specifications table.
Install a 1" Lens Tube (SM1L10) to the thread
coulpler (SM1T1) to baffle any external light
sources to see if this improves the response.

InAsSb Amplified Fixed Gain Detector Chapter 6: Specifications
Rev C, January 3, 2019 Page 7
Chapter 6 Specifications
All performance specifications are typical, performed at 25 °C ambient
temperature, and assume a 50 Ω load, unless stated otherwise.
5
The PDA07P2 has a 50 Ω series terminator resistor (i.e., in series with the amplifier output).
This forms a voltage divider with any load impedance (e.g., 50 Ω load divides signal in half).
Electrical Specifications5
Detector
-
InAsSb
Active Area
-
0.7 mm x 0.7 mm (0.49 mm2)
Wavelength Range
λ
2.7 to 5.3 µm
Peak Wavelength
λp
4.1 µm (Typ.)
Peak Response
( λ p)
4.5 mA/W (Typ.)
Small Signal Bandwidth
-
9 MHz
NEP (λp)
W/√Hz
1.0 x 10-10
Noise (RMS)
-
1 mVrms
Max Ouput Current
IOUT
100 mA
Dark Offset
-
±40 mV (Max)
Load Impedance
-
50 Ωto Hi-Z
Transimpedance Gain
-
1.5 x 105V/A (50 Ω)
3 x 105V/A (Hi-Z)
Output Voltage
VOUT
0 to 5 V (50 Ω)
0 to 10 V (Hi-Z)

InAsSb Amplified Fixed Gain Detector Chapter 6: Specifications
Page 8 TTN161140-D02
6
Measured from the active area to the start of the threads on the housing body. The detector
active area surface is flush with the front of the housing body.
7
Although the power supply is rated for 6 W, this detector’s actual usage is <5 W over the full
operating range.
General
On/Off Switch
Slide
Output
BNC (DC Coupled)
Package Size
2.79" x 1.96" x 0.89"
(70.9 mm x 49.8 mm x 22.5 mm)
PD Surface Depth6
0.09" (2.2 mm)
Weight, Detector Only
0.10 kg
Accessories
SM1T1 Coupler
SM1RR Retainer Ring
Operating Temp
10 to 50 °C
Storage Temp
-25 to 70 °C
AC Power Supply
AC –DC Converter
Input Power7
6 W
100 V / 120 V / 230 V, 50 –60 Hz

InAsSb Amplified Fixed Gain Detector Chapter 6: Specifications
Rev C, January 3, 2019 Page 9
6.1. Response Curve
The responsivity curve of the PDA07P2 photodetector measured at 25 °C ambient
temperature. The blue-shaded region indicates the specified 2.7 - 5.3 µm
wavelength range.
2.5 3.0 3.5 4.0 4.5 5.0 5.5
0
1
2
3
4
5PDA07P2 Responsivity (T = 25 °C)
Responsivity (mA/W)
Wavelength (µm)

InAsSb Amplified Fixed Gain Detector Chapter 6: Specifications
Page 10 TTN161140-D02
6.2. Mechanical Drawing

InAsSb Amplified Fixed Gain Detector Chapter 7: Certificate of Conformance
Rev C, January 3, 2019 Page 11
Chapter 7 Certificate of Conformance

InAsSb Amplified Fixed Gain Detector Chapter 8: Regulatory
Page 12 TTN161140-D02
Chapter 8 Regulatory
As required by the WEEE (Waste Electrical and Electronic Equipment Directive)
of the European Community and the corresponding national laws, Thorlabs offers
all end users in the EC the possibility to return “end of life” units without incurring
disposal charges.
This offer is valid for Thorlabs electrical and electronic equipment:
Sold after August 13, 2005
Marked correspondingly with the crossed out “wheelie
bin” logo (see right)
Sold to a company or institute within the EC
Currently owned by a company or institute within the
EC
Still complete, not disassembled and not
contaminated
As the WEEE directive applies to self contained operational electrical and
electronic products, this end of life take back service does not refer to other
Thorlabs products, such as:
Pure OEM products, that means assemblies to be built into a unit by the
user (e.g. OEM laser driver cards)
Components
Mechanics and optics
Left over parts of units disassembled by the user (PCB’s, housings etc.).
If you wish to return a Thorlabs unit for waste recovery, please contact Thorlabs or
your nearest dealer for further information.
Waste Treatment is Your Own Responsibility
If you do not return an “end of life” unit to Thorlabs, you must hand it to a company
specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public
waste disposal site.
Ecological Background
It is well known that WEEE pollutes the environment by releasing toxic products
during decomposition. The aim of the European RoHS directive is to reduce the
content of toxic substances in electronic products in the future.
The intent of the WEEE directive is to enforce the recycling of WEEE. A controlled
recycling of end of life products will thereby avoid negative impacts on the
environment.
Wheelie Bin Logo

InAsSb Amplified Fixed Gain Detector Chapter 9: Thorlabs Worldwide Contacts
Rev C, January 3, 2019 Page 13
Chapter 9 Thorlabs Worldwide Contacts
For technical support or sales inquiries, please visit us at
www.thorlabs.com/contact for our most up-to-date contact information.
USA, Canada, and South America
Thorlabs, Inc.
sa[email protected]
[email protected]
Europe
Thorlabs GmbH
[email protected]
France
Thorlabs SASSA
[email protected]
Japan
Thorlabs Japan, Inc.
[email protected]
UK and Ireland
Thorlabs Ltd.
[email protected]
[email protected]
Scandinavia
Thorlabs Sweden AB
[email protected]
Brazil
Thorlabs Vendas de Fotônicos Ltda.
[email protected]
China
Thorlabs China
[email protected]

www.thorlabs.com
