netvox R718A User manual

Mode：R718A
Temperature and Humidity Sensor for Low Temperature Environment
Temperature and Humidity Sensor for Low Temperature
Environment
R718A
User Manual

1
Table of Content
1. Introduction..............................................................................................................................................................2
2. Appearance...............................................................................................................................................................3
3. Main Features...........................................................................................................................................................3
4.Set up Instruction......................................................................................................................................................4
4.1 Power on and Turn on / off ............................................................................................................................4
4.2 Join Into Lora Network..................................................................................................................................4
4.3 Function Key..................................................................................................................................................4
4.4 Data Report....................................................................................................................................................5
5. Restore to Factory Setting........................................................................................................................................5
6. Sleeping Mode.........................................................................................................................................................5
7. Low Voltage Alarming.............................................................................................................................................6
8. MyDevice Dashboard Demonstration......................................................................................................................6
9. Installation................................................................................................................................................................6
10. Important Maintenance Instruction........................................................................................................................7

2
1. Introduction
R718A, mainly used to detect the temperature and humidity at low temperature environment such as
the freezer air. It collects data over LoRa network and sends it to devices to be shown, fully
compatible with LoRa protocol.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power
consumption. Compared with other communication methods, LoRa spread spectrum modulation
method greatly increases to expand the communication distance. Widely used in long-distance,
low-data wireless communications. For example, automatic meter reading, building automation
equipment, wireless security systems, industrial monitoring. Main features include small size, low
power consumption, transmission distance, anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure
interoperability between devices and gateways from different manufacturers.

3
2. Appearance
Fig.1 R718 Appearance
3. Main Features
⚫Compatible with LoRa protocol.
⚫2 x 3.6V ER14505 AA lithium batteries（3.6V/ section）
⚫Capable to detect the ambient temperature and humidity
⚫Simple and easy installation

4
4.Set up Instruction
4.1 Power on and Turn on / off
(1) Power on: open the battery cover; insert two sections of 3.6V ER14505 AA lithium batteries and
close the battery cover.
(2) Turn on: the device (not in the network) is at off mode by default after inserting batteries. At this
time, press and hold the function key (about 3 seconds) till the green light flashes once. The boot is
successful.
(3) Turn off: press and hold function key for 5 seconds till the green indicator flashes quickly and
release. The green indicator will flash 20 times to show that R718A is turned off.
Note:
1. The interval between shutting down twice or power off/on is suggested to be about 10 seconds to
avoid the interference of capacitor inductance and other energy storage components.
2. Do not press function key and insert batteries in the same time, otherwise, it will enter engineer
testing mode.
3. Each time the battery is removed and inserted, it will be at off mode by default and users need to
turn it on again.
4.2 Join Into Lora Network
To join R718A into LoRa network to communicate with LoRa gateway.
The network operation is as following:
(1) If R718A had never joined any network, turn on the device; it will search an available LoRa
network to join. The green indicator will stay on for 5 seconds to show it joins into the network,
otherwise, the green indicator will be off.
(2) If R718A had been joined into a LoRa network, remove and insert the batteries; it will repeat
step (1).
4.3 Function Key
(1) Press and hold function key for 5 seconds to reset to factory setting. After restoring to
factory setting successfully, the green indicator will flashes quickly 20 times.
(2) Press function key to turn on the device which is in the network and the green indicator will flash
once and the device will send a data report. If the device is not in the network, press function key;
the indicator does not work.

5
4.4 Data Report
When the device is turned on, it will immediately send a version package and a data report of
temperature/humidity/voltage.
The device sends data by default setting as below before any configuration.
Temperature default report value: mintime = maxtime = 15 minutes, reportchange = 0x0064 (1 ℃),
Humidity default report value: mintime = maxtime = 15 minutes, reportchange = 0x0064 (1%),
Battery voltage default report value: mintime = maxtime = 15 minutes, reportchange = 0x01 (0.1V).
Note: MinInterval is the sampling period for the Sensor. Sampling period >= MinInterval.
Remarks:
1. The device data sending cycle depends on the burning configuration before shipment.
2. The interval between two reports must be the minimum time.
Data report configuration and sending period are as following:
5. Restore to Factory Setting
R718A saves data including network key information, configuration information, etc. To restore to
factory setting, users need to execute below operations.
1. Press and hold function key for 5 seconds till the green indicator flashes and then release; LED
flashes quickly 20 times.
2. R718A will stay off mode by default setting after restoring to factory setting. Press function key to
turn on R718A and to join a new LoRa network.
Note: The device operation of turning off is the same as the device restore factory settings.
6. Sleeping Mode
R718A is designed to enter sleeping mode for power-saving in some situations:
Min Interval
(Unit:second)
Max Interval
(Unit:second)
Reportable
Change
Current Change≥
Reportable Change
Current Change ＜
Reportable Change
Any number
between 1~65535
Any number
between 1~65535
Can not be 0.
Report
per Min Interval
Report
per Max Interval

6
(A) While the device is in the network →the sleeping period is Min Interval. (During this
period, if the reportchange is larger than setting value, it will wake up and send a data report).
(B) When it is not in the network →R718A will enter sleeping mode and wake up every 15
seconds to search a network to join in the first two minutes. After two minutes, it will wake up
every 15 minutes to request to join the network.
If it’s at (B) status, to prevent this unwanted power consumption, we recommend that users
remove the batteries to power off the device.
7. Low Voltage Alarming
The operating voltage threshold is 3.2V. If the voltage is lower than 3.2V, R718A will not work
normally, in the mean time, it will send a low-power report to the Lora network.
8. MyDevice Dashboard Demonstration
9. Installation
This product comes with waterproof function. When using it, the back of it can be adsorbed on the
iron surface, or the two ends can be fixed to the wall with screws.
Note: To install the battery, use a screwdriver or similar tool to assist in opening the battery cover.

7
10. Important Maintenance Instruction
Your device is a product of superior design and craftsmanship and should be used with care. The
following suggestions will help you use the warranty service effectively.
•Keep the equipment dry. Rain, moisture, and various liquids or moisture may contain minerals
that can corrode electronic circuits. In case the device is wet, please dry it completely.
•Do not use or store in dusty or dirty areas. This can damage its detachable parts and electronic
components.
•Do not store in excessive heat. High temperatures can shorten the life of electronic devices,
destroy batteries, and deform or melt some plastic parts.
•Do not store in a cold place. Otherwise, when the temperature rises to normal temperature,
moisture will form inside, which will destroy the board.
•Do not throw, knock or shake the device. Rough handling of equipment can destroy internal
circuit boards and delicate structures.
•Do not wash with strong chemicals, detergents or strong detergents.
•Do not apply with paint. Smudges can block debris in detachable parts and affect normal
operation.
•Do not throw the battery into a fire to prevent the battery from exploding. Damaged batteries may
also explode.
All of the above suggestions apply equally to your device, battery and accessories. If any device is
not working properly.
Please take it to the nearest authorized service facility for repair.
