Timtech MP5000S User manual

MP5000S User Guide
Product overview
MP5000S is a light weight universal rechargeable battery, you can enjoy hours of
extended time on mobile phone, iPhone/iPad/ iPod, Samsung Galaxy, PDA, PSP,
GPS, blackberry and other portable consumer electronic products. With
MP5000S, making it a versatile solution for the power needs of mobile products
in any time anywhere.
Specification
Weight：135 g
Dimension：121mm(L)*32mm(W)*22.5mm(H)
Cell style：Li-polymer
Capacity：5000mAh
USB OUT port’s voltage/current: 5.2V/2.1A;
Apple 30 pin Connector’s voltage/current: 5.2V/2.1A;
Male Micro USB OUT Connector’s voltage/current: 5.2V/2.1A;
Micro USB Charging in port’s voltage/current：5V/0.3~0.9A
Charging time：5h~ 8h
Battery power：18.5Wh
Standard package
1. MP5000S main body
2. USB to Micro USB output cable
3. Samsung Galaxy tip
Illustration description
1. Capacity Display Touched key
2. Capacity Indicated LED
3. Micro USB Charging in port
4-2 USB OUT port
4-1 Apple 30 pin Connector
4-3 Male Micro USB OUT Connector

1. Capacity Display Touched key：
The Capacity Indicated LED will be display capacity state while contact the
Capacity Display Touched key by your finger.
2. Capacity Indicated LED：There are three different colors (blue & pink & orange)
to indicate the capacity status.
3. Micro USB Charging in port：
Charge for MP5000S by attached cable to plug in this Port; the charging
voltage /current：5V/0.3 ~0.9A.Smart charging input current varies from 0.3A
to 0.9A . It will depend on the charger’s output driving current capability to
modify it . The charged timing will be shortened if charger’s output current as
larger as well .
4. Three Output ports: The total output current of 3 output ports can’t be over
2.1A while application which more than one output.
1) Apple 30 pin Connector:
The Apple 30 pin Connector can directly plug in iPad / iPhone / iPod without
charging cable. It is setting fast charging for iPad / iPhone / iPod, the iPad 2
can be charged into 25% fully capacity or iPhone 4S can be charged into 70%
fully capacity within 1hour;
2) USB OUT port:
The USB OUT port is setting fast charging for Samsung Galaxy ..Tablet PC ,
Motorola ,Sony ,Nokia , HTC, Black Berry …mobile phone by original
charging cable or attached cable ; it also can slow charging (500mA) for
iPhone / iPod by Apple 30 pin charging cable . But iPad can’t be charged by
this port.
3) Male Micro USB OUT Connector:
TheMaleMicroUSBOUTConnector can directly plug in Kindle Fire or
Smart phone (Motorola, Sony ,Nokia , HTC, Black Berry …mobile phone)
for fast charging without charging cable .
Turn light Capacity of charging Capacity of discharging
Orange color 0%~30% 10%~ 0%
Pink color 30%~80% 70%~10%
Blue color 80% ~100% 100%~70%

5. Each of three output ports of MP5000S will auto turn ON while theApple
30 pin Connector or Male Micro USB OUT Connector plug in loading device
directly or the USB OUT port connected with loading device by the charging
cable. Its power will turn OFF automatically after 30 sec while the Apple 30
pin Connector or Male Micro USB OUT Connector unplug from the loading
device or the USB OUT port disconnected with loading device by unplug
charging cable , which can save the power when it idle.
How to use:
1. Charging for MP5000S:
2. Charging for your device by MP5000S:
a. Charging for iPad/iPhone/iPod by Apple 30 pin Connector
Apple 30 pin Connector plug
in iPad/iPhone/iPod directly
Plug in Micro USB
charging in port
The Charger with
USB OUT port
Charging by attached
USB to Micro USB
output cable

b. Charging for Samsung Galaxy….Tablet PC from USB OUT port by
attached USB to Micro USB output cable & Samsung Galaxy tip :
c. Charging for Kindle Fire or Smart phone (Motorola, Sony ,Nokia ,
HTC, Black Berry …mobile phone) by Male Micro USB OUT
Connector:
Male Micro USB OUT Connector plug in
Kindle Fire or Smart phone directly charging
Plug in USB OUT port
Samsung Galaxy tip
Charging by attached
USB to Micro USB
output cable

Troubleshooting
Please use the following steps if MP5000S can not charge for your device.
1. Verify that MP5000S has been completely charged.
2. Check that the USB charging cable is connected well with MP5000S main
body, and check whether the tip is suitable for the power socket of your
device, if not, please replace another tip.
3. Check your the digital device is installed the battery（Some digital device
can not work if not installed battery）
4. Check whether your digital device is designed with charging input voltage
limited circuit, if so, MP5000S maybe can not charge and power for the
device.
Warranty
Your MP5000S is guaranteed against original defects in materials,
manufacture and workmanship for one year from the date of purchase.
