Thule Outrigger II 847 User manual

OUTRIGGER™II 847
part description part number qty.
A853-5840 2
B853-5838 1
C938-0600-54 1
D919-0616-54 1
E
stop
end cap
nut
bolt
hex key 853-0930 1
PARTS INCLUDED
A
B
D C E
NOTE: OUTRIGGER II CAN BE MOUNTED TO THE FRONT OR REAR LOAD BAR.
INSTALLATION
2"
1
•Remove standard end cap from load bar.
2•There must be minimum 2" of load bar outside of foot for
installation. Adjust load bar as necessary.

3
•Loosen screw on Outrigger II end cap.
4NOTE: Heavy corrosion inside load bar could prevent smooth operation. Clean
as necessary.
•With curved surface on top, insert into open load bar.
5•Slide Outrigger II end cap onto load bar.
•Tighten to load bar by turning screw. DO NOT OVERTIGHTEN.
NOTE: To test, pull on end cap to ensure it holds to load bar.

A B
6•Push arm into load bar and close cover onto end cap to secure.
NOTE: Test by pulling out on cover without lifting cover up to ensure it stays
in place.
8NOTE: Use caution when loading boat as it could slide and fall.
•Lift one end of boat and lean on extended bar.
•While holding boat to prevent sliding, lift opposite end and place on top of vehicle.
•Lift remaining boat off extended bar and place on top of vehicle.
7
NOTE: To prevent accidental contact, protect vehicle surface
while loading a boat.
•Gradually pull out bar.
•Pull up on cover to unlock.
USE

9•Push extended bar into load bar and close cover onto end cap to secure.
NOTE: Pull out on cover to ensure it holds to end cap.
FOLLOW ACCESSORY INSTRUCTIONS TO SECURE BOAT TO VEHICLE.
