User Manual
SYD6 Powered Speaker
Supporting your digital lifestyle™
English
YUMI
POWERED SPEAKERS

2
Table of Contents
Important Safety Precautions . . . . . . . 2
Introduction / What’s in the Box? . . . . . 3
Front & Rear Panels . . . . . . . . . . . . 4
Remote Control . . . . . . . . . . . . . . 5
Setting Up Your Speakers. . . . . . . . . . 6
Connecting Audio Sources . . . . . . . . . 7
USB Charging . . . . . . . . . . . . . . . 9
Connecting a Sub-Woofer. . . . . . . . . . 10
Specifications . . . . . . . . . . . . . . . .11
Warranty . . . . . . . . . . . . . . . . . .12
Important Safety Precautions
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
• Protect the power-supply cord from being walked on or
pinched, particularly at plugs, convenience receptacles and
the point where they exit from the apparatus.
• Only use attachments / accessories specified by the
manufacturer.
• Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, the
apparatus does not operate normally, or the apparatus has
been dropped.
• Apparatus shall be connected to a MAINS socket outlet with
a protective earthing connection.
• An appliance input coupler is used as the disconnect device
- the disconnect device shall remain readily operable.
• Batteries or battery packs shall not be exposed to excessive
heat such as sunshine, fire or the like.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE BACK PANEL.
NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
DANGEROUS VOLTAGE
The lightning flash with arrowhead, within an
equilateral triangle, is intended to alert the user
of the presence of non-insulated “dangerous
voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a
risk of electric shock to persons.
ATTENTION
The exclamation point within an
equilateral triangle is intended to
alert the user of the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the apparatus.
FCC Warnings
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
• This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules.
FCC Notice:
• This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Industry Canada Notice:
• Complies with CAN ICES-3(B) / NMB-3(B)

3Supporting your digital lifestyle™
Introduction
Thank you for choosing SYD6 Powered Speaker, designed by Kanto in Canada. SYD6 outputs
40 W RMS per channel into 4 Ohm speakers, for remarkably bold and clean sound. Excellent
sensitivity and frequency response provide deep thumping lows and clear, scintillating highs.
SYD6 is an amazingly flexible speaker system that can accept five input sources and connect
to a subwoofer for enhanced low frequency effects (LFE). Additionally, it is equipped with the
latest Bluetooth technology and a USB port for charging USB devices. SYD6 operates on a multi-
voltage power source from 110 V to 240 V and can be used worldwide.
We recommend you read all instructions carefully before using the system and keep them for
future reference. Kanto cannot be liable for damage or injury caused by incorrect setup or use of
this product.
This powered speaker system was carefully tested and inspected during production, and before
packaging and shipping. After unpacking, please check for any damage. It is rare that a unit is
damaged during shipping, but if this happens contact your retailer immediately. You can also
call Kanto directly at 1-888-848-2643 or email [email protected].
What’s In the Box?
SYD6 Active
Speaker
Power
Cord
User
Manuals
x3 x8
Self-Adhesive
Rubber Feet
3.5 mm cable
AUX (10’)
AUX
RCA OPT2OPT1
BALANCE
TREBLEBASS
SYD6
Remote
x2
‘AAA’
Batteries

Front & Rear Panels
1 1” Silk Dome Tweeter
2 5.25” Kevlar Mid/Woofer Driver
3 LED
Blue - Power on / Playback Mode
Yellow - Standby (solid)
- Mute (flashing)
White - Discover Mode (flashing)
- Paired (solid)
4 Volume / Input Select Knob
5 RCA L/R Input
6 3.5mm Stereo Mini-Jack AUX Input
7 Subwoofer Output
8 Optical 1 and Optical 2 Inputs
9 USB Charge Port (5 V 2.1A)
10 ON / OFF Switch
11 AC Input Connection (100 V - 240 V)
4
234
6 7 85910 11
1
The SYD6’s volume knob functions as an input select knob as well.
Push the knob to select an input source - it cycles through following inputs depending on
what input source was last used.
RCA AUX OPT1 OPT2 BLUETOOTH
Volume/Input Select Knob
REAR PANELFRONT PANEL

5Supporting your digital lifestyle™
AUX
RCA OPT2OPT1
BALANCE
TREBLEBASS
Remote Control
1 Standby Button - press to enter
Standby Mode or return to
Playback Mode
2 RCA Input Select
3 3.5 mm Stereo Mini-Jack AUX
Input Select
4 Optical 1 Input Select
5 Optical 2 Input Select
6 Bluetooth Input Select
7 Bluetooth Reset
8 Increase Volume
9 Decrease Volume
10 Increase Bass Output
11 Decrease Bass Output
12 Reset Bass Output
13 Increase Treble Output
14 Decrease Treble Output
15 Reset Treble Output
16 Mute
17 Balance Control Left Channel
18 Balance Control Right Channel
19 Reset Balance (Left and Right
Channels)
20 Previous Track
21 Play / Pause
22 Next Track
2
3
1
6
7
8
4 5
9
10
11
13
14
15
12
18
19
17
16
20 22
21
Install two supplied AAA batteries in the back of your SYD6 remote. Remote Control functions
are listed below.

6
Setting Up Your Speaker
The SYD6 powered speaker system is designed for either desktop or bookshelf mounting to
enhance your audio listening experience. The SYD6 can also be used as a stand-alone stereo
speaker system or in a 2.1 home theater setup with a subwoofer. SYD6 is versatile and can be
mated with a multitude of audio sources.
The SYD6 is designed to perform optimally positioned at least 20cm from a rear wall in an
average listening room or if placed in audio-video furniture in a TV set up. A certain amount
of experimentation may be necessary to determine the most suitable position that delivers the
most satisfying sound performance.
As with any rear-ported speakers, moving the SYD6 very close to the rear wall will enhance the
bass frequencies but will tend to reduce soundstage depth, while moving the speakers away
from the rear wall will tend to have the opposite effect. Avoid positioning the speaker close to
the floor or in the corners of the room, as this will excite undesirable room coupling in the low
and middle frequencies. Room characteristics and positioning have a profound effect on the
performance of the speakers, so time and effort devoted to achieving the optimum operating
position will be rewarded.
Ensure that the ON/OFF Switch is in the OFF position.
Follow the instructions on the ensuing pages to connect your audio sources to SYD6. The
examples in the following pages are not meant to be exhaustive - just examples.
Connect the power cord from SYD6 to the wall outlet.
ATTENTION
When connecting audio cables the ON/OFF Switch must be turned OFF. After connecting all cables, the unit can be
turned ON.
When the volume is high, this system can produce noise levels that could permanently damage your hearing.
SYD6 is a self-powered speaker system. Do not connect the speaker terminals to the speaker outputs of a stereo
amplifier. Damage may occur. Use only the power cord provided with the speakers.

7Supporting your digital lifestyle™
Connecting Audio Sources
RCA & 3.5 mm Stereo Mini-Jack AUX Connection
SYD6 features a high quality DAC (digital-to-analog converter) that supports data streams up to
24-bit/192 kHz resolution.
SYD6 supports Bluetooth 4.0 with aptX CODEC technology.
Use the appropriate audio cable to connect your audio source components to your speakers.
Refer to the following diagrams on connectivity options.
• 3.5 mm stereo mini-jack AUX cable
• Stereo RCA to 3.5 mm stereo mini-jack ‘Y’ cable
• Optical Toslink cable
PHONO PRE-AMP
TURNTABLE
LAPTOP
MP3
AUDIO
IN
OUT
CD / DVD
MP3 DOCK
R
3.5mm
L
R
L
(if necessary)*
ATTENTION
*Some models of turntables include a built-in Phono Pre-Amp.

8
Optical & Bluetooth Connection
MOBILE
DEVICES
OPT 2 OPT 1
GAME CONSOLES
DIGITAL DOCK
MEDIA PLAYERS
Bluetooth Pairing
SYD6 features Bluetooth 4.0 with aptX CODEC technology and can be paired with many
devices for wireless audio playback from your phone, MP3 player or tablet. Pairing is easy.
1. Press the Bluetooth button on SYD6’s remote to select it as the input source. The
Bluetooth LED (white) will flash slowly to indicate that SYD6 is in pairing mode.
2. Enable your Bluetooth device to search for a new device to pair with. Select ‘SYD6 by
Kanto’ from the list of Bluetooth devices available for pairing.
3. If pairing is successful, the Bluetooth LED (white) will remain solid. You will not need to pair
the same Bluetooth device again - ‘SYD6 by Kanto’ will remain on your device list until you
remove it from the list.
4. If the device does not pair with SYD6, turn the speaker’s ON/OFF Switch to the OFF
position, then repeat Steps 1 to 3. Alternatively, you can turn off Bluetooth in your device
and turn it back on again.

9Supporting your digital lifestyle™
USB Charging Operation
SYD6 features one 5 V 2.1 A USB charging port on the back panel. This is a convenient power
source to charge your devices.
When SYD6 is in Operating Mode (LED blue) and Standby Mode (LED yellow), the port is
active, and whatever device is connected is able to draw up to 2.1 A of power.
Bluetooth Operation
1. We recommend keeping a maximum distance of 10 meters between the speaker and your
device. The best signal fidelity is within this range.
2. If pairing is successful, the connection between the speaker and your device remains active
and functional – that is, you can stream audio from your device to the speaker using either
the player control buttons of your device or the control buttons of the remote control (see
diagram of Remote Control on page 5 of this manual – buttons #20, #21, and #22).
3. Take note of the following behavior and functionality during Bluetooth operation. When
you are successfully connected, the Bluetooth LED will be lit solid, and your device will
show as connected to ‘SYD6 by Kanto’.
• The connection between speaker and device remains active even if input source has
changed. For instance, you can switch to another input source (e.g. CD player) and
return to Bluetooth operation without losing signal connection and, therefore, do not
need to pair with the device again.
• When the speaker is put in Standby mode or powered OFF, Bluetooth connection
with the device is lost. When the speaker returns to Playback mode, the Bluetooth
connection between the speaker and device is re-established. However, you may notice
a choppy playback signal for approximately 30 seconds after reconnection. It will
normalize.
• While the speaker can be paired with more than one device, only one device can play
and transmit audio signal at a time.
4. The SYD6 remote control features a Bluetooth Reset button to quickly disconnect a paired
device and allow a second device to pair with the speaker (button #7 on the Remote
Control diagram on page 5).
• Press Bluetooth Reset button to disconnect a paired device.
• Follow the pairing instructions to pair another device.
• The same behavior and functionality apply to the second device.

10
Connecting a Subwoofer
SYD6 is equipped with an RCA connector to provide output signal to a powered subwoofer.
Simply connect a single RCA subwoofer cable from the SUB OUT connection on the SYD6 to
the AUDIO INPUT on your subwoofer. If your subwoofer has a stereo L/R RCA input, either left
or right inputs will work.
We recommend the Kanto sub6 or sub8 powered subwoofer with crossover and volume
controls. Most quality subwoofers offer these controls, which allow you to customize the
amount of bass you will experience.
Look for details on the Kanto website at: www.kantoaudio.com
L
L
R
R
U
U
Use either L or R
inputs

11 Supporting your digital lifestyle™
Specifications
SYD6 POWERED SPEAKER SYSTEM
Tweeters 1 inch Silk Dome
Woofers 5.25 inch Kevlar
Nominal Impedance 4 Ohm
Sensitivity 2.83V (/1W/1m) 87 dB
Amplifier Type Class D
Power Output 40 Watts RMS per channel
Input Sensitivity 550 mV
Total Harmonic Distortion < 0.3%
Crossover System 2-way
Crossover Frequency 2.0 kHz
Frequency Range 20 Hz - 20 kHz
Frequency Response 50 Hz - 10 kHz ± 6 dB
Inputs 1 x 3.5 mm stereo mini-jack AUX
1 x RCA L/R
2 x Optical (Toslink)
1 x Bluetooth 4.0 (Supports aptX CODEC)
Outputs 1 x Subwoofer
1 x USB Charge Port 5 V 2.1A
Input Voltage / Frequency AC 100 V - 240 V 50/60 Hz (auto switching)
Standby Power Consumption < 0.5 W
Remote Included
Dimensions W 21.3”x H 6.9” x D 8.9” (540 x 175 x 225 mm)
Net Weight 18.6 lbs (8.4 kg)
Gross Weight 22.8 lbs (10.3 kg) (boxed)
NOTICE: The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Kanto Distribution Inc. is under license.

13-10
Limited Warranty To Original Purchaser
Kanto Distribution Inc. (Kanto) warrants the equipment it manufactures to be free from defects in material
and workmanship for the following limited warranty period of:
24 months parts and labour
If equipment fails because of such defects and Kanto or an authorized dealer is notified within 24 months
from the date of shipment with proof of original invoice. Kanto will, at its option, repair or replace the
equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse
or modifications. Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the repair. Such repairs are warranted for 90 days from the day
of reshipment to the original purchaser. This warranty is in lieu of all other warranties expressed or implied,
including without limitation, any implied warranty or merchantability or fitness for any particular purpose, all
of which are expressly disclaimed.
The information in the owner’s manual has been carefully checked and is believed to be accurate. However,
Kanto assumes no responsibility for any inaccuracies that may be contained in the manual. In no event will
Kanto, be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect
or omission in this manual, even if advised of the possibility of such damages.
Warranty
www.kantoliving.com | [email protected]
Tel [phone]
To learn more about all our products, visit www.kantoliving.com
• Check out our full line of bookshelf and desktop speaker systems
• Available in a stunning array of colors
Kanto Speakers
• Full line of Audio and Video Cables
• Attractive white cables and heads
• HDMI, Optical, Mini-jack, RCA, USB
• Switchers, Hubs, Adapters
• Visit kantoliving.com/cable for more!
• Visit kantoaudio.com for more!
BEN
by
kantoliving kantoliving
Check out more great products from Kanto!
