Timex Ti72 User manual

Model Ti72
NATURE SOUNDS STEREO
CLOCK RADIO FOR YOUR iPod

The exclamation point within an equilateral triangle is intended to alert the user of the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user of the presence
of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute
a risk electric shock to persons.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
The symbols above are located at the bottom of the cabinet.
CAUTION: To prevent electric shock, do not use this (Polarized) plug with an extension cord receptacle, or other
outlets unless the blades can be fully inserted to prevent blade exposure.
ATTENTION: Pour prévenir les chocs électriques ne pas utiliser cette fiche polarisée avec un prolongateur. Une
prise de courant, ou une autre sortie de courant sauf si les lames peuvent étre insérées à fond sans en laisser
aucune partie à decouvert.
• The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on
apparatus.
L'appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun objet ne contenant de liquide, tel qu'un vase, ne doit
être placé sur l'objet.
• Main plug is used as disconnect device and it should remain readily operable during intended use. In order to disconnect the apparatus
from the mains completely, the mains plug should be disconnected form the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être facilement accessible pendant son utilisation. Pour être complètement déconnecté
de l'alimentation d'entrée, la prise doit être débranchée du secteur.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu'à la lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the bottom of apparatus.
Les précautions d'emploi sont inscrites en bas de l'appareil.
• The marking information is located at the bottom of apparatus.
Les marquages sont inscrits en bas de l'appareil.
A Consumer Guide to Product Safety

A Consumer Guide to Product Safety
This unit has been designed and manufactured to assure your personal safety. Improper use can result in potential electrical shock or fire
hazards.
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Water and Moisture - Do not use this apparatus near water. For example: near a bathtub, washbowl, kitchen sink, laundry tub, swimming
pool or in a wet basement.
6. Ventilation - Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. For example, it
should not be situated on a bed, sofa, rug or similar surface that may block ventilation openings. Also, it should not be placed in a built-in
installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.
7. Heat - Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce
heat.
8. Power Sources - The unit should be connected to a power supply only of the type described in the operating instructions or as marked
on the appliance.
9. Grounding or Polarization - Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong
are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10. Power-Cord Protection - Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus. It is always best to have a clear area from where the cord exits the unit to where it is
plugged into an AC outlet.
11. Cleaning - Unplug this product from the well outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Clean only with a dry
cloth.
12. Non-Use Periods – The power cord of the unit should be unplugged from the outlet when it is to be left unused for a long period of
time.
13. Objects and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through
openings.
14. Attachments - Only use attachments/accessories specified by the manufacturer.
15. Lightning - Unplug this apparatus during lightning storms or when unused for long periods of time.
16. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or
electric shock.
17. Damage Require Service - Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
18. Servicing - The user should not attempt to service the unit beyond that described in the user’s operating instructions. All other servicing
should be referred to qualified service personnel.
19. Safety Check - Upon completion of any service or repairs to this product, ask the service telchnician to perform safety checks to
determine that the product is in proper operating condition.
20. Antenna - Do not connect to an external antenna.
Questions? Service? Warranty? Visit www.timexaudio.com

Table of Contents
Quick Start ........................................................................................................................................................................1
Controls and Indicators .................................................................................................................................................. 2
Ti72 display / Installing Clock Backup Batteries / Installing iPod Insert ....................................................................3
Using the Ti72................................................................................................................................................................4-6
Using the Optional Remote Control ...............................................................................................................................7
Trouble Shooting .............................................................................................................................................................8
Warranty Information.......................................................................................................................................................9
FCC Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide resonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and , if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed
between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzene, thinner or similar
materials can damage the surface of the unit.

Quick start
1
• Press & hold the Time Zone
button on back until the
display flashes
• Press the << or >> button to
select your time zone
• Press the Time Zone button
again.
• Move the DST switch on back
of unit to +1 or -1 (adds or
subtracts an hour)
3:time
Select the dock insert for your iPod
model from the table below and
place insert in dock. Never dock
an iPod without an insert in place.
Plug the AC cord into a working
wall socket.
Snap AM antenna into stand,
then plug antenna cable into
socket on back of Ti72. Move
antenna 12”away.
NOTE: If you do not have an
insert for your iPod, please call
timex toll free at 800-888-4491
to purchase one.
thin iPod with video (30 GB)
Insert 9
thin (30 GB) iPod with video
thin (80 GB) iPod classic
nano 4G
Insert 17
nano 4G
Use this insert
For this iPod
iPod touch 2G
Insert 16
iPod touch 2G
3:inserts
4:iPod 5:radio
Press the Mode button until AM
or FM frequency appears in the
lower part of the display. Turn
the Tuning dial to tune in a
station.
5:radio
Insert an iPod into the dock with
proper insert (iPod must not be in
a skin or case). The iPod will
charge while docked. Press the
Button on the Ti72 to play your
iPod.
MP3-IN
AMANTENNA
DST
+1 -1
TIME
TIME ZONE
2:antenna
MP3-IN
AMANTENNA
DST
+1 -1
TIME
TIME ZONE
1:power

2
Controls and Indicators
Rear Panel
Top Panel
Snooze/Dimmer Button
Alarm 1 Button
Mode Button
ReverseButton Forward Button
Dock
DST switch
AM loop antenna socket
MP3 Line-in Jack
FM Antenna
Sleep Button
Alarm Reset / Power Button
Volume – Button
Volume + Button
Alarm 2 Button
Tuning Dial
Play/Pause Button
SNOOZE/DIMMER
MODE SLEEP
ALM RESET
MP3-IN AM ANTENNA
DST
+1 -1
TIMETIME ZONE
Time Zone Button
Time Button

3
Ti72 display
Installing Clock Backup Batteries
Installing iPod Insert
The Ti72 uses 2 AA batteries (installed) for backup to provide continuous alarm operation and clock settings in the event of a
power failure. If the backup batteries have been installed and a power failure occurs or if the AC cord is accidentally disconnected,
the display backlight will not remain lit, but current time and alarm time settings will be temporarily maintained. Otherwise, you
must reset the time and alarm settings.
Note: You should replace backup batteries when the Battery Low Indicator appears on the display.
1. Please make sure the AC cord is connected. Otherwise all settings may be lost during battery replacement.
2. Open backup battery compartment door located on the bottom of the unit.
3. Insert two “AA” batteries, checking the + and – ends of the batteries. We recommend
to use alkaline battery for longer life time. Do not mix alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium) batteries.
4. Close the compartment cover.
Note: Make sure you dispose of batteries properly (see your local regulations).
Battery Low Indicator
The Battery Low Indicator is located in the top of display. When it lights up it is time to
replace backup batteries.
Your Ti72 comes with 3 inserts to ensure your iPod fits properly in the dock on the top of the system. If the inserts that come
with the unit do not match your iPod model, use the insert that came with your iPod or visit www.timexaudio.com or call
1-800-888-4491 toll free to purchase the proper insert for your iPod model.
To place an insert:
1. Select the insert for your iPod. Using the correct insert ensures the proper fit to your iPod.
2. Gently press the iPod insert into the dock.
3. Carefully place your iPod into the dock. The iPod must not be in a case or “skin”.
4.
To remove/replace an insert, first remove your iPod then press down the insert latch, grip the insert and pull gently upwards.
Alarm 1, Alarm 2 Indicators
Battery Low Indicator
Time Display
PM Indicator
Alarm time PM Indicator
DST indicator
AM/FM Indicator
iPod Indicator
Sleep Indicator
MP3 Indicator
Radio/Alarm Time/Date Display
Year/Date Indicator

4
Using the Ti72
This unit is a PRESET Clock/Radio; the clock is already preset at the factory. You just need to set the time zone for your
location.
1. Depending on your location and whether or not Daylight Saving Time (DST) is in effect, set the DST Switch located on
the back of the unit to +1 to add an hour or to -1 subtract an hour.
2. Press and hold the Time Zone Button located on the back of the unit the Time Zone Indicator at the lower part of the
display flashes the current time zone. Press the << or >> Button to select your time zone.
3. Press Time Zone Button again (or no button within 10 seconds) to exit the setting mode.
4. If the time showing is not correct, please see Setting Time and Calendar to set the clock.
Setting Time and Calendar
1. Press and hold the Time Button located on the back of the unit until the time blinks on the display.
Press the << or >> Button to adjust to correct time (holding the button for few seconds to advance or reverse rapidly).
2. Remember to set the correct AM or PM time. A PM Indicator appears to the right side of the time digits; there is
no AM indicator.
3. Press the Time Button again. The year will blink. Press the << or >> Button until the current year is displayed.
4. Press the Time Button again to adjust month and date. Press the << or >> Button until the current month/date is
displayed. Hold the button for a few seconds to advance or reverse rapidly.
5. Press the Time Button again (or no button within 10 seconds) to exit the setting mode.
Using the Alarms
Setting the Alarms
1. Press and hold the Button until the display flashes. Press the << or >> Button to set the alarm time. Remember to
set the correct AM or PM time. Press the Alarm 1 Button to confirm alarm time.
2. Press the MODE Button to select iPod, AM radio, FM radio or Nature sounds to wake to (if AUX is selected, you will
wake to buzzer). Set the volume to the level you wish to wake to.
Press the Button to exit alarm time setting.
3. Once Nature sounds is selected as the wake to source, the display will show “Sd1” (sound 1). Press the << or >> Button
to select the Nature sound you wish to wake to.
4. To set Alarm 2 just repeat step 1 and 3 about but using Button.
5. If you select iPod as the alarm source but no iPod is docked/detected, the Ti72 will default to the buzzer alarm.
Note: make sure you have an hour of audio on your iPod.
Review, Arming and Disarming Alarm (Turn Alarm Function On and Off)
1. Once alarm is set, it is armed and the lower part of the display will show the alarm time. If both alarms are armed, the
earliest alarm time will show.
2. To arm/disarm an alarm, just press the related alarm button to toggle it on or off. If the alarm is armed, the related alarm
icon will light up.
Resetting the Alarm to Come on the Next Day
1. When the alarm is sounding, press the Button to stop the alarm and reset it to come on the following day at the
same time.

5
Using the Ti72
Snooze Opeartion
1. Press and hold the Snooze/Dimmer Button for a few seconds to set snooze time. Press the << or >> Button to set
the snooze timer from 1 to 29 minutes.
2. Press the Snooze/Dimmer Button when the alarm sounds. The alarm will be silenced and come on again after the set
snooze time. Snooze can be pressed several times during the 1 hour alarm cycle.
Sure Alarm
The Ti72 has a sure alarm feature. If backup batteries are installed, the buzzer alarm will still sound in the event of power
failure.
Charging your iPod
Note: Please make sure you are using the correct insert for your iPod (see Installing iPod Insert) and that the iPod is properly
docked into the Ti72. Failure to do so may damage your iPod.
1. While your iPod is docked in the unit and the unit is connected to AC power, it recharges (until fully charged). Note that
other non-docking iPods will NOT charge.
Listening to iPod
1. Dock the already playing iPod. The Ti72 will automatically turn on and you will hear the music playing from your iPod.
Note: If the volume on the playing track is too low, the Ti72 may not detect that your iPod is in play mode. If this happens,
press the Button on the main unit to play it.
2. When the iPod is docked and in standby mode, press the Button on main unit to play it. The Icon will appear on
the display, showing iPod playing mode.
3. Press the Button again to pause play; press again to resume it.
4. Press the or Button to adjust the system volume.
5. Press the >> or << Button on main unit to go to the next or previous track. Press and hold while a track is playing for
high speed forward or reverse music search of the current track.
6. To turn off the unit, press the Button. The iPod will continue charging while in the dock.
Listening to non-docking iPod or other portable audio devices
If you are using an iPod without a docking port or another MP3 player or portable audio device, you can play it through the
Ti72 via the MP3 Line-in Jack.
1. Plug one end of the audio patch cord (not included) into the headphone or line-out jack on your device and the other
end of the patch cord into the Ti72 MP3 Line-in Jack, located on the back of the unit.
2. Press the Button to turn the Ti72 on.
3. Press the MODE Button until the Icon appears.
4. Turn on and play your device.
5. Press the or Button to adjust the system volume. You may need to adjust your device volume, too.
6. To turn off the unit, press the Button. Please remember to turn off your device, too.

6
Using the Ti72
Listening to Radio
Setting up Antenna
1. Snap the AM antenna cable into AM Antenna Socket on the back of the unit. Move the antenna 12” away from the unit
for best reception.
2. Extend FM wire antenna fully for best reception. Do not strip, alter or attach to other antennas.
Tuning and Playing the Radio
1. Press the Button to turn on the Ti72.
2. Press the MODE button until AM or FM frequency appears in the lower part of the display.
3. Turn the tuning dial to tune the radio to a desired station. The current radio frequency will show in the lower part of the
display.
4. Press the or Button to adjust the system volume.
5. To turn off the unit, press the Button.
Listening to Bedtime Beats or Nature Sounds
1. Press the Button to turn on the Ti72.
2. Press the MODE button until the desired Nature sound (Sd1 = wind chimes, Sd2 = birds, Sd3 = ocean surf, Sd4 =
brook) or Bedtime Beat (bb1 = classical, bb2 = jazz, bb3 = new age, bb4 = selections from beats 1-3) appears in the
lower part of the display.
3. Press the << or >> Button to select the sound. Press the or Button to adjust the system volume.
4. To turn off the unit, press the Button.
Sleep Operation
Sleep mode lets you sleep to your iPod, radio, or Bedtime beats, gradually lowering the volume until the unit shuts off at a
selected time.
1. Press the SLEEP Button to enter sleep mode. The Sleep Icon will appear on the display to indicate it is sleep mode.
2. You can adjust the sleep timer from 90, 60, 30 or 15 minutes (or OFF) by pressing the button again.
3. When the display changes back to show the real time, press the SLEEP Button once to show the sleep time remaining.
Pressing it again will change the sleep time to the next lowest increment.
4. Ti72 has an independent volume setting for sleep mode so you can adjust the sleeping volume without affecting the
alarm volume. Press the or Button on the main unit to adjust the sleep volume. The sleep volume will remain at
that level the next time you enter sleep mode (until you change it).
5. To stop listening at any time, press the Button.
Dimmer Operation
During normal operation, press the Snooze/Dimmer Button to control the brightness of the LCD display.

Pressing Play/Pause from power off mode will play iPod.
Pressing Play/Pause while iPod is docked and playing will pause iPod.
Press again to resume play.
Pressing FWD/REW while iPod inserted will FWD/REV to next/previous track
Pressing and holding FWD/REV while iPod is docked will scan forward/reverse
within currently playing track.
Volume Buttons raise and lower volume on the unit.
Pressing Sleep Button will select an amount of time before the Ti72 shuts off:
90, 60, 30 or 15 minutes (OFF shuts unit off)
Pressing the mute button will mute unit.
Snooze/Dimmer Button snooze mode when alarm sounds, otherwise dims display
Installing/Replacing the Remote Control Battery
The remote control battery is already installed at the factory. When the remote control
stops operating or its range seems reduced, it is time to replace the battery with a
new one.
1. The battery door is located on the back end of the remote.
2. Slide the battery door open and remove old battery.
3. Insert a CR2032 battery, checking that the + and – sides of the battery
match the drawing inside the battery compartment.
4. Replace the battery door.
Note: Make sure you dispose of all batteries properly (see your local regulations).
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Power Button turns unit ON and OFF or resets alarm when alarm is sounding
7
Using the Optional Remote Control
Remote not included
with all Ti72
models.
To order a remote,
please visit
www.timexaudio.com
Install Remote Control Battery

8
Trouble Shooting
Unit doesn’t
respond
(no power)
iPod does not
dock properly
iPod does not
respond to the
unit
iPod doesn’t
charge up
Sound is distorted
Remote Control
doesn’t work
Wall outlet is not functioning
Using no or wrong iPod insert
Possible ProblemSymptom Solution
iPod is not docked properly
Your iPod software is too old
iPod is locked up
iPod is not docked properly
Using 3rd generation iPod
iPod is locked up/frozen
iPod battery has problem
Volume level is set too high
Sound source is distorted
Remote Battery is weak
Remote Control is out of range of
the Ti72 remote sensor
Plug another device into the same outlet to
confirm the outlet is working
Make sure the dock insert is the proper one for your iPod
Remove your iPod from the dock and check for
obstruction on the connectors in the dock and on your
iPod. Then reseat it in the dock.
Remove your iPod from the dock and check for
obstruction on the connectors in the dock and on your
iPod. Then reseat it in the dock.
Upgrade software on your iPod via iTunes
Please refer to your iPod manual for details.Please make
sure your iPod is working properly before docking in
the unit.
Remove your iPod from the dock and check for
obstruction on the connectors in the dock and on your
iPod. Then reseat it in the dock.
Ti72 doesn’t support 3rd generation iPod
Please refer to your iPod manual for details. Please make
sure your iPod is working properly before dock into the unit.
If iPod original sound source is poor quality, distortion and
noise are easily noticed with high-power speakers.
Try a different audio source such as a music CD.
Replace with new remote battery
Move closer to the unit.
If you are using an iPod Shuffle or external sound source
like older generation iPod, try reducing the output volume
on the device itself. Also, try reducing bass.
Dock or connector is obstructed
Decrease the volume.

Timex Audio Products, a division of SDI Technologies Inc. (hereafter referred to as SDI Technologies), warrants this product to be free
from defects in workmanship and materials, under normal use and conditions, for a period of 90 days from the date of original purchase.
Should service be required by reason of any defect or malfunction during the warranty period, SDI Technologies will repair or, at its
discretion, replace this product without charge (except for a $10.00 charge for handling, packing, return UPS/postage, and insurance).
This decision is subject to verification of the defect or malfunction upon delivery of this product to the Factory Service Center listed below.
The product must include proof of purchase, including date of purchase. The fee for service after the warranty period or without proof of
purchase is $30.00.
Before returning this product for service, please first replace the batteries (if applicable) with fresh ones, as exhausted or defective batteries
are the most common cause of problems encountered.
If service is still required:
1. Remove batteries (if applicable) and pack the unit in a well-padded, heavy corrugated box.
2. Enclose a photocopy of your sales receipt, credit card statement, or other proof of the date of purchase.
3. Enclose a check or money order payable to the order of SDI Technologies, Inc. for the sum of $10.00 (or $30.00 if after the warranty
period or without proof of purchase).
4. Send the unit prepaid to the Factory Service Center listed below:
Consumer Repair Department
SDI Technologies Inc.
Timex Audio Products Division
1330 Goodyear Drive
El Paso TX 79936-6420
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products which
have been damaged by negligence, misuse or accident, or which have been modified or repaired by unauthorized persons; (ii) cracked
or broken cabinets, or units damaged by excessive heat; (iii) damage to tape cassettes (if applicable); (iv) the cost of shipping this product
to the Factory Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product subsequent to the original
purchaser. Any applicable implied warranties are also limited to 90 days, and SDI Technologies will not be liable for consequential damages.
(Some states do not allow limitations on implied warranties or exclusion of consequential damages, so these restrictions may not apply
to you.) This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
© 2008 SDI Technologies, Inc. All rights reserved
TIMEX is a registered trademark of Timex Corporation the United States and other countries
Ti72IB-112808-A Printed in China
Limited 90 day Warranty Information
