TMI Products VD57B User manual

Revised on: 08... Aug. 2014
ψ29. 50 mm
H 4. 57 mm
Specification - 1
Specification - 2
Appearance
Casing
Hand Fitting - 1
Hand Fitting - 2
Hand Setting Stem
Dial - 1
Dial - 2
Dial - 3
Assembly Plan - 1
Assembly Plan - 2
Assembly Plan - 3
Assembly Plan - 4
Hands
SII Products
Cal. VD57B
Version 2
Version 5
Version 5
Version No.Item
Version 8
Version 1
Version 1
Version 4
Version 9
Version 9
Version 8
Version 2
Version 1
Version 1
Version 1
Version 6

MOVEMENT SPECIFICATION - 1
CAL.VD57B 12 3 / 4 Ligne Quartz Movement
Three Hands with 3 Eyes / Date ( Minute, Second, 1 / 10 Second Chronograph & Calendar )
1. MOVEMENT DIMENSIONS
·
Outside diameter ψ29.50mm
(12H~6H) x 26.00mm (3H~9H)
·
Casing diameter ψ28.80mm
(12H~6H)
·
Total height 4.57 mm
·
Dimensions of small hands away from center 7.50 mm
2. TIME STANDARD
·
Type of quartz oscillator Tuning fork
·
Frequency of quartz oscillator 32,768 H Z
·
Accuracy Monthly rate: Less than 20 seconds per month at
normal temperature range
·
Regulation device Nil
·
Regulation hands unbalance Second : Less than 0.09 µN·m ( 9mg·mm )
Minute : Less than 0.60 µN·m ( 60mg·mm )
Hour : Less than 0.50 µN·m ( 50mg·mm )
Chronograph hands : Less than 0.05 µN·m ( 5mg.mm )
·
The moment of inertia 1/10 chronograph hand : Less than 0.40 µg·m² ( 400mg·mm² )
(Disc hand)
·
Additional function Stopwatch : up to 1 minute in 1/10 second ( 2 seconds per round )
up to 60 minutes in 1 second split time
3. BATTERY
·
Type Silver oxide battery
·
Size ψ9.5 x t 2.0 ( mm )
·
Battery life Approx. 2 years
·
Recommended battery SR920SW ( SEIZAIKEN )
4. STEPPING MOTOR
·
Number of units 3 pieces
·
Type Two pole stepping motor
·
Step 180°every second
5. JEWEL
0 jewel
6. ANTIMAGNETISM
≧1600 A / m
( direct current magnetic field )
7. SHOCK RESISTANCE
On equal level with general quartz movement
8. OPERATING TEMPERATURE RANGE From - 5 ℃to + 50 ℃
9. TEST OF ACCURACY
·
Equipment to be used SEIKO Quartz Tester QT - 99
Greiner Quartz Timer - C
Witschi Q-Tester 4000
·
Duration of measurement 10 seconds
·
Microphone to be used Electromagnetic detection type
10. ATTACHED PARTS
* All specifications are subject to change without notice.
SII Products
Version: 6
3013 - 14G0
0110 - 3570
Parts Name
Hand setting stem
Sticker
Silver oxide battery
Parts Code
0351-1770 (Normal) / 0351-1220 (Long)

Movement Specification - 2
OPERATION 3 step motors ( 3 hands with calendar, 1 / 10 sec. chrono. maximum to 60 minutes )
1st click 2nd click
adjusting calendar adjusting minute, hour & chrono. hands
( clockwise )
* Stopwatch 1/10 second hand moves for a first minute.
* Pull the crown to 2nd click to adjust the stopwatch hand position.
* AC functions is available if stopwatch hand position is disorderly.
* When using AC functions, stopwatch hand moves back and returned to where it was
( second hand moves 1/2 circle counterclockwise and 1/2 circle clockwise, 1/10
second hand moves 1 circle clockwise ) Version 1
SII Products
CAL. VD57B
stopwatch
second hand
stopwatch
minute hand
3 hands
N
ormal position
AC FUNCTIONS
( KEEP
BUTTONS
"A" AND "B"
PRESSED AT
THE SAME TIME
FOR 2 SECONDS,
AND THEN,
RELEASE THE
BUTTONS )
START
STOP
FREE
linkage
SPLIT
RESET
ADJUSTING THE
STOPWATCH SEC.& MIN.
HAND POSITION
(CLOCKWISE )
TIMING SETTING
RESET SWITCH
SECOND SETTING DEVICE
ADJUSTING THE
STOPWATCH 1/10 SEC.
HAND POSITION
(CLOCKWISE )
Press button A, stopwatch 1/10 sec.hand indicates 1/10
unit of measurement time during stopwatch 1/10 second
hand moves for a first minute.
date
ADJUSTING
CALENDAR
SPLIT
RESET
START
STOP

Maximum height from main plate surface
與機芯平面之最大高度
Total height incl. movement
機芯總高度
Type M
一般針高
Type L
高針
Type LLA/LLB
特高針 A/ 特高針 B

TYPE M 一般針高
TYPE L 高針
Hour wheel 時針輪
Center wheel 分針輪
Fourth wheel 秒針輪
Chronograph minute wheel 計時分輪
Chronograph second wheel 計時秒輪
Chronograph 1/10 second wheel 計時1/10秒針輪
TYPE M 一般針高
TYPE L 高針
TYPE M 一般針高
TYPE L 高針

Type LLA 特高針 A
Type LLB 特高針 B
Hour wheel 時針輪
Center wheel 分針輪
Fourth wheel 秒針輪
Chronograph minute wheel
計時分針輪
Chronograph second wheel
計時秒針輪
Type LLB 特高針 B
Type LLA 特高針 A
Chronograph 1/10 sec. wheel
1/10 時秒針輪

SII Products
ANALOGUE QUART
Z
TECHNICAL GUIDE
&
PARTS CATALOGU
E
Cal.VD57B
Revised on : 12. Nov. 2010
