Tisbury Audio MINI PASSIVE User manual

TISBURY AUDIO
MINI PASSIVE PREAMPLIFIER
Caring for the wood:
With proper care, the wooden enclosure will last a
lifetime. To ensure it stays in perfect condition, do not
place near any heat source or on top of any hot
equipment. Avoid leaving in direct sunlight, or in
excessively dry or humid environments for long periods
of time.
Warranty:
The Mini Passive Preamp is covered by a two year limited
warranty for materials and workmanship.For more details,
please visit www.tisburyaudio.co.uk/terms
Contact:
General Enquiries: [email protected]
Website: www.tisburyaudio.co.uk
Address: Tisbury Audio
G21 Olympic House
12 Somerford Grove
London
N16 7RZ
United Kingdom

TISBURY AUDIO
HANDMADE IN ENGLAND
MINI
PASSIVE PREAMPLIFIER
IN OUT
Volume Control
Input Selector
Inputs
Output 1: Variable - level set by volume control
Output 2: See below
1.
2.
3.
4.
5.
Output 2 Settings: Set by switches on base.
Variable: Level set by volume control simultaneously with
Output 1. Provides a second main output for connecting
another amplifier, active subwoofer etc.
Loop: Bypasses the volume control. Use this to loop out to
a headphone amp or other device without adjusting the
volume.
Off: If Output 2 is not needed, set to Off and leave
unconnected. This is not essential, but is good practice to
prevent any stray noise pick up.
Fixed Attenuation: Set by switches on base.
0 dB, -10 dB or -20 dB: Reduces the overall volume by a
fixed amount and lowers the sensitivity of the volume
control. Useful for systems with too much gain.
