INSTRUCTION MANUAL
EF6L, EF6L2
120V ELECTRIC FRYERS

WARNINGS
Do not touch any hot surfaces
Do not immerse unit, cord or plug in liquid at any time
Unplug cord from outlet when not in use and before cleaning
It is recommended that the fryer not be moved when it contains hot oil or any other hot liquid
Do not use this unit for anything other than intended use
Do not use outdoors
Always cook on a firm, dry and level surface
High temperature will cause scalding. Do not stand over fryer when operating and do not
touch any part of machine while in operation, other than handle of basket and power controls
Do not use unit with a damaged cord or plug, in the even the appliance malfunctions, or has
been damaged in any manner
Keep children and animals away from fryer
Any incorrect installation, alterations, adjustments and/or improper maintenance can lead to
property loss and injury. All repairs should be done by authorized professionals only
Keep all flammable and combustible materials away from this unit
This machine must be placed on a level surface
Volume of food should be limited to avoid overflowing
Foods that do not absorb oil easily should be limited to avoid overflow
Use caution when placing large foods in fryer
When transporting the unit, the machine should be handled carefully, and held by the side
handles
FEATURES
These fryers are available in 2 different models. One is a 1-tank fryer (EF6L); another is a 2-
tank fryer (EF6L2). The 2-tank fryer is able to fry two different kinds of food at the same time.
The oil temperature is regulated by the temperature regulator and includes a yellow (Hot
Light) which cycles on and off to indicate when the desired temperature has been reached.
The automatic shut off feature cuts power to the unit when the oil has reached 446° F (The
maximum allowable temperature).
There is an automatic micro-switch on the bottom of the unit head. This will cut power to the
unit if the head has been separated from the base of the unit without the power switch turned
off or the power cord unplugged.
The heating coils are protected by a stainless steel panel base at the bottom of the unit.

TO USE
1. Make sure the power supply you are using is adequate for continual fryer use and voltage is
adequate. The use of a surge protector or circuit breaker is advisable.
2. Make sure that the temperature regulator knob is set to the off position.
3. Remove basket from the machine.
4. Make sure the oil valve is closed.
5. Fill oil receptacle with vegetable oil somewhere between the minimum and maximum levels,
allowing room for food volume.
6. Plug the machine in.
7. A green “Power Light” will come on. Rotate the temperature regulator knob clockwise to the
desired temperature. When the desired temperature has been reached, the yellow (Hot Light)
will turn off and cycle and the temperature controller will maintain the temperature
automatically.
8. Load food into basket, and carefully place loaded basket into machine to avoid splash.
9. Gently shake off excess oil from food when removing from tank after frying.
The enclosed frying basket is intended to hold small foods such as French fries and onion rings.
Large food can be placed directly into the basket or oil tank.
CLEANING
After fryer usage, turn power controller counterclockwise to the “OFF” position and remove plug
from power supply. The procedure is as follows:
1. Carefully remove unit head from box and place in a safe dry place.
2. Lift out the tank and carefully dispose of oil
3. Gently wipe oil tank removing any excess oil or sludge. Dry completely and place back on
machine.
For best results, cover the fryer when oil is cool and not in use. This will keep unwanted debris from
falling into the oil. Always use fresh vegetable oil with each use. It is recommended that you inspect
the unit before each use to check that the power cord is not frayed or damaged in any way.

TROUBLESHOOTING –Troubles listed are for reference. If any fault occurs, please discontinue
use. Do not attempt to repair yourself. This will void the warranty.
Problem: Not working as well as expected
Cause: Unit is not on a dedicated circuit
Solution: Unplug unit, plug into a dedicated line and retry
Problem: Not working as well as expected
Cause: Basket is overloaded
Solution: Too much product will bring down the temperature of the oil bringing it to a boil rather
than a frying temperature. Use less product.
Problem: Stopped working
Cause: Reset button was tripped
Solution: Here is a reset button located on the back of the head. Unscrew the cap and push the
button to reset. (Be sure to replace black cap)
Problem: Stopped working
Cause: Micro/safety switch is not making contact
Solution: Make sure that the unit is on a level surface and that the switch is sitting flush making
contact with the metal on the back of the body
Problem: Indicator light won’t turn on and unit will not heat
Cause: Plug not properly inserted into outlet
Solution: Reinsert the plug
TO RESET:
Located on the back of the fryer head, it will read “RESET”. With the unit unplugged and fully cooled
off, unscrew the knob to expose red button. Press the red button to reset the unit.

One Year Limited Warranty
Patriot warrants its equipment against defects in materials and workmanship, subject to the
following conditions:
Patriot is warranted for one year, effective from the date of purchase by the original owner. A copy
of the original receipt or other proof of purchase is required to obtain warranty coverage. This
warranty applies to the original owner only, and is not assignable.
Should any product fail to function in its intended manner under normal use within the limits
defined in this warranty, at Patriot’s discretion, such product will be repaired, replaced with a
refurbished unit, or replaced with a new unit by Patriot, after defective unit has been inspected and
defect has been confirmed. Patriot does not assume any liability for extended delays in replacing
any item beyond its control. This warranty does not apply to rubber and non-metallic synthetic parts
that may need to be replaced due to normal usage, wear or lack of preventative maintenance.
This warranty covers products shipped into the 48 contiguous United States, Hawaii, and
metropolitan areas of Alaska and Canada. Warranty coverage on products used outside the 48
contiguous United States, Hawaii and metropolitan areas of Alaska and Canada may vary.
The following conditions are not covered by warranty:
Equipment failure relating to improper installation, improper utility connection or supply and
problems due to improper ventilation.
Equipment that has not properly been maintained, damage from improper cleaning, and
water damage to controls.
Equipment that has not been used in an appropriate manner, or has been subject to misuse,
neglect, abuse, accident, altercation, negligence, damage during transit, delivery or
installation, fire, flood, riot, or act of God.
Equipment that has the model number or serial number removed or altered.
Equipment on which the security seal has been broken.
If the equipment has been changed, altered, modified, or repaired without express written
permission from Patriot, then the manufacturer shall not be liable for any damages to any person or
to any property, which may result from the use of equipment thereafter.
This equipment is intended for commercial use only and this warranty is void if equipment is used in
other than a commercial application.
“THE FOREGOING WARRANTY IS IN LIEU OF ANY AND ALL WARRANTIES EXPRESSED OR IMPLIED
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILTY OR FITNESS FOR PARTICULAR PURPOSES
AND CONSTITUES THE ENTIRE LIABILITY OF ACE. IN NO EVENT DOES THE LIMITED WARRANTY
EXTEND BEYOND THE TERMS STATED HEREIN.”
