Titan Controls Saturn 2 User manual

Saturn™2
Day/Night Temperature, Humidity
& CO2 Integration Controller
Instruction Manual
www.titancontrols.net
www.titancontrols.net
Notes:
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
________________________________________________
1 Square = ____ Foot/Feet
®
VANCOUVER, WASHINGTON U.S.A.
VANCOUVER, WASHINGTON U.S.A.
Revision C – 4/23/2012 © Titan Controls®

Saturn™2
• Warnings&Cautions
• Saturn™2- Day/Night Temperature, Humidity & CO2 Integration Controller Overview
• InstructionsforOperation
• TroubleshootingTips
• ControllerSpecications
• InstallationExample
• WarrantyInformation
•ServiceandRepairProgram
Warnings & Cautions
• Readallinstructionsbeforeoperatingcontroller.
• Donotputyourcontrollerinanareawhereitcangetwetorsprayed.
• Mountyourcontrollersecurelytothewallusinghardwareprovided.
• Whenusing“bugbombs”inarea,covercontrollercompletelytoavoidcorrosion.
• Therearenoserviceablepartsincontroller.Donotattempttorepairtheunit.
• Breakingtamperproofsealwillvoidyourwarranty.
• Donotputpaperclips,tools,etc.intounit.Possibleelectrocutionmayoccur.
• Plugcontrollerintosurgeprotectortoavoidpotentialdamagetotheunit.
• Conrmthatyourpowersourceis120Volts/15Ampspriortopluggingcontrollerintooutlet.
• Checkthatallequipmentthatwillbeactivatedbythiscontrolleristhepropervoltage(s).
• Verifythattheequipmentyouarecontrollingdoesnotexceedatotalof15amps.
• Thiscontrollerisdesignedfor“insideuse”only.
• AvoidplacingthecontrollernearheatgeneratingsourcessuchasaCO2Generatororheater.
• Usecautionifoperatingcontrollerinextremelyhumidenvironments(90%andabove).
• Donotusecontrollerforpurposesotherthantheunitwasdesignedtofunction
• Usecontrollerwithindenedenvironmentalspecications.
• AskyourDealerfortipsandtechniquesregardingtheuseofthiscontroller.
• Beconscientiouswhendisposingofanyproducts.
• EnjoyyourTitanControlsenvironmentalcontrollerforyearstocome!
Saturn™2 Day/Night Temperature,
Humidity & CO2 Integration Controller Overview
TheSaturn™2isintendedforuseinmaintainingthetemperature,humidityandtoprovideCO2
inyourgrowingenvironment.Boththetemperatureandhumiditycanbeadjustedbysetting
thedialsonthefrontofthecontrollertoyourpreferredsettings.Duringthedaytimehoursthe
WARRANTY SERVICE: Please read warranty information first
Ifafterreviewingthetroubleshootingtipstheunitwillstillnotwork,youshouldreturnittothe
Dealerwhereyoupurchasedit.Theymaybeabletofurtherevaluatetheunitandtestitsvarious
componentsandquitepossiblywillbeabletoidentifyand/orxanyproblems.IftheDealeris
unabletoxtheunit,theywillreturnittousforfactoryrepair.
IftherearenoDealersinyourarea,youmaycontactusdirectlyfortechnicalsupport.Ifwe
cannothelpyouresolvetheproblemoverthephone,wewillissueyouaReturnMerchandise
Authorization(RMA)numberauthorizingyoutoreturntheunittousforfactoryreconditioning
(ifthecontrolleriscurrentlyunderwarranty).ContactthenumberbelowforaRMAnumberand
shippingaddress.Pleasecompletetheformbelowandincludeitwithyourunit,andwritethe
RMAnumberclearlyontheoutsideofthebox.
Pleasepackagetheunitinitsoriginalpackaging.Ifitisdamagedinshipmentwecannotbeheld
responsible.Insuringtheparcelisrecommended.
Oncewereceivetheunitback,wewillrepairitwithin48hours(business)andreturnittoyou
freightprepaidviaUPSgroundshipment.
IncludethefollowingifreturningdirectlytoTitanControls®
•Proofofpurchase•Thiscompletedform•RMA#ontheoutsideofthebox
ReturnMerchandiseAuthorizationNumber(Required)____________________________________________
Dealer/Customer’sName:___________________________________________________________________________
Dealer/Customer’sContactName:___________________________________________________________________
ShippingAddress:___________________________________________________________________________________
_____________________________________________________________________________________________________
Phone#:____________________________________________________________________________________________
Emailaddress:_______________________________________________________________________________
What is the nature of the problem? Please provide as much information as possible. ________
____________________________________________________
____________________________________________________
____________________________________________________
____________________________________________________
____________________________________________________
____________________________________________________
Sendtoyournearestlocation–shippingaddresswillbegivenwhentheRMA#isissued.
www.titancontrols.net
For technical assistance call us at 1-888-80-Titan or 1-888-808-4826.
®
CUT HERE

controllerleavesthe‘CO2OUTLET’activeuntilthetemperaturesetpointisexceeded.When
thisoccurs,the‘CO2OUTLET’isdeactivatedandthenthe‘FANOUTLET’isactivated;and
yourexhaustfanwillrununtilthetemperatureislowerthanyourpreferredsetting.After
thetemperaturehasloweredbelowtheselectedtemperaturelevelthe‘FANOUTLET’is
defeatedandthe‘CO2OUTLET’isactivatedandcanbegindosingyourgardenwithCO2
again,ifrequired.Thisinnovativefunctionservestwopurposes:One,thisallowsmaximum
CO2coveragewithminimumCO2waste;Two,yourexhaustfanisworkingonlywhenitis
required-savingpowerandwear&tearonyourgear.Atanytimeifthehumiditysetpointis
exceeded,thecontrollerwillactivatethe‘HUMIDITYOUTLET’andreducethehumiditylevel
tobelowyourpreferredhumiditysetting.Duringthenighttimehoursthecontrollerdefeats
the‘CO2OUTLET’(NoneedforCO2atnight)andactivatesthe‘NIGHTOUTLET’.The
‘NIGHTOUTLET’maybeusedtooperateacirculationfan,CO2exhaustfanusingashort
cycletimer,gardenmaintenancenightlightoranyotherdevicethatyouwouldlikeonlyto
runduringthenighttimehours.Ifduringthenighttimehoursthetemperatureexceedsyour
preferredsetting,thenthe‘FANOUTLET’isactivatedtolowerthetemperaturetodesired
levels.Ifthehumiditysetpointisexceededduringthenighttimehours,thenthe‘HUMIDITY
OUTLET”isactivatedandwilllowerthegardenshumiditytodesiredlevels.Thisprovides
thegrowerwith24hourtemperatureandhumiditycontrol.TheSaturn™2isbuiltwiththe
highestqualitycomponentstoprovidetheuserwithyearsoftroublefreeservice.Controllers
createdforourindustry,byourindustry!
Instructions for Operation
• SecurelymountyourSaturn™2inyourgrowareaandawayfromanymoisture,spray,
pesticides,etc.usingthemountingbracketsandhardwareprovided.
• Plugtheexhaustfanintothe‘FANOUTLET’.
• Turnthefan‘ON’tothehighestsettingpossible,ifadjustable.
• PlugtheCO2Controller(Atlas®SeriesCO2Controller)orarepeatcycletimer(Apollo™
seriestimers)intothe“CO2OUTLET’.Then,plugyourCO2GeneratororCO2Regulator/
TankintotheCO2controllerorrepeatcycletimer(SeeInstallationExamplesectionfor
moreinformation)
• TheintegratedphotocellensuresthattheCO2generatororCO2tankonlyactivatewhen
yourgardenisinthedaytimehours(lightsare‘ON’).ThisiswhenyourplantsuptakeCO2
andcangainthemostbenetsfromenrichingtheenvironmentwithCO2.Topreserve
yourCO2,the‘CO2OUTLET’isautomaticallydisabledwhenyour‘FANOUTLET’isactive
orinyourgarden’snighttimehours.
• Whenthe‘CO2OUTLET’isdisabledduringdaytimehoursbecauseofexcessive
temperature,theventilationprocessbeginsandcontinuesuntilthetemperaturelevelhas
loweredtobelowyourpreferredsettingonthetemperaturedial.Afterthetemperature
dropstobelowthepreferredtemperaturesetting,thenthe‘CO2OUTLET’isreactivated
andresumesnormalfunctioning.
• Plugyourcirculationfan,shortcycletimerforCO2exhaustfan,orgardenmaintenance
nightlightintothe“NIGHTOUTLET’.
• Plugthedehumidierintothe‘HUMIDITYOUTLET’
• Turnthedehumidier‘ON’tothelowestsetting.Thisallowsthecontrollertomaintain
precisecontrolofthehumidityinyourgarden.
• Setthe‘Temperature’and‘Humidity’dialsatthepreferredtemperatureandhumidity
levelsforyourgarden.
Warranty Information
•TitanControls®warrantstheoriginalpurchaseofthisproductagainstdefectsinmaterial
andworkmanshipundernormaluseforthree(3)yearsfromthedateofpurchase.
•Duringthewarrantyperiod,TitanControls®will,atouroption,andwithoutcharge,repairor
replacethisproductifthecontrolleroranyofitscomponentsfailormalfunction.
•AllreturnsorrepairsmustbeaccompaniedbyaReturnMerchandiseAuthorization(RMA)
numberpriortoanyserviceoftheproduct.
•Thiswarrantyisinlieuofallotherwarranties,expressedorimplied,includingthewarranties
ofmerchantabilityandtnessforuse,andofallotherobligationsorliabilitiesonthepartof
theseller.
•Thiswarrantyshallnotapplytothisproductoranypartthereofwhichhadbeendamaged
byaccident,abuse,misuse,modication,negligence,alterationormisapplication.
•Controllerswithserialnumbersordatetagsthathavebeenremoved,alteredorobliterated;
brokensealsthatshowevidenceoftampering;mismatchedboardserialnumbersor
nonconformingparts,areexcludedfromcoverage.
•TitanControls®makesnowarrantywhatsoeverinrespecttoaccessoriesorpartsnot
suppliedbyTitanControls®.
•Monetaryrefundsofthewarrantywillnotbegiven.
•TheBuyerassumesallresponsibilityregardingtheproperuse&installationofthis
controller.
•AllwarrantyserviceisprovidedthroughtheTitanControls®factory.
•ThiswarrantyshallapplyonlytotheUnitedStates,includingAlaska,Hawaiiandterritories
oftheUnitedStates.
•Defectivecontrollersarerequiredtobereturnedwiththe“proofofpurchase/receipt”for
warrantycoverage.
•Foradditionalwarrantyinformation,contacttheTitanControls®TechnicalService
RepresentativeoryourlocalDealer.
•NOTE:TitanControls®isaManufacturerofenvironmental,timing,lighting,ventilationand
CO2controls.Allsalesofferingstothepublicaredonethroughanationwidegroupof
Dealers.Nosalesofferingswillbemadedirectlytothegeneralpublic.
Service and Repair Program
• Forallserviceandrepairs,pleasecontactbyourTechnicalServiceRepresentativefor
troubleshootingyourgearandattainingaReturnMerchandiseAuthorization(RMA)number,
ifapplicable.
• Allfactoryservice&repairswillbecompletedwithin48hoursofreceiptofcontrolleratthe
factory.
• TitanControls®will,atitsdiscretion,repairorreplacethecontroller.
• FactorycalibrationservicesareavailableforallTitanControls®.
• ReturningUnits:Pleasecontactyourretailstoreforinformationregardingreturns.

• Finally,plugtheSaturn™ 2intoadedicated120Volt–15Amppowersource.
• UseofasurgeprotectiondeviceisrecommendedtoprotectyourSaturn™2frompotential
powerdamageinareaswherethismaybeanissue.
• YourSaturn™2willnowcontrolyourequipmentatthedesiredsettings.
Troubleshooting Tips
IftheSaturn™2isnotperformingasexpected,trythefollowing:
a.Conrmthatyourpowerinputsourceisactivebyusingavoltagetestmeter,andverifythat
thepowerinputsourceisproviding120VoltsofpowertotheSaturn™2.
b.ValidatethatthepoweroutletsoftheSaturn™2areactivebysettingthetemperature
andhumiditydialstothelowestsettings.Thenuseavoltagetestmetertoverifypoweris
owingthroughthecontrollertothepoweroutlets.
c.Ensurethattheexhaustfananddehumidierare‘ON’andsettothelowesttemperature
andhumiditylevels.
d.VerifythattheSaturn™2issetatthepropertemperatureandhumiditylevelstoactivate
anddeactivateequipment.
e.Ifyourventilationordehumidicationequipmentdoesnotturnoff,verifythatyourexhaust
fananddehumidierarethecorrectsizeforyourgrowarea.Increasesizeofexhaustfanor
dehumidier(ifnecessary)tocoolanddehumidifythegardenasquicklyaspossible.
f. IfyouarestillhavingproblemswithyourSaturn™2,pleasecontactourTechnicalService
Representativeat888-808-4826toassistyoufurther.
Controller Specifications:
• Size=8”Hx6”Wx4”D
• Weight=3lbs.
• InputVoltage=120Volts/AC
• OutputVoltage=120Volts/AC
• MaximumAmperage=15Amps
• OperatingHertz=60Hz
• Minimum/MaximumHumidityControlLevels=20%to80%(non-condensing)
• HumidityAccuracy=±5%ofdesiredsetting
• Minimum/MaximumTemperatureControlLevels=40°to100°F(5°Cto38°C)
• TemperatureAccuracy=±3°Fofdesiredsetting
• Cordset=8feet-14/3SWJ
• StorageTemperature=32°to135°F(0to58°C)
• OperatingTemperature=45°to95°F(7to35°C)
Installation Example
