EtherWAN EX46910F User manual

Copyright 2022 EtherWAN Systems, Inc. Page 1
All Rights Reserved
EX46910F
8/2/2022
EX46910F Hardened PoE Switch
Installation Guide
1 Unpacking
Unpack the items. Your package should
include:
 One EX46910F PoE switch
 Power input terminal block
 Wall and DIN-Rail mounting hardware
brackets
If items are missing or damaged, notify your
EtherWAN representative. Keep the carton
and packing material.
More information available at:
https://www.etherwan.com/us
For warranty information, visit:
https://www.etherwan.com/us/support/war
ranty-policy
2 Equipment Needed
 Category 5e or better cable for RJ-45
ports
 48VDC power supply with voltage
adjustable up to 56VDC and power output
to handle 240W PoE power budget.
3 Select a Location
 DIN-rail installations: Attach the bracket
on the unit using the included screws and
then mount on a DIN-rail.
 Wall installations: Attach the brackets on
the unit using the included screws and
then mount on a wall.
 Identify a power source within 6 feet (1.8
meters).
 Choose a dry area with ambient
temperature between -40 and 75ºC (-40
and 167ºF).
 Keep away from heat sources, sunlight,
warm air exhausts, hot-air vents, and
heaters.
 Make sure there is adequate airflow.
4 Connect to the Ports
The EX46910F has the following ports:
 8 10/100/1000 Mbps PoE ports
 2 1000 Mbps SFP slots
10/100/1000BASE-T Ports
Ports 1 to 8 are gigabit copper ports that are
compliant with IEEE 802.3af/at PoE protocol,
with up to 30W power output per port.
SFP Slots
Ports 9 and 10 are 1000BASE SFP slots.
5 Connect Power
Terminal Block
Connect the unit to a suitable power supply
using appropriate wire, 18-24 AWG, rated for
105°C or higher.
Redundant power is supported. However,
only one power input is required to operate
the unit.
1. Connect power wires to the
appropriate P1+/- or P2+/- pins on
the terminal block.
2. Connect the grounding wire to the
ground screw.
3. Plug the terminal block into the
socket.
4. Alternatively, connect power 3 to an
external power adapter.
Relay Output Alarm
The switch provides relay output contacts for
redundant power. The relay output can be
connected to an alarm signaling device. The
current capacity is 1A@24VDC.
 When dual power sources are connected,
the circuit is open.
 When a single power source is connected
the circuit is closed.
 The relay works with only power 1 and
power 2. It is not connected to power 3.

Copyright 2022 EtherWAN Systems, Inc. Page 2
All Rights Reserved
EX46910F
8/2/2022
EX46910F Hardened PoE Switch
Installation Guide
6 Front Panel LEDs
LED Panel Layout
LED Color Status
Power
1/2
Green ON = power detected
OFF = power not detected
Power
3
Green ON = power detected
OFF = power not detected
Amber ON = One power source
connected (P1 or P2)
OFF = Both power sources
connected (P1 and P2)
PoE
(1-8)
Amber ON = PD is detected
Off = No PD detected
Link/ACT Green ON = Connection
established
Off = Link not detected
Flashing = Port is sending
or receiving data
SFP
(F9-F10)
Green ON = Connection
established
Off = Link not detected
Flashing = Port is sending
or receiving data
7 DIP Switch
DIP Switch Settings
The SFP slots on EX46910F operate at
1000Mbps only. Make sure the DIP switch is
set to the OFF position for operation of each
SFP slot.
DIP
1
Off 1000M F10
On Not used
DIP
2
Off 1000M F9
On Not used
