TMI Products VH6 Series Installer manual

ANALOGUE QUARTZ
TECHNICAL GUIDE
&
PARTS CATALOGUE
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
31032022

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
*Refer to the pages 2 for other Cal. No. specifications.
φ23.70 mm
22.60 mm ：between 12 o'clock and 6 o'clock sides
22.60 mm ：between 3 o'clock and 9 o'clock sides
φ23.30 mm
22.10 mm ：between 12 o'clock and 6 o'clock sides
21.40 mm ：between 3 o'clock and 9 o'clock sides
Electronic circuit reset switch
Second setting device
SR920SW (Silver oxide battery)
Battery life is approximately 2 years
Use 10 second gate
* Set the winding stem with crown at the normal position
Movement
size
Outside diameter
Casing diameter
Total height
3.45 mm
SPECIFICATION
Cal. No.
VH63A
Item
Movement
Time
indication
Cal. No.
VH60A
VH61A
VH63A
Date Calendar
Hand （3H）
－
－
○
24 Hour hand (6H)
○
○
○
Date Calendar
Hand （2H）
－
－
VH65A
VH67A
VH68A
3 Hands
○
○
○
○
〇
〇
VH64A
〇
(hour, minute, second)
○
○
○
─
─
○
－
─
─
○
－
○
Date Calendar
Hand （12H）
－
○
－
－
－
○
─
－
－
－
Accuracy
Less than ± 15 seconds : Monthly rate at normal temperature range
○
─
Day Calendar
Hand (10H)
－
－
－
－
－
－
○
Day Calendar
Hand （9H）
－
－
○
Driving system
Step motor
Additional mechanism
Antimagnetic
≧1600 A/m
Battery
Measuring gate by quartz tester
Jewels
2 Jewels
1

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
2
VH65A
VH67A
VH68A
MOVEMENT VARIATION
VH60A
VH61A
VH63A
VH64A
day
date
24hours
day
date
24hours
24hours
day date
date
date
24hours
date
day
24hours

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
Hour, minute and
Second hands
24 Hour hands
Dial
0012 354
Support for dial side
parts screw
0012 354
Support for dial side 0604 015
parts screw Support for dial side parts
0491 014
Dial washer
0157 018
Small hour hand 0273 043
wheel Hour wheel
0802 469
Date driving wheel
3
⑧
①
②
⑨
PARTS CATALOGUE
③
④
⑤
④
⑥
⑦
<<VH60A>>

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
Hour, minute and
Second hands
Dial Date calendar, 24 Hour hands
0012 354
Support for dial side
parts screw 0012 354
Support for dial side
parts screw
0273 043 0604 014
Hour wheel Support for dial side parts
0491 014
Dial washer
0970 004
Date star
0157 018
Small hour hand wheel 0012 354
Intermediate wheel for
date corrector holder screw
0802 469
Day driving wheel 0802 469
Date driving wheel
0836 005
Intermediate wheel for 0737 006
date corrector holder
Intermediate wheel for
date corrector (D)
0804 170 0737 169
Intermediate wheel for Date corrector wheel
date corrector (C) 0962 033
Intermediate wheel for
date corrector (B)
4
14
⑭
⑪
⑰
⑬
⑧
⑨
⑯
<<VH61A>>
PARTS CATALOGUE
15
⑮
⑦
1
①
2
③
②
④
④
⑫
⑤
⑥
⑩

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
Hour, minute and
Second hands
Date-Day calendar,
24 Hour hands
Dial
0012 354
Support for dial 0012 354
side parts screw Support for dial side
parts screw
0273 043 0604 014
Hour wheel Support for dial side parts
0491 014
Dial washer
0970 004
Date star
0157 018
Small hour hand
wheel 0012 354
Intermediate wheel for
1019 010 date corrector holder screw
Day wheel 0802 469
0802 469 Date driving wheel
Day driving wheel 0962 033
0873 018 Intermediate wheel for
Day jumper date corrector (C)
0737 006
Intermediate wheel for
date corrector (D)
0836 005 0737 169
Intermediate wheel for Date corrector wheel
date corrector holder 0962 033
Intermediate wheel for
date corrector (B)
⑬
⑰
⑯
⑫
⑲
⑮
⑥
⑩
⑨
④
PARTS CATALOGUE
5
<<VH63A>>
①
②
③
④
⑱
⑭
⑤
⑦
⑪
⑧

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
Hour, minute and
Second hands
Date-Day calendar
0012 354 Dial
side parts screw
0012 354
Support for dial side parts screw
0604 014
Support for dial side parts
0273 043 0970 004
Hour wheel Date star
1019 010 0012 354
Day wheel Intermediate wheel for
date corrector holder screw
0802 469
Day driving wheel 0802 469
Date driving wheel
0873 018 0962 033
Day jumper Intermediate wheel for
date corrector (C)
0962 033
Intermediate wheel for
0737 006
date corrector (B)
Intermediate wheel for
date corrector (D)
0836 005 0737 169
Intermediate wheel for Date corrector wheel
date corrector holder
⑭
⑩
⑦
⑧
⑪
⑯
⑰
⑮
PARTS CATALOGUE
6
<<VH64A>>
①
②
④
③
Support for dial
④
⑤
⑫
⑨
⑥
⑬

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
Hour, minute and
Second hands
Date calendar
Dial
0012 354
Support for dial
side parts screw 0012 354
Support for dial side
parts screw
0604 014
Support for dial side parts
0012 354
Intermediate wheel for
date corrector holder screw 0970 004
Date star
0273 043
Hour wheel 0802 469
Date driving wheel
0836 005
Intermediate wheel for 0962 033
date corrector holder Intermediate wheel for
date corrector (C)
0962 033 0737 006
Intermediate wheel for
Intermediate wheel for
date corrector (B) date corrector (D)
0737 169
Date corrector wheel
⑥
⑪
⑤
PARTS CATALOGUE
7
<<VH65A>>
①
②
③
④
④
⑬
⑭
⑫
⑧
⑩
⑦
⑨

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
Hour, minute and
Second hands
Dial Date-Day calendar,
Dial 24 Hour hands
0012 354 0012 354
parts screw
Support for dial side
parts screw
0604 014
0273 043 Support for dial side parts
Hour wheel
0491 014
Dial washer
0970 004
0157 018 Date star
Small hour hand
wheel 0012 354
Intermediate wheel for
1019 010 date corrector holder screw
Day wheel 0802 469
0802 469 Date driving wheel
Day driving wheel 0804 170
0873 018 Intermediate wheel for
Day jumper date corrector (C)
0737 006
Intermediate wheel for
date corrector (D)
0836 005
Intermediate wheel for 0737 169
date corrector holder Date corrector wheel
0962 033
Intermediate wheel for
date corrector (B)
8
⑲
⑬
15
⑰
14
⑯
⑫
⑱
Support for dial side
④
⑤
⑭
⑦
⑪
⑧
⑮
⑥
⑩
⑨
④
PARTS CATALOGUE
<<VH67A>>
1
①
③
2
②

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
Hour, minute and
Second hands
Dial Dial
Date-Day calendar,
24 Hour hands
0012 354
parts screw 0012 354
Support for dial side
parts screw
0273 043 0604 015
Hour wheel Support for dial side parts
0491 014 0970 004
Dial washer
Date star
0157 018 0012 354
Small hour hand Intermediate wheel for
wheel date corrector holder screw
1019 010 0802 469
Day wheel Date driving wheel
0802 469 0804 170
Day driving wheel Intermediate wheel for
date corrector (C)
0873 018
Day jumper 0737 006
Intermediate wheel for
date corrector (D)
0737 169
0836 006 Date corrector wheel
Intermediate wheel for
date corrector holder 0962 033
Intermediate wheel for
date corrector (B)
9
⑫
⑯
⑲
⑥
⑩
⑨
⑬
⑰
⑱
<<VH68A>>
PARTS CATALOGUE
⑧
⑮
①
③
②
④
Support for dial side
④
⑭
⑤
⑦
⑪

Version-02
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Lubricating : Types of oil
Disassembling procedures Figs.
①→㊻
A3a / Moebius 9010
A2a / Moebius 9030
Reassembling procedures Figs.
㊻→①
Oil quantity
Normal quantity
Sufficient quantity
*1 Oiling position
*Refer to pages 11 for each parts code
PARTS CATALOGUE
10
㉒
*Battery connection (+)
㉖
0144 004
Fourth wheel and pinion
㉗
0560 005
Friction spring for
fourth wheel and pinion
㉝
0281 015
Setting wheel
㉟
0261 052
Minute wheel
and pinion
㊹
0012 354
Center wheel
bridge screw
㊻
0221 089
Center wheel and pinion
㊷
4002 070
Coil block
㉔
4270 339
Battery connection (-)
㉕
0125 321
Train wheel bridge
㉙
0701 017
Fifth wheel and pinion
㉞
0391 029
Train wheel
setting lever
㊱
*Setting lever
㊲
0384 452
Yoke
㊴
0282 452
Clutch wheel
㊵
0804 169
Intermediate wheel for
date corrector (A)
㊳
0351 177
Winding stem
㉜
4004 474
Circuit block
㉚
0706 008
Sixth wheel and pinion
㉘
0231 061
Third wheel and pinion
㉛
4146 104
Step rotor
㊺
0121 060
Center wheel bridge
㊸
4239 065
Stator
㊶
0012 354
Coil block screw
㉑
0012 168
Battery connection (+) screw
⑳Battery
㉓
4216 103
Insulator
*1

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
Remarks:
O Different parts for each CAL.
* All parts code are subject to change without notice.
VH64A
VH65A
VH67A
VH68A
Parts name
Parts code
VH60A
VH61A
VH63A
―
O
O
O
0383 154
O
―
―
―
―
―
O
㊱Setting lever
0383 891
―
O
O
―
―
4268 113
O
―
―
―
―
―
―
4268 086
―
―
―
―
O
―
―
4268 084
―
―
―
O
―
―
―
4268 082
―
O
―
―
―
―
4268 072
―
―
―
―
―
4268 074
―
―
―
―
PARTS CATALOGUE
11
㉒Battery connection (+)
4268 070
―
―
O
―
―
―
―
―
O
―
O

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
・The explanation here is only for the particular point of Cal.VH60A/VH61A/VH63A/VH64A/VH65A/
VH67A/VH68A
REMARKS ON DISASSEMBLING AND REASSEMBLING
(1)HAND
・How to install hands:
Place the movement directly on a flat metal plate
or such a hard plate when you install the hands.
Necessary procedure to setting hands:
①Set the dial.
②Install the date calendar hand at the 12 o'clock position.
③Pull out the crown to the second click position, and change the
date by rotating the crown clockwise.
④Install the day calendar and 24 hour and hour and minute and second hands
at the 12 o'clock position.
(2)Winding stem
・How to remove:
Pull out the winding stem while pushing
the indented portion of the arrow.
(3)Battery
・How to install:
Insert the battery in the aslant direction as shown by the arrow.
Check the battery connection (+) securely touches the
side face of the battery.
・How to remove:
Firstly slide the battery in the direction of the arrow with tweezers,
and then lift the battery.
(4)Insulator
・How to set:
To insulate between the battery connection (+)
and the battery connection (-), the insulator
should be put at the two pins securely as bellow.
12
TECHNICAL GUIDE
Push
Metal plate
Pin
Insulator

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
(5)Setting position adjustment (at the time of disassembling and reassembling)
・How to set the Date & Day driving wheels in the correct position:
Note:
Set the indicator finger of a Date & Day driving wheels to the setting position mark on the Main plate.
An adjustment is unnecessary for VH60A/VH61A/VH65A.
≪Cal.VH63/64A setting position≫ ≪Cal.VH67A setting position≫ ≪Cal.VH68A setting position≫
Setting position
Setting position
13
Day driving wheel
TECHNICAL GUIDE
Date driving wheel
Setting position
Enlargement Enlargement
Enlargement
Indicator finger
Indicator finger

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
・How to assemble and set the Date & Day jumpers of the support of dial side parts:
There are two hooks on the support for dial side parts. (Fig.1)
Assemble the two hooks on the support for dial side parts
to the position of the built-in height A of the base plate. (Fig.2)
Set the Date & Day jumper to the teeth of the Date star & Day wheel.
Assemble the two hooks on the position of the built-in height B of the base plate. (Fig.3)
example VH63A
Fig.1 (example VH63A) Fig.2 (built-in height A) Fig.3 (built-in height B)
TECHNICAL GUIDE
14
height A position
height B position

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
≪VH60A≫
Note:
*1:
Hour hand
*2: Minute hand
*3: Second hand
*4: 24Hour hand
*5: Crown at normal position
*6: First click
・Time setting
1.pull out the crown to the
2.Turn the crown to set 3.Push the crown back in
first click when the
the hour and minute
to the normal position in
second hand is at the hands to the time. accordance with a time
12 O'clock position. (Check that AM / PM is signal.
set correctly)
OPERATION
TIME SETTING
《VH60A》
15
DISPLAY AND CROWN OPERATION
*1
*3
*2
*4
*5
*6

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
≪VH61A≫ ≪VH63A≫
≪VH64A≫ ≪VH65A≫
≪VH67A≫ ≪VH68A≫
*1: Hour hand
*4: Date calendar hand *7: Crown at normal position *9: Second click
*2: Minute hand *5: Day calendar hand *8: First click ・Time setting
*3: Second hand *6:
24 Hour hand
・Date setting (Quick change function)
OPERATION
DISPLAY AND CROWN OPERATION
16
Note:
*6
*2
*1
*5
*3
*7
*4
*8
*9
*2
*3
*4
*6
*7
*8
*9
*1
*1
*5
*3
*2
*4
*7 *8
*9
*1
*3
*2
*4
*7
*8
*9
*1
*5
*3
*6
*4
*7
*8
*9
*2
*5
*1
*3
*6
*4
*2
*7
*8
*9

Version-01
Cal.VH6 Series
（VH60A/61A/63A/64A/65A/67A/68A）
1.Pull out the crown to the 2.Push the crown back
3.Pull out the crown to
4.Push the crown back
second click when the into the normal position the first click. into the normal position.
second hand is at the in signal. Turn the crown counter-
12 O'clock position. clockwise to set the date.
Turn the crown rotation to
set the day of the week.
Turn the crown to set the
hour and minute hands
to the time.
(Check that AM / PM is
set correctly)
*Do not set the date between 10:00 PM and 2:00 AM
Otherwise, the day may not change properly. If it is necessary to set the date during that time period,
first change the time to any time outside it and set the date, and then reset the correct time.
OPERATION
17
TIME SETTING
《VH61A/VH63A/VH64A/VH65A/VH67A/VH68A》
