Instruction Manual
F-500WP, F-500WP-L
F-600WP, F-600WP-L
SPEAKER SYSTEM
Handlin
1. The speaker system is rainproo ed or outdoor applications. However, do not dash water intentionally over unit or
the cleaning purpose as this can cause damage to the internal speaker components.
2. Do not loosen any ixing screws o this speaker or disassembly or modi ication. This impairs the speaker's rain-
proo capability, involving a risk o accidents or breakdowns.
3. Sea breezes shorten the li e o this speaker. Do not install the speaker in the seaside areas.
4. Toa can accept no responsibility or accidents or unit's breakdowns resulting rom improper installations or dis-
assemblies or modi ications per ormed or purposes other than legitimate maintenance or repair services.
Features Specifications
1. Rain- and weather-proo construction that makes the
speaker most ideal or outdoor applications.
2. 2-way, sealed speaker incorporating a woo er with
high power handling capacity and a constant-
directivity (CD) horn tweeter with a high-e iciency driv-
er.
3. Uni orm requency response within the range o 60°
horizontal × 40° vertical thanks to the CD horn.
4. Enclosure is made rom polypropylene resin that
assures high sound per ormance.
5. Designed or high e iciency, extended range and high
durability as well as or easy installation, the speaker
can be used in wide applications.
Type ...
Woofer
Tweeter
Rated power or
Power handlin capacity
F-500WP F-500WP-L
F-600WP F-600WP-L
Sealed type
20cm cone 30cm cone
CD horn + drive r
60W*
80W"
240W***
120W*
120W***
Output SPL
Frequency ...
Crossover ...
Ambient ...
Material ...
Color
Dimensions
(W×H×D)
Wei ht
93dB (1W/1m)
80~20000Hz
3000Hz
98dB(1W/1m)
80~20000Hz
2000HZ
-15°C ~ +50°C
Polypropylene resin
Ivory
452x282x210 mm
17.8x11.1x8.3 inches
Approx. 11 kg Approx. 9.5kg
552×392x250 mm
21.7x15.4x9.8 inches
Approx. 20kg | Approx. 17.5kg
Impedance
* Rated power input ** Continuous pink noise input *** Continuous
program input
The above specifications are subject to chan e without notice.
precautions
Important: READ RULE FOR SAFE INSTALLATION, OPERATION AND INSTRUCTIONS CAREFULLY.

Installation
1. To avoid breakdowns, we suggest that you install the
speaker in the areas where the ambient temperature is
rom -15°C to +50°C. In snowy areas, protect unit
rom the snow.
2. When installing the speaker, use the optional mounting
bracket or outdoor installation. Also, take care about
the ollowing:
(1)The bottom sur ace o the speaker has two air
vents and one drain hole. Be sure to mount the
speaker with that side down, taking care that such
holes are not blocked. (The drain hole is or drain-
age o rainwater that enters the horn.)
Air vent
(2 locations)
Drain hole
Bottom sur ace
(This side down.)
(2)As shown in the igure below, the speaker can be
positioned at any angle rom 0° (horizontal) to a 45°
downward angle. As this mounting range permits
ree drainage o rainwater rom the inside o the
speaker, do not exceed this range, nor direct the
speaker upward.
Positioning angle
Frequency response (1W/1m: 1/3 Octave Pink Noise)
TOA Corporation
KOBE, JAPAN Printed in Japan
133-01-312-20
1. Polarity
When connecting the speaker, observe the polarity
shown in the igure below.
2. Impedance switching (Only available or F-500WP and F-600WP)
The speaker input impedance can be switched in 4
steps with a built-in selector. See the table below.
The impedance is actory-preset to position 3.
F-500WP
Position [1]
Position [21
Position [3]
Position [4]
100V Line
70V Line
15W
30W
60W
7.5W
15W
30W
60W
F-600WP
Position [1]
Position [2]
Position [3]
Position [4]
100V Line 70V Line
30W
60W
120W
15W
30W
60W
120W
Overload protection device
The speaker is provided with individual overload protec-
tion devices or woo er and tweeter. (When the woo er's
device is activated, the woo er's output signal level is
attenuated by about 15 dB, while the tweeter is cut o i
the tweeter's device is activated.) I the sound volume o
the woo er or tweeter suddenly decreases during use,
this indicates that the protection devices have leaped into
action. In such a case, lower the speaker input power
level once irst to wait till the protection devices automati-
cally return to the normal condition (about 2 to 20
seconds). A ter they are reset, use the speaker turning
down the volume a little more than be ore.

F-500WP, F-500WP-L
F-600WP, F-600WP-L
