Timberline 4000 Series Manual

1
Series 4000
Solar Powered Chemical Injecon Pump
Installaon, Operaon, and Maintenance Instrucons
The model 4000 Chemical Injecon Pump is designed to inject low to medium volumes of chemical into high pressure lines. Depending on
the motor and plunger conguraon, these pumps are capable of pumping against up to 6000 PSI or up to 130 gallons/day. Due to the
varying nature of applicaons, proper sizing is essenal for each solar powered applicaon to ensure pump performance. Timberline
Manufacturing and it’s associated representaves are available to assist with any quesons or pump sizing. Variables you will need to know
to ensure proper sizing are:
Required Flow Rate
Discharge Pressure
Locaon of Pump
Mission Crical Level of Applicaon
These systems are typically sold including a pump unit, solar panels, solar panel mounng hardware and pipe, solar power voltage
regulator, pump controller, and baery/controller enclosure. Baeries are generally supplied by the end user aer a sizing
recommendaon by Timberline Manufacturing or their associated representaves, but are available upon request.
INTRODUCTION
TABLE OF CONTENTS
SECTION PAGE
IMPORTANT SAFETY PRECAUTIONS 2
SPECIFICATIONS 2
PUMP 2
MOTOR 2
PRESSURE AND FLOW RATE INFORMATION 3
MAXIMUM FLOW RATE CURVES 4
SOLAR PUMP ASSEMBLY 6
PUMP ASSEMBLY 6
PUMP ASSEMBLY PARTS LIST 7
BODY ASSEMBLY AND PARTS LIST 8
INCLUDED COMPONENTS 9
INSTALLATION 10
MOUNTING DIMENSIONS 10
PUMP MOUNTING AND TUBING 10
TUBING SCHEMATIC 11
SOLAR PANEL MOUNTING AND ASSEMBLY 12
SOLAR PANEL POSITIONING 13
WIRING 14
WIRING DIAGRAMS 15
OPERATION 16
STARTUP 16
ADJUSTING FOR DESIRED FLOW RATE 16
MAINTENANCE 18
TROUBLESHOOTING 19
ORDERING INFORMATION 20

2
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
IMPORTANT SAFETY PRECAUTIONS
Read this manual completely and carefully. Pay special aenon to all warnings, cauons, and safety rules. Failure to follow
the instrucons could produce safety hazards which could injure personnel or damage the pump or motor. If you have any
doubts about how to connect the pump or motor, refer to the pertaining secons of this manual.
Please pay special aenon to all those paragraphs with the following safety symbols:
Warning
This indicates a potenally hazardous situaon which, if not avoided, could result in death or serious injury.
Cauon
This indicates a potenally hazardous situaon which, if not avoided, may result in minor or moderate injury
and/or property damage.
Cauon This indicates a potenally hazardous situaon which, if not avoided, may result in property damage.
SPECIFICATIONS
FEATURE SPECIFICATION
MATERIALS OF CONSTRUCTION
Weed Parts 316 SST (Excluding Plunger)
Plunger 17-4PH SST / H900 OR Ceramic Coated 17-4PH SST
Packing PTFE / Aas OR Viton
Check Seats TFE
Check Balls 316 SST
Drivesha/Pushrod Bushings Oil Impregnated Bronze
Drivesha Housing Aluminum, Powder Coated
Baseplate Carbon Steel, Powder Coated
OPERATING
Pump Type Posive Displacement
Drive Mechanism Eccentric Cam and Bearing
MAWP-All Plungers 10,000 PSI
Feature Specicaons
Motor MODEL 4000 MODEL 4001
Voltage 12 VDC 12 VDC
Power 1/9 1/21
Gear Rao 43.9:1 20:1
Speed 55 RPM 59 RPM
Controller Current 10 A 4 A
PUMP
MOTOR

3
PRESSURE AND FLOW RATE INFORMATION
*Adversed minimum and maximum ow rates shown were tested at 0 PSI; increased discharge pressure may result in increased minimum and reduced
maximum ow rates. For addional informaon, refer to ow rate curves on pages 4 and 5.
Cauon
BEFORE INSTALLATION, REVIEW THE APPLICATION TO ENSURE THAT PROPER PUMP SELECTION HAS BEEN PERFORMED. THIS
SHOULD BE DONE AFTER READING THIS MANUAL AND ALL APPLICABLE SAFETY STANDARDS. IF IN DOUBT, CONTACT YOUR
LOCAL TIMBERLINE MANUFACTURING REPRESENTATIVE OR THE HOME OFFICE. DETERMINATION OF SYSTEM FITNESS FOR
PURPOSE OR USE IS SOLELY THE CUSTOMER’S RESPONSIBILITY.
PLUNGER HEAD CONFIG. MAOP
(PSI)
MIN FLOW
(QPD)
MAX FLOW
(QPD)
3/16” SINGLE 6,000 0.40 37
DUAL 0.70 74
1/4” SINGLE 5,000 0.68 66
DUAL 1.24 131
3/8” SINGLE 2,500 1.40 148
DUAL 2.80 295
1/2" SINGLE 1,250 2.49 262
DUAL 4.97 525
PLUNGER HEAD CONFIG. MAOP
(PSI)
MIN FLOW
(QPD)
MAX FLOW
(QPD)
3/16” SINGLE 6,000 2.97 43
DUAL 4.41 82
1/4” SINGLE 5,000 4.41 73
DUAL 8146
3/8” SINGLE 2,500 10 164
DUAL 22 328
1/2" SINGLE 1,250 16 291
DUAL 45 583
PLUNGER HEAD CONFIG. MAQP(PSI) MIN FLOW
(QPD)
MAX FLOW
(QPD)
3/16” SINGLE 4,500 2.96 44
DUAL 888
1/4” SINGLE 2,000 10 78
DUAL 19 156
3/8” SINGLE 750 35 176
DUAL 60 352
1/2" SINGLE 250 46 313
DUAL 83 625
PLUNGER HEAD CONFIG. MAOP
(PSI)
MIN FLOW
(QPD)
MAX FLOW
(QPD)
3/16” SINGLE 5,000 0.41 40
DUAL 0.82 79
1/4” SINGLE 2,500 0.72 70
DUAL 1.45 141
3/8” SINGLE 1,500 1.63 158
DUAL 3.26 317
1/2" SINGLE 750 2.90 281
DUAL 6563
ON/OFF
CONTROLLER
CONTINUOUS RUN
CONTROLLER
ON/OFF
CONTROLLER
CONTINUOUS RUN
CONTROLLER
MODEL 4000
MODEL 4001
Cauon DO NOT EXCEED MAXIMUM ALLOWABLE OPERATING PRESSURES LISTED IN THESE CHARTS. EXCEEDING
MAXIMUM OPERATING PRESSURES MAY CAUSE IRREPARABLE DAMAGE TO THE PUMP AND/OR MOTOR.

4
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
MAXIMUM FLOW RATE CURVES: 4000 MOTOR
ON/OFF CONTROLLER
CONTINUOUS RUN CONTROLLER
0
25
50
75
100
125
150
0 1000 2000 3000 4000 5000
Quarts/Day
PSI
1/4" Plunger
1/4" Dual
1/4" Single
0
50
100
150
200
250
300
350
400
0 500 1000 1500 2000 2500
Quarts/Day
PSI
3/8" Plunger
3/8" Dual
3/8" Single
0
100
200
300
400
500
600
700
0 250 500 750 1000 1250
Quarts/Day
PSI
1/2" Plunger
1/2" Dual
1/2" Single
0
20
40
60
80
100
0 1000 2000 3000 4000 5000 6000
Quarts/Day
PSI
3/16" Plunger
3/16" Dual
3/16" Single
0
25
50
75
100
125
150
175
0 1000 2000 3000 4000 5000
Quarts/Day
PSI
1/4" Plunger
1/4" Dual
1/4" Single
0
50
100
150
200
250
300
350
0 500 1000 1500 2000 2500
Quarts/Day
PSI
3/8" Plunger
3/8" Dual
3/8" Single
0
100
200
300
400
500
600
0 250 500 750 1000 1250
Quarts/Day
PSI
1/2" Plunger
1/2" Dual
1/2" Single
0
20
40
60
80
100
0 1000 2000 3000 4000 5000 6000
Quarts/Day
PSI
3/16" Plunger
3/16" Dual
3/16" Single

5
MAXIMUM FLOW RATE CURVES: 4001 MOTOR
ON/OFF CONTROLLER
CONTINUOUS RUN CONTROLLER
0
20
40
60
80
100
0 1000 2000 3000 4000 5000
Quarts/Day
PSI
3/16" Plunger
3/16" Dual
3/16" Single
0
100
200
300
400
500
600
0 100 200 300 400 500
Quarts/Day
PSI
1/2" Plunger
1/2" Dual
1/2" Single
0
50
100
150
200
250
300
350
0 250 500 750
Quarts/Day
PSI
3/8" Plunger
3/8" Dual
3/8" Single
0
25
50
75
100
125
150
0 250 500 750 1000 1250 1500 1750 2000
Quarts/Day
PSI
1/4" Plunger
1/4" Dual
1/4" Single
0
25
50
75
100
125
150
175
0 500 1000 1500 2000 2500
Quarts/Day
PSI
1/4" Plunger
1/4" Dual
1/4" Single
0
50
100
150
200
250
300
350
0 250 500 750 1000 1250
Quarts/Day
PSI
3/8" Plunger
3/8" Dual
3/8" Single
0
20
40
60
80
100
0 1000 2000 3000 4000 5000
Quarts/Day
PSI
3/16" Plunger
3/16" Dual
3/16" Single
0
100
200
300
400
500
600
0 250 500 750
Quarts/Day
PSI
1/2" Plunger
1/2" Dual
1/2" Single

6
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
SOLAR PUMP ASSEMBLY
PUMP ASSEMBLY
BODY ASSEMBLY SHOWN
ON PAGE 8
*Single Head conguraon shown

7
SOLAR PUMP ASSEMBLY
PUMP ASSEMBLY PARTS LIST
ITEM
PART
NUMBER DESCRIPTION MATERIAL
QUANTITY
SINGLE
HEAD
DUAL
HEAD
175260 BASE PLATE CARBON STEEL 1
270022 MOTOR 1/5 HP, BRUSHLESS 1
375360 HEX SCREW 1/4-20 X .625 CARBON STEEL 4
4 75320 COUPLING .625 BORE ALUMINUM *
75321 COUPLING .50 BORE ALUMINUM
575319 COUPLING SPIDER RUBBER / BUNA 1
675250 SOLAR HOUSING ALUMINUM 1
775220 DRIVESHAFT BUSHING BRONZE 1
875211 TOLERANCE RING SST 1
975210 DRIVESHAFT BEARING SST 1
10 75150 DRIVESHAFT 303 SST 1
11 75420 DRIVESHAFT KEY CARBON STEEL 1
12 75390 ROLL PIN 3/16 X 1.25 SST 1
13
75145 CAM AND BEARING ASSEMBLY
175140 CAM 303 SST
75200 MAIN BEARING SST
14 75130 PUSHROD 17-4 PH SST / 1150M 1
15 75230 PUSHROD BUSHING BRONZE 2
16 75367 LOCK WASHER 1/4 CARBON STEEL 4
17 75365 NUT 1/4-20 CARBON STEEL 4
18 75280 HOUSING COVER CARBON STEEL 1
19 75270 HOUSING COVER GASKET RUBBER 1
20 75330 SCREW 10-32 X 1/2 CARBON STEEL 14
21 75172 YOKE 3/16"-3/8" PLUNGERS CARBON STEEL,
ZINC PLATED 1 2
185175 YOKE 1/2" PLUNGER
22 75400 SET SCREW 3/8-24 X .375 SST 710
23
75240 PLUNGER 3/16
17-4 PH SST / H900
12
75241 PLUNGER 1/4
75242 PLUNGER 3/8
75243 PLUNGER 1/2
75245 PLUNGER 3/16
CERAMIC COATED
17-4PH SST
75246 PLUNGER 1/4
75247 PLUNGER 3/8
75248 PLUNGER 1/2
24 185290 SOLAR BLANK CAP 303 SST 1
25 75410 ROLL PIN 3/16 X .875 SST 12
26 75430 MOTOR COVER ALUMINUM 1
*Model 4001 pump comes with one of each coupling (Item 4 parts 75320 and 75321) while Model 4000 pump comes with two of part 75320.
Model 4001 motors must use the 1/2” bore coupling.

8
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
SOLAR PUMP ASSEMBLY
BODY ASSEMBLY AND PARTS LIST
ITEM PART NUMBER DESCRIPTION MATERIAL
QUANTITY
SINGLE
HEAD
DUAL
HEAD
1
75180 PACKING NUT, 3/16"
303 SST 12
75181 PACKING NUT, 1/4"
75182 PACKING NUT, 3/8"
75183 PACKING NUT, 1/4"
2
75190 BODY, 3/16"
316 SST 12
75192 BODY, 1/4" AND 3/8"
185193 BODY, 1/2"
3
75339 PACKING, 3/16"
PTFE/AFLAS
12
75341 PACKING, 1/4"
75342 PACKING, 3/8"
75343 PACKING, 1/2"
75340 PACKING, 3/16"
VITON
75344 PACKING, 1/4"
75345 PACKING, 3/8"
75346 PACKING, 1/2"
475380 SUCTION CHECK VALVE
4A 60010 SUCTION CHECK OUTLET BODY 316 SST 12
4B 60020 SUCTION CHECK INLET BODY 316 SST 12
4C 40281 O-RING TFE 12
4D 40341 O-RING TFE 12
4E 40320 BALL SST 12
530325 DISCHARGE CHECK VALVE
5A 30230 DICHARGE CHECK INLET BODY 316 SST 12
5B 30240 DISCHARGE CHECK OUTLET BODY 316 SST 12
5C 40281 O-RING TFE 12
5D 40341 O-RING TFE 12
5E 40320 BALL SST 12
5F 40260 DISCHARGE CHECK SPRING 302 SST 12
630100 BLEED SCREW (NOT SHOWN) 316 SST 12

9
INCLUDED COMPONENTS
Item 1: Pump Unit
Components below are shown for a standard, single panel solar pump setup (e.g. part number 4000-4A1A-02). Addional
panels, baery enclosures, and charge controllers are available for systems requiring addional power.
*Not included with Plasc Baery Box opon
Your product is delivered with the following components:
ITEM DESCRIPTION QTY
1Pump Unit 1
2Baery/Control Enclosure 1
2a Pump Controller 1
2b Charge Regulator 1
2c Horizontal Support Assembly 1
3Solar Panel 1
4Solar Panel Mounng Pole (6-8’) 1
5Solar Panel Mounng Hardware Kit
5a Unistrut Clamp 4
5b ¼”-20 x 1” Bolt 2
5c ¼”-20 Square Nut 2
6Wiring Accessories
6a Baery Jumper Wires 2
6b Baery Fuse Wire 1
6c Spare 15A Inline Fuse 2
7Baery Enclosure Pole Mounng Kit*
7a ¼”-20 U-Bolt 2
7b ¼” Flat Washer 4
7c ¼”-20 Hex Nut 4
Dual Battery, Pole / Stand Mount Single Baery, Crate Style
Item 2c: Horizontal Support Assembly

10
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
INSTALLATION
This product should only be installed by a qualied person familiar with its operaon and associated hazards. The Naonal
Electrical Code (NEC), local electrical and safety codes, and when applicable, the Occupaonal Safety and Health Act (OSHA)
should be observed to reduce hazards to personnel and property. READ ALL INSTRUCTIONS BEFORE PROCEEDING.
MOUNTING DIMENSIONS
1. The pump unit should be mounted on a at and level surface. The chemical supply level must be at least 6”
above the sucon check valve at startup.
2. Verify that the arrow on the end of the pump body is poinng straight upward and sucon check valve is
facing downwards for 1/4”, 3/8”, and 1/2” plunger bodies (Shown to the right).
For 3/16” plunger bodies, verify bleed screw is poinng directly upwards and sucon check valve is
facing downwards.
3. Install the pump unit onto a rm base through the use of 1/4” mounng hardware using the six holes
provided in the Baseplate. Mounng hole locaons are shown above.
4. Typical installaons include the following:
A rate gauge or drum gauge to accurately set the injecon rate
Isolaon valves on the sucon and discharge lines
Line check on the chemical discharge line (i.e., Timberline model 24SV-6 check valve)
A lter/strainer on the uid sucon line to prevent trash from embedding in the seat O-rings
5. Install sucon and discharge line tubing and ngs per manufacturer’s recommendaons. Timberline
recommends using 3/8” tubing minimum for sucon and discharge lines. Sucon/Discharge connecons 1/4”
Cauon
BEFORE INSTALLATION, REVIEW THE APPLICATION TO ENSURE THAT PROPER PUMP SELECTION HAS BEEN
PERFORMED. THIS SHOULD BE DONE AFTER READING THIS MANUAL AND ALL APPLICABLE SAFETY STANDARDS.
IF IN DOUBT, CONTACT YOUR LOCAL TIMBERLINE MANUFACTURING REPRESENTATIVE OR THE HOME OFFICE.
DETERMINATION OF SYSTEM FITNESS FOR PURPOSE OR USE IS SOLELY THE CUSTOMER’S RESPONSIBILITY.
LEAK HAZARD—PUMP MAY GENERATE PRESSURES IN EXCESS OF 10,000 PSI IN THE EVENT OF DEAD-HEAD OR
BLOCKAGE. A PRESSURE SAFETY VALVE SHOULD BE INSTALLED IN ALL APPLICATIONS ON THE PUMP DISCHARGE
LINE WITH RELIEF VALVE OUTLET PIPED BACK TO THE CHEMICAL SUPPLY TO PREVENT OVERPRESSURE OF
DOWNSTREAM EQUIPMENT.
Warning
PUMP MOUNTING AND TUBING

11
INSTALLATION
TUBING SCHEMATIC

12
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
Warning
THIS SYSTEM SHOULD ONLY BE INSTALLED BY A QUALIFIED TECHNICIAN, ELECTRICIAN, OR ELECTRICAL
MAINTENANCE PERSON FAMILIAR WITH ITS OPERATION AND ASSOCIATED HAZARDS. THE NATIONAL ELECTRICAL
CODE (NEC), LOCAL ELECTRICAL AND SAFETY CODES, AND WHEN APPLICABLE, THE OCCUPATIONAL SAFETY AND
HEALTH ACT (OSHA) SHOULD BE OBSERVED TO REDUCE HAZARDS TO PERSONNEL AND PROPERTY.
TIMBERLINE MANUFACTURING PROVIDES A SUPPLIED WIRING HARNESS FOR DC POWER CONNECTIONS
UTILIZING TYPE B LIQUIDTIGHT FLEXIBLE NONMETALLIC CONDUIT AND APPLICABLE FITTINGS. DETERMINATION
OF SYSTEM FITNESS FOR PURPOSE OR USE IS SOLELY THE CUSTOMER’S RESPONSIBILITY.
Before installing any photovoltaic system, contact local authories to determine the necessary permits and installaon/
inspecon permits.
1. Inspect for any damage to the solar panel and/or mounng hardware before proceeding.
2. Locate the Solar Panel Mounng Pole (Item 4). Install and secure pipe stand for mounng the photovoltaic module(s).
Cauon
THE MOUNTING METHOD USED TO SUPPORT THE MODULE AND BATTERY ENCLOSURE (IF A METAL ENCLOSURE
IS USED) SHOULD BE WIND RATED AND APPROVED TO THE LOCAL AND CIVIL CODES PRIOR TO INSTALLATION.
3. Aach the horizontal support assembly (Item 2c) to the unistrut which is pre-
aached to the solar panel with the provided unistrut clamps as shown in the
illustraon to the right.
4. Mount the solar panel(s) and horizontal support assembly to the pipe stand
using the adjustment tee ng (image on next page).
5. Mount the baery enclosure onto the pipe stand with U-bolts provided in the
baery enclosure pole mounng kit (Item 7, metal enclosure only).
Cauon
NEVER EXPOSE THE MODULE TO ARTIFICIALLY CONCENTRATED SUNLIGHT.
UNDER NORMAL CONDITIONS A PHOTOVOLTAIC MODULE MAY EXPERIENCE CONDITIONS THAT PRODUCE
MORE CURRENT AND/OR VOLTAGE THAN REPORTED AT STANDARD TEST CONDITIONS. ACCORDINGLY, THE
VALUES OF ISC AND VOC MARKED ON UL LISTED MODULES SHOULD BE MULTIPLIED BY A FACTOR OF 1.25
WHEN DETERMINING THE COMPONENT VOLTAGE RATINGS, CONDUCTOR CAPACITIES, FUSE SIZES AND SIZE
OF CONTROLS CONNECTED TO THE MODULE OUTPUT. REFER TO SECTION 690-8 OF THE NATIONAL ELECTRIC
CODE FOR AN ADDITIONAL MULTIPLYING FACTOR OF 1.25 WHICH MAY BE APPLICABLE.
INSTALL CABLE WITH APPROPRIATE HARDWARE IN ACCORDANCE WITH APPLICABLE ELECTRICAL CODES.
GROUNDING IS ACHIEVED BY SECUREMENT TO THE ARRAY FRAME. THE ARRAY FRAME SHALL BE GROUNDED
IN ACCORDANCE WITH NEC ARITCLE 250.
SOLAR PANEL MOUNTING AND ASSEMBLY
INSTALLATION

13
INSTALLATION
SOLAR PANEL POSITIONING
The solar panel should be posioned to achieve maximum solar exposure. Proper adjustment of the mounng assembly is
crical to proper performance of the assembly.
1. Rotaon: Loosen the rotaon set screw on the adjustment tee (shown below) and posion the panel so that it is facing
true south (for northern hemisphere installaons) or true north (for southern hemisphere installaons), then re-ghten
the set screw. True south (or north) is dened as the posion halfway between sunrise and sunset. Determine the
halfway point between sunrise and sunset for a given day, and face the solar panel(s) in that direcon. True south varies
slightly from magnec south as shown on a compass.
2. Tilt: The opmum lt angle for the panel (measured from the horizontal) is determined by the site latude. See the table
below for recommendaons. Loosen the lt set screw on the adjustment tee and using either a smart phone app or
protractor and plumb-bob, adjust the lt angle of the panel unl the angle the panel makes with the horizontal matches
the recommended lt angle. Re-ghten the set screws.
Site Latude Recommended Tilt Angle
25° to 30° (Houston, TX) Site Latude minus 2.5°
31° to 35° (Dallas, TX) Site Latude minus 5°
36° to 40° (St. Louis, MO) Site Latude minus 6.5°
41° to 45° (Chicago, IL) Site Latude minus 7.5°
46° to 50° (Bismarck, ND) Site Latude minus 8.5°
Recommended Tilt Angles
These numbers are based on a xed angle to provide the most energy year round. Increasing the lt angle during winter
months may increase solar panel output, however leaving panels at a winter lt angle will signicantly reduce output during
summer months. Contact the manufacturer for more informaon.
Example: For a Houston, TX installaon (Latude 29.8°), lt angle is 27.3° (29.8° - 2.5° = 27.3°).

14
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
INSTALLATION
WIRING
1. Insert baeries into the baery/control enclosure and ensure that baeries are wired in parallel using the provided baery jumper
cables. An example of parallel wiring is shown below.
2. Locate the posive (red) and negave (black) baery wires which are pre wired into the controller and ASC. These wires are terminated
with #10 ring lugs for connecng the baeries.
3. Connect the baery wires to the baery ensuring that posive and negave terminals receive the corresponding wire color.
4. Cover the solar panel(s) as completely as possible, i.e., with a blanket or cardboard, to minimize power generaon while performing
wiring steps below.
5. Each solar panel should include 3. of aached wire with quick connect adapters pre-installed. Addionally, the baery/control
enclosure should include 12 . of aached wire with corresponding quick connect adapters.
6. Connect the solar panel cables by plugging in the aached MC4 connectors. The connectors should snap into place to prevent
accidental removal.
7. For dual panel systems, branch connectors are provided for wiring the panels in parallel. An example is shown below when wiring
mulple panels.
8. Run the pump motor wire through the supplied cord grip and into the control enclosure. The pump motor wire is terminated with
male/female bullets for easy connecon. Tighten the cord grip.
9. Locate the corresponding male/female bullets inside of the enclosure and terminate the leads.
10. For pumps using the oponal temperature sensor, adjust for the desired set point. To test funconality, increase the temperature set
point unl contact is made.
Cauon BATTERIES AND PANELS MUST BE WIRED IN PARALLEL FOR 12VDC OPERATION. WIRING IN SERIES WILL DOUBLE
THE OUTPUT VOLTAGE AND RESULT IN SERIOUS SYSTEM HARM.
Cauon
SINGLE PANEL SYSTEMS ARE SUPPLIED WITH AN 8 AMP REGULATOR WHICH IS SUFFICIENT FOR (1) 90 OR 140W
PANEL. DUAL PANEL SYSTEMS ARE SUPPLIED WITH A 16 AMP REGULATOR WHICH IS SUFFICIENT FOR (2) 90 OR
140W PANELS. WHEN UPGRADING A SYSTEM A LARGER OR ADDITIONAL CHARGE REGULATOR MAY BE
REQUIRED. CONTACT FACTORY FOR ASSISTANCE.

15
INSTALLATION
WIRING DIAGRAMS
Connuous Run, Variable Speed Controller
On/O Controller
*For any addional or more detailed informaon contact the manufacturer.

18
Timberline Mfg. Company
3255 Execuve Blvd. Suite 108
Beaumont, Tx 77705
MAINTENANCE
PUMP
Lubricate sha and bearings with mul purpose grease. Alternavely, lubricate by lling the pump housing with hydraulic oil. Add or
replace lubricant quarterly, as a minimum. Use lubricant suitable for climate where the pump is installed.
Monitor plunger packing for leaks. Packing may need to be ghtened 24-72 hours aer installaon to account for the inial break-in
period. Replace packing if necessary.
Cauon OVER-TIGHTENING PACKING MAY CAUSE EXCESSIVE FRICTION ON PLUNGER RESULTING IN INCREASED POWER
CONSUMPTION AND DEGRADED SYSTEM PERFORMANCE
Monitor drivesha and pushrod bushings for wear. Replace if necessary.
SOLAR PANELS
Repeated deep discharge cycles may permanently damage the baeries. Proper sizing is essenal to ensure baery life. Replacement
may be necessary aer an extended period of me or repeated deep discharges.
BATTERIES
Periodically clean the solar panel to ensure opmum performance. Use a mild soap with warm water and a clean so towel to remove
dust, bird droppings, etc.
Cauon THE SOLAR PANELS ARE FRAGILE—HANDLE WITH CARE TO AVOID IRREPARABLE DAMAGE. AVOID IMPACTING, TWISTING, OR
BENDING THE ASSEMBLY.

19
TROUBLESHOOTING
SYMPTOM PROBABLE CAUSE VERIFICATION CORRECTIVE ACTION
PUMP NOT
RUNNING
Low battery voltage Voltage test battery See other section
Fuse blown Fuse visibly blown
Replace fuse (Proper diagnosis should
be performed to determine cause of
fuse failure)
Obstructed flow Pump operates when bleed screw is
opened
Verify all valves between injection point
and pump are open and lines are free
of debris
Pressure over MAOP Pump operates when bleed screw is
opened; Process gauge readings
Verify injection pressure is within the
pumps limits; Smaller plunger sizes
may be able to accommodate higher
pressure
Plunger roll pin inserted too far
Visual inspection to verify roll pin is not
protruding enough to contact pushrod
bushings
Replace roll pin and insert correctly
Air/vapor in pump Bubbles in bleed screw output Bleed pump until flow from bleed screw
is smooth with no bubbles.
PUMP RUNS,
BUT WITH
LITTLE OR NO
FLUID OUTPUT
Pump mounted too high to create
adequate suction
Verify pump suction check is 6” below
chemical level
Mount pump such that suction check is
at least 6” below chemical level
Discharge or suction lines plugged N/A Clean lines
Suction check failure Rate gauge “bounces” when pumping Clean suction O-rings; Replace suction
check parts; Replace suction check
Discharge check failure No movement in rate gauge Replace discharge check parts; Replace
discharge check
Electrical short N/A Qualified technician should identify and
repair the electrical short
LOW BATTERY
VOLTAGE
Solar panel positioned improperly See page 15 Re-position as required
Panel not getting adequate sunlight Visual Inspection Relocate panel if possible. Clear any
obstructions such as tree limbs.
Panel is dirty Visual Inspection Clean as required
Battery failure N/A Replace if necessary
Solar array improperly sized Contact manufacturer Add panels/batteries as necessary
BLOWN FUSE
Over current on motor N/A
Check for dead-head due to closed
valves or blockage; Check for discharge
pressure over MAOP; Check for pump
mechanical failure
Lightning strike N/A Complete replacement may be required

While this informaon is presented in good faith and believed to be accurate, Timberline Manu-
facturing Company does not guarantee results based upon such informaon. Timberline Manu-
facturing Company reserves the right to change the design or specicaons of these products
without noce.
South Texas Location
206 S. Sunset Strip
Kenedy, TX 78119
830-583-8112
Main Office
11122 West Little York RD
Houston, TX 77041
713-466-3552
Norrisealwellmark.com
Oklahoma Location
3100 S Ann Arbor
Oklahoma City, OK 73179
405-813-4562
ORDERING INFORMATION
Before seng up any solar pump system, contact the manufacturer for proper sizing based on your locaon, pressure, and ow rate.
Improper sizing and/or unintended use may cause system failure.
SAMPLE MODEL CODE
4
0
0
0
-
4
A
1
A
-
0
2
Configuration
Code
Standard
0
Methanol
5
Standard Motor
Code
Pole Mount Box
0
Plastic Box
0P
Crate Style Box
0S
Low Pressure Motor
Code
Pole Mount Box
1
Plastic Box
1P
Crate Style Box
1S
Packing
Code
PTFE/Aflas
-
Viton
V
Plunger Size
Code
3/16”
3
1/4”
4
3/8”
6
1/2"
8
Style
Code
Single Head Pump
A
Dual Head Pump
B
Plunger Material
Code
17-4 PH SST / 1150 M
1
Ceramic Coated 17-4 PH SST
2
Control
Code
Continuous Run, Variable Speed
A
Start/Stop
B
Start/Stop, Low Flow
D
Batteries
Code
No Batteries (Standard)
0
One 100Ah Battery
1
Two 100Ah Batteries
2
Solar Panels
Code
One 90W Panel
1
One 140W Panel
2
Two 90W Panels
3
Two 140W Panels
4
West Texas Location
1460 Windway Street
Odessa, TX 79763
432-238-3913
