Timberk WHEL-3OC User manual
/ Models
WHEL-3OC
WHEL-6OC
WHEL-7OC
Electrical
instant
water heater
Instruction manual
.
Outlook of devices, aslo colour scores can be revised without any special advance notices.
WHEL-3OSC
WHEL-6OSC
WHEL-7OSC
WHEL-3OS
WHEL-6OS
WHEL-7OS
Primalux series / Серия Primalux
2www.timberk.com electric instant water heater
THE IMPORTANT PRECAUTIONS AND INSTRUCTIONS CONTAINED IN
THIS INSTRUCTION MANUAL DO NOT INCLUDE ALL POSSIBLE MODES
AND SITUATIONS, WHICH MAY OCCUR. IT IS NECESSARY TO
UN DER STA ND THAT COMMON SE NSE, C AUTIOUSNESS, AND
CAREFULNESS ARE FACTORS, WHICH CANNOT BE "INTEGRATED" TO
ANY PRODUCT. THESE FACTORS SHALL BE TAKEN INTO ACCOUNT BY
THE PERSON, WHO IS INTERESTED IN PROPER OPERATION OF THE
DEVICE. THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGE OF
THE APPLIANCE OR ITS COMPONENTS DURING TRANSPORTATION, AS A
RESULT OF IMPROPER INSTALLATION, DUE TO VOLTAGE SURGES, AS
WELL A S IN THE E V E NT OF U N AUTHORI Z E D CHANG E S OR
MODIFICATIONS IN ANY PART OF THE APPLIANCE.
2. PRECAUTIONS
During operation of the water heater, it is necessary to observe some pre-
cautions. Improper operation due to ignorance of the precautions may
result in personal injury of the user or other people, as well as damage of
their property.
1. Any electric appliance shall be under observation during its operation,
especially if there are children close by. Carefully watch that children do
not touch the appliance.
2. Before installation and connection of the water heater to the electric
mains, check and make sure that the wall socket for the water heater has a
grounding contact and it is properly grounded (for 3,5 kW series). If your
electric main is not provided with a grounding loop, operation of the water
heater is hazardous for life.
3. Connect the water heater only to 220VAC/50Hz mains. If necessary,
clarify specifications of your electric mains from the power suppliers.
4. To avoid overheating, as well as risk of fire and damage of the internal
electric circuit, do not change length of the power cord and do not con-
nect the water heater via electric extension cables.
5. Never use the water heater, if it is faulty.
6. Immediately disconnect the water heater from the electric mains in case
of strange sounds, odor, or smoke from it.
7. Always disconnect the water heater from the electric mains during
storms.
CONTENTS:
1. Important information
2. Precautions
3. Specifications
4. Package contents
5. Water heater installation
6. Water heater control
7. Maintenance
8. Troubleshooting
9. Disposal
Dear customer!
We thank you for happy choice and purchase of a Timberk electric inline
water heater. It will serve you long. The inline water heater is designed for
instantaneous preheating of main water. The water heater can be installed
in places, where it is possible to connect it to the water pipeline and elec-
tric wiring (single-phase electric power supply is required), except for
rooms with possible temperature drops below 0°C.
The water heater is easy to install and efficient in use thanks to minimum
loss of electric power and effective consumption of hot water. The appli-
ance design consisting of a heat-resistant robust heating vessel, durable
copper heating elements, and safety control devices allows us to confirm
with certainty that the TIMBERK water heater convenient in operation will
serve you for many years.
1. IMPORTANT INFORMATION
Please carefully read this instruction manual before using the water heater.
This instruction manual contains important information concerning your
safety, as well as recommendations on proper use and care of the appli-
ance. Please keep the instruction manual together with the warranty card,
sales slip, and, if possible, with the cardboard box and packing materials.
This instruction manual describes different types of this device.
The water heater purchased by you may slightly differ from that described
in the instruction manual, but this does not affect the methods of its use
and operation.
2
2
3
4
6
6
9
10
10
21. Do not allow children to use the water heater without control by
adults.
22. Thoroughly observe the connection procedure of the water heater,
since improper connection will result in its failure and may inflict harm to
the user.
23. Do not swap locations of the water inlet and outlet positions, since this
will result in failure of the water heater and may inflict harm to the user
(see IN (inlet) and OUT (outlet) marks). The water heater shall be con-
nected only with its water connections downward in strictly horizontal
position.
24. Connection of the water heater in another position will result in its
failure. The water heater shall be operated only with an original shower
nozzle and/or kitchen spout excluding their clogging.
25. The water heater is designed only for heating of water. Do not use the
product for heating of other liquids. This may inflict a severe damage to
the water heater.
26. Do not connect electric wires of the device to a water pipeline, a gas
pipeline, etc.
27. Make sure in proper connection of electric wiring (including ground-
ing loop).
28. Before use, make sure that parameters of your electric mains meet the
specifications of this water heater.
29. Inlet temperature of water shall not exceed +35°C.
30. For use of the water heater in a bathroom, it is recommended to install
it above body height so that water splashes do not get onto its enclosure.
ENGLISH
3
8. Before beginning of cleaning and maintenance of the water heater, al-
ways disconnect it from the electric mains. Perform cleaning and mainte-
nance in accordance with the guidelines of this instruction manual.
9. Do not use hazardous chemicals for cleaning of the water heater and
exclude their contact with it.
10. To avoid hazard of electric shock, the damaged power cord shall be
replaced only by qualified specialists.
11. To avoid hazard of electric shock, do not place the power cord near
heating appliances and flammable or combustible materials.
12. Do not use the water heater for purposes not specified in this instruc-
tion manual.
13. Do not use the water heater in explosive or corrosive environment. Do
not store gasoline and other volatile highly inflammable liquids near the
appliance. This is very hazardous!
14. It is prohibited to change the design of the water heater or modify it.
15. Any service works shall be performed by a specialized organization, by
qualified specialists. Improper installation may result in refusal of warranty
service.
16. The water heater is not designed for use by people (including children)
with physical, sensory, or mental disability, having insufficient experience
and knowledge, without observation and instructing on use of the appli-
ance by the person responsible for their safety. It is necessary to watch
children not to play with the appliance.
17. Use only for household purposes. The water heater is not designed for
industrial use.
18. Do not use the water heater with the damaged power cord or other
damages. For troubleshooting and repairs, please contact the nearest
authorized service center of the manufacturer in your region.
19. Make sure that the power cord does not cross sharp edges and does
not contact with hot surfaces.
20. Never leave the energized water heater unattended.
ATTENTION!
The water heater shall be certainly grounded.
It is expressly PROHIBITED to do the following:
Pull electric wires inside the water heater;
Remove the enclosure of the water heater, when it is energized;
Install other fixtures, except for fixtures recommended by the manufac-
turer;
www.timberk.com instant water heaterelectric
3. SPECIFICATIONS
Specifications for different series of water heaters are given in Tables 1a, 1b,
1c.
PARAMETER
Version
Rated voltage
Rated current
Rated power consumption
Rated pressure
Operating pressure
Flow rate (at t=20°C)
Electric protection class
Moisture protection class
Wire section of electric connection cabel
Dimensions
Net weight
Unit of
measure
-
V/Hz
A
kW
Mpa
Mpa
L/min
-
-
mm2
mm (H W H)
kg
WHEL-3
crane
~220/50
16
3,5
0
0,03 - 0,6
1,9
I
IPX4
3 1,5
159x272x112
1,35
WHEL-3 OS
shower
~220/50
16
3,5
0
0,03 - 0,6
1,9
I
IPX4
3 1,5
159x272x112
1,35
WHEL-3 OSC
crane and shower
~220/50
16
3,5
0
0,03 - 0,6
1,9
I
IPX4
3 1,5
159x272x112
1,35
Table 1
4www.timberk.com electric instant water heater
IMPORTANT!
Technical characteristics of the water heater you purchased as of
the date of manufacture correspond to data, specified in the
table. Technical characteristics and scope of delivery can be
revised without any prior notice.
ENGLISH
WHEL-6
crane
220/50
25
5,5
0
0,03 - 0,6
4,0
I
IPX4
3x2,5
159x272x112
1,19
WHEL-6 OS
shower
220/50
25
5,5
0
0,03 - 0,6
4,0
I
IPX4
3x2,5
159x272x112
1,19
WHEL-6 OSC
crane and shower
220/50
25
5,5
0
0,03 - 0,6
4,0
I
IPX4
3x2,5
159x272x112
1,19
Table 1b
WHEL-7
crane
220/50
30
6,5
0
0,03 - 0,6
4,5
I
IPX4
3x4
159x272x112
1,19
WHEL-7 OS
shower
220/50
30
6,5
0
0,03 - 0,6
4,5
I
IPX4
3x4
159x272x112
1,19
WHEL-7 OSC
crane and shower
220/50
30
6,5
0
0,03 - 0,6
4,5
I
IPX4
3x4
159x272x112
1,19
Table 1c
PARAMETER
Version
Rated voltage
Rated current
Rated power consumption
Rated pressure
Operating pressure
Flow rate (at t=20°C)
Electric protection class
Moisture protection class
Wire section of electric connection cabel
Dimensions
Net weight
Unit of
measure
-
V/Hz
A
kW
Mpa
Mpa
L/min
-
-
mm
mm (H W H)
kg
PARAMETER
Version
Rated voltage
Rated current
Rated power consumption
Rated pressure
Operating pressure
Flow rate (at t=20°C)
Electric protection class
Moisture protection class
Wire section of electric connection cabel
Dimensions
Net weight
Unit of
measure
-
V/Hz
A
kW
Mpa
Mpa
L/min
-
-
mm
mm (H W H)
kg
www.timberk.com instant water heaterelectric
4. PACKAGE CONTENTS
The package contents are given in Table 2.
STOCK NUMBER / QUANTITY PER PACKAGE
Shower nozzle
Wall holder for shower
Hose for shower nozzle
Adapter - water flow switch
Adapter - tube
Crane - kitchen spout
Sealing gaskets
Kitchen spout rings (replaceable)
Filter in O-ring
Installation fixtures (screw - dowel pin)
Water heater assembly
Instruction manual
Warranty card
pcs
1
1
1
1
1
1
3
2
1
3
1
1
1
WHEL 3 /
WHEL 6 OC /
WHEL 7 OC
+
+
+
+
+
+
+
+
+
WHEL 3 S /
WHEL 6 OS /
WHEL 7 OS
+
+
+
+
+
+
+
+
WHEL 3 S /
WHEL 6 OSC /
WHEL 7 OC
+
+
+
+
+
+
+
+
+
+
+
+
Table 2
*Electicity connection cabel (for WHEL-3... series)
5. WATER HEATER INSTALLATION
Location
1. The water heater can be installed in any place provided that
temperature in the room is not below 0°C.
2. Possible installation options of the water heater are given in Fig.1.
6www.timberk.com electric instant water heater
ENGLISH
When pressure in the water mains exceeds 0.6 MPa, OBLIGATORY installa-
tion of a pressure reducing valve is required.
It is recommended to use a shutoff safety valve at the cold water inlet.
Connect the water heater to the water pipeline (threaded pipe outlet with
obligatory installation of a valve to shut off water feed to the water heater)
using a separate flexible hose (! not included to the package).
CERTAINLY install all sealing gaskets included to the package and coarse
filter, which is fitted at the cold water inlet.
At that, it is necessary to observe the OBLIGATORY REQUIREMENT:
The water feed shutoff valve shall be installed upstream of the water heater
inlet.(Proper installation of the water heater is shown in Fig.2)
PROHIBITED:
Installation of a shutoff valve at the hot water outlet from the water
heater. (Fig.2a) This will result in failure of the water heater and may inflict
harm to the user.
Water heater installation
- Remove the enclosure of the water heater unscrewing three mounting
screws.
- Select the electric cable entry place. If necessary, cut the thin wall on the
enclosure in the proper place using a knife.
- Selection the water heater installation place.
- Install the appliance on the wall horizontally with its connections strictly
downward securing it with screws from the set of installation fixtures
included by the manufacturer to the package.
NOTE:
Installation of the water heater in the operation place and arrange-
ment of a power supply line shall be performed by a specialized
organization, representatives of the manufacturer's service
department, or specialists having permits for installation of electric
equipment with observations of safety requirements.
If the installation and operation instruction manual of the water heater
is violated, the appliance is not subject to warranty service and the
manufacturer does not bears the responsibility.
Connection to water mains
The water heater shall be connected to the water mains with water pres-
sure from 0.03 to 0.6 MPa. The water heater can be fed with water from a
tank, where water level shall be at least by 4 m above the water heater level.
ATTENTION!
When the water heater is operated in particularly difficult (includ-
ing obsolete) water pipeline systems with a large quantity of sus-
pended particles and impurities in flowing water, application of
purification filters at the inlet of the water heater is OBLIGATORY.
Use this recommendation; otherwise, non-fulfilment of this item
may affect service life of the product and warranty service condi-
tions (up to refusal of warranty liabilities by the product manufac-
turer and manufacturer's service departments).
Fig. 1
Kitchen Shower Bathroom
www.timberk.com instant water heaterelectric
Valve
Outlet
Inlet
Inlet
Valve Outlet
Make sure that the water heater is operable passing water flow through it.
Check tightness of all connections and, if necessary, tighten nuts and
mounting screws including screws in flanges of the heating vessel.
NOTE:
Before installation of the water heater, flush water pipes with flowing
water.
Connection to electric mains
The water heater shall be connected to the 220VAC electric mains with a
three-core electric cable (not more than 15 m long to the maximum).
Minimum wire section of 3x1.5 mm (copper) with a 16A circuit breaker -
for water heaters of WHEL-3... series
Minimum wire section of 3x2.5 mm (copper) with a 25A circuit breaker -
for water heaters of WHEL-6... series
Minimum wire section of 3x4 mm (copper) with a 30A circuit breaker - for
water heaters of WHEL-7... series
Connection to electric circuit:
- It is necessary to increase wire section, if the water heater and electric ca-
ble itself are located on a thermally insulated or heating wall.
- The water heater shall be connected to the electric mains stationly (exept
WHEL-3...).
- Install an external circuit breaker for protection of the electric circuit
(16/25/30A depending on series of the water heater).
- Lead the electric cable into the water heater.
- Fix bare ends of the electric cable in a connection box hardly tightening
them with screws and in strict correspondence with the box marking (re-
fer to Fig.3)
- Check connection tightness of all internal electric contacts including re-
movable contact groups and bolt contact connections on heating ele-
ments. If there are loose connections, they shall be fixed and tightened.
- Connect the electric cable with the fixed method (exept WHEL-3...) to the
220VAC power supply source using a circuit breaker (16/25/30A depend-
ing on series of the water heater) with obligatory electric grounding.
- Install the enclosure of the water heater and tighten three mounting
screws.
- Switch on the 220VAC power supply and check operability of the water
heater with the practical method in all operation modes.
ATTENTION!
The water heater requires obligatory connection of electric ground-
ing.
It is necessary to increase wire section, if the water heater and elec-
tric cable itself are located on a thermally insulated or heating wall.
The water heater shall be connected to the electric mains perma-
nently (with a fixed method).
~220 W
to grounding loop
Fig. 2 Fig. 2a
Fig. 3
8www.timberk.com electric instant water heater
ENGLISH
www.timberk.com electric instant water heater
6. WATER HEATER CONTROL
Control panel
WHEL3 model (Fig. 4), WHEL-6 / WHEL-7 model (Fig. 5)
Fig. 4 Fig. 5
Water heater operation
- Feed water to the water heater and switch on electric power supply.
- Water flow is controlled by the mixer at the water inlet to the water heater. It is
prohibited to install a mixer and/or shut off water feeding at outlet from the
water heater.
- Water heating is activated using a switch (Fig.4; Fig.5)
- It is necessary to wait for 10-20 sec until temperature of heated water is stabi-
lized.
- To switch off the water heater, you can just shut off water flow at inlet to the
appliance. At that, the pressure sensor will automatically open the electric
power supply circuit to the heating element. To switch on the water heater
again, it is sufficient to just open the valve.
Water heater operation
Inlet water is heated, when it flows through the heating element inside the
vessel. Water temperature in the water mains may fluctuate throughout the
year from 3°C to 20°C.
To obtain the optimum temperature in winter, water flow shall be made lower
than in summer.
For adjustment of hot water temperature, you can use the valve at the inlet
connection (cold water inlet) changing water flow rate. When you decrease
inlet flow rate of water, you increase outlet temperature and vice versa.
- To switch on the appliance, it is necessary to place the switch to the "ON"
position ("Low" for WHEL-6/7 series)
- When the switch is in the "OFF" position - there is no heating.
- When the switch is in the "ON" position ("High" for WHEL-6/7 series) -
heating is maximum.
- To adjust water heating temperature, you can change flow rate of water
(using the flow control valve at the water inlet to the water heater).
- To switch off the appliance, place the switch to the "OFF" position and
close the cold water feed valve.
ATTENTION!
Do not switch on the water heater, if you suspect freezing of water in
it.
The water heater is equipped with the following instrumentation:
- The heating element is activated only at optimum water pressure in range
from 0.03 to 0.6 MPa. Its lower range value is automatically monitored by
the integrated pressure sensor.
If inlet pressure of water decreases excessively (below 0.03 MPa), the inte-
grated pressure sensor trips and disconnects power supply.
- Thermal switch: it will stop power supply to the heating element in the
event of water overheating in the water heater. If the water heater is
switched on and water heating is activated, but water is not heated actu-
ally, this means tripping or need for reset of the thermal switch. To return
the water heater to the operational condition, push the button on the
thermal switch. For that, use the following procedure:
Switch off the electric heater, remove the front panel, push the black but-
ton located at the center of the thermal switch until the button clicks (the
thermal switch itself is located from the right side of the water heater
vessel on the heating element).
ATTENTION!
If these actions do not give a positive result or the thermal switch
trips on repeated occasions for a short period of time, then switch
off the water heater, shut off water feeding to the water heater, and
contact the authorized service center of Timberk in your region for
consultation or repair of the product.
The address of the authorized service center can be obtained from
the vendor or at www.timberk.com.
ATTENTION!
The WHEL-3 series shall be used in a summer season with tempera-
ture of inlet water - +16-18°C
7. MAINTENANCE
During use of the water heater, scale may appear in nozzle openings of the
shower or kitchen spout. This reduces efficiency of heating, deteriorated
water spraying, and increases water pressure in the heating vessel.
For prevention of such phenomena, it is necessary to periodically clean the
nozzle using household chemical agents and soft brushes. Do not use
abrasive cleaning substances and inappropriate chemical agents.
a) Outer care:
- Switch off the appliance and allow it to fully cool down.
- Clean the outer surface of the appliance enclosure using a slightly moist-
ened soft cloth and then wipe it dry. Do not use abrasive cleaning sub-
stances.
b) Filter cleaning:
If water flow rate from the heater decreases, it is necessary to clean the
coarse filter installed at the cold water inlet to the water heater. Use the
following procedure:
- Switch off the appliance and allow it to fully cool down.
- Shut off cold water feeding.
- Unscrew the cold water feed hose from the water heater, remove the
coarse strainer and flush it under a jet of flowing water.
- Restore the inlet connections in the reverse sequence.
8. TROUBLESHOOTING
Table 3
9. DISPOSAL
Upon expiration of service life, the water heater shall be disposed. For
more details regarding disposal of the water heater, please contact a repre-
sentative of the local authorities.
Water is too hot
Water is too cold
Increase water flow rate
Clean spout openings
Check electric power supply
Decrease water flow rate
Reset the thermal switch
10 www.timberk.com electric instant water heater
11
, -
.
, -
,
, .
, ,
, «
, ,
.
, ,
, , -
.
2.
,
. -
-
,
.
1.
, , -
. ,
.
2. , -
, ,
( -
3,5 ). -
.
3. ~220/50. -
-
.
4. ,
,
-
.
:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
!
Timberk. .
-
.
, -
( ), ,
0°.
. , -
, , -
, ,
,
TIMBERK .
1.
.
-
, , -
. -
, -
, , -
.
.
11
11
13
15
15
18
19
19
19
20
www.timberk.com
17. . -
.
18.
. -
.
19. ,
.
20. -
.
21.
.
22. ,
.
23. , ..
(. IN -, OUT -).
, -
.
24. -
.
/ , -
.
25. . -
, -
.
26. -
, .
27. ( ..
).
28. , -
.
29. +35 °.
30. -
,
.
31. .
5. , .
6.
, , .
7.
.
8. -
. -
.
9. -
.
10. , -
-
.
11. -
-
12. , ,
.
13. -
.
!
14.
.
15. -
, . -
-
.
16.
( ) ,
,
,
,
. , , -
.
12 www.timberk.com
13
:
;
;
,
.
3.
1, 1, 1
!
.
.
( t=20 °)
.
-
/
/
-
-
( )
WHEL-3
220/50
16
3,5
0
0,03 - 0,6
1,9
I
IPX4
1,5
159x272x112
1,35
WHEL-3 OS
220/50
16
3,5
0
0,03 - 0,6
1,9
I
IPX4
1,5
159x272x112
1,35
WHEL-3 OSC
220/50
16
3,5
0
0,03 - 0,6
1,9
I
IPX4
1,5
159x272x112
1,35
1
www.timberk.com
!
1,
1, 1.
.
14
. ()
( t=20 °)
E .
-
/
/
-
-
( )
WHEL-6
220/50
25
5,5
0
0,03 - 0,6
4,0
I
IPX4
32,5
159x272x112
1,19
WHEL-6 OS
220/50
25
5,5
0
0,03 - 0,6
4,0
I
IPX4
32,5
159x272x112
1,19
WHEL-6 OSC
220/50
25
5,5
0
0,03 - 0,6
4,0
I
IPX4
32,5
159x272x112
1,19
1
. ()
( t=20 °)
E .
-
/
/
-
-
( )
WHEL-7
220/50
30
6,5
0
0,03 - 0,6
4,5
I
IPX4
34
159x272x112
1,19
WHEL-7 OS
220/50
30
6,5
0
0,03 - 0,6
4,5
I
IPX4
34
159x272x112
1,19
WHEL-7 OSC
220/50
30
6,5
0
0,03 - 0,6
4,5
I
IPX4
34
159x272x112
1,19
1
www.timberk.com
4.
2
/
-
-
-
()
( - )
1
1
1
1
1
1
3
2
1
3
1
1
1
WHEL 3 /
WHEL 6 OC /
WHEL 7 OC
+
+
+
+
+
+
+
+
+
WHEL 3 S /
WHEL 6 OS /
WHEL 7 OS
+
+
+
+
+
+
+
+
WHEL 3 S /
WHEL 6 OSC /
WHEL 7 OC
+
+
+
+
+
+
+
+
+
+
+
+
2
5.
1.
, 0°
2.
. 1
15
www.timberk.com
* - 1,5 ( WHEL-3)
16
0,6
.
-
.
(-
, -
) -
(! ).
,
.
:
, , -
. ( -
.2)
:
-
. (. 2)
.
, .
. -
-
.
.
,
, -
.
:
,
,
,
.
,
, .
-
0,03 0,6 .
,
4 .
!
( ..-
) -
, -
. ; -
(
).
. 1
www.timberk.com
, -
.
, , -
, ..
.
:
.
-
220 -
, 15
.
3 1,5 ()
16 WHEL-3...
3 2,5 ()
25 WHEL-6...
3 4 ()
30 WHEL-7...
!
-
.
, -
-
.
( ).
, -
-
.
-
( WHEL-3).
(16/25/30
).
.
, , -
, (. . )
, -
. -
.
(
WHEL-3) 220,
( 16/25/30
) .
-
.
220 -
-
.
. 2 . 2
17
www.timberk.com
18
~220 В
к контуру заземления
6.
WHEL3 (. 4)
WHEL-6 / WHEL-7 (. 5) - (LOW,
MEDIUM, HIGH)
Рис. 4 Рис. 5
.
-
.
- -
. / -
.
-
(.4; .5)
- 10-20
.
-
.
. -
.
.
3° 20°.
, .
( ),
. ,
, , .
-
"ON" (Low WHEL-6/7)
- "OFF" - ;
- "ON" (High WHEL-6/7) -
.
- -
, (
)
-
"OFF" .
!
, ,
.
-
:
-
0,03 0,6 . -
.
( 0,03
), -
.
. 3
www.timberk.com
!
WHEL-3... 3,5 , -
,
+16-18°.
- : ,
.
, , -
. -
. :
, ,
, -
, -
.
!
,
, -
, -
Timberk
.
www.timberk.com
7.
-
.
,
.
-
. -
.
) :
- -
.
-
, , .
.
) :
, -
, -
. :
- -
.
- .
- ,
-
.
- -
.
8.
3
9.
-
.
. -
- 5 .
19
www.timberk.com
10.
EEC 89/336, -
,
.
.
Timberk ,
Timberk , -
, ,
, ,
.
-
: . RU.0001.11AB71
«».
: 123308, . , . , . 3, . 1, .
323; : 115162, . , .,
28, 4, . +7 495 6044266, +7 495 6044266
.
,
:
P 60335-2-35-2000
P 51318.14.1-2006 .4
P 51318.14.2-2006 p.5,7
P 51317.3.3-2008
P 51317.3.2-2006 p.6,7
: RU C-IL.AB71.B.00051
.
,
: 09.02.2012 08.02.2015
20 www.timberk.com
* ,
, \ \
.
, ,
.
:
« » , 10,
, 88000
/ +972-8-637-88-311
*:
«»
: , 111024, . , . 5- , .2, . 1
: +7 499 653 7356
: + 7 (495) 6275285
This manual suits for next models
8
Table of contents
Other Timberk Water Heater manuals
Timberk
Timberk SWHRE350V User manual
Timberk
Timberk SWH FSM5 30 V User manual
Timberk
Timberk SWH RS1 30 V User manual
Timberk
Timberk SWH ME1 10 VO User manual
Timberk
Timberk WHE 3,5 XTR H1 User manual
Timberk
Timberk RE9 30 V User manual
Timberk
Timberk RS1 Series User manual
Timberk
Timberk SWH RED3 50 V User manual
Timberk
Timberk SWHFS130V User manual
Timberk
Timberk SWH RS1 30V User manual
Timberk
Timberk SWH RE11 30 V User manual
Timberk
Timberk T-WSS30-N40D-V User manual
Timberk
Timberk Lotta FS1D V Series User manual
Timberk
Timberk Intelligent FS51D V Series User manual
Timberk
Timberk SWH RS1 30 VH User manual
Timberk
Timberk SWH FEL1 30 V User manual
Timberk
Timberk T-WSS30-R20-V User manual
Timberk
Timberk SWH SE1 10 VU User manual
Timberk
Timberk WHE 3,5 XTRH1 User manual
Timberk
Timberk WHEL-6 OC User manual
Popular Water Heater manuals by other brands
STIEBEL ELTRON
STIEBEL ELTRON HFA-E 30 Operating and installation instructions
Amtrol
Amtrol WELL-X-TROL WX-101C-DD Installation & operation instructions
TEFAL
TEFAL BR303 QUICK CUP user manual
Atmor
Atmor Super 900 Assembly guide
Cordivari
Cordivari BOLLY 1 FIT user manual
SUNFLOWER
SUNFLOWER SFD-SS Series installation manual
Bradford White
Bradford White GAS-FIRED WATER HEATER Installation & operating instruction manual
Aqua-Hot
Aqua-Hot 600-D installation manual
Viessmann
Viessmann VITOCELL-V 100 Service instruction
Custom Design & Fabrication
Custom Design & Fabrication Monkey PWH-100/3 Operation manual
Siemens
Siemens DO0570CM Installation and operating instructions
andrews
andrews COMBIflo 100/300 manual
Noritz
Noritz NC1991-OD installation manual
Windhager
Windhager AquaWIN Air 273 Installation instructions and use
Mira
Mira Essentials 7.5 instruction manual
Trinity Lx
Trinity Lx Lx200-800 manual
Armstrong
Armstrong Flo-Direct installation guide
Lochinvar
Lochinvar 000 through 2 Installation and service manual
