Thorne & Derrick THR880i Ex Installation instructions

THR880i Ex
Safety Instructions




















This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission. 1
02.02/EN
PS10952BENAB01

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission.
2
Table of Contents
1Application..................................................................................... 3
2Safety information ........................................................................... 3
3Safety regulations............................................................................ 3
4Battery cover protection................................................................... 5
4.1 To unscrew the battery cover ..................................................... 5
4.2 To install the safety plug ............................................................ 6
5Faults and damage........................................................................... 6
6Ex-data .......................................................................................... 7
7Specifications ................................................................................. 7
8Cleaning, maintenance and storage.................................................... 8
9EC-Type Examination Certificate........................................................ 9
Note:
The current safety precautions, operating instructions,
EC Declaration of Conformity and the Certificate of Conformity can
be downloaded from the relevant product page at
www.ecom-ex.com
or requested directly from the manufacturer.

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission. 3
1APPLICATION
The THR880i Ex is a digital radio unit based on the TETRA standard
for industrial application in areas with an increased risk of explosion
in zones 1 and 2, in accordance with directive 1999/92/EC
(ATEX 137).
2SAFETY INFORMATION
These safety instructions contain information and safety regulations
which are to be observed without fail for safe operation in the
described conditions. Non-observance of this information and these
instructions can have serious consequences, endanger the lives and
health of people, damage property or may violate regulations.
Please read these operating instructions carefully before
starting to use the unit!
In case of any doubt, please contact ecom instruments GmbH.
3SAFETY REGULATIONS
Use of this unit assumes that the user observes conventional safety
regulations and has read the certificate in order to eliminate faulty
operation of the unit.
The following safety regulations must also be complied with:
- The unit itself and the battery must not be opened.
- The battery of the THR880i Ex must be safely installed and
connected in the handset inside the ex-hazardous areas.
Depending on the product reference, this regulation is
guaranteed when one of the following requirements is
fulfilled :

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission.
4
a) Opening of the battery cover is prevented with a
locking screw (for the specific instructions, see
chapter 4 Battery cover protection, figures 1 and 2)
b) Opening of the battery cover is prevented with a
specific ATEX Safety bag THR-LT1
c) Opening of the battery cover is prevented with an ATEX
Safety plug (for the specific instructions, see chapter 4
Battery cover protection, figures 3 and 4)
d) Opening of the battery cover is prevented with a safe
connection of an ATEX accessory.
- The battery may only be exchanged or charged outside the
Ex-area.
- Additional batteries must not be carried in the Ex-area.
- Only BLN-Ex batteries specified by the manufacturer may be
used.
- The use of other batteries is strictly prohibited and will
result in the nullification of Ex-protection.
- The battery may only be charged outside the Ex-areas using
an appropriate charger.
- Before using the unit in Ex-areas, the combined charging
and accessory interface must be inspected for contamination
and, if required, cleaned with a brush or by blowing off with
compressed air.
- Only ATEX-approved accessories may be used inside the Ex-
area. For a list of approved ATEX accessories, please see
http://www.ecom-ex.com/
- It must be ensured that the unit is not taken into zones 0, 20,
21 or 22.

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission. 5
4BATTERY COVER PROTECTION
4.1 To unscrew the battery cover
Figure 1
1) Unscrew the screw (1) at
the bottom of the terminal
by using the tool in the
sales package.
Figure 2
2) When the head of the
screw is completely out of
its seating, push the battery
door to open it.
To lock the battery door, close it normally and screw on the screw (1)
until its head fits completely inside its seating.

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission.
6
4.2 To install the safety plug
Figure 3
1
1
2
1) Make sure that the hatches
(1) on both sides of the
safety plug are out and the
slot is in the horizontal
position (2).
2) Insert the safety plug
Figure 4
4
3
3) Lock the safety plug in
place by turning the slot
(e.g.with a coin) to the
vertical position (4). The
safety plug is properly
installed when the slot is in
the vertical position and the
hatches are closed (inside
the safety plug).
To remove the safety plug, open it by turning the slot to the
horizontal position (3). This opens the hatches on both sides of the
safety plug. You can now remove the plug.
5FAULTS AND DAMAGE
If there is any reason to suspect that the safety of the unit has been
impaired, it must be withdrawn from use and removed immediately
from the Ex-area.

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission. 7
It is necessary to make sure that the radio is not restarted, not even
accidentally.
We recommend that the unit is returned to ecom instruments GmbH
for inspection.
The safety of the unit may be compromised, if, for example:
- there is visible damage to the housing
- the unit has been subjected to excessive loads
- the unit has been improperly stored
- the unit has been damaged in transit
- unit markings or inscriptions are illegible
- malfunctions occur
- permitted limit values have been exceeded.
6EX-DATA
EC-Type Examination Certificate No.: ZELM 07 ATEX 0347 X
Ex-Designation: Ex II 2 G Ex ib IIC T4
Approved for:
Zone 1 and 2, device group II, explosion group IIC explosive gases,
vapours or mist, temperature class T4
7SPECIFICATIONS
Frequency range: 380-400 MHz (RC-12)
410-430 MHz (RC-13)
806-825, 851-870 MHz (RC-21)
Operating voltage: 3.7 V
Protection rating: IP54
Dimensions (LxWxD): 157 x 57 x 35 mm
Weight: approx. 300g
Battery / power supply: BLN-Ex, 1400 mAh Li-Poly
Operating time
(standby/RX/TX)
8-17 hours (90/5/5)
Ambient temperature Ta-20°C ... +50°C
Storage temperature: -20°C ... +50°C
CE-Designation: CE0102

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission.
8
8CLEANING, MAINTENANCE AND STORAGE
- Only use a damp and suitable cloth or sponge to clean the radio unit
or the CRR-1 active holder. Do not use any solvents or abrasive
cleaning agents when cleaning.
- It is recommended that you have the functionality and accuracy of
the unit inspected by ecom instruments GmbH every two years.
- The battery should be removed from the unit during prolonged
periods of storage.
- Do not allow storage temperatures to exceed or fall below the
permitted range of -20°C to +50°C.

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission. 9
9EC-TYPE EXAMINATION CERTIFICATE
Here is the original Ex certificate in German language. It is granted to ecom instruments GmbH
by Prüf- und Zertifizierungsstelle ZELM Ex in Braunschweig in Germany on 23.8.2007.

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission.
10

Here is the translation of the certificate.
Page 1/2
EC-type examination certificates without a signature and stamp are not valid.
This EC-type examination certificate may only be circulated without alteration.
Extracts or alterations are subject to approval by the Prüf- und Zertifizierungsstelle (Test and Certification Body) ZELM Ex
Prüf- und Zertifizierungsstelle (Test and Certification Body) ZELM Ex • Siekgraben 56 • D-38124 Braunschweig
Prüf- und Zertifizierungsstelle
(Test and Certification Body) ZELM Ex
(1) EC-Type Examination Certificate
(2) Devices and shielding systems intended for regulated use in explosive
areas - Directive 94/9/EC
(3) EC-Type Examination Certificate number
ZELM 07 ATEX 0347 X
(4) Device: Digital trunked radio type THR880i Ex
(5) Manufacturer: ecom Instruments GmbH
(6) Address: D-97959 Assamstadt
(7) The construction of this device and the various permissible details are specified in the appendix
to this Type Examination Certificate.
(8) As notified body No. 0820, according to article 9 of the Council Directive of the European
Communities dated 23 March 1994 (94/9/EC), Prüf- und Zertifizierungsstelle (Test and
Certification Body) ZELM Ex certifies the fulfilment of the fundamental health and safety
requirements for the conception and construction of devices and protective systems for
intended use within explosive areas in accordance with appendix II of the directive.
The results of the examination are specified in the confidential inspection report No. ZELM Ex
0370724554.
(9) The fundamental health and safety requirements are fulfilled through compliance with
EN 60079-0:2006 EN 60079-11 :2007
(10) If the character "X" appends the certificate number, it refers to special conditions in the
appendix to this certificate for the safe application of the device.
(11) This EC-Type Examination Certificate only refers to the construction, examination and testing of
the specified device or protective system in agreement with directive 94/9/EC. Further
requirements of this directive may apply for the manufacturing process and the supply of this
device or protective system. These are not covered by the present certificate.
(12) The designation of the device must contain the following details:
II 2 G Ex ib IIC T4
Certification body ZELM Ex Brunswick, 23.08.2007
This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission. 11

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission.
12
EC-type examination certificates without a signature and stamp are not valid.
This EC-type examination certificate may only be circulated without alteration.
Extracts or alterations are subject to approval by the Prüf- und Zertifizierungsstelle (Test and Certification Body) ZELM Ex
Prüf- und Zertifizierungsstelle (Test and Certification Body) ZELM Ex • Siekgraben 56 • D-38124 Braunschweig
Prüf- und Zertifizierungsstelle
(Test and Certification Body) ZELM Ex
(13) Appendix
(14) EC-Type Examination Certificate ZELM 07 ATEX 0347 X
(15) Description of the device
The explosion-shielded digital hand-held radio THR880i Ex serves the purpose of
providing communication in explosive areas. The device is available in various models, which
fundamentally deal with different frequency ranges.
Only those accessories that are approved by the manufacturer may be used under the
specified conditions.
The device must be charged outside the Ex-area using the corresponding battery charger.
Electrical data
Supply current circuit from an integrated rechargeable battery pack
Type BLN-Ex
Transmitting power up to 2 W
Interface electric circuit in ignition protection class Intrinsic Safety Ex ib IIC
Only for connection to approved accessories
permissible ambient temperature range -20 °C to + 5 0 °C
(16) Test report No.
ZELM Ex 0370724554
(17) Special conditions
1. The instruction manual is to be observed, particularly with regard to the approved
corresponding accessories. Only these accessories may be used.
2. The device may only be charged outside the explosive area using the corresponding
charger or the appropriate charging accessories.
3. Only the BLN-Ex battery pack may be used!
4. All connection sockets, with the exception of the external antenna socket, must be kept
sealed in the Ex-area.
(18) Fundamental health and safety requirements
fulfilled by standards
Certification body ZELM Ex Brunswick, 23.08.2007
Page 2/2

This document is the property of EADS Secure Networks Oy
and should not be copied or circulated without permission. 13

CASSIDIAN is a registered trademark of EADS Defence and Security Systems.
Copyright © 2012 CASSIDIAN. All rights reserved.
PS10952BENAB01
