SPX FLOW Johnson Pump CombiProLine OH3 User manual

CRL/EN (1810) 2.2
CombiProLine
Orginal instructions
Read and understand this manual prior to operating or servicing this product
INSTRUCTION MANUAL
Vertical heavy duty process in-line pump according to API 610 (OH3 & OH5)

EC/EN (1712) 6.0 1
EC Declaration of conformity
(Directive 2006/42/EC, appendix II-A)
Manufacturer
SPX Flow Technology Assen B.V.
Dr. A.F. Philipsweg 51
9403 AD Assen
The Netherlands
hereby declares that all pumps member of productfamilies CombiBloc, CombiBlocHorti,
CombiChem, CombiDirt, CombiFlex(U)(B), CombiPrime H, CombiLine, CombiLineBloc,
CombiMag, CombiMagBloc, CombiNorm, CombiPro(L)(M)(V), CombiPrime V, CombiSump,
CombiTherm, CombiWell, FRE, FRES, FREF, FREM, KGE(L), KGEF, HCR, MCH(W)(S),
MCHZ(W)(S), MCV(S), PHA, MDR whether delivered without drive (last position of serial
number = B), or delivered as an assembly with drive (last position of serial number = A),
are in conformity with the provisions of Directive 2006/42/EC (as altered most recently)
and where applicable the following directives and standards:
• EC directive 2014/35/EU, "Electric equipment for use within certain voltage limits"
• standards EN-ISO 12100 part 1 & 2, EN 809
The pumps to which this declaration refers may only be put into operation after they have
been installed in the way prescribed by the manufacturer, and, as the case may be, after
the complete system of which these pumps form part, has been made to fulfil the
requirements of Directive 2006/42/EC (as altered most recently).
Declaration of incorporation
(Directive 2006/42/EC, appendix II-B)
Manufacturer
SPX Flow Technology Assen B.V.
Dr. A.F. Philipsweg 51
9403 AD Assen
The Netherlands
hereby declares that the partly completed pump (Back-Pull-Out unit), member of
productfamilies CombiBloc, CombiBlocHorti, CombiChem, CombiDirt, CombiFlex(U)(B),
CombiPrime H, CombiLine, CombiLineBloc, CombiMag, CombiMagBloc, CombiNorm,
CombiPro(L)(M)(V), CombiTherm, CombiPrime V, FRE, FRES, FREF, FREM, KGE(L), KGEF,
HCR, PHA, MDR is in conformity with the following standards:
• EN-ISO 12100 parts 1 & 2, EN 809
and that this partly completed pump is meant to be incorporated into the specified pump
unit and may only be put into use after the complete machine of which the pump under
consideration forms part has been made and declared to comply with that directive.
Assen, December 1st 2017
B. Peek,
Managing Director

2EC/EN (1712) 6.0

INT/EN (1512) 1.2 3
Instruction manual
All technical and technological information in this manual as well as possible drawings
made available by us remain our property and shall not be used (otherwise than for the
operation of this pump), copied, duplicated, made available to or brought to the notice of
third parties without our prior written consent.
SPXFLOW is a global multi-industry manufacturing leader. The company's highly-
specialized, engineered products and innovative technologies are helping to meet rising
global demand for electricity and processed foods and beverages, particularly in
emerging markets.
SPX Flow Technology Assen B.V.
P.O. B ox 9
9400 AA Assen
The Netherlands
Tel. [phone]
Fax. [phone]
Copyright © 2015 SPXFLOW Corporation

4INT/EN (1512) 1.2

CRL/EN (1810) 2.2 5
CombiProLine
Table of Contents
1 Introduction 9
1.1 Preface 9
1.2 Safety 9
1.3 Guarantee 10
1.4 Inspection of delivered items 10
1.5 Instructions for transport and storage 10
1.5.1 Weight 10
1.5.2 Use of pallets 10
1.5.3 Hoisting 11
1.5.4 Storage 12
1.6 Ordering parts 12
2 General 13
2.1 Pump description 13
2.2 Applications 13
2.3 Type code 14
2.4 Serial number 15
2.5 Construction 15
2.6 Pump casing 15
2.7 Impeller 16
2.8 Pump cover 16
2.9 Wear rings 16
2.10 Mechanical seal 16
2.11 Bearing OH3 pump 16
2.12 Coupling OH3 pump 16
2.13 Application area 16
2.14 Re-use 17
2.15 Scrapping 17
3Installation 19
3.1 Safety 19
3.2 Preservation 19
3.3 Environment 19
3.4 Mounting OH3 pump 20
3.4.1 Installation of a pump unit 20
3.4.2 Assembling a pump unit 20
3.4.3 Alignment of the coupling 20
3.4.4 Tolerances for aligning the coupling 21
3.5 Piping 21
3.6 Accessories 22

6CRL/EN (1810) 2.2
3.7 Connection of the electric motor 22
4 Commissioning 23
4.1 Inspection of the pump 23
4.2 Inspection of the motor 23
4.3 Preparing the pump unit for commissioning 23
4.4 Checking the sense of rotation 23
4.5 Start-up 23
4.6 Pump in operation 24
4.7 Noise 24
5 Maintenance 25
5.1 Daily maintenance 25
5.2 Mechanical seal 25
5.3 Lubrication of the bearings 25
5.3.1 OH3 pump 25
5.3.2 OH5 pump 25
5.4 Environmental influences 25
5.5 Noise 26
5.6 Motor 26
5.7 Faults 26
6 Problem solving 27
7 Disassembly and assembly 29
7.1 Precautionary measures 29
7.2 Special tools 29
7.3 Position numbers 29
7.4 Liquid draining 29
7.5 Disassembly and assembly Top Pull Out unit OH3 30
7.5.1 Disassembling the Top Pull Out unit OH3 30
7.5.2 Assembling the Top Pull Out unit OH3 30
7.6 Disassembly and assembly Top Pull Out unit OH5 31
7.6.1 Disassembly Top Pull Out unit OH5 31
7.6.2 Assembly Top Pull Out unit OH5 31
7.7 Replacing the impeller and the wear ring 32
7.7.1 Disassembling the impeller 32
7.7.2 Mounting the impeller 32
7.7.3 Disassembling the wear rings 32
7.7.4 Assembling the wear rings 33
7.8 Mechanical seal 34
7.8.1 Instructions for mounting a cartridge seal 34
7.8.2 Disassembling a cartridge seal 34
7.8.3 Mounting a cartridge seal 34
7.9 Bearing OH3 35
7.9.1 Instructions for assembly and disassembly of bearings 35
7.9.2 Disassembling bearing 35
7.9.3 Assembling bearing 36
8Dimensions 37
9Parts 39
9.1 Ordering parts 39
9.1.1 Order form 39
9.1.2 Recommended spare parts 39
9.2 Pump OH3 40

CRL/EN (1810) 2.2 7
CombiProLine
9.2.1 Sectional drawing pump 40
9.2.2 Parts list pump 41
9.3 Bearing OH3 43
9.3.1 Sectional drawing bearing 43
9.3.2 Parts list bearing 44
9.4 Pump OH5 45
9.4.1 Sectional drawing pump 45
9.4.2 Parts list pump 46
9.5 Mechanical seal piping plan 11 - tubing 48
9.5.1 Drawing plan 11 - tubing 48
9.5.2 Parts list plan 11 - tubing 48
9.6 Mechanical seal piping plan 11 - flanged 49
9.6.1 Drawing plan 11 - flanged 49
9.6.2 Parts list plan 11 - flanged 49
10 Technical data 51
10.1 Tightening moments 51
10.1.1 Tightening moments for bolts and nuts 51
10.1.2 Tightening moments for cap nut 51
10.1.3 Tightening moments stud bolts for drain and seal flushing 51
10.1.4 Torques settings for nuts for pump casing 52
10.2 Permissible forces and moments on the flanges 53
10.2.1 Allowable forces and moments on suction and discharge flanges 54
10.2.2 Allowable forces and moments on the drain flange 54
10.3 Grease 54
10.4 Hydraulic performance 55
10.4.1 Performance overview cast steel material class S-1 55
10.4.2 Performance overview material classes S-6, S-8, C-6, A-8, D-1, D-2 57
10.5 Noise data 59
10.5.1 Pump noise as a function of pump power 59
10.5.2 Noise level of entire pump unit 60
Index 61
Order form for spare parts 63

8CRL/EN (1810) 2.2

CRL/EN (1810) 2.2 Introduction 9
CombiProLine
1 Introduction
1.1 Preface
This manual is intended for technicians and maintenance staff and for those who are in
charge of ordering spare parts.
This manual contains important and useful information for the proper operation and
maintenance of this pump. It also contains important instructions to prevent potential
accidents and damage, and to ensure safe and fault-free operation of this pump.
! Read this manual carefully before commissioning the pump, familiarize
yourself with the operation of the pump and strictly obey the instructions!
The data published here comply with the most recent information at the time of going to
press. However they may be subject to later modifications.
SPXFLOW reserves the right to change the construction and design of the products at
any time without being obliged to change earlier deliveries accordingly.
1.2 Safety
This manual contains instructions for working safely with the pump. Operators and
maintenance staff must be familiar with these instructions.
Installation, operation and maintenance has to be done by qualified and well prepared
personnel.
Below is a list of the symbols used for those instructions and their meaning:
Personal danger for the user. Strict and prompt observance of the
corresponding instruction is imperative!
! Risk of damage or poor operation of the pump. Follow the corresponding
instruction to avoid this risk.
➢Useful instruction or tip for the user.
Items which require extra attention are shown in bold print.
This manual has been compiled by SPXFLOW with the utmost care. Nevertheless
SPXFLOW cannot guarantee the completeness of this information and therefore
assumes no liability for possible deficiencies in this manual. The buyer/user shall at all
times be responsible for testing the information and for taking any additional and/or
deviating safety measures. SPXFLOW reserves the right to change safety instructions.

10 Introduction CRL/EN (1810) 2.2
1.3 Guarantee
SPXFLOW shall not be bound to any guarantee other than the guarantee accepted by
SPXFLOW. In particular, SPXFLOW will not assume any liability for explicit and/or
implicit guarantees such as but not limited to the marketability and/or suitability of the
products supplied.
The guarantee will be cancelled immediately and legally if:
• Service and/or maintenance is not undertaken in strict accordance with the
instructions.
• The pump is not installed and operated in accordance with the instructions.
• Necessary repairs are not undertaken by our personnel or are undertaken without our
prior written permission.
• Modifications are made to the products supplied without our prior written permission.
• The spare parts used are not original SPXFLOW parts.
• Additives or lubricants used are other than those prescribed.
• The products supplied are not used in accordance with their nature and/or purpose.
• The products supplied have been used amateurishly, carelessly, improperly and/or
negligently.
• The products supplied become defective due to external circumstances beyond our
control.
All parts which are liable to wear are excluded from guarantee. Furthermore, all
deliveries are subject to our “General conditions of delivery and payment”, which will be
forwarded to you free of charge on request.
1.4 Inspection of delivered items
Check the consignment immediately on arrival for damage and conformity with the advice
note. In case of damage and/or missing parts, have a report drawn up by the carrier at
once.
1.5 Instructions for transport and storage
1.5.1 Weight
A pump or a pump unit is generally too heavy to be moved by hand. Therefore, use the
correct transport and lifting equipment. Weight of the pump or pump unit are shown on
the label on the cover of this manual.
1.5.2 Use of pallets
Usually a pump or pump unit is shipped on a pallet. Leave it on the pallet as long as
possible to avoid damages and to facilitate possible internal transport.
! When using a forklift always set the forks as far apart as possible and lift the
package with both forks to prevent it from toppling over! Avoid jolting the
pump when moving it!

CRL/EN (1810) 2.2 Introduction 11
CombiProLine
1.5.3 Hoisting
When hoisting a pump unit OH3 or pump unit OH5 the straps must be fixed in
accordance with figure 1 and figure 2.
When lifting a pump unit always use a proper and sound lifting device,
approved to bear the total weight of the load! Never go underneath a load
that is being lifted!
! If the electric motor is provided with a lifting eye, this lifting eye is intended
only for the purpose of carrying out service activities to the electric motor!
The lifting eye is designed to bear the weight of the electric motor only!
It is NOT permitted to lift a complete pump unit at the lifting eye of an electric
motor!
Figure 1: Lifting instructions for OH3 pump unit.

12 Introduction CRL/EN (1810) 2.2
1.5.4 Storage
If the pump is not to be used immediately the pump shaft must be turned by hand twice
per week.
1.6 Ordering parts
This manual contains a survey of the spare parts recommended by SPXFLOW as well as
the instructions for ordering them. A fax-order form is included in this manual.
You should always state all data stamped on the type plate when ordering parts and in
any other correspondence regarding the pump.
➢This data is also printed on the label on the front of this manual.
If you have any questions or require further information with regard to specific subjects,
then do not hesitate to contact SPXFLOW.
Figure 2: Lifting instructions for OH5 pump unit.

CRL/EN (1810) 2.2 General 13
CombiProLine
2 General
2.1 Pump description
The CombiProLine represents a range of vertical "heavy duty" centrifugal pumps. The
design of this range of pumps is based on the guidelines for: "Centrifugal Pumps for
Petroleum, Petrochemical and Natural Gas Industries" from the "American Petroleum
Institute" otherwise known as the API Standard 610 (identical to ISO 13709). The
CombiProLine range therefore meets the high requirements which have been set by the
refineries and the petrochemical industry.
The API 610 contains important technical guidelines in order to guarantee optimum
reliability. This pump amply complies with these requirements. This has been
demonstrated through extensive research and can be supported on the basis of
advanced methods of calculation.
2.2 Applications
• In general, this pump can be used for thin, clean or slightly polluted liquids. These
liquids should not affect the pump materials.
• The maximum allowed system pressure and temperature and the maximum speed
depend on the pump type and the pump construction.
• Further details about the application possibilities of your specific pump are mentioned
in the order confirmation and/or in the data sheet enclosed with the delivery.
• Do not use the pump for purposes other than those for which it is delivered without
prior consultation with your supplier.
Using a pump in a system or under system conditions (liquid, working
pressure, temperature, etc.) for which it has not been designed may hazard
the user!

14 General CRL/EN (1810) 2.2
2.3 Type code
Pumps are available in various designs. The main characteristics of the pump are shown
in the type code.
Example: CRL 50A-200 OH3 A-8 1CW-FX
Pump family
CRL CombiProLine
Pump designation
OH3 vertical, in-line
OH4 close-coupled, vertical, in-line
Pump size
50A discharge connection [mm]. A and B design pump types have the same
designation though they have different hydraulic performances
200 nominal impeller diameter [mm]
Pump casing material according to API 610
S-1 carbon steel
S-6 carbon steel
S-8 carbon steel
C-6 12% CHR
A-8 316 AUS
D-1 duplex
D-2 super duplex
Impeller material according to API 610
S-1 cast iron
S-6 12% CHR
S-8 316 AUS
C-6 12% CHR
A-8 316 AUS
D-1 duplex
D-2 super duplex
Shaft sealing code according to API 682
Arrangement 1
1CW-FX Contacting single wet seal with a fixed throttle bushing
1CW-FL Contacting single wet seal with a floating throttle bushing
Arrangement 2
2CW-CW Liquid buffer fluid, Dual contacting wet seals
2CW-CS Gas buffer fluid or no buffer fluid, Contacting wet inner seal with a
containment seal
2NC-CS Gas buffer fluid or no buffer fluid, Non-contacting inner seal with a
containment seal
Arrangement 3
3CW-FB Liquid barrier fluid, Contacting wet seals in a face-to-back configuration
3CW-BB Liquid barrier fluid, Contacting wet seals in a back-to-back configuration
3CW-FF Liquid barrier fluid, Contacting wet seals in a face-to-face configuration
3NC-BB Gas barrier fluid, Non-contacting seals in a back-to-back configuration
3NC-FF Gas barrier fluid, Non-contacting seals in a face-to-face configuration
3NC-FB Gas barrier fluid, Non-contacting seals in a face-to-back configuration

CRL/EN (1810) 2.2 General 15
CombiProLine
2.4 Serial number
Serial number of the pump or pump unit are shown on the name plate off the pump and
on the label on the cover of this manual.
2.5 Construction
The pump has a modular design. The main components are:
• Pump casing
•Impeller
• Shaft sealing
•Bearing
In general for each individual pump type there is only one design of the pump casing and
the impeller. So, the hydraulic performance is fixed. However for several pump types
there has been developed an additional “low’ or “high flow” design. The required
capacity and head are obtained by pump speed selection and, if necessary, reduction of
the impeller diameter.
The pumps are divided into three bearing groups. The OH3 pumps each bearing group
only has one pump shaft and one bearing arrangement. The OH5 pump is provided by
the motor bearings. The selection of the pump/motor combination is such that the
bearings of the applied electric motors can absorb the axial and radial forces without the
bearing life being affected.
The pumps are also standardized into six groups with the same connection for the pump
casing and pump cover, depending on the nominal impeller diameters. For each
combination of shaft and nominal impeller diameter there is one pump cover, in various
materials, and for OH3 pumps one bearing bracket which is made from carbon steel.
The various designs of pumps are created by the addition of shaft seal “cartridges”.
These “cartridges” are standardized in the same three groups as the pump shafts and
are designed in accordance with API 682 (identical to ISO 21049).
In addition to this various material varieties can be used for components which come into
contact with the pumped liquid.
2.6 Pump casing
On the suction side of the impeller the pump casing is provided with a renewable wear
ring. An anti-rotation partition is fitted into the inlet. The centering edge for the pump
cover is located on the outside of the packing for the pump casing and does not
therefore come into contact with the liquid.
The suction and discharge flanges are designed and machined in accordance with
ASME B16.5 300 lbs RF (ISO 7005 PN50), and it is also possible to supply the flanges
drilled in accordance with the ASME B16.5 150 lbs RF (ISO 7005 PN20). The outside
diameter and the thickness of the inlet and outlet flanges are, in this case, in accordance
with ASME B16.5 300 lbs. The surface finish of the flanges is according ASME B16.5
requirements. The drain of the pump casing is a “butt-welded” flanged design coherent
to the pump casing’s pressure class.
Example: 01-1000675A
01 year of manufacture
100067 unique number
5number of pumps
Apumpwithmotor
Bpump with free shaft end

16 General CRL/EN (1810) 2.2
2.7 Impeller
The back of the closed impeller is provided with back vanes in order to limit the pressure
on the shaft seal and to allow the flushing liquid to circulate. Contamination of the shaft
seal is also prevented. On the inlet side the impeller is provided with an interchangeable
wear ring. Running clearances meet the requirements of API 610.
2.8 Pump cover
The pump is designed to fit any seal type in accordance with API 682. In collaboration
with various suppliers of mechanical seals the design has been closely evaluated in order
to be able to build in the required variants.
2.9 Wear rings
Both the impeller and the pump casing are fitted with a renewable wear ring. The impeller
wear ring has a hardness at least 50°Br over the casing wear ring. The rings are secured
by three lock screws.
2.10 Mechanical seal
The various designs of pumps are created by the addition of shaft seal "cartridges".
These "cartridges" are standardized in the same three groups as the pump shafts and are
designed in accordance with API 682.
2.11 Bearing OH3 pump
• The bearing construction consists of two angular contact bearings (in "O"
arrangement) combined with a cylindrical roller bearing. The bearings are grease
lubricated. The bearings on the coupling side with which the axial force is taken up are
retained on the shaft by a shaft nut. The outer ring of these bearings is retained by the
bearing cover.
• The cylindrical roller bearing on the impeller side takes up radial forces and is mounted
"floating" on the outer ring. As a result of this the machining tolerances and expansions
can be easily accommodated. The bearing arrangement is sealed by labyrinth rings.
2.12 Coupling OH3 pump
Pump and motor are coupled by means of a flexible coupling with spacer sleeve
('spacer'). After the guards and spacer have been removed, the rotating part of the pump
can be easily dismantled as a whole without having to disconnect the electric motor or
the piping. This construction is called the Top Pull Out principle.
2.13 Application area
The application area globally looks as follows:,
However, the maximum allowable pressures and temperatures depend strongly on the
selected materials and components. Also working conditions may cause differences.
Table 1: Application area.
Maximum value
Capacity 470 m3/h
Discharge head 160 m
System pressure 5000kPa (50 bar)
Temperature -30 to +200 °C
Viscosity 300 mm2/s

CRL/EN (1810) 2.2 General 17
CombiProLine
2.14 Re-use
The pump may only be used for other applications after prior consultation with
SPXFLOW or your supplier. Since the lastly pumped medium is not always known, the
following instructions should be observed:
1 Flush the pump properly.
2 Make sure the flushing liquid is discharged safely (environment!)
Take adequate precautions and use the appropriate personal protection
means like rubber gloves and spectacles!
2.15 Scrapping
If it has been decided to scrap a pump, the same flushing procedure as described for
Re-use should be followed.

18 General CRL/EN (1810) 2.2
