Titan TTB653SDS User manual

Original Instructions_TTB653SDS_GB_V3_160614
TTB653SDS
1500W SDS Plus
Rotary Hammer
Barcode: 5052931538713
Ref. No.: 6846H
WARNING: Read the instructions before using the product!
MNL_TTB653SDS_TIT_GB_V02_150819.indd 1 8/19/15 9:47 AM

Congratulations on your purchase of a power tool from
Titan Power Tools (UK) Ltd. We want you to continue getting the
best performance from it so this handbook includes information on
safety, handling and care. Please retain this handbook in case you
need to refer to any of the information in the future.
Your power tool comes with a 2 year guarantee, so should
it develop a fault within this period contact your retailer.
GUARANTEE
This product carries a guarantee of 2 year. If your product develops a
fault within this period, you should in the rst instance contact the retailer where
the item was purchased.
This guarantee specically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (Such as chains, bars and sprockets)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in
the UK.
For any enquiries relating to the guarantee please refer to your retailer.
ROTARY HAMMER 1500W - TTB653SDS
MNL_TTB653SDS_TIT_GB_V02_150819.indd 2 8/19/15 9:47 AM

05
TTB653SDS by TITAN
Safety information
Getting started...
EN
>Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
>Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
>When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
>If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal safety
>Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
>Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
>Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 5 8/19/15 9:47 AM

06
TTB653SDS by TITAN
Safety information
Getting started...
EN
Safety warnings
>Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
>Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
>Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
>If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
Power tool use and care
>Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
>Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
>Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
>Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 6 8/19/15 9:47 AM

07
TTB653SDS by TITAN
Safety information
Getting started...
EN
>Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
>Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
>Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
Service
>Have your power tools serviced by a qualied repair
person using only identical replacement parts. This
will ensure that safety of the power tool is maintained.
Hammer safety warnings
>Wear ear protectors. Exposure to noise can cause
hearing loss.
>Use auxiliary handle supplied with the tool. Loss of
control can cause personal injury.
>Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live” and
could give the operator an electric shock.
>The SDS MAX drill is not commended for core drilling.
For core drilling, always select suitable core drill.
>When using this product it is essential that the following
rules for use are followed:
MNL_TTB653SDS_TIT_GB_V02_150819.indd 7 8/19/15 9:47 AM

08
TTB653SDS by TITAN
Safety information
Getting started...
EN
Safety warnings
• When drilling it is common that the core / drill bit jams in
the material being drilled. This will result in the product
trying to rotate around the drill bit and potentially
come out of your grip. This product has a safety clutch
mechanism. This safety clutch mechanism will be
activated and stop the drive to the drill bit BUT only if
you resist the initial forces caused by the jamming by
securely holding the product with both hands. As this
is a very powerful product these forces are signicant.
• ALWAYS ensure that the auxiliary handle is rmly
afxed and secured.
• The auxiliary and main handle must be rmly held to
resist any movement of the product when the core drill
or drill bit becomes jammed.
• ALWAYS use this product when standing on a rm
and secure platform or the ground. (DO NOT USE ON
LADDERS OR STEPS.)
• NEVER start the product with the core or drill bit
jammed in position.
• DO NOT stretch to hold the product. Do not work
above shoulder height or below knee height, as the
product cannot be securely held.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
MNL_TTB653SDS_TIT_GB_V02_150819.indd 8 8/19/15 9:47 AM

09
TTB653SDS by TITAN
Safety information
Getting started...
EN
>Only use the product as intended by its design and
these instructions.
>Ensure that the product is in good condition and well
maintained.
>Use correct attachments for the product and ensure
they are in good condition.
>Keep tight grip on the handles/grip surface.
>Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
>Plan your work schedule to spread any high vibration
tool use across a longer period of time.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
>Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage to
property.
>Switch off and disconnect from the power supply
if there are malfunctions. Have the product checked
by a qualied professional and repaired, if necessary,
before you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
>Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 9 8/19/15 9:47 AM

TTB653SDS by TITAN
Safety information
Getting started...
EN
10
EN
Getting started...
Safety warnings
>Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects
during use.
>Danger of injury and property damage caused by ying
objects.
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Warnings for construction dust
WARNING! Some dust created by power sanding,
sawing, grinding, drilling and other construction
activities contains chemicals known to cause
cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paint
• Crystalline silica from bricks and cement and
other masonry products
• Arsenic and chromium from chemically treated
timber
Your risk from these exposures varies, depending
upon how often you do this type of work. To reduce
your exposure to these chemicals:
• Work in a well-ventilated area.
• Work with approved protective equipment,
such as those dust masks that are specially
designed to lter microscopic particles.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 10 8/19/15 9:47 AM

TTB653SDS by TITAN
Safety information
Getting started...
EN
11
Getting started...
EN
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce
the risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at-risk groups within
this because of the dust that they breathe: silica dust is
not just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts
in things like sand, sandstone and granite. It is also
commonly found in many construction materials such as
concrete and mortar. The silica is broken into very ne
dust (also known as Respirable Crystalline Silica or RCS)
during many common tasks such as cutting, drilling and
grinding.
Breathing in very ne particles of crystalline silica can
lead to the development of:
Lung cancer
Silicosis
Chronic Obstructive Pulmonary Disorder (Chronic
obstructive pulmonary disease (COPD))
And breathing in ne particles of wood dust can lead to
the development of Asthma.
The risk of lung disease is linked to people who regularly
breathe construction dust over a period of time, not on
the odd occasion.
To protect the lung, the COSHH Regulations sets a limit
on the amount of these dusts that you can breathe (called
a Workplace Exposure Limit or WEL) when averaged
over a normal working day. These limits are not a large
amount of dust: when compared to a penny it is tiny – like
a small pinch of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
How to reduce the amount of dust?
MNL_TTB653SDS_TIT_GB_V02_150819.indd 11 8/19/15 9:47 AM

TTB653SDS by TITAN
Getting started...
EN
12
EN
Getting started...
Safety information
>Reduce the amount of cutting by using the best sizes of
building products.
>Use a less powerful tool e.g. a block cutter instead of
angle grinder.
>Using a different method of work altogether – e.g. using
a nail gun to direct fasten cable trays instead of drilling
holes rst.
Please always work with approved safety equipment,
such as those dust masks that specially designed to lter
out microscopic particles and use the dust extraction
facility at all time.
For more information please see the HSE website:
http://www.hse.gov.uk/construction or http://www.hse.gov.
uk/pubns/cis69.pdf
Symbols
On the product, the rating label and within these instructions you will nd among
others the following symbols and abbreviations. Familiarize yourself with them to
reduce hazards like personal injuries and damage to property.
V~ Volt, (alternating voltage) kg Kilogram
Hz Hertz °C Degree Celsius
W Watt dB(A) Decibel (A-rated)
/min or min-1 Per minute m/s² Metres per second
squared
mm Millimetre
Lock / to tighten or secure. Unlock / to loosen.
Note / Remark. Caution / Warning.
Read the instruction
manual.
Wear hearing protection.
Wear eye protection. Wear a dust mask.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 12 8/19/15 9:47 AM

TTB653SDS by TITAN
Safety information
Getting started...
EN
13
Getting started...
EN
Wear protective gloves. Wear protective, slip-
resistant footwear.
Utilisation en intérieur uniquement, dans un environnement sec.
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage
and transportation.
This product is of protection class II. That means it is equipped
with enhanced or double insulation.
The product complies with the applicable European directives
and an evaluation method of conformity for these directives was
done.
WEEE symbol. Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week
of manufacturing (Wxx)
MNL_TTB653SDS_TIT_GB_V02_150819.indd 13 8/19/15 9:47 AM

TTB653SDS by TITAN
Getting started...
EN
14
EN
Getting started...
Your product
Your product
7a 8
15
1 2 3 4 5 6 7
15a
11
12
13
22a
14
9
10
16
17
18
19 20 21 22
MNL_TTB653SDS_TIT_GB_V02_150819.indd 14 8/19/15 9:47 AM

TTB653SDS by TITAN
Getting started...
EN
15
Getting started...
EN
Your product
1. SDS PLUS drill chuck
2. Dust protection cap
3. Chuck sleeve
4. Depth stop
5. Collar
6. Wing nut
7. Mode selector – rotation
stop switch
a. Lock-off button
8. Gearbox cover
a. Bolt* (x 4)
9. On/off switch
10. Main handle
11. Mode selector – hammer
stop switch
12. Speed dial
13. Power cord with plug
14. Air vents
15. Auxiliary handle
a. Hand grip
16. Flat chisel
17. Point chisel
18. Ø 6/8/10/12/14 SDS drill bit
19. Keyed drill chuck with SDS adaptor
20. Chuck key
21. Dust cover
22. Carbon brush (x 2)
a. Indicator
23. Chisel / drill bit storage box
(not illustrated)
24. Transportation case
(not illustrated)
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective section in the instruction manual.
Technical specications
General
>Rated voltage, frequency : 230 - 240 V~, 50 Hz
>Rated power input : 1500 W
>Rated no load speed n0:200 - 750 min-1
> Impact rate : 3000 min-1
> Chuck type : SDS PLUS
> Protection class : II
> Weight : approx. 6 kg
Drilling capacity
> into wood : 40 mm
>into metal : 13 mm
>into concrete : 32 mm
MNL_TTB653SDS_TIT_GB_V02_150819.indd 15 8/19/15 9:47 AM

TTB653SDS by TITAN
Your product
Getting started...
EN
16
EN
Getting started...
Technical specications
Sound values (hammer drilling mode)
>Sound pressure level LpA :91.46 dB(A)
>Sound power level LWA :102.46 dB(A)
>Uncertainty KpA, KWA :3 dB(A)
Sound values (chiselling mode)
>Sound pressure level LpA :94.54 dB(A)
>Sound power level LWA :105.54 dB(A)
>Uncertainty KpA, KWA :3 dB(A)
The sound values have been determined according to noise test code given in
EN 60745-1 and EN 60745-2-6, using the basic standards EN ISO 3744 and EN
ISO 11203.
The sound intensity level for the operator may exceed 80 dB(A) and ear
protection measures are necessary.
The European Physical Agents (Vibration) Directive has been brought in to help
reduce hand arm vibration syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide indicative vibration
test results to enable users to make informed decisions as to the period of time a
power tool can be used safely on a daily basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
Vibration total values (triax vector sum) determined according to EN 60745:
Hammer drilling into concrete Vibration emission value ah,HD = 15.30 m/s2
Uncertainty K = 1.5 m/s2
Chiselling Vibration emission value ah,Cheq = 18.95 m/s2
Uncertainty K = 1.5 m/s2
The declared vibration emission value should be used as a minimum level and
should be used with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difcult and the
HSE website has further information.
The declared vibration emission been measured in accordance with a
standardised test stated above and may be used to compare one tool with
another tool.
The declared vibration emission value may also be used in a preliminary
assessment of exposure.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 16 8/19/15 9:47 AM

TTB653SDS by TITAN
Getting started...
EN
17
Getting started...
EN
Your product / Before you start
WARNING! The vibration emission value during actual use of the
power tool can differ from the declared value depending on the ways
in which the tool is used dependant on the following examples and
other variations on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and
in good condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these
instructions.
While working with this power tool, hand/arm vibrations occur. Adopt the correct
working practices in order to reduce the exposure to vibration.
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed.
WARNING! Identify safety measures to protect the operator that are
based on an estimation of exposure in the actual conditions of use
(taking account of all parts of the operating cycle such as the times
when the tool is switched off and when it is running idle in addition to
the trigger time).Note The use of other tools will reduce the users’ total
working period on this tool.
Helping to minimise your vibration exposure risk. ALWAYS use sharp
chisels, drills and blades Maintain this tool in accordance with these
instructions and keep well lubricated (where appropriate) Avoid using
tools in temperatures of 10ºC or less
Plan your work schedule to spread any high vibration tool use across
a number of days.
Unpacking
> Unpack all parts and lay them on a at, stable surface.
> Remove all packing materials and shipping devices, if applicable.
> Make sure the delivery contents are complete and free of any damage. If you
nd that parts are missing or show damage do not use the product but contact
your dealer. Using an incomplete or damaged product represents a hazard to
people and property.
> Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 17 8/19/15 9:47 AM

TTB653SDS by TITAN
Before you start
Getting started...
EN
18
EN
Getting started...
Unpacking
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
You will need
(items not supplied)
Suitable personal protective equipment
Suitable drill bits (for wood and metal)
Suitable crosshead screwdriver
Grease
Cooling lubricant (for drilling into metal)
(items supplied)
Depth stop (4)
Flat chisel (16)
Point chisel (17)
Ø 6/8/10/12/14 SDS drill bit (18)
Keyed drill chuck with SDS
adaptor (19)
Chuck key (20)
Dust cover (21)
Carbon brush (x 2) (22)
Setup
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!
Drill bits + chisels
Different drill bits can be used with this product depending on the workpiece
material and application required.
MNL_TTB653SDS_TIT_GB_V02_150819.indd 18 8/19/15 9:47 AM
