Tinytots Optimo Complete User manual

INSTRUCTION
MANUAL
www.tinytotsonline.co.uk
OPTIMO COMPLETE
Travel System by Tinytots
Please keep this manual in a safe place for future reference
Scan the code to get this
manual on your mobile

Dear Parent,
Congratulations on your purchase of the Tinytots ™ Optimo
Complete Travel System.
While designing the Optimo, safety, comfort and usability played a
significant part. As a result this product meets the strictest safety
requirements.
Our research has indicated that in a high percentage of cases where
accidents have occurred, the safety guidelines for use of the
product were not followed. The safety of your child is your highest
priority. Therefore kindly spend some time reading through this
manual very carefully.
We are constantly striving to exceed the latest safety requirements
set by the governing bodies. If you have any questions or concerns,
please do not hesitate to contact us. Our contact information can
be found on our website www.tinytotsonline.co.uk.
Regards,
Tinytots Customer Relations
WELCOME

1
•It is dangerous to leave your child unattended in the Tinytots Optimo.
•Do not stand on the axles between the wheels. This is unsafe and could damage
the Tinytots Optimo.
•The child seat attachment is not suitable for children under 6 months.
•Do not add a mattress thicker than 10 mm in the carrycot.
•Do not change the position of the seat when the child is in the seat.
•Keep the Tinytots Optimo away from open flames and other heat sources such as
electrical or gas heaters etc.
•Do not use the Tinytots Optimo if any part is broken, torn or missing.
•Every weight attached to the handlebar will have a negative impact on the
stability of the Tinytots Optimo.
•This product is not suitable for running or skating.
•Ensure that all locking devices are engaged before use.
•Check that the carrycot body or seat unit attachment is correctly installed before
use.
•Never pick up the Tinytots Optimo by the carry handle while your child is lying or
sitting in the carrycot or seat.
•Do not let other children play unattended near the carrycot.
•The carrycot is only suitable for a child who cannot sit up unaided.
•YOUR CHILD’S SAFETY IS YOUR RESPONSIBILITY. Children should be harnessed in
at all times and should never be left unattended.
•The child should be clear of moving parts while making adjustments.
•This vehicle requires regular maintenance by the user. Failure to keep up the
maintenance will shorten the life of your Tinytots Optimo.
DO NOT EXCEED THE MAXIMUM USER CRITERIA DEFINED BELOW OR SERIOUS
INJURY MAY RESULT
Age
Weight/Height
Car seat
0 - 12 months
Max 13kg/66cm(26in)
Carrycot
0 - 6 months
Max 9kg/78cm(30in)
Child Seat
6 - 36 months
Max 17kg
WARNINGS

Table of Contents
INSIDE THE BOX ........................................................................................................ 3
ASSEMBLING FOR THE FIRST TIME ............................................................................4
FOLDING AND UNFOLDING ....................................................................................... 6
USING THE CHILD SEAT WITH THE OPTIMO FRAME .................................................. 7
INSTALLING THE CARRYCOT ON THE OPTIMO FRAME............................................. 10
ADJUSTING THE HANDLE AND SEAT RECLINE POSITION.......................................... 13
PUTTING YOUR CHILD IN THE CHILD SEAT............................................................... 14
USING THE CAR SEAT WITH THE OPTIMO FRAME ................................................... 16
INSTALLING THE CAR SEAT INSIDE THE CAR ............................................................ 18
USING THE COSY TOES ............................................................................................ 20
USING THE WINTER BAG AND UMBRELLA............................................................... 21
MAINTENANCE........................................................................................................ 22
ACCESSORIES .......................................................................................................... 23
WARRANTY ............................................................................................................. 24
IMPORTANT WARNINGS ......................................................................................... 26
TABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTS

3
CHECK THAT YOU HAVE RECEIVED THE FOLLOWING IN THE BOX
1 chassis with handlebar
2 front swivel wheels
2 large rear wheels
1 aluminium frame (for child seat and carrycot)
1 rear wheel mounting frame with brakes
1 under seat basket
1 bumper bar
1 base carrycot fabric with base plate
1 carrycot mattress
1 carrycot tailored apron
1 child seat fabric with safety belts
1 fabric hood for carrycot/child seat
1 car seat
1 car seat fabric hood
2 car seat adapters
1 changing bag
1 cup holder
1 cosy toes
1 rain cover
1 umbrella and clip
1 user guide
1 Optimo assembly and demonstration DVD
INSIDE THE BOX

4
1. If the handle is folded down, press
the big round buttons at both ends
of the handle simultaneously and
adjust the height. Then release the
lock near the right rear wheel.
2. Move the rear handle in an upward
direction until the frame erects
completely and locks.
3. Take the black brakes bracket and
insert the two sides of the brakes
into the metal frame of the Optimo
as shown in the picture. Push until
the spring locks on the Optimo
frame are engaged properly,
holding the brakes bracket into
place.
ASSEMBLING FOR THE FIRST TIME

5
4. Take the bigger rear wheel and
insert it into the side of the brake
frame. Press and hold the button at
the centre of the wheel while
pushing the wheel gently into the
frame. Release the button and
make sure the wheel is securely
attached. Repeat this step for the
other rear wheel.
5. Insert the smaller front wheel into
the hole facing downward at the
front of your Optimo while
pressing the silver button on the
inside of the Optimo frame. When
the wheel is fully in, release the
button to secure the wheel. Repeat
this step for the other front wheel.
Look through the rest of this
manual to assemble and attach the
seat of your choice or the carrycot.
ASSEMBLING FOR THE FIRST TIME

6
1. To collapse your Optimo, locate
release locks ‘A’ and ‘B’. Press and
keep hold of the button underneath
lock ‘A’ while pulling locks ‘A’ and
‘B’ towards you simultaneously.
2. Apply a little downward force on
the handle bar when the frame is
unlocked.
3. Make sure the front wheels are
facing inwards so it is easier to lock
your Optimo.
4. Press down gently until the lock on
the side of the Optimo is engaged
automatically. To fold the handle
bar, press and keep hold of the two
big buttons on the side of the
handle bar simultaneously and
press the handle bar down. Release
the buttons when the desired
position is reached.
To unfold the Optimo, follow steps
1 and 2 in the previous section
‘ASSEMBLING FOR THE FIRST TIME’.
FOLDING AND UNFOLDING

7
1. Attach the bumper bar to the
frame ensuring it locks with a CLICK
on each side.
2. One side of the seat canvas has a
pocket behind it which goes over
the seat frame. Make sure you
cover the side of the frame that
does not have the studs sticking
out, as the side with the studs will
be at the lower part of the seat as
shown in step 3 below.
3. Secure the seat by locking the
holes in the belts over the studs on
the side of the frame. Make sure
the belts on both sides are
attached. Some force will be
required to lock the second belt. It
is normal and ensures the safety
and comfort of your child.
USING THE CHILD SEAT WITH THE
OPTIMO FRAME

8
4. Tie the belts at the back of the seat
as shown in the picture so the belts
are neatly tucked away.
5. At the foot side of the seat, locate
the 3 Velcro straps and tie them
around the metal frame to provide
maximum support.
6. To attach the seat, simply place the
holes in the seat frame over the
vertical metal bars in your Optimo
frame and press down on the
bumper bar gently. Make sure both
sides lock with a ‘CLICK’ sound.
USING THE CHILD SEAT WITH THE
OPTIMO FRAME

9
7. Attach the fabric sun hood to the
frame by clipping it to the frame on
the left and right side. Your seat is
now ready to use.
8. To release the child seat from the
Optimo frame, press the release
locks on the left and right side of
the seat. You can now lift up the
child seat.
USING THE CHILD SEAT WITH THE
OPTIMO FRAME

10
1. Locate the seat frame and put it on
an even surface. Remove the
bumper bar for the next step.
NOTE: Your Optimo will come with the carrycot already attached to the seat
frame. You should use this carrycot from birth until your child starts to sit up
unassisted, usually at 6 months of age. At this age, remove the carrycot and
attach the seat unit. Follow the procedure below to remount the carrycot when
required. Alternatively, you may order an additional mounting frame if you
wish to interchange between the seat and carrycot attachments frequently.
2. Locate the 4 fabric ends at the middle of the soft carrycot (labelled 1,2,3
and 4 in the picture). Find the grooves on the inside of the metal frame
(see picture inset). Now put end 1into groove aand end 3into groove cin
an anti-clockwise direction as illustrated by the arrows in the picture above.
INSTALLING THE CARRYCOT ON
THE OPTIMO FRAME

11
3. Alternate between pushing the two
fabric ends in an anti-clockwise
direction. When pushing, grab the
top of the fabric about 10cm away
from where the groove starts and
push it into the groove.
4. Once the fabric ends reach the
other side of the frame to where
they started, your carrycot will be
fully attached.
5. Insert the carrycot base and the
carrycot mattress into the carrycot.
INSTALLING THE CARRYCOT ON
THE OPTIMO FRAME

12
6. Attach the carrycot hood by
clipping it to the frame on the left
and the right side.
7. Attach the carrycot apron. Start
with both the fasteners (zippers)
on the left side of the carrycot.
Insert the left end of the apron
through both zippers. Fasten the
first zipper from left to right (anti-
clockwise motion). Your apron is
now fixed to the carrycot. Attach
the bumper bar making sure it
locks into place on both ends.
Serious injury can be caused to
your child if the bumper bar is not
properly attached.
8. To remove the carrycot from the
Optimo frame, press the left and
right release button. Then simply
lift up the carrycot.
INSTALLING THE CARRYCOT ON
THE OPTIMO FRAME

13
1. Locate the handle release buttons
on each side of the Optimo as
displayed in picture 1.
2. Press in both buttons at the same
time and adjust the handle height
upwards or downwards as
required. Once you are happy with
the height, you can release the
buttons.
3. To adjust the seat recline position,
locate the black recline adjustment
button on each side of the seat.
Press and hold both the buttons
simultaneously and adjust the
recline position. Release the
buttons once the desired recline
position is reached. The seat can
lock at 45, 60, 75 and 90 degrees.
NOTE: When using the carrycot
accessory, ensure the recline
position is set to 90 degrees (fully
flat position).
ADJUSTING THE HANDLE AND
SEAT RECLINE POSITION

14
1. Before putting your child into the
Tinytots Optimo, engage the foot
brake.
2. It is recommended to lock the front
wheels as well, especially if the
ground is uneven. To lock the front
wheels, make sure they are
pointing directly backwards and
press down on the button just
above the wheel.
TIP: The front side of the wheel has
the longer mud guard. Ensure this
side is facing to the back when
locking the wheels.
3. Before putting the child into the
seat for the first time, undo the
two hooks to separate the bottom
part of the harness from the top
part.
PUTTING YOUR CHILD IN THE
CHILD SEAT

15
4. Put the child into the seat and
engage the safety lock on the
harness. You should hear a ‘CLICK’
sound. This ensures the safety lock
is engaged properly. Clip back the
hooks if they were removed in the
previous step.
5. Adjust the belts of the safety
harness to ensure the child is held
securely. Ensure the child will not
slide out. Do not over-tighten the
belts as the child should be able to
maintain a natural posture.
PUTTING YOUR CHILD IN THE
CHILD SEAT

16
1. Attach the car seat hood to the car
seat. To do this, locate the locking
clips to the left and right side of the
hood and slide them in from the
top into the mounts either side of
the car seat. A firm push is needed
for a proper lock.
2. To install the car seat, locate the
two supplied car seat adapters.
Insert them into each side of the
car seat as displayed in the picture,
ensuring a ‘CLICK’ sound is made
when they lock in place. An
adapter will only fit on one of the
two sides, so do not try to force it
into place.
3. The car seat can be installed as
forward or rear facing. Locate the
two seat mounting points on the
frame, and lower the seat slowly
making sure the mounting points
align with the car seat adapters.
Gently push the car seat down until
a ‘CLICK’ locking sound is heard
from each side.
USING THE CAR SEAT WITH THE
OPTIMO FRAME

17
4. You can adjust the carry handle
height by pressing and holding the
red buttons each side of the handle
and releasing once the desired
carry handle position is reached.
5. To release the car seat, locate the
left and right release locks and
push them in the direction
indicated.
6. If you need to release the car seat
adapters for storage or
replacement, press the red buttons
located on each side of the car seat
to release the adapters. These
buttons may be hidden from view
under the car seat fabric.
USING THE CAR SEAT WITH THE
OPTIMO FRAME
