INSTRUCTION MANUAL
PLANe wAve SPeAkeRS
Thank you for purchasing TOA’s Plane Wave Speaker.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
Pw-1230DB/1230Dw
Pw-1230SB/1230Sw
Pw-1430DB/1430Dw
Pw-1430SB/1430Sw
133-01-481-1A

2
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS ............................................................................. 3
2. GENERAL DESCRIPTION .......................................................................... 4
3. FEATURES ............................................................................................................ 4
4. DIMENSIONAL DIAGRAM .......................................................................... 5
4.1. PW-1230DB, PW-1230DW, PW-1230SB, and PW-1230SW .................................. 5
4.2. PW-1430DB, PW-1430DW, PW-1430SB, and PW-1430SW ................................. 5
5. SETTING ................................................................................................................. 6
5.1. Impedance Setting ................................................................................................ 6
5.2. Beam Tilting and High Pass Filter Settings .......................................................... 6
6. INSTALLATION PRECAUTIONS ............................................................. 8
7. INSTALLATION ................................................................................................... 9
7.1. Speaker Installation ............................................................................................... 9
7.2. Installation of Double-Sided Type Speakers ....................................................... 10
7.3. Installing the Safety Wire .................................................................................... 10
8. SPECIFICATIONS ........................................................................................... 11

3
1. SAFETY PRECAUTIONS
• Beforeinstallationoruse,besureto carefullyread alltheinstructionsinthissection forcorrect andsafe
operation.
• Besuretofollowalltheprecautionaryinstructionsinthissection,whichcontainimportantwarningsand/or
cautions regarding safety.
• Afterreading,keepthismanualhandyforfuturereference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual rst and
understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
resultinmoderateorminorpersonalinjury,and/orpropertydamage.
WARNING
CAUTION
When Installing the Unit
• Referallinstallationworktothedealerfromwhom
the speaker was purchased. Installation requires
extensive technical knowledge and experience.
The speaker may fall off if incorrectly installed,
resulting in possible personal injury.
• Installtheunitonlyinalocationthatcanstructurally
support the weight of the unit and the mounting
bracket. Doing otherwise may result in the unit
falling down and causing personal injury and/or
property damage.
• When installing the unit in the snowy area, take
appropriate measures to prevent snow from lying
on the unit. If the snow lies on the unit, the unit may
fall, causing personal injuries.
• Owingtotheunit’ssizeandweight,besurethatat
least two persons are available to install the unit.
Failure to do so could result in personal injury.
• Donotuseothermethodsthanspeciedtomount
the bracket. Extreme force is applied to the unit and
the unit could fall off, possibly resulting in personal
injuries.
• Fit the unit with a safety wire to prevent it from
falling.Ifnottted,theunitcouldfalloff,resultingin
personal injury.
• Use nuts and bolts that are appropriate for the
ceiling’s or wall’s structure and composition. Failure
to do so may cause the speaker to fall, resulting in
material damage and possible personal injury.
• Tighten each nut and bolt securely. Ensure that
the bracket has no loose joints after installation
to prevent accidents that could result in personal
injury.
• Be sure to use the supplied mounting bracket
in combination. Doing otherwise may cause the
speaker to fall, resulting in personal injury.
• Do not mount the unit in locations exposed to
constant vibration. The mounting bracket can be
damaged by excessive vibration, potentially causing
the unit to fall, which could result in personal injury
• Avoidinstallingthespeakerinlocationsclosetothe
seashore or in indoor swimming facilities that are
not well ventilated. In such locations, the bracket
may be vulnerable to corrosion, eventually allowing
the speaker to fall resulting in personal injury.
When Installing the Unit
• Avoid touching the unit’s sharp metal edge to
prevent injury.
When the Unit is in Use
• Donot operatetheunit for an extended periodof
time with the sound distorting. Doing so may cause
theunittoheat,resultinginare.
• Donotstandorsiton,norhangdownfromtheunit
as this may cause it to fall down or drop, resulting in
personalinjuryand/orpropertydamage.
• Havetheunitcheckedperiodicallybytheshopfrom
where it was purchased. Failure to do so may result
WARNING
CAUTION

4
in corrosion or damage to the unit or its mounting
bracket that could cause the unit to fall, possibly
causing personal injury.
· Never connect a 170 Ω speaker lead to high
impedance 100 V line, as this will damage the
speakerandamplier.
2. GENERAL DESCRIPTION
ThePlaneWaveSpeakerfeaturesaatspeakersystemequippedwithplanewaveunits,realizinganarrow
directivity pattern by radiating plane wave sound.
Since the Plane Wave Speaker can deliver sound output toward a limited target area, it is suited for use
in locations such as station platforms and escalator areas that require information announcements to be
broadcast, and in such spaces as museums and art galleries where the reverberation time is long.
The Plane Wave Speaker lineup includes the following 8 models.
• PW-1230DBandPW-1230DW(compactdouble-sidedradiationtype)
• PW-1230SBandPW-1230SW(compactsingle-sidedradiationtype)
• PW-1430DBandPW-1430DW(largedouble-sidedradiationtype)
• PW-1430SBandPW-1430SW(largesingle-sidedradiationtype)
Note: The rightmost letter of each model number indicates color: “B” for black and “W” for light ivory.
A double-sided radiation type radiates sound both backward and forward, while a single-sided radiation type
radiates sound forward only.
The most appropriate model can be selected depending on the condition of installation location and application.
3. FEATURES
• TwotypesofPlaneWaveSpeakersavailable:Acompacttype(PW-1230series)consistingof2planewave
unitsandalargetype(PW-1430series)consistingof4planewaveunits.
• Sound dispersion range is narrow in both horizontal and vertical directions, enabling sound output to be
deliveredtowardalimitedtargetarea.Lesssusceptibletotheinuenceofsoundreectionsfromtheceiling
andoor,allowingclearsoundtobedeliveredeveninspaceswithpooracousticconditionssuchaslong
reverberation time.
• Abuilt-inbeamtiltingfunctionfortiltingsoundradiationdirectionabout5°downwardfromthehorizontal
• Abuilt-inhighpasslterforcuttinglowfrequencies
• ComplianttoIPX4(IEC60529)*waterprotectionrating
• Stainlesssteel-mademetalpartsoftheplanewaveunitandthespeakerenclosure
* The performance of the unit is not harmfully affected even if water is splashed upon the unit from every
direction.

5
4. DIMENSIONAL DIAGRAM
4.1. PW-1230DB, PW-1230DW, PW-1230SB, and PW-1230SW
4.2. PW-1430DB, PW-1430DW, PW-1430SB, and PW-1430SW
505
(19.88)
151 (5.94) 151 (5.94)
428 (16.85)
524 (20.63)
496 (19.53)
60 (2.36)
54 (2.13)
355 (13.98)
284 (11.18)
25 (0.98)
* Dimension when the eyebolt
is maximally projected
MAX. 6 (0.24)*
4-9 × 20 (4-0.35 x 0.79)
3-ø14 (3-ø0.55)
(Cable entry holes)
(Hole for installation)
Speaker lead
(2 m or 6.56 ft)
[Top]
[Front]
[Bottom]
[Side]
304 (11.97) 304 (11.97)
831 (32.72)
735 (28.94)
812
(31.97)
355 (13.98)
284 (11.18)
25 (0.98)
803 (31.61) 54 (2.13)
60 (2.36)
MAX. 6 (0.24)*
* Dimension when
the eyebolt is
maximally projected
4-9 × 20 (4 -0.35 x 0.79)
3-ø14 (3-ø0.55)
(Cable entry holes)
(Hole for installation)
[Top]
[Front]
[Bottom]
[Side]
Speaker lead (2 m or 6.56 ft)
Unit:mm(in)
Unit:mm(in)

6
White
Black
Brown
Red
Yellow
Green
Speker leads
Input
High impedance
100 V line 30 W 15 W 10 W 5 W
High impedance
70 V line 30 W 15 W 7.5 W 5 W 2.5 W
Impedance 170Ω 330Ω 670Ω 1kΩ 2kΩ
Speaker leads HOT Green Black Brown Red Yellow
COM White White White White White
Speaker body
(bottom side)
Switch
cover
BEAM TILTING
DOWNWARD
FLAT
ON
OFF
HIGH PASS FILTER
(VERTICAL BEAM ANGLE) (450Hz -12dB/oct)
Switch name Setting
BEAMTILTING FLAT
HIGHPASSFILTER OFF
These switches are factory-preset as follows.
5. SETTING
5.1. Impedance Setting
Referringtothetablebelow,usethespeakerleadscorrespondingtoyourdesiredimpedance(ratedinput)for
connectiontotheamplier.
The green lead is for high impedance 70 V line use only.
Never use it on high impedance 100 V line since the amplifier or
speaker itself may be damaged.
CAUTION
Notes
•Besuretoinsulateunusedleadssoasnottoshort-circuit.
•Waterproofthecablejointbywrappinginsulatingtapearounditwhenthejoint
may be exposed to rain or water.
5.2. Beam Tilting and High Pass Filter Settings
To change the setting, loosen 2 screws on the bottom surface of the speaker, open the switch cover, then
change the setting using the toggle switch.

7
5.2.1. Beam tilting function
Shiftingthebeamtiltingswitchto“DOWNWARD”causesthesoundradiationtobedirectedabout5°downward
from the horizontal.
Central axis of sound radiation
[When shifted to “FLAT”]
[When shifted to “DOWNWARD”]
Switch setting Radiationdirection
FLAT 0°
DOWNWARD 5°Downward
5°
Central axis of sound radiation
Area where sound is especially intelligible
5.2.2. High pass filter function
Both types of speakers provide dispersion
characteristics shown as radiation patterns at
right.
To cut unwanted low-frequency sounds radiated
outside from the coverage area, shift the
high pass lter switch to the “ON” position.
Frequenciesbelow450Hzarecutat−12dB/oct.
In this case, low-frequency sounds in the
coverage area are cut as well, however, this will
havelittleinuenceonsoundintelligibility.
These ratiation patterns are viewed from above the speakers.
[Radiation patterns]
Coverage area
Coverage area
Coverage area
Speaker
Speaker
: High-frequency sound
: Low-frequency sound
Legend
• Double-sided type • Single-sided type

8
• Installthespeakersothatitsbottomsurfaceispositioneddownward.Fiveairventsareprovidedinthebottom
surface. Never block these air vents.
Air vent
Air vent
Do not install vertically.
30°
Downward
0°
Downward
30°
Speaker front
Downward
0°
Speaker Speaker
• PW-1230SB/1230SW/1430SB/1430SW
(single-sidedradiationtype)
Install the speaker within a downward tilt
angleofupto30°.
• PW-1230DB/1230DW/1430DB/1430DW
(double-sidedradiationtype)
Install the speaker within a downward tilt
angleofonly0°.
6. INSTALLATION PRECAUTIONS
ThePlaneWaveSpeakerfeaturessplash-proofconstruction(IPX4waterprotection)andcanbeinstalledunder
eaves not directly exposed to rain or snow. But the speaker installation orientation is limited as follows.
Be sure to follow the instructions below. Failure to do so may cause damage to the speaker.

9
7. INSTALLATION
Be sure to observe the following instructions.
Failure to do so may cause the unit to fall, possibly resulting in personal
injury.
•Useboltsandnutsthatareappropriateforthematerialandstructure
at the installation location.
•Securelytightenallbolts.
•Besuretouseatleast4boltstosecurethemountingbrackettothe
installation location.
WARNING
7.1. Speaker Installation
Step 1. Removethemountingbracketfromtheunit.
Removetheboltsontheunit’sbothsidestodetachthebracket.
Step 2. Secure the mounting bracket to the installation location.
Mounting bracket
2
3
4
Holes for installation
Holes for installation
Cable entry holes
Speaker lead
Separately prepare
these bolts and nuts.
Note
Boltsandnutsforxingthemounting
bracket to the installation location are
not included. Separately prepare them.
After removing the bolts, detach the
protection sheet inserted between
the mounting bracket and the bolts on
each side of the unit.
The removed protection sheets are no
more used at speaker installation. Protection
sheet
Protection
sheet
Remove this protection
sheet before installattion
Step 3. Secure the speaker to the mounting
bracket.
Usetheboltsremovedinstep1above.
Step 4. Pass the speaker lead through one of
3 cable entry holes in the mounting
bracket.

10
7.3. Installing the Safety Wire
7.2. Installation of Double-Sided Type Speakers
Connectasafetywiretotheunittopreventitfromfalling.
If not connected, the unit could fall, resulting in personal injury.
WARNING
Secure to rigid structure such as
iron frame or steel beam.
Thedouble-sided typespeakers (PW-1230DB/1230DW/1430DB/1430DW)emitpositivepressure wavefrom
theirfront(thesidewithTOAlogoafxed)andnegativepressurewavefromtheirrear.
It is recommended to orient these speakers as shown below when installing them in platforms or long narrow
passages.
Positve pressure wave : “Positive”
Negative pressure wave : “Negative”
Positive Positive Positive Positive
Negative Negative Negative Negative
Legend
Front
( Logo)
[Installation example]
Within 30 cm
(11.81")
(Surplus length*)
Joist or bar
The state that the
safety wire is tight
Safety wire
Eyebolt
Notes
• No safety wire is supplied with the speaker. Separately prepare a safety wire that meets the following
requirements.
·Thediameterofthesafetywiremustbe2mm(0.08")ormore.
·Thesurpluslength*ofthesafetywiremustbewithin30cm(11.81")fromthestatethatthesafetywireistight.
• Neverloosentheeyebolt.
If loosened, rain or water gets into the speaker, resulting in speaker failure.
*Thesurpluslengthreferstothelengthwithenoughslack.

11
Note:Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
8. SPECIFICATIONS
ModelNo. PW-1230DB , PW-1230DW PW-1230SB , PW-1230SW
TypeofRadiation Double-sided radiation Single-sided radiation
RatedInput 30 W
RatedImpedance High impedance 100 V line
330Ω(30W),670Ω(15W),1kΩ(10W),2kΩ(5W)
High impedance 70 V line
170Ω(30W),330Ω(15W),670Ω(7.5W),1kΩ(5W),2kΩ(2.5W)
Sensitivity 86 dB
(1W,1mequivalentmeasured
at4m,1k–10kHz)
87 dB
(1W,1mequivalentmeasured
at4m,1k–10kHz)
86 dB
(1Wmeasuredat1m,1k–10kHz)
87 dB
(1Wmeasuredat1m,1k–10kHz)
(Beamtilting:FLAT,Highpassfilter:OFF) (Beamtilting:FLAT,Highpassfilter:OFF)
FrequencyResponse 300 Hz – 17.5 kHz 450 Hz – 17.5 kHz
(Beamtilting:FLAT,Highpassfilter:OFF) (Beamtilting:FLAT,Highpassfilter:OFF)
Directivity Angle Horizontal:38º(2kHz,1/3octaveband),Vertical:75º(2kHz,1/3octaveband)
SpeakerUnit Planewaveunit(152x214mmor5.98"x8.43")x2pcs.
Setting Switch Beamtilting(tiltsradiationaxis5ºdownward) :FLAT/DOWNWARD
Highpassfilter(450Hz,–12dB/oct) :OFF/ON
SpeakerCord Φ9mm(0.35"),6-corecabtyrecable,2m(6.56ft)
Water Protection IPX4
Operating
Temperature
- 10to+50℃(14to122ºF)
Finish Enclosure,Punchednet,andMountingbracket:Stainless,semi-gloss,paint
Color PW-1230DB : Black PW-1230SB : Black
PW-1230DW : Light ivory PW-1230SW : Light ivory
Dimensions 524(w)x355(h)x60(d)mm(20.63"x13.98"x2.36")
(includingmountingbracket)
Weight 7.3kg(16.09lb)
(includingmountingbracket)
7.8kg(17.2lb)
(includingmountingbracket)

Traceability Information for Europe
Manufacturer:
TOACorporation
7-2-1,Minatojima-Nakamachi,Chuo-ku,Kobe,Hyogo,
Japan
Authorized representative:
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg,
Germany
URL:http://www.toa.jp/
Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
ModelNo. PW-1430DB , PW-1430DW PW-1430SB , PW-1430SW
TypeofRadiation Double-sided radiation Single-sided radiation
RatedInput 30 W
RatedImpedance High impedance 100 V line
330Ω(30W),670Ω(15W),1kΩ(10W),2kΩ(5W)
High impedance 70 V line
170Ω(30W),330Ω(15W),670Ω(7.5W),1kΩ(5W),2kΩ(2.5W)
Sensitivity 88 dB
(1W,1mequivalentmeasured
at4m,1k–10kHz)
90 dB
(1W,1mequivalentmeasured
at4m,1k–10kHz)
85 dB
(1Wmeasuredat1m,1k–10kHz)
87 dB
(1Wmeasuredat1m,1k–10kHz)
(Beamtilting:FLAT,Highpassfilter:OFF) (Beamtilting:FLAT,Highpassfilter:OFF)
FrequencyResponse 250 Hz – 17.5 kHz 400 Hz – 17.5 kHz
(Beamtilting:FLAT,Highpassfilter:OFF) (Beamtilting:FLAT,Highpassfilter:OFF)
Directivity Angle Horizontal:19º(2kHz,1/3octaveband),Vertical:78º(2kHz,1/3octaveband)
SpeakerUnit Planewaveunit(152x214mmor5.98"x8.43")x4pcs.
Setting Switch Beamtilting(tiltsradiationaxis5ºdownward) :FLAT/DOWNWARD
Highpassfilter(450Hz,-12dB/oct) :OFF/ON
SpeakerCord Φ9mm(0.35"),6-corecabtyrecable,2m(6.56ft)
Water Protection IPX4
Operating
Temperature
- 10to+50℃(14to122ºF)
Finish Enclosure,Punchednet,andMountingbracket:Stainless,semi-gloss,paint
Color PW-1430DB : Black PW-1430SB : Black
PW-1430DW : Light ivory PW-1430SW : Light ivory
Dimensions 831(w)x355(h)x60(d)mm(32.72"x13.98"x2.36")
(includingmountingbracket)
Weight 11.4kg(25.13lb)
(includingmountingbracket)
11.9kg(26.23lb)
(includingmountingbracket)
