TMT PAPILLON 250 User manual

PAPILLON 250
ARTICULATED ARM OPENERS
24V DC GEAR MOTOR
USER MANUAL

INDEX
1.1 WARNINGS
1.2 MOTOR INSTALLATION
1.3 DIMENSION CHART
1.4 COMPONENTS OF INSTALLATION
1.5 INSTALLATION OF ARTICULATED ARM OPENER
1.6 EMERGENCY RELEASE
1.7 POWER SUPPLY CONNECTIONS
2.1 WIRING CONNECTION
2.2 MASTER MOTOR IS INSTALLED AT LEFT SIDE
2.2.1 STANDARD INSTALLATION
2.2.2 ADVANCED INSTALLATION (MOTOR WITH LIMIT SWITCH)
2.3 MASTER MOTOR IS INSTALLED AT RIGHT SIDE
2.3.1 STANDARD INSTALLATION
2.3.2 ADVANCED INSTALLATION (MOTOR WITH LIMIT SWITCH)
2.4 TRANSMITTER MEMORIZING AND ERASING PROCESS
2.5 SYSTEM LEARNING PROCESS
2.6 GET MOTOR RUNNING
2.7 RESTORE DEFAULT SETTING
2.8 LED INDICATION
2.9 GATE-MOVING LOGIC
2.10 CHECKING THE GATE MOVEMENT
2.11 MEANING OF LED DISPLAY
3. ADVANCED FUNCTION PARAMETER SETTING
3.1 HOW TO CHANGE
3.2 ADVANCED FUNCTION PARAMETER
4. PHOTOCELL INSTALLATION
4.1 PHOTOCELL WORKING LOGIC ADJUSTMENT
5. GREEN BOX INSTALLATION (OPTIONAL)
6. TROUBLE SHOOTING
7. TECHNICAL FEATURES
7.1 DIMENSION
7.2 TECHNICAL FEATURE
8. MAINTENANCE
1
1
2
2
3
4
4
5
5
5
6
6
6
7
7
8
8
9
9
9
9
10
10
11
13
15
16
17
17
17
18
18
1.1 WARNINGS
WARNING :
This user manual is only for qualified technicians who is specialized in installations and automations.
(1) All installations, electrical connections, adjustments and testing must be performed only after reading and understanding of all
instructions carefully.
(2) Before carrying out any installation or maintenance operation, disconnect the electrical power supply by turning off the magneto
thermic switch connected upstream and apply the hazard area notice required by applicable regulations.
(3) Make sure the existing structure is up to standard in terms of strength and stability.
(4) When necessary, connect the motorized gate to reliable earth system during electricity connection phase.
(5) Installation requires qualified personnel with mechanical and electrical skills.
(6) Keep the automatic controls (remote, push bottom, key selectors…etc) being placed properly and away from children.
(7) For replace or repair of the motorized system, only original parts must be applied. Any damage caused by inadequate parts and
methods will not be claimed to motor manufacturer.
(8) Never operate the drive if you have any suspect with what it might be faulty or damage to the system.
(9) The motors are exclusively designed for the gate opening and closing application, any other usage is deemed
in appropriate. The manufacture should not be liable for any damage resultingfrom the improper use. Improper usage should void
all warranty, and the user accepts sole responsibility for any risks thereby may accrue.
(10) The system may only be operated in proper working order. Always follow the standard procedures by following the instructions in this
installation and operating manual.
(11) Only command the remote when you have a full view of the gate.
Please keep this installation manual for future reference.

ARTICULATED ARM OPENERS USER MANUAL
1.3 DIMENSION CHART
1
1.2 MOTOR INSTALLATION
1. 24V DC blinker with integrated antenna
2. Push Button
3. Photocells
4. 24V DC articulated arm opener
5. PR-1 Transmitter
Plea n the chart for proper installation. If necessary, please adjust the gate structure to the
best operation.
Before starting the installation, please make sure that the gate moves freely and that :
1) Hinges are properly positioned and greased.
2) No any obstacle in the moving area.
3) No frictions between two gate leafs or and on the ground while moving.
4) Installation reference: to open the gate with 90 degree, please refer the data table below:
A: Distance between the gate hinge and the wall bracket.
B: Distance between the gate hinge and side face of the motor.
C: Distance between the gate hinge and the fixing point of the arm.
A
To open 90 degree.
C
B
C
50
100
150
200
250
300
unit: mm
A
B
50
625
615
600
585
565
540
100
575
565
550
535
515
/
150
545
540
/
/
/
/
Optional Optional
2x1.5 mm2
4x0.5 mm2
TX - 4x0.5 mm2
RX - 4x0.5 mm2
2x1.5 mm2 2x1.5 mm2
44
2
33
1
5

1.4 COMPONENTS OF INSTALLATION
1.5 INSTALLATION OF ARTICULATED ARM OPENER
ARTICULATED ARM OPENERS USER MANUAL
2
1
2
3
4
5
6
7
8
9
10
11
12
13
Straight arm
Curved arm
U-shaped fixing plate
Mechanical stopper
Front-end fixing bracket
Screw
Nut Ø10
Screw
Gasket
Screw
Spring washer
Nut Ø8
Cable gland
1 pce
1 pce
1 pce
2 pcs
1 pce
4 pcs
2 pcs
2 pcs
2 pcs
2 pcs
4 pcs
4 pcs
1 pce
2
3 4 5
6
7
8
13 12 11 10 9
1
1. Refer to the Dimension Chart to choose the correct dimensions of the motors and
position to be installed.
2. Check if the mounting surface of the brackets to be installed is smooth, vertical and rigid.
3. Arrange the cables for power supply cable of the motors.
4. Motor installation and setting for mechanical stopper in opened and closed position.
2) Place the gate in the full closed position and
fix the U-shaped fixing plate on the wall.
1) Remove the upper cover and mechanical
stoppers on the bottom of motor.

ARTICULATED ARM OPENERS USER MANUAL 3
1.6 EMERGENCY RELEASE
1) Insert the release key to the release slot
2) Turn the release key anti-clockwise
3) Pull out the release bar
4) Turn the release key clockwise to fix the release bar, the release bar has to be in pulled out position when turning
the release key clockwise
4) After positioning the front of curved arm on the bottom of motor,
release the motor and position the minor arm on the end of
curved arm and mounting bracket with corresponding screws
and nuts.
5) Closed position adjustment :
4.1 After the full closed position decided, fix the corresponding mechanical stopper at the position.
4.2 After the full closed position decided, make the pointer on limit switch aligned with the pointer on the curved arm.
(Red points shown on the figure below indicate the pointers)
6) Opened position adjustment :
5.1 Adjust the gate to full opened position and after the position decided, fixed with corresponding mechanical stopper.
5.2 Adjust the gate to full opened position and after the position decided, make the pointer on the electromechanical
limit switch aligned with the pointer on the curved arm. (Red points shown on the figure below indicate the pointers)
1
5
2
7
6
3
8
12
3) Install the motor on the U-shaped fixing
plate with corresponding screws and nuts.
12
9
10
4
13
11
Limit switch
Mechanical
Stopper

ARTICULATED ARM OPENERS USER MANUAL
4
Please kindly notice that the operation of power connection should be carried out by a qualified electrician with
following steps:
1). Make sure the gearmotor is not connected to the power supply before the installation is done.
2). Make sure all the wires are firmly connected.
3). Supply the gearmotor with the power.
2.1 WIRING CONNECTION
1.7 POWER SUPPLY CONNECTIONS
Figure 2(1)
Open Only
Device
Dual / Single
Gate (FJ)
Photocells connection is
detailed on page 5
Flashing
LightLatch
Transformer
Antenna
Green Box
LED Display
Blue LED – RF Learning
LED2 Push button or Key selector
LED3 Photocell 1
LED 4 Photocell 2
UP
SET
SET
DOWN
RF-LEARN
RF-LEARN
LED2LED4LED3
11
Lit+Lit-Lat+Lat-M1+M1-M2+M2-5VS1S2GNDLmt1Lmt2GNDLmt3Lmt4GNDGND Ph1Ph2 PhVccPhVcc GND DKeySKey
26 2425 23 2122 1920 18 1617 15 1314 11 1012 9 8 67 5 34 12

ARTICULATED ARM OPENERS USER MANUAL 5
M1+ M1-
Motor1 Power
2.2.1 STANDARD INSTALLATION
2.2.2 ADVANCED INSTALLATION (MOTOR WITH LIMIT SWITCH)
2.2 MASTER MOTOR IS INSTALLED AT LEFT SIDE
Antenna
M2-M1-
Lat-
Lit- Lmt4Lmt3
Lmt2
Lit+ SKey
S1
M2+
M1+Lat+ Ph2Ph1 PhVcc PhVcc
S25V
ANT
GND
DKey GND
GND GND GND
Lmt1 GND
PC190-PCB1
40121-377-A1
T4
SW3
UP
Q17
J5
SW1
RF-LEARN
RF1
K5
K3
K2K1
J4 J3
J7
F1
DB1
J8
SW4
SET
SW5
DOWN
NC NO
CO
+-
NC NO
CO
+-- +
CO
NONC
- +
CO
NONC
NC NO
CO
+-
-
+
12345678
910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
LED2 LED3
LED4
M1- Limit1 Limit2 GNDM1+
Motor1 PowerLimit Switch
M2- Limit4 Limit3 GNDM2+
Motor2 PowerLimit Switch
Figure 2(2)
Figure 2(3)
Remark:
Limit1, Limit3 (Open limit)
Physical stopper mounted under motor unit (optional) + Driveway gate stopper (optional)
Limit2, Limit4 (Close limit)
M1 M2
M1+ M1-
Motor1 Power
Transformer
Antenna
M2-M1-
Lat-
Lit- Lmt4Lmt3
Lmt2
Lit+ SKey
S1
M2+
M1+Lat+ Ph2Ph1 PhVcc PhVcc
S25V
ANT
GND
DKey GND
GND GND GND
Lmt1 GND
CB19-PCB1
40121-377-A1
+ -
T4
SW3
UP
J1
Q17
R113
R112
R111
R110
R108
R107
R106 R105
R104
R103
R102
J5
SW1
RF-LEARN
RF1
MOV1
K5
K3
K2K1
J4 J3
J7
J2
F1
DB1
J8
SW4
SET
SW5
DOWN
NC NO
CO
+-
NC NO
CO
+-- +
CO
NONC
- +
CO
NONCNC NO
CO
+-
-
+
12345678
910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
LED2 LED3
LED4
M2+ M2-
Motor2 Power

ARTICULATED ARM OPENERS USER MANUAL
6
2.3.1 STANDARD INSTALLATION
2.3.2 ADVANCED INSTALLATION (MOTOR WITH LIMIT SWITCH)
2.3 MASTER MOTOR IS INSTALLED AT RIGHT SIDE
Physical stopper mounted under motor unit (optional) + Driveway gate stopper (optional)
M2+ M2-
Motor2 Power
M1+ M1-
Motor1 Power
M2- Limit4 Limit3 GNDM2+
Motor2 PowerLimit Switch
Antenna
M2-M1-
Lat-
Lit- Lmt4Lmt3
Lmt2
Lit+ SKey
S1
M2+
M1+Lat+ Ph2Ph1 PhVcc PhVcc
S25V
ANT
GND
DKey GND
GND GND GND
Lmt1 GND
PC190-PCB1
40121-377-A1
SW3
UP
Q17
J5
SW1
RF-LEARN
RF1
K5
K3
K2K1
J4 J3
J7
F1
J8
SW4
SET
SW5
DOWN
NC NO
CO
+-
NC NO
CO
+-- +
CO
NONC
- +
CO
NONC
NC NO
CO
+-
-
+
12345678
910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
LED2 LED3
LED4
Antenna
M2-M1-
Lat-
Lit- Lmt4Lmt3
Lmt2
Lit+ SKey
S1
M2+
M1+Lat+ Ph2Ph1 PhVcc PhVcc
S25V
ANT
GND
DKey GND
GND GND GND
Lmt1 GND
PC190-PCB1
40121-377-A1
+ -
T4
SW3
UP
J1
Q17
R113
R112
R111
R110
R108
R107
R106 R105
R104
R103
R102
J5
SW1
RF-LEARN
RF1
MOV1
K5
K3
K2K1
J4 J3
J7
J2
F1
DB1
J8
SW4
SET
SW5
DOWN
NC NO
CO
+-
NC NO
CO
+-- +
CO
NONC
- +
CO
NONC
NC NO
CO
+-
-
+
12345678
910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
LED2 LED3
LED4
M1- Limit1 Limit2 GNDM1+
Motor1 PowerLimit Switch
Figure 2(5)
Figure 2(6)
Remark:
Limit1, Limit3 (Close limit)
Limit2, Limit4 (Open limit)
M1M2
AC INPUT
1
1
23456

ARTICULATED ARM OPENERS USER MANUAL 7
2.5 SYSTEM LEARNING PROCESS
2.4 TRANSMITTER MEMORIZING AND ERASING PROCESS
(A) Transmitter Memorizing: Press and hold the “RF-LEARN” button on the PCB for 1 second and then the blue LED
indicator on the RF board will be “ON”. Press A button for dual-gate installation ; press B button for single-gate
installation on the transmitter within 5 seconds. The transmitter learning is completed
when the blue indicator blinks 3 times and turns OFF.
(B) Transmitter Memory Erasing: Press and hold the “RF-LEARN” button on the PCB for 10 seconds until blue LED off.
(C) One radio receiver can be memorized with 200pcs of transmitters.
Step1: Connect the master motor wires to M1 terminals and the slave motor wires to M2 terminals correctly.
If only one gate is installed, the motor wires have to be connected to M1 terminals.
Step2: Set the function F2-1 for dual gate learning; or set the function F2-2 for single gate learning.
Step3: To start dual gate system learning.
To start dual gate system learning:
Press and hold the "SET+DOWN" button on the PCB for 3 seconds. The LED display will show “LEA” and process the
system learning automatically. Do not interrupt this procedure by pressing the remote or stop the gate. In system
learning mode, the gate will proceed with the following procedure figure on page 8.
The LED display will show “RUN”, once the system learning is complete.
To single dual gate system learning:
Press and hold the "SET+DOWN" button on the PCB for 3 seconds. The LED display will show “LEA” and process the
system learning automatically. Do not interrupt this procedure by pressing the remote or stop the gate. In system
learning mode, the gate will proceed with the following procedure figure on page 8.
The LED display will show “RUN”, once the system learning is complete.
Press
3 Sec
1 2
1314
LED1
LED2
LED3
ON
OFF
UP
SET LEA
3
RUN

ARTICULATED ARM OPENERS USER MANUAL
8
2.6 DUAL/SINGLE GATE OPERATION
SYSTEM LEARNING IN PROCESS
Press the button “A” on the transmitter for dual-gate operation.
Press the button “B” on the transmitter for single-gate
operation in either single-gate or dual-gate installation.
2.7 RESTORE DEFAULT SETTING
Press and hold “UP+SET+DOWN” button on the PCB for 5 seconds. The system will restore to the default setting
without any system learning memory.
A. Dual Gate:
Slave Gate Close → Master Gate Close → Master Gate Open → Slave Gate Open →
Slave Gate Close → Master Gate Close
B. Single Gate :
Master Gate Close → Master Gate Open → Master Gate Close
1
1
5
2 3
1 2 3
4
6
2 3
1 2 3
4 5 6
Notes:
(A) System learning fails and needs to be learned again when an unpredictable interruption occurs.
(B) Once the system learning is completed, there is no need to proceed with the learning process again when there isa
power failure.
(C) While using limit switch mode, please make sure the motor hit limit switch when it’s in deceleration speed.
A B

ARTICULATED ARM OPENERS USER MANUAL
9
2.9 GATE-MOVING LOGIC
(A) In gate-opening phase: The gates stop if the transmitter/push button/key selector is activated, and close when
the transmitter/push button/key selector is reactivated.
(B) In gate-closing phase: The gates stop if the transmitter/push button/key selector is activated, and open when
the transmitter/push button/key selector is reactivated.
(C) In gate-opening or gate-closing phase: For safety purpose, the gates stop if encountering obstacles.
2.10 CHECKING THE GATE MOVEMENT
1). Release the gearmotor with the release key and move the gate to the middle so that it is free to move in both
opening and closing directions; then lock the gearmotor.
2). Perform the gate opening and closing several times and make sure the gates reaches the limit switch at least
2~3 centimeters before the mechanical stop.
Blue LED on receiver board: Blinks three times when remote learning is completed.
LED2 External device : If the switch of the key selector, or the push button is activated, LED2 will be on.
LED3 Photocells 1 : LED3 will be on when the first pair of the photocells are activated.
LED4 Photocells 2 : LED4 will be on when the second pair of the photocells are activated.
Antenna
M2-M1-
Lat-
Lit- Lmt4Lmt3
Lmt2
Lit+ SKey
S1
M2+
M1+Lat+ Ph2Ph1 PhVcc PhVcc
S25V
ANT
GND
DKey GND
GND GND GND
Lmt1 GND
PC190-PCB1
40121-377-A1
SW3
UP
Q17
J5
SW1
RF-LEARN
RF1
K5
K3
K2K1
J4 J3
J7
F1
J8
SW4
SET
SW5
DOWN
NC NO
CO
+-
NC NO
CO
+-- +
CO
NONC
- +
CO
NONC
NC NO
CO
+-
-
+
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
LED2 LED3
LED4
2.8 LED INDICATION
2.11 MEANING OF LED DISPLAY
LED Display Programmable Functions LED Display Programmable Functions
The memory of the system is all
deleted/cleaned by press and hold the
UP + SET + DOWN button together for 5s
and the panel will be back to default settings.
The motor is operating to open direction.
The motor is stopped.
The motor is operating to close direction.
[LEA] means motor into the
system learning mode, do not
interrupt during this procedure.
[D-G] means motor completed
the learning procedure for dual
gate installation.
[S-G] means motor completed
the learning procedure for
single gate installation.

ARTICULATED ARM OPENERS USER MANUAL 10
3. ADVANCED FUNCTION PARAMETER SETTING
For exmple: How to set the function “F1-0”; the steps are following:
(1) Press the “SET” button for 3seconds then releases it, and the
system enters the first option. The LED will display “F1” (*) as the
right hand-side picture.
(*) If you would like to enter “F2” function or others as the first option,
please press the “UP” button to adjust F2~F8 until you get “F2”.
1.
3.1 HOW TO CHANGE
Step Operations LED Display after the Step
(2) After completing the operation (1), then press the “SET” button
again, you will enter the second option as the right hand-side picture.
And you will see the third number for the second option.
(3) Continually press the “Down” button until you search the function
“0” (**) of F1 as the right hand-side picture. “F1-0” is set completely.
(**) If you would like to set one of functions “0 ~ 8” as the second
option, please press the “UP” or “Down” button to adjust it.
(4) If you would continue setting up the next functions, please press
“SET” to return the first option, like F1 or F2 or F3…or F8.
For example, after complete “F1-0” setting. You would continue
setting “F2-5”, please press “SET” to return the formal option. The
LED display shows the first two numbers as as the first option as the
right hand-side picture, “F1”. And then follow the operation (*) and (2)
~ (3) until you get “F2-5” as the right hand-side picture. “F2-5” is set
completely.
After setting all functions you need, then wait for 10seconds, the LED
will display “RUN”. And you can use transmitter to operate the gate.
2.
3.

ARTICULATED ARM OPENERS USER MANUAL
11
3.2 ADVANCED FUNCTION PARAMETER
Note(F3 Setting is for F1-3 Motor with Hall sensor):
Only in “F1-3”Hall sensor mode, the PCB will record all the current value while learning mode. Please set F3 function
after learning mode. The LED display 10 to indicate all of the recorded values will increase 1 ampere as the over current
value. In other words, the LED shows 20 to indicate all the recorded values will increase 2 ampere as the over current
value. The value can be adjusted by pressing button UP and DOWN. The maximum value is 40(4.0A) and the minimum
value is 05(0.5A).
LED Display Definition Parameter Table Description
Motor Type
Dual or Single Gate
Over Current Setting
Over Current Setting
Operation Speed
Deceleration function
Deceleration Speed
Open/Close delay of dual
gate operation adjustment
Auto-Close adjustment
Photocell function mode
Pedestrian Mode function
Pre-Flashing function
F1
F2
F3
F3
F4
F5
F6
F7
F8
F9
FA
FB
F1-1
F1-2
F1-3
F2-1
F2-2
F3-1
F3-2
F3-3
F3-4
F4-1
F4-2
F5-1
F5-2
F6-1
F6-2
F7-1
F7-2
F7-3
F7-4
F7-5
F7-6
F7-7
F7-8
F7-9
F8-0
F8-1
F8-2
F8-3
F8-4
F8-5
F8-6
F8-7
F8-8
F9-1
F9-2
F9-3
F9-4
FA-0
FA-1
FB-0
FB-1
Motor only
Motor with Limit Switch
Motor with Hall sensor
Dual Gate
Single Gate
2A
3A
4A
5A
100% Full speed
80% Full speed
Function ON
Function OFF
70% Full speed
50% Full speed
2 sec
3 sec
4 sec
5 sec
6 sec
7 sec
8 sec
9 sec
10 sec
Function OFF
3 sec
10 sec
20 sec
40 sec
60 sec
120 sec
180 sec
300 sec
Mode 1
Mode 2
Mode 3
Mode 4
Function OFF
Function ON
Function OFF
Function ON
1. The factory setting is "F1-1".
1. The factory setting is "F2-1".
1. The factory setting is "F3-4",
2. F3 setting is for F1-1 Motor only and F1-2 Motor with
Limit Switch
1. The factory setting is "F4-1".
1. The factory setting is "F5-1".
1. The factory setting is "F6-2".
1. The factory setting is "F7-1".
1. Auto-close mode activates when the gates move to
the end position or stopped manually. If the transmitter,
push button, or the key selector is activated before the
auto-close counting, the gate will close immediately.
2. The factory setting is "F8-2".
1. The factory setting is "F9-1".
1. When funciton on and push B key in the transmitter,
one gate will open partically.
2. The factory setting is "FA-1".
1. When function ON, the light will flash before the gate
operate 3 seconds. If set OFF, the flash light will operate
with motor in the same time.
2. The factory setting is "FB-0".

ARTICULATED ARM OPENERS USER MANUAL
12
LED Display Definition Function Table Description
Photocell 1 function
Photocell 2 function
Buzzer function
Latch release function
Open/Stop/Close/Stop
function key
Pedestrian Mode function key
Auto-Close function Key
Dual/single gate on Skey
terminal
To release the tension at fully
close position, motor will
reverse for (over current)
FC
FD
FE
FF
FG
FH
FI
FJ
FK
FC-0
FC-1
FD-0
FD-1
FE-0
FE-1
FF-0
FF-1
FG-1
FG-2
FG-3
FG-4
FH-0
FH-1
FH-2
FH-3
FH-4
FI-0
FI-1
FI-2
FI-3
FI-4
FJ-0
FJ-1
FK-0
FK-1
FK-2
FK-3
FK-4
FK-5
FK-6
Function OFF
Function ON
Function OFF
Function ON
Function OFF
Function ON
Function OFF
Function ON
A Key
B Key
C Key
D Key
Function OFF
A Key
B Key
C Key
D Key
No key to control
A Key
B Key
C Key
D Key
Dual gate
single gate
No reverse
0.1 sec
0.2 sec
0.3 sec
0.4 sec
0.5 sec
0.6 sec
1. The factory setting is "FC-0".
1. The factory setting is "FD-0".
1. The factory setting is "FE-1".
1. If the function on, the gate will move forword a little before the
gate operate for releasing the latch.
2. The factory setting is "FF-1".
1. The factory setting is "FG-1".
1. The factory setting is "FH-2".
1. The key is to turn on or off the Auto-Close function.
2. The factory setting is "FI-3".
3.When the flasher and buzzer is running, the auto closed
button has no function till flasher and buzzer finish running.
1. Function activated when Skey teminal is connected
2. The factory setting is "FJ-0".
1. The factory setting is “FK-3”

ARTICULATED ARM OPENERS USER MANUAL 13
The safety photocells are security devices for control automatic gates. Consist of one transmitter and one receiver
based in waterproof covers; it is triggered while breaking the path of the beams.
INSTALLATION:
Wire Connection of Photocells
TX: Connect terminals 1 and 2 on the transmitter with the terminals GND and PhVcc on the PC190 PCB.
RX: Connect terminals 1,2 and 4 on the receiver with the terminals GND, PhVcc, and Ph1/Ph2 on the PC190 PCB.
And use an extra wire to connect terminals 2 and 5 on the receiver as a bridge.
Detection Method
Sensing Range
Input Voltage
Response Time
Emitting Element
Operation Indicator
Dimensions
Output Method
Current Consumption Max
Water Proof
Through Beam
25M
AC/DC 12~24V
100MS
IR LED
Red LED(RX): ON(When Beam is Broken), Green(TX):ON
96*45*43mm
Relay Output
TX: 35MA/Rx: 38MA (When beam aligned properly);
TX: 35MA/ Rx: 20MA (When beam is broken)
IP54
SPECIFICATION:
Figure 1(2)
Figure 1(1)
4. PHOTOCELL INSTALLATION
RX
Lens
Beam Alignmnet
Indicator
Power Led
Indicator
Terminal Block
Power
Terminal Block
TX
1 2 3 4 5 1 2

ARTICULATED ARM OPENERS USER MANUAL
14
Figure 1(3)
SKey Ph2Ph1 PhVcc PhVccDKey GND GND
19 20 21 22 23 24 25 26
1 2 3 4 5
COMNCNO+
-
+
-
1 2
RX1TX1
1 2 3 4 5
COMNCNO+
-
+
-
1 2
RX2 TX2

ARTICULATED ARM OPENERS USER MANUAL 15
4.1 PHOTOCELL WORKING LOGIC ADJUSTMENT
The actions of the photocells safety edge loop detector when they detecting obstacles.
F9-1 Photocell OPEN/CLOSE (Standard set up)
Type of Safety Device
FULLY CLOSED
FULLY OPENED
STOP DURING MOVING
CLOSING
OPENING
PH1
Photocell-CLOSE
No effect
Reload automatic closing time
Reload automatic closing time
Open
No effect
PH2
Photocell-OPEN
Open not allowed
No effect
Open not allowed
No effect
Close
Position of Gate When safety devices are activated
F9-2 Safety Edge
Type of Safety Device
FULLY CLOSED
FULLY OPENED
STOP DURING MOVING
CLOSING
OPENING
PH1
Photocell-CLOSE
No effect
Reload automatic closing time
Open
No effect
Reload automatic closing time
PH2
Safety Edge
Open not allowed
OPEN/CLOSE not allowed
Reverse to open for 2 seconds
Reverse to close for 2 seconds
Position of Gate When safety devices are activated
F9-3 Open Only Device (Vehicle detector)
Type of Safety Device
FULLY CLOSED
FULLY OPENED
STOP DURING MOVING
CLOSING
OPENING
PH1
Photocell-CLOSE
No effect
Reload automatic closing time
Open
No effect
Reload automatic closing time
PH2
Opening Device
Open
Open
Open
No effect
Position of Gate When safety devices are activated
F9-4 Double photocell set up
Type of Safety Device
FULLY CLOSED
FULLY OPENED
STOP DURING MOVING
CLOSING
OPENING
PH1
Photocell-CLOSE
No effect
Closing in 2 sec after activation
Close not allowed
Open
No effect
PH2
Photocell-OPEN/CLOSE
Open not allowed
No effect
Open not allowed
No effect
Close
Position of Gate When safety devices are activated

ARTICULATED ARM OPENERS USER MANUAL
16
OFF ON
Green Box
5+
Cable AC out
AC in
Green Box is for purpose when gate opener is in standby mode to allow it enter the power saving mode.
Installation manner:
AC IN: connect the electricity
AC OUT: connect the power of gate opener, and connect the transformer
5V CABLE: connect 3 pins white socket of control board
Please make sure the switch of Green Box is off before proceeding the system learning and installation of device.
Wait for the system learning and installation of device to be completed, power on the Green Box
Gate opener will enter power saving mode without receiving any instruction in 1 min, and red LED light on Green Box
will be activated. Gate opener start the operation, red LED light and power saving mode will turn off.
CAUTION:
In case of loop or installation of photocell which need power consumption anytime, please do not install Green Box.
5. GREEN BOX INSTALLATION (OPTIONAL)

ARTICULATED ARM OPENERS USER MANUAL 17
7. TECHNICAL FEATURES
7.1 DIMENSION
Overheated Back-up Batteries
The gate doesn’t move when pressing the
button of the transmitter
The gate only moves a little distance when
pressing the button of the transmitter.
The transmitting distance is too short
The gear motors run very slowly
The Flashing light does not work
The leaves shall be closed instead of opening
The leaves suddenly stop during moving
The leaves does not move or only move toward
one direction
The master gate closes to the end first and the
slave gate stops, the flashing light blinks fast for
five seconds.
The gear motors does not run and the relay is
noisy when operating the gate opening and
closing
Check the wiring connection of the batteries.
1. Check if LED3 or 4 is “OFF”.
2. Check if the voltage of the batteries is upon 22V.
3. Make sure all the wiring connections are firmly connected to the
terminals on the PCB.
4. Make sure the fuse is workable.
Make sure the wiring connection of the hall sensor is firm.
Make sure the connecting terminals of the
Antenna is firm.
Check the dip switch setting of the speed adjustment.
Check if the wiring connection of the flashing light is correct.
Change the polarity connection of the positive (+) with the negative (-)
of the gear motors.
1. Check if the “RESET” socket is activated.
2. Make sure the wiring connection of the gear motors is firm.
3. Make sure the hall sensor wiring connection is firm.
4. The GND terminal of the photocells on the PCB must be
short-circuited if no photocells installed.
5. Make sure the fuse is workable.
1. Check if the “RESET” socket is activated.
2. Make sure the wiring connection of the gear motors is firm.
3. Make sure the hall sensor wiring connection is firm.
4. The GND terminal of the photocells on the PCB must be
short-circuited if no photocells installed.
Cut off the AC input power and the output of the batteries. Release the
master gate and slave gate manually, then open the master to the end
and close the slave gate to the end by hand, then power the whole unit
by connecting the AC and battery terminals.
Check if the fuse is burned.
6. TROUBLE SHOOTING
190mm250mm
255.2mm

18
8. MAINTENANCE
Conduct the following operations at least every 6 months. If in high intensity of use, shorten the period in between.
Disconnect the power supply:
(1) Clean and lubricate the screws, the pins, and the hinge with grease.
(2) Check the fastening points are properly tightened.
(3) Make the wire connection are in good condition.
Connect the power supply:
(1) Check the power adjustments.
(2) Check the function of the manual release.
(3) Check the function of photocells or other safety devise.
7.2 TECHNICAL FEATURE:
Model
Motor
Gear type
Nominal thrust
Maximum Gate Weight
Maximum Gate Length
Operating Temperature
Dimension
Weight
PAPILLON 250
24Vdc motor
Electromechanical worm gear
2500N
250 kg per leaf
2.5 meters per leaf
-20oC~+50oC
256 x 187 x 267mm
6 kg
Model
Main power supply
Back-up battery
Receiver board
Installation
Operating Temperature
Dimension
CB19
230Vac/110Vac, 50Hz/60Hz
2pcs of batteries for emergency operation, 1.2A each
433.92MHz; 200 transmitters memory
Built - in PCBA
-20oC~+50oC
275mm x 195mm x 102mm
