Chamberlain ART200K User manual

en-1
CARTON CONTENTS ART200K
Drive motors 2x
Release key 2x
Box for control 1x
Cover for box 1x
Hinges for box 4x
Control 1x
Transformer 1x
Baseplate For Transformer 1x
Remote control 1-2x*
Radio receiver 1
Radio module 1x
Hardwarebag For Box 1x
Pillar fittings 2x
Gate fittings 2x
Door arm 2x
Hardwarebag 1x
Instructions 1x
Flashing light 1x
Key switch 1x
Photocells 1x
* depending on model resp. available as optional accessory
INSTALLATION CHECKLIST - PREPARATIONS
Check the carton contents and read the instructions carefully. Make sure your gate equipment operates perfectly. The gate must run evenly and
smoothly and must not stick at any point. Remember that the ground level may be several centimeters higher in winter. The gate must be stable
and as free of backlash in order to prevent any unwanted movement. The easier the gate movement the less power is needed by the motor.
Write down any materials you still need and obtain them before starting to install. Heavy-duty plugs, bolts, gate stops, cables, distribution boxes,
tools, etc.
PLEASE START BY READING THESE IMPORTANT SAFETY RULES • SAVE THESE INSTRUCTIONS
This safety alert symbol means "Caution" - failure to comply with such an instruction involves risk of personal injury or
damage to property. Please read these warnings carefully.
This gate drive mechanism is designed and tested to offer appropriately safe service provided it is installed and operated in
strict accordance with the following safety rules.
Incorrect installation and/or failure to comply with the following instructions may result in serious personal injury or property
damage.
Installation and wiring must be in compliance with
your local building and electrical installation codes.
Power cables must only be connected to a properly
earthed supply.
Any entrapment possibility by the moving wing
between wing & walls must be secured with safety
edges or IR-sensors.
Disconnect electric power to the system before making
repairs or removing covers.
A disconnecting device must be provided in the
permanently-wired installation to guarantee all-pole
disconnection by means of a switch (at least 3mm
contact gap) or by a separate fuse.
When using tools and small parts to install or carry
out repair work on a gate exercise caution and do not
wear rings, watches or loose clothing.
Make sure that people who install, maintain or operate
the gate drive and/or the control board are qualified and
follow these instructions.
Keep these instructions in a safe place so that you can
refer to them quickly when you need to.
Please remove any locks fitted to the gate in order to
prevent damage to the gate.
Frequently examine the installation for imbalance and
signs of wear or damage to cables, hardware and
mountings. Do not use if repair or adjustment is
necessary. Gates which stick or jam must be repaired
immediately. Employ a qualified technician to repair the
gate, never attempt to repair it yourself.
Keep additional accessories away from children. Do not
allow children to play with pushbuttons or remote controls.
A gate can cause serious injuries as it closes.
After the installation a final test of the full function of
the system and the full function of the safety devices
must be done.
The full protection against potential squeeze or
entrapment must work direct when the drive arms are
installed.
This drive cannot be used with a gate incorporating a
wicket door unless the drive cannot be operated with
the wicket door open.
IMPORTANT FITTING AND OPERATING INSTRUCTIONS
WARNING / ATTENTION
Intelligent Security & Fire Ltd.

3x
en-2
BEFORE YOU BEGIN: The ART is suitable for use with wide pillars, up to about 30cm in width.Width of doorwing must comply with chart.
The maximum recommended opening angle of the gate is 105 degrees. Ensure that ample space is available next to the drive for the arms and
assembly. Gates exposed to a high wind load must be fixed with an electric lock for additional protection. Gate stops must be installed
There are many important factors when deciding on the correct motor. Assuming a well functioning gate, the initial force is the most difficult
moment. When the gate is moving it generally requires a considerably smaller amount of force.
Gate Size: Gate size is an important factor. Wind can slow down gate or distort it, leading to higher amount of required force.
Gate weight: Specification of gate weight represents only a rough parameter, which can vary according to actual demand. Operation is
important.
Influence of temperature: Low outdoor temperatures can impede or even prevent starting torque (ground deformation etc.). High outdoor
temperatures can lead to premature initiation of temperature protection (approx. 135°)
Attention: Motors are not designed to run continuously (continuous operation). The motor warms up and can reach a temperature at which it
shuts down until operating temperature is reached again. Outside temperature and gate represent important parameters for actual operating
duration.
AVAILABLE INSTALLATION ACCESSORIES
1. 041ASWG-0482-50 50m roll of installation cable, 6-pole for
outdoor use, Laying possible without
cable duct with the identical wire colours
as motor
2. LA400-JB40E Kit for cable extension of one installation
unit. Consists of 12m of cable 6-pole with
identical colours, distribution box IP65,
cable screw joints and fastening material
3. E-lock 203285 (12Volts)
4. Transformer for E-lock 207399
5. Floor locking 203339 (in combination with E-lock)
6. Stops for wings 203315 (standard) and 203322
(high)
7. Safety edge 600046 2.5m set of safety edge
(profile & rail)
600053 20m of rubber profile (small)
600077 20m of mounting rail
600077-1 2m of mounting rail
600060 Assembly pack is required for
each safety edge
8. IR Sensor stand 600008 single, height 530mm
9. Emergency Stop switch 600084 plastic enclosure, IP65
10. Keyswitch 100034 2-Function, flush-mount
100041 2-Function, surface-mount
11. External Antenna ANT4X-1LM
12. Remote Controls 94330E 1-channel
94333E 3-channel
94334E 4-channel, mini
94335E 3-channel, mini
13. Wireless keypad 9747E
14. Base plate slim ART-6
TECHNICAL DATA:
Motor voltage 24V
Nominal power 10W
Max. power 40W
Current nom. 0,5A
Current max. 1,3A
Torque max. 200Nm
Opening time 90° ~16 sec.
Cycles/h ~ 20
Consecutive cycles max. 8
Operating temperature -20°C - +55°C
Degree of protection IP44
Weight 8kg
2
3
4
5
6
7
8
9
10
11
12
13
1
14
Intelligent Security & Fire Ltd.

en-3
GATE TYPES
The location of the motor installation depends on the type of gate.
If the gate stop is on the floor the motor should also be installed as
low as possible in order for the gate not to be distorted. Only use
frame elements for fastening.With steel gates the fittings should be
fastened to the main frame. If you are not sure about the stability of
the frame in question then reinforce it.
With wooden gates the frame has to be drilled through
completelywhere the fittings are to be fastened. Attaching a plate
from the outside is recommended in order to prevent fastening from
becoming loose. Thin wooden gates must be reinforced additionally
as they do not withstand the strain otherwise.
GATE CONFIGURATION
The ART is suitable for use with wide pillars, up to about 30cm in width. The amount of room around the pier affects the opening angle and the
position of the arms.
2 A B
C D
E F
GATE STOPS
A SWING GATE NEEDS A FIXED GATE STOP IN BOTH THE OPEN AND
CLOSE POSITIONS. Gate stops save wear and tear on the motor, gate and
fittings. Operating a gate without fixed limit stops results in poor performance. It is
often dangerous, leads to premature wear and voids your warranty!
900900
Max gate width/weight
Max gate height
2,5m per wing / 150Kg
2,0m per wing / 200Kg
1,5m per wing / 250Kg
1,5m
Specifications calculated without windload
A=38,5cm
8,5cm 30cm
C
B=60-70cm
ca.
7-8 cm = 90°
max. 10 cm
=
90 o90 o
105° 105°
Intelligent Security & Fire Ltd.

en-4
BASE PLATE
Select and mark the mounting height on the pier.
Finding the right mounting position. Mount the drive on the pier and
attach it to the gate. The drive exerts a great amount of force on the
pier. A steel pier will provide the most stability. Welding the supplied
hinge plate directly on to the pier will generally provide enough room
for mount. In the case of thick brick or concrete pillars, the hinge
plate should be welded onto a support plate, that is mounted in such
a way that the plugs cannot work loose. Adhesive shear connectors
are better than steel or plastic wedge anchors for this purpose. A
threaded rod is then mounted into the masonry with a stress free
adhesive seal. A watertight distribution unit should be mounted on
the pier next to the hinge plate. The feed cable for the wing gate
opener is led into this unit from underneath.
GATE FITTING
With steel gate the fastenings should either be welded on or drilled
through completely. If drilling then attach large washers or a plate to
the back of the frame.With wooden gates the gate frame has to be
drilled through completely where the fittings are to be fastened.
Attach reinforcement plate on the outside and inside of the gate in
order to prevent wood from giving and the connection to become
loose.
Thin wooden gates without metal frame must be reinforced
additionally, as they do not withstand the strain otherwise.
Before installing the gate fitting, check if you measured the right
position for it. Adjust if needed.
Attach gate fitting with a c-clamp or mark its designated position.
To compare, open the gate to designated OPEN position.
Now finally mont gate fitting.
Mount operator and run cable the right way
Once the base plate has been mounted, the drive can then be fitted.
The drives can be used left or right without requiring conversion. For
the purposes of fitting the drive, the lock screws need to be re-
inserted and tightened up.
Several openings for the cable have been pre-punched in the base
and need only be broken through, as required. The drive must be
standing on a solid surface for the purposes of breaking the holes
through to prevent the PVC base plate from breaking. A small, flat
screwdriver should be used for breaking the holes through. For this
purpose, tap on the screwdriver handle with the palm of the hand
from the inside. Repeat this as necessary at several points on the
pre-marked circle. The pre-punched area can then be easily
removed and the strain relief supplied as standard fitted in its place.
Intelligent Security & Fire Ltd.

en-5
RELEASE/ MANUAL GATE OPERATION
The release lock for the casing is located under the rubber waterproof
cover. Use the socket spanner supplied in the hardware bag to lift the
cover up. The release key located beneath the hood should be
inserted into the side openings and turned approx. 180 degrees until
it cannot turn any further. The drive has now been released. To re-
engage it, the key should be turned back to its original position.
Take care when unlatching the drive for manual operation. The
door leaf can move in an uncontrolled way, especially if it is
defective and not properly balanced.
Before initial operation check if operator does not come in contact
with the gate in the fully OPEN position.
SWITCHES, CAMS AND RIGHT ADJUSTMENT
There is a small switch operated by a cam under the operator’s
cover. The cam rotates simultaneously to the operator and pushes
the switch temporarily. The cam can be adjusted (rotated). (Tight)
Deinstallation is not required.
Use pliers or a big screwdriver to adjust (see picture).
RIGHT ADJUSTMENT
Gate closed: switch free
Gate at approx. 45°: switch fully pushed (cam operates
switch)
Gate open: switch free
4
+
TYPICAL CONFIGURATION OF A UNIT:
1. Motor
2. Control board
3. Photocell (active for closing), max. height 200 mm
First photocell.
4. photocell (active for opening and closing), max. height 200 mm
Second photocell (optional).
5. Flashing light (optional)
Important visual information on the movement of the gate.
6. Key-operated switch or wireless keypad (optional)
Is mounted on the outside. The gate is opened by key or by
entering a number.
7. Contact strip (optional)
Safeguards the gate on being touched. Contact strips can be
mounted on the gate or on the pillars. If required, contact strips
must be mounted at a height of up to 2.5m.
The control board complies with the latest EU
guidelines. One of these guidelines specifies that the
closing forces at the gate edge must not exceed 400 N (40 kg) for
the last 500 mm before the door is CLOSED. Above 500 mm, the
maximum force at the gate edge must not exceed 1400 N (140
kg). If this cannot be ensured, a contact strip must be mounted on
the gate at a height up to 2.5 m or on the pillar on the opposite
side (EN12453).
Note: The listed accessories on page 2 are especially suited for the professional
installation of a gate system.
Intelligent Security & Fire Ltd.

en-6
INSTALLATION OF CONTROL BOX
The control consists of several components which are fitted together
and are screwed into the box. Precision is important.
Complete the electrical installation (wiring, supply etc.) before turning
your attention to this point.
Find the following parts in the control box:
- Remote control 1-2x*
- Exterior installation box 1
- Cover for box 1
- Control 1
- Transformer 1
- Baseplate for transformer 1
- Radio receiver 1
- Radio module 1
- Cable bushing large 1
- Cable bushing small 1
- Flat washer 5
- Screws 3,5x 9,5 mm 17
* depending on model resp. available as optional accessory
PREPARING THE CONTROL BOX
Open the 4 pre-cut holes at the bottom of the casing with a
screwdriver or a similar device.
Attach large cable bushing on the left then the rest as shown in
picture.
Humidity and water destroy the control. All openings and cable
bushings must be sealed against water (waterproof). The control box
with the motor control is to be mounted with the cable bushings
facing down.
RECOMMENDED PROCEDURE:
A. Fasten control box of casing to wall, after previously measuring
required distances and establishing correct position of drill-holes.
(Hardware not included)
B. Fasten baseplate for transformer in casing. (Screws 3.5 x 9.5mm)
C. Fasten transformer on to baseplate; do this using 4 screws
( Screws 3.5 x 9.5mm). On the right hand side of transformer
there is sufficient space for a second transformer( Screws 3.5 x
9.5mm), which can control locking of a 12Volts E Lock.
(accessories).
Attach short earthing cable (yellow/green) to the plate using a
screw and a washer.
D. Attach logic board underneath baseplate; do this using 5 screws
and fasten in the box at the marked positions. Before that pull all
plug ins from their sockets. A small bag contains jumpers for the
control. These might be needed later on individual settings in the
controls’ programming. (refer to JUMPERS)
Put the 4 large closure screws of the box through cover of the
box. Fasten 2 of them (left or right) approx 2cm into the box. After
that the cover may be opened to the side.
Close box on a trial basis turning the screws all the way in. If the
lid does not close completely, then the box is not fitted to the wall
evenly and is therefore distorted. This must be corrected. It is very
important for the box to be waterproof once closed.
A
B
C
D
X 5
Intelligent Security & Fire Ltd.

en-7
TECHNICAL DATA OF MOTOR CONTROL:
Voltage 230VAC
Transformer 230/24VAC minimum60VA
Output motor 24VDC max.
Supply accessories 24VDC - 100mA
Operating temperature -20°C - +55°C
Degree of protection IP54
30VDC
MOTOR
MASTER
+-
MOTOR
SECOND
24V/150mA BRN GRN WHT YEL
MASTER
BRN GRN WHT YEL
SECOND
COM PHOTO
1 2
COM STOP/*
8.2
Ω
DIAGNOSTIC
LEARN
PHO1
PHO2
STOP/8.2K
JP2
JP1
OPEN / PED
1/2 MOTOR
STOP/8.2K
P1 P2 P3
LN
250V/2A
250V/2A
TRANSFORMER
230VAC INPUT
24VAC
RADIO
801719
/ LAMP
Ω
8.2
+
+-
RED
RED
BLUE
BLUE
230VAC
+
+
+
Ω
+
PE
PE
WIRING OF CONTROL / SUMMARY
a) start with still dead 230Volts supply cable on the left side of the box.
b) Attach cable eye to ground wire. Then connect ground wire to base
plate with washer and nut (exactly as shown in picture detail).
Connect all other cables to control.
Attention:Check repeatedly that cable colours are connected correctly
to motor. Otherwise motor might be damaged or will not operate
properly. Pay special attention when using distribution boxes.
We recommend the following accessories: LA400-JB40E Kit for
cable extension of one installation unit. Consists of 12m of
cable 6-pole with identical colours, distribution box IP65,cable screw
joints and fastening material
Intelligent Security & Fire Ltd.

en-8
DESCRIPTION OF PUSH BUTTONS
P1 button to program “simple” mode
P2 button to program “individual” mode
P3 button to program “Timer to close”
Description of LED’s (light-emitting diode)
Description Colour Function
STOP/8.2KOhms green monitors emergency switch
or safety edge
ON: blocks control board
OFF: OK
“Key symbol” red key switch
ON: key switch is operating
OFF: key switch is not
operating
PHO2 red Photocells 2
ON: OK (active)
OFF: no photocell fitted
PHO1 red Photocells 1
ON: OK (active)
OFF: no photocell fitted
LEARN yellow learn mode indication
ON: learn mode active
OFF: learn mode inactive
DIAGNOSTIC red diagnosis mode
Refer to FAQ’s
DESCRIPTION FUNCTION
L Connector L 230V supply
N Connector N 230V supply
Battery Connector for a battery kit +/-
475E + 041ADBL-0115
Motor MASTER motor 1 (master opens first)
Motor SECOND motor 2 (Second opens second)
24V/150mA Flashing light (accessory)
MASTER Motor1
BRN brown cable
GRN green cable
WHT white cable
YEL yellow cable
SECOND Motor2
BRN brown cable
GRN green cable
WHT white cable
YEL yellow cable
“Key symbol” key switch
COM negative pole
PHOTO1 Photocells 1
PHOTO2 Photocells 2
COM negative pole
STOP 8.2KOhms connector for emergency switch or
safety edge with 8.2KOhms
RADIO connection for 801719 radio receiver
E-lock symbol connection for E-lock control board
INPUT 24VAC 24V power input from transformer.
Can be connected with any polarity.
Transformer 230VAC 230V supply to transformer. Can be
connected with any polarity.
250V/2A Fuse 250V/2A (2x included)
Only modify settings when control bord
is disconnected. Otherwise modifications will
not be accepted!!!
Intelligent Security & Fire Ltd.

en-9
+-COM PHOTO
1 2
COM STOP/*
8.2
Ω
KEY SWITCH (OPTIONAL)
The system can be operated by key switch. It is possible to operate
only 1 wing or two wings. This depends on how the JUMPERS are
used (connectors: key symbol and COM)
+-COM PHOTO
1 2
COM STOP/*
8.2
Ω
+-
+-COM PHOTO
1 2
COM STOP/*
8.2
Ω
Ω
8.2
+-
Ω
8.2
+
+
+
+
+
E-LOCK (OPTIONAL)
The control board allows the use of a 12V E-lock. (instructions
included with E-lock).
A support board must be connected for the E-lock on the main
board.
Attach support board next to the transformer on to the baseplate
using screws.
Open its casing and make all necessary electrical wiring.
Plug support board in to where the E-lock symbol is depicted.
+-
P1 P2 P3
PHOTOCELLS (OPTIONAL)
The photocells are for safeguarding the gate and must be used. The
fitting location depends on the gate’s design. EN12453 specifies that a
pair of photocells must be installed at a height of 200 mm and activated
to “Close”. The photocells consist of a transmitter and a receiver and
must be opposite each other. The photocell is mounted on the wall
using small screws and wall plugs. To enable the “Automatic Closing”
function, the Chamberlain failsafe photocell must be installed. The
Chamberlain failsafe system (2-cable system) has small LEDs (light)
that can be seen from the outside on both sides to indicate the status
of the photocell.
Diagnosis at the Chamberlain failsafe photocell
LED constant = OK
LED flashes = photocell disables control board
LED off = no current, incorrect connection or polarity
Diagnosis on the control board
LED off = OK no photocell connected
LED on constantly = OK
LED flashes = photocell disables control board
Connection between 1 & COM will give:
ignored when gate is opening, when closing if beam is blocked gate
stops then reopens (does not matter when beam is unblocked).
Connection between 2 & COM will give:
when gate is opening block beam gate stops when you un-block beam
gate caries on opening.
When gate is closing block beam gate stops un-block beam gate
reopens.
SAFETY EDGE (OPTIONAL)
A safety edge working according to the 8.2 kilo ohm principle can be
connected to the control board, i.e. a 8.2 kilo ohm test resistor is
attached to the end of the safety edge. It ensures that the electric
circuit is monitored permanently. The control board is supplied with
an 8.2 kilo ohm resistor installed. Several safety edges are
connected in series.
Cable cross-section: 0.5 mm2or more.
Intelligent Security & Fire Ltd.

en-10
RADIO
There are two small cartons. One of the cartons contains the receiver,
which stores remote control codes. The other one contains the radio
module, which receives the radio signal.
1. connect the smaller radio module with the receiver
Make sure all pins are properly engaged
2. connect the receiver with the control board
Antenna: The receiver includes a short antenna. It should
not come in contact with any cable and should not be rolled
up. It is possible to install an external antenna which
enlarges the operating distance of the remote control
(optional accessory).
PROGRAM / DELETE REMOTE CONTROLS
The receiver has two channels CH1 and CH2. Using the different
channels enables the opening of one wing resp. both wings. For
example, if CH1 receives the code from the remote control only one
wing will open. Choosing a different button on the remote control in
combination with CH2 will cause both wings to open.
In order to store a code press a previously selected button on the
remote control while simultaneously pressing the learn-buttons CH1
or CH2 of the receiver. Repeat for all remote controls.
A maximum of 12 remote controls can be programmed to each
channel.
Note: Make sure not to pogramm the same remote button to CH1
and CH2, otherwise the gate may work improperly. Redo
programming if required.
DELETE
Press learn-buttons (CH1 or CH2) for approx. 10 seconds until LED
goes out. All codes programmed to this channel are deleted.
1 / 2 Motor
1 or 2 motors are connected to the control board.
FREE: both motors connected
LINKED: only one motor connected
STOP / 8.2 KOhms
Defines if connector STOP / 8.2 KOhms is used for an emergency
stop switch or for a safety edge. The emergency stop switch stops
any movement of the system immediately. The safety edge causes
the wings to reverse for one second.
FREE: Factory setting is for 8.2 KOhms. In this case safety edge
must be installed or a 8.2 KOhms resistor must be
connected.
LINKED: used for emergency stop switch, in this case the pre-
installed resistor has to be removed from terminals and
replaced by a suitable switch or terminals have to be
bridged.
Open / Ped
Defines if key switch operates only one wing (Master) or both wings
FREE: only one wing (Master)
LINKED: both wings
JUMPERS
+-
JP2
JP1
OPEN / PED
1/2 MOTOR
STOP/8.2K
Ω
30VDC
MOTOR
MASTER
+-MOTOR
SECOND
24V/150mA BR
/ LAMP
+-
RED
BLUE
FLASHING LAMP (OPTIONAL)
A flashing lamp can be connected to the control board. It warns
when the gate is being moved. The flashing light should be fitted as
high as possible and in good clear view. The control board emits a
constant signal that the lamp converts to a flashing signal.
Cable cross-section: 0.5 mm2or more.
Voltage: 24 V DC
Intelligent Security & Fire Ltd.

en-11
INITIAL OPERATION
BASIC SETTING
Proceed step by step. If you are not sure, start again at the beginning. Take sufficient time to make these settings.
1. Are all components required for operation connected? Motors, photocells, safety contact strip, stop switch.
2. Make sure that nobody is present in the range of the gates.
3. Check/Adjustment/Correction of cams on both motors
Gate closed: switch free
Gate at approx. 45°: switch fully pushed (cam operates switch)
Gate open: switch free
(for adjustment refer to mechanical installation)
PROGRAMMING TRAVEL DISTANCES “ADVANCED”
NOTE: In this mode P1 must be pressed 9 times. With every time the button is pressed a position (time) is stored. (This allows
programming of SOFT-STOP (slow travel) in order to adjust to application. Long or short phases of SOFT-STOP are possible.
1. Both wings must be closed.
2. Press P1 and P2 for approx.5-6 seconds until wing / motor 1 starts opening.Release buttons!!!
3. Press P1 again. SOFT-STOP for wing / motor 1 in OPEN direction starts at this point.
4. Press P1 again when OPEN position is reached.Now wing / motor 2 starts automatically to open.
5. Press P1 again. SOFT-STOP for wing / motor 2 in OPEN direction begins at this point.
6. Press P1 again when OPEN position is reached. Now wing / motor 2 starts closing automatically.
7. Press P1 again. SOFT-STOP for wing / motor 2 in CLOSE direction begins at this point.
8. Press P1 again when CLOSE position is reached. Now wing / motor 1 starts automatically to close.
9. Press P1 again. SOFT-STOP for wing / motor 1 in CLOSE direction begins at this point.
10. Press P1 again when CLOSE position is reached.
Done!
BASIC SETTING:
1. Press buttons P1, P2 and P3 simultaneously for approx. 2-3 seconds until yellow LED flashes.
2. Monitor the gate. Press and hold P1 for 1-2 seconds. The wing with motor 1 opens. If motor 1 closes, it is wired incorrectly and
the red and blue wires of the motor cable must be inverted. (Caution: Disconnect Power!)
Repeat steps 1 and 2. Leave gate/s in partially open position.
NOTE: General operation – if you release the button, the gate will immediately stop. By pressing the button again the gate will
move in the opposite direction until you release the button, and so on.
3. Press and hold P2 for 1-2 seconds. The wing with motor 2 must open. (Do not open gate completely, only short distances.)
If motor 2 closes, it is wired incorrectly and the red and blue wires of the motor cable must be inverted.
(Caution: Disconnect Power!)
Repeat steps 1 and 2. Leave gate/s in partially open position.
NOTE: The control board is active for this manual setting mode for approx. 20 seconds. If necessary, start again by pressing P1,
P2 and P3 simultaneously.
Now check the following:
1. If both operators connected open both wings completely.
2. Both wings must open completely. Do not open the wings too far! A gate stop in OPEN position is required.
Caution: Gate must not come in contact with operator (i.e. when operator has been released for manual operation)
Wait until learn-LED goes out (20 seconds after a button was pressed).
PROGRAMMING TRAVEL DISTANCES “SIMPLE I”
NOTE: only with stops in OPEN and CLOSE position
1. Wings must be closed
2. Press P1 until wing / motor 1 starts opening (learn-LED flashes resp. glows)
Automatic programming starts (slow travel)
Wing 1 moves to the stop in OPEN position
Wing 2 moves to the stop in OPEN position
Then wing 2 moves to the stop in CLOSE position.
Then wing 1 moves to the stop in CLOSE position.
When the learn-LED goes out the programming has finished.
Intelligent Security & Fire Ltd.

en-12
NOTE: If one wing reaches a stop and button P1 is not pressed, then the motor moves towards the stop and stores this position
automatically.
COMPLETION OF INSTALLATION / PROGRAMMING
Once the travel distances are programmed, the remote controls can be programmed as well.
(Refer to PROGRAMM / DELETE REMOTE CONTROLS).
1. Operate the gate with a remote control or with a connected switch and monitor the direction. Close the gate again WITHOUT
any interuptions.
2. If all adjustments are done, check operation of photocells, switch, flashing light, remotes, accessories, etc.
3. Advise people using the gate with regard to gate operation, safety functions and how to release the gate in order to operate it
manually.
TIMER TO CLOSE
NOTE: Only possible with connected photocells (1 + COM). Time frames from 2 seconds up to 120 seconds are possible.
Activate:
1. Press and hold P2 until yellow LED starts flashing
2. Now count the time you wish to program
3. Press P2 again. Done!
Deactivate:
1. Press and hold P2 until yellow LED starts flashing.
2. Press P3. Yellow LED goes out. Done!
TORQUE OF MOTOR
Thrust of the motor is set automatically while programming
the travel distance. Thrust can only be modified by
programming the travel distance again. If gate movement is
impeded by weather or changes to the installation (rust or
inappropriate lubrication) it may have to be repaired.
The control board complies with the latest EU
guidelines. One of these guidelines specifies that the
closing forces at the gate edge must not exceed 400 N (40 kg) for
the last 500 mm before the door is CLOSED. Above 500 mm, the
maximum force at the gate edge must not exceed 1400 N (140 kg). If
this cannot be ensured, a contact strip must be mounted on the gate
at a height up to 2.5 m or on the pillar on the opposite side
(EN12453).
Intelligent Security & Fire Ltd.

en-13
Indication Description Remedy
1x blinking Motor 1 has insufficient connection to control board Green or white cable not wired or badly connected Check
terminals precisely. Consider wire lengths
2x blinking Motor 2 has insufficient connection to control board Refer to 1x blinking
3x blinking Limits for motor 2 have not been accepted A: Open gate wide enough when programming the travel. Make
A: After or during first travel: operator did not open sure cam passes all 3 states (switch free, pushed, free)
open wide enough to meet not meet passpoint B: Check terminals precisely. Consider wire lengths
(cam did not operate switch)
B: Motorcables have insufficient connection to contol board
Yellow or white cable not wired or badly connected
4x blinking Limits for motor 1 have not been accepted Refer to 3x blinking
5x blinking Travel has not been programmed Repeat programming travel
The process of programming has been interrupted
6x blinking Force to operate the gate is too high
A: Gate is out of order A: Repair gate
B: Gate is rough-running B: Check if gate can be easily moved
C: Gate stopped through windload C: Do not operate gate by windstorm
D: Reprogram travel to achieve sufficient level of fo
7x blinking Photocells 1 block installation
A: Object blocks photocells A: Remove object
B: Alignment of the lenses is incorrect B: Check alignment
C: Power supply to photocells is insufficient C: Check cable widths and contacts
8x blinking Photocells 2 block installation Refer to 7x blinking
9x blinking Emergency stop switch blocks installation A: Check wiring
B: Check basic setting of control board (Jumpers)
10xblinking Safety edge blocks installation
A: Object obstructs safety edge A: Remove object
B: Defective safety edge B: Check wiring. Check resistor 8.2KOhms
C: Power too low or broken wire in supply C: Check basic setting of control board (Jumpers)
11xblinking Power supply to control board is too low
A: Defective supply 230V or malfunctioning contact A: Check electric contact
B: Broken wire in supply cable (copper cable) B: Check by electrician
C: The battery (accessory) to operate the gate whilst C: Allow battery to charge 24 hours
power failure is dead.
12xblinking EEPROM Fault
Power up failed Replace contol board
INDICATION OF THE DIAGNOSIS LED
Intelligent Security & Fire Ltd.

en-14
The gate opener doesn’t respond at all; no LED is
on.
Possibly power failure. 1. Check conductor and zero conductor.
2. Check house fusing.
Immediately after the gate has started moving, it
stops and reverses.
Obstacle in area of gate. Check area of gate for objects
If there is no obstacle, make another initial
operation to ensure the force will be learned
again.
The gate opener does not open the gate fully. 1. Are the post dimensions A+B correct?
2. Has the travel of the controller been set
correctly?
1. Check A+B dimensions.
2. Reprogram if required
Gate can only be opened 1.photocell blocks 1.Function and connection must be
checked
“Timer to close” doesn’t work. 1. Only works if the 2-cable photocell
770E(ML) or 771E(ML) has been
installed.
The control board does not work any more using
the transmitter, only with the switch and even then
only as long as a button is pressed and kept
pressed.
A safety photocell, a contact strip or the stop
disables the control board
Only one photocell was connected for OPEN
At least one photocell must be
connected and activated for CLOSED
or OPEN.
The gate opener doesn’t respond at all, although
the controller has been connected (LEDs are on).
1. Remote control has not been programmed.
2. LEDs indicate a fault.
3. Photocell connected incorrectly.
4. Motor terminal possibly not connected
properly.
1. Programming remote control.
2. Find and rectify fault(s) (see description of
LEDs).
3. Check photocell connection / programming.
4. Check terminals and connections.
Control board does not work with transmitter 1.transmitter not programmed
2.An photocell blocks
1.Program transmitter
2.Check photocells
The control board is not running No travel has been learned Learn travel.
See Initial operation
The wings do not open completely. 1.Insufficient force in the event of high
wind loads (entire gates)
2.Gate sluggish/heavy
1.Reset force ( increase )
2.Improve ease of movement
3.Program control board again
The remote control’s range is too short. The installation of an external aerial is recommended as the controller with the short cable
aerial is located either behind the post or near ground level in most cases. The optimum
location of the aerial is as high as possible in all cases. An appropriate aerial with installation
kit can be obtained from Chamberlain as an accessory with the product ref. no. ANT4X-1LM.
The gate must follow a slope. Not recommended! Change gate! The gate can move in an uncontrolled (dangerous) manner if
the gate opener has been released. A stronger force is needed in the upwards direction of the
slope and then, in the opposite direction, the gate opener’s force is too strong.
The gate post is so thick that I am unable to
comply with the requisite A+B dimensions.
Reduce post thickness or shift gate location.
FAQs
Intelligent Security & Fire Ltd.
