TLS Electronics 875300 User manual
User manual
875300
HDMI 2.0 Switch 3/1
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: [email protected]e 2
Table of contents
Table of contents................................................................................................2
Safety and Notice ..............................................................................................3
Introduction........................................................................................................4
Application.........................................................................................................4
System Requirements .......................................................................................4
Features.............................................................................................................4
Panel Description...............................................................................................5
Front Panel.....................................................................................................5
Rear Panel......................................................................................................5
Connection Diagram..........................................................................................6
Remote Control Description ..............................................................................6
Specifications.....................................................................................................7
Package Contents .............................................................................................7
Maintenance......................................................................................................8
Warranty Policy..................................................................................................8
Limitations of Warranty......................................................................................8
Exclusive Remedies ..........................................................................................9
RMA Policy ........................................................................................................9
Standard Replacement....................................................................................10
Once you have obtained an RMA number.......................................................10
Please note:.....................................................................................................10
Warranty.......................................................................................................... 11
Return and RMA Policies................................................................................. 11
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: info@tls-electronics.de 3
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may be damaged by
electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the life
of your equipment.
Safety and Notice
1) Servicing Personnel: Do not attempt to service the unit beyond that
described in these operating instructions. Refer all other servicing to
authorized servicing personnel.
2) Replacement parts: When parts need replacing ensure the servicer uses
parts specified by the manufacturer or parts that have the same
characteristics as the original parts. Unauthorized substitutes may result in
fire, electric shock, or other hazards.
3) Safety check: After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.
4) Do not substitute or use any other Power Supply other than the enclosed unit,
or a TLS approved Replacement Part. Doing so will void the warranty and
potentially expose the user to dangerous voltages resulting in an electrical
shock.
5) Do not disassemble the device for any reason. Doing so will void the
manufacturer’s warranty. Also, our unique case is an integral part of the
design of this unit and is responsible for cooling and circuitry shielding. Any
modifications to this case will potentially cause malfunction and product
failure.
6) Do not expose the device to water, moisture, or liquids. Possible electric
shock may result as well as failure of the unit to operate.
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: [email protected]e 4
Introduction
This Model allows switching of three HDMI signals to one HDMI output. It
supports HDMI 2.0, CEC and HDR10. IR remote control or switch button is
uused to choose the input source.
Application
1. Connect source devices with input ports of the switch by HDMI Cable.
2. Connect HDMI output port with TV or other HDMI sink devices by HDMI
Cable.
3. Connect 5V POWER adaptor with DC power socket.
4. Power on
System Requirements
Input HDMI source equipment such as DVD/Blu-ray player, PC/Laptop
Equipped output display (TV, monitor, projector)
Features
HDMI 2.0 version (Support 4K@60Hz YUV4:4:4)
Bandwidth upto 18Gbps
HDCP2.2/ HDCP1.4 , CEC
Support HDR10
Support 3xHDMI in, IR or switch button to choose source out
Micro USB interface for user to upgrade firmware
Keeps memory of the last power state when switch different HDMI channels
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: [email protected]e 6
Connection Diagram
Remote Control Description
①HDMI sources(1~3)
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: info@tls-electronics.de 7
Specifications
Package Contents
1) 1x HDMI Switch
2) 1x 5V DC power adapter
3) 1x User manual
4) 1x IR Remote controller
Operating Temperature Range
-5 to +40℃(+23 to +104℉)
Operating Humidity Range
5 to 90%RH (No Condensation)
Power supply
5V
Minimum power
(work under 480p60hz)
182mA
Maximum power
(work under 4K2K/60hz)
277mA
Max resolution
4k@60hz YUV4:4:4
Function
HDR10 and CEC
HDMI version
HDMI 2.0
HDCP version
HDCP2.2 / HDCP1.4(Auto choose
depend on TV version)
Control ways
Switch button and IR remote control
Distance
1080P 20m, 4k@30hz 10m,
4k@60hz under HDR can support 3m
Dimensions(LxWxH)
125x64.2x17mm
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: [email protected]e 8
Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or
benzene to clean this unit.
Warranty Policy
TLS electronics products are warranted against defects in material and
workmanship for two years from the date of shipment. During the warranty
period, TLS electronics will, at its option, repair or replace products that prove
to be defective. Repairs are warranted for the remainder of the original
warranty or a 90 day extended warranty, whichever is longer.
For equipment under warranty, the owner is responsible for freight to TLS
electronics and all related customs, taxes, tariffs, insurance, etc. TLS
electronics is responsible for the freight charges only for return of the equip-
ment from the factory to the owner. TLS electronics will return the equipment by
the same method (i.e., Air, Express, Surface) as the equipment was send to
TLS electronics.
All equipment returned for warranty repair must have a valid RMA number
issued prior to return and be marked clearly on the return packaging. TLS
electronics strongly recommends all equipment be returned in its original
packaging. TLS electronics obligations under this warranty are limited to repair
or replacement of failed parts, and the return shipment to the buyer of the
repaired or replaced parts.
Limitations of Warranty
The warranty does not apply to any part of a product that has been installed,
altered, repaired, or misused in any way that, in the opinion of TLS electronics,
would affect the reliability or detracts from the performance of any part of the
product, or is damaged as the result of use in a way or with equipment that had
not been previously approved by TLS electronics. The warranty does not apply
to any product or parts thereof where the serial number or the serial number of
any of its parts has been altered, defaced, or removed.
The warranty does not cover damage or loss incurred in transportation of the
product. The warranty does not cover replacement or repair necessitated by
loss or damage from any cause beyond the control of TLS electronics, such as
lightning or other natural and weather related events or wartime environments.
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: info@tls-electronics.de 9
The warranty does not cover any labor involved in the removal and or
reinstallation of warranted equipment or parts on site, or any labor required to
diagnose the necessity for repair or replacement.
The warranty excludes any responsibility by TLS electronics for incidental or
consequential damages arising from the use of the equipment or products, or
forany inability to use them either separate from or in combination with any
other equipment or products. A fixed charge established for each product will
be imposed for all equipment returned for warranty repair where TLS
electronics cannot identify the cause of the reported failure.
Exclusive Remedies
TLS electronics’s warranty, as stated is in lieu of all other warranties, expressed,
implied, or statutory, including those of merchantability and fitness for a
particular purpose. The buyer shall pass on to any purchaser, lessee, or other
user of TLS electronics’s products, the aforementioned warranty, and shall
indemnify and hold harmless TLS electronics from any claims or liability of such
purchaser, lessee, or user based upon allegations that the buyer, its agents, or
employees have made additional warranties or representations as to product
preference or use. The remedies provided herein are the buyer’s sole and
exclusive remedies. TLS electronics shall not be liable for any direct, indirect,
special, incidental, or consequential damages, whether based on contract, tort,
or any other legal theory.
RMA Policy
When returning product to TLS electronics for any reason, the customer should
fill out the official RMA form to obtain a RMA number. Without the permission or
approval, TLS electronics will be no responsible for any return. This can be
initiated by emailing or calling your related sales.
All requests are processed within 48 hours.
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: [email protected]e
10
Standard Replacement
For customers that agree to return defective product to TLS electronics first, a
Standard Replacement option is available.
An RMA number must first be issued by sales. This RMA number will need to
be referenced on the outside of the return shipment.
Upon receipt of the defective product, TLS electronics will, at its discretion,
either repair or replace the product and ship it out in the most expeditious
manner possible. Subject to availability, the replacement product will be
shipped on the business day following receipt of the defective product.
In the event the product returned to TLS electronics has been discontinued (i.e.
the product is no longer being manufactured by TLS electronics but is still
under warranty), TLS electronics will, at its discretion, either repair or replace
with recertified product.
Once you have obtained an RMA number
After obtaining an RMA number from TLS electronics, you must send the
product - freight prepaid - to TLS electronics. The TLS electronics RMA number
must be prominently displayed on the outside of your package. If you send your
product to TLS electronics without the RMA number prominently displayed on
the outside of the package, it will be returned to you unopened.
Please use a shipping company that can demonstrate proof of delivery. TLS
electronics does not accept responsibility for any lost shipments unless proof of
delivery to TLS electronics is provided.
Please note:
Product shipped to TLS electronics must be properly packaged to prevent loss
or damage in transit.
Shipping your RMA to TLS electronics using regular mailing envelopes is not
acceptable, as they do not protect the product from damage during shipping.
TLS electronics will not repair or replace a module that is shipped in such a way
that the product is not properly protected. TLS electronics will not accept any
product that has been damaged as a result of accident, abuse, misuse, natural
or personal disaster, or any unauthorized disassemble, repair or modification.
875300 HDMI 2.0 Switch 3/1
Relens GmbH Contact: info@tls-electronics.de 11
Warranty
Warranty time is two year and from the date of original shipment. This warranty
shall be void if a serial number has been removed from the product.
Upon determination of a legitimate defect covered by this warranty and at TLS
sole discretion, user should bear the transport cost during the warranty.
If product is out of warranty then repair charge is required. Minimum repair
charge: 10% of the retail price plus the cost of failed components. We will
repair the failed product after repair cost has been approved by Customers and
proper financial arrangements are made. Customer must cover round trip ship-
ment expenses.
Return and RMA Policies
Shipments will not be receiver and processed for warranty repair/replacement
without an TLS electronics RMA(Return Materials Authorization).
Relens GmbH
Germany
33175 Bad Lippspringe
An der Eiche 4
+49 (05252) 270
info@tls-electronics.de
www.tls-electronics.de
Table of contents
Other TLS Electronics Switch manuals
