Titon auralite TP518 User manual

EN
Important: Read these instructions fully before installation.
1. Installation of the appliance and accessories MUST be carried
out by a qualied and suitable competent person.
2. All wiring must conform to current I.E.E. Wiring Regulations
and all applicable national standards and Building Regula-
tions.
3. Installation must be inspected and tested by a suitably quali-
ed person after completion.
4. Installation of the appliance must be carried out in clean, dry
conditions where dust and humidity are at minimal levels.
5. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
6. Children should be supervised to ensure that they do not
play with the appliance.
ventilation systems
auralite®
TP518
LED Status Indicator

2
auralite®
auralite® is a low voltage hard wired remote LED ventilation system status indicator,
designed to t a standard UK patress or recessed backbox. The indicator is for use
with specic Titon HRV units. The indicator has six LEDs which display:-
yNormal Solid light - Unit is running at Continuous Speed.
Flashing light- Unit is running at Setback Speed.
yFrost Unit is in Automatic Frost Protection mode.
yFilter Filters require change.
yBoost Solid light unit is running at Boost Speed.
Flashing light Boost Alert is active.
ySummer Unit is in Summer -bypass or Summer Mode; model dependant.
yFault Unit has a fault - Contact the installer.
Ventilation
System
auralite® Indicator Panel

3
Wiring Diagrams
0V
12V
A
B
0V
12V
A
B
Red
White
Yellow or Green
Black
auralite® connection at Indicator
0V
12V
A
B
0V
12V
A
B
Red
White
Yellow or Green
Black
Wire connection to HRV
typical plug connection to HRV

4
DO 5179 Issue 03
Wiring
1. Using Male Plug Connector & wire XP 40368 3m
Communication Cable XP 47074A 3m
XP 47074 30m
or alternately unshielded 4 Core 18-24AWG Stranded, Tinned Copper.
2. Communication cable should not be placed within 50mm or on the same
metal cable tray as 230V switched live, lighting or power cables and any cables
not intended for use with the HRV.
Filter notication reset
Following a lter change to HRV the auralite® will require resetting, see below.
Ensure the HRV is powered up. To clear the auralite® lter notication press &
hold the reset switch with a ball point pen or similar object for 10 second. The
switch is located behind the small hole in the front of the auralite®. All lights will
momentarily be illuminated indicating a successful reset.
