1. Before assembling the mounting hardware as shown on above, decide where and
which set up you will want the guide post placed on your trailer.
(Use the diagrams on back to determine guide post placement.)
2. Using 4 - 3/8"x 5" hex head bolts, 8 flat washers and 4 nyloc nuts, for each, attach
the guide support mounts onto your trailer frame, as shown in figure 1. Use the
holes that will keep the bolts closest to the frame tube. Finger tighten at this time.
Repeat for other side.
3. Slide the guide support tube into the channel bracket as shown in figure 1.
4. Adjust the guide tubes for proper distance on each side. Tighten support mounts
bolts at this time.
5. Side the PVC tubes over the side guide tubes.
Front
Out
Figure 1
Heavy Duty PVC Guide On’s
Assembly/Installation Instructions
A1406;051216
Instruction Sheet #08158 Page 1 of 2
5
1
8
7
3
4
2
7
6
# Qty. Qty. Part # Description
1 2 --- 48116 Side Guide Tube
48” w/Oragne Cap
1 --- 2 48117 Side Guide Tube
60” w/Oragne Cap
2 2 2 48066 Support Tube
3 2 2 48011 Mounting Plate
4 2 2 48012 Channel Bracket
5 8 8 10924 3/8"x 5" Hex Head Bolt
6 8 8 10627 3/8" Hex Nyloc Nut
7 16 16 10841 3/8” Washer
8 2 2 17266 LED Light Kit
# Qty. Qty. Part # Description
1 2 --- 48074 Side Guide Tube
48” w/Orange Cap
1 --- 2 85001-1 Side Guide Tube
60” w/Oragne Cap
2 2 2 48066 Support Tube
3 2 2 48011 Mounting Plate
4 2 2 48012 Channel Bracket
5 8 8 10924 3/8"x 5" Hex Head Bolt
6 8 8 10627 3/8" Hex Nyloc Nut
7 16 6 10841 3/8” Washer
Part #’s: 86441 & 86440 - Kits with LED Lights
Part #’s: 86103 & 86119

15 ”
11”
Mounting position
for 3” wide tubes
Mounting position
for 2” wide tubes Horizontal Movement 5” to 15” Vertical Movement 15” to 15” Minus Tube Height
Trailer Frame
Long Tube Side Out
Short Tube Side Out
15” max.
5”
mim.
19 ”
15”
Horizontal Movement 5” to 11” Vertical Movement 19” to 19” Minus Tube Height
Trailer Frame
11” max.
5”
mim.
2” x 4”
Trailer Frame
2” x 4”
Trailer Frame
Guide Post
Placement
Guide
A1406;051216
Page 2 of 2
*Heavy Duty PVC Guide On’s with Lights
Wiring Instructions for Models 86441 & 86440
Trailer
Running Light Wire
(Normally Brown)
Black Wire
(From LED Light)
Splice
Connector
Splice Plate
1. Pull out the white and black wire from the bottom of the
PVC tubes. Straighten both lines to the full length.
2. Position the PVC tubes so the red light faces backward.
While holding the ends of both wires slide the PVC tubes
over the steel support tubes. The remaining wire should
extend below the tube and steel support tube.
3. Press the trailer running light wire (brown) into the open
side of the splice connector. Push the black LED wire
into the opposite side of the splice connector.
4. Place the splice connector in the pliers and press the metal
splice plate thru both wires. Close the locking tab.
5. Place the self tapping screw thru the eyelet on the white
grounding wire. Screw the self tapping screw into the
trailer frame.
6. Hook up the trailer and test your towing lights.
When the trailer/tow vehicle lights are on the red
LED lights should also be on.
Locking
Tab
