Tobii Pro Mobile Testing Accessory User manual

Mobile Testing Accessory
User’s Manual

User’s manual Mobile Testing Accessory
Version 1.1
08/2020
All rights reserved.
Copyright © Tobii AB (publ)
The information contained in this document is proprietary to Tobii AB. Any reproduction in part or whole without prior written
authorization by Tobii AB isprohibited.
Products that are referred to in this document may be either trademarks and/or registered trademarks of the respective
owners. The publisher and the author make no claim to these trademarks.
While every precaution has been taken in the preparation of this document, the publisher and the author assume no re-
sponsibility for errors or omissions, or for damages resulting from the use of information contained in this document or from
the use of programs and source code that may accompany it. In no event shall the publisher and the author be liable for
any loss of profit or any other commercial damage caused or alleged to have been caused directly or indirectly by this
document.
Content subject to change without notice.
Please check Tobii web site www.tobiipro.com for updated versions of this document.

Table of Contents
1 Introduction..............................................................................................................................1
1.1 Symbols used inthis document......................................................................................................1
2 System Requirements .............................................................................................................2
2.1 Mobile Testing Accessory requirements.........................................................................................2
2.2 Additional TobiiPro software..........................................................................................................2
3 Safety......................................................................................................................................3
3.1 Mounting.........................................................................................................................................3
3.2 Proper Use.....................................................................................................................................3
3.3 Emergency.....................................................................................................................................3
3.4 Magnetic field.................................................................................................................................3
3.5 Child safety.....................................................................................................................................3
3.6 Electricity........................................................................................................................................3
4 Overview of the MobileTesting Accessory ...............................................................................4
4.1 What’s in the box............................................................................................................................4
4.2 How the Mobile TestingAccessory works ......................................................................................5
4.3 Next steps ......................................................................................................................................5
5 Set up your display ..................................................................................................................6
5.1 Download and install Tobii Pro EyeTracker Manager....................................................................6
5.2 Calibrate your eye tracker ..............................................................................................................6
5.3 Display setup in Tobii Pro EyeTracker Manager............................................................................6
5.4 Assemble the MobileTesting Accessory......................................................................................11
5.5 Detach the eye tracker from the Mobile Testing Accessory..........................................................14
6 Start Experimenting............................................................................................................... 15
Appendix A Support, Learning Center,and Warranty .................................................................16
A1 Customer Support........................................................................................................................16
A1.1 Get help online.............................................................................................................16
A2 Learning Center............................................................................................................................16
A3 Warranty information....................................................................................................................16
Appendix B Compliance Information...........................................................................................17
B1 CE Statement...............................................................................................................................17
B2 VCCI.............................................................................................................................................17
B3 Industry Canada Statement..........................................................................................................17
B4 EMC .............................................................................................................................................17
B5 Sustainability................................................................................................................................17
B6 Safety...........................................................................................................................................18
Appendix C Technical Specifications..........................................................................................19
Appendix D Limitations and Considerations ...............................................................................20
D1 Intended use.................................................................................................................................20
D2 Light conditions ............................................................................................................................20
D3 Eyelashes.....................................................................................................................................20
D4 Droopy eyelids..............................................................................................................................20
D5 Glasses and contact lenses .........................................................................................................20
D6 Distance .......................................................................................................................................20
D7 Head and hand movements .........................................................................................................20

1
1 Introduction
Mobile Testing Accessory User’s manual v.1.1 - en-US
1 Introduction
The Mobile Testing Accessory is a slim and compact accessory that enables eye tracking on small mobile devices. It offers
a natural and efficient way to do high quality research and usability tests on mobile devices. Used together with the Tobii
Pro Nano eye tracker and Tobii Pro Lab software, it makes a complete mobile testing solution.
The solution is perfect for when you want to perform mobile device user experience testing and other forms of research.
Research participants can interact naturally with the mobile device, creating a distraction-free user experience. The flexible
arm adjusts to a suitable position that mimics the natural feeling of holding the mobile device in your hand. Magnetic
mounting brackets and sticky pads make it easy to detach the eye tracker and switch between different mobile devices.
The Mobile Testing Accessory works with both iPhone and Android phones, as well as smaller tablets with no need to in-
stall or download an app on the phone.
For more information, read 4.2 How the Mobile Testing Accessory works, page 5
The Pro Nano eye tracker and analytical software are not included with the purchase of the Mobile Device Stand.
You will also need a laptop computer for setup and analysis. For more information, read 2.1 Mobile Testing Ac-
cessory requirements, page 2
1.1 Symbols used in thisdocument
In this manual we use symbols for three levels of information:
The Note symbol is used for notifying the user of something important or of something that needs special
attention.
The Caution symbol is used to inform of something that could cause harm to, or malfunction of, the equipment.
The Warning symbol is used to inform of something in which there is a conceivable risk of harm to the user if the
Warning is ignored.

2
2 System Requirements
Mobile Testing Accessory User’s manual v.1.1 - en-US
2 System Requirements
2.1 Mobile Testing Accessoryrequirements
In order to use the Mobile Testing Accessory, you will need a computer running analysis software such as Tobii
Pro Lab and a Tobii Pro Nano eye tracker.
Operating system
Windows 10
Mobile Device
Screen mirroring via USB Type-C port Alt mode
Samsung galaxy 8 or later
iPhone 7 or later
Huawei P30 Pro and later
HTC 10 or later
Mobile Device port
USB Type-C or iPhone Lightning
Computer RAM
2 GB RAM memory*
*Software for eye tracking research may require higher RAM
2.2 Additional Tobii Pro software
Pro Lab
tobiipro.com/product-listing/tobii-pro-lab/
Pro Lab is a comprehensive research software platform for
eye tracking designed to meet the highest demands on dif-
ferent research scenarios with exact timing accuracy. This
software offers an efficient workflow, making it easy to de-
sign experiments, record data, analyze and visualize eye
tracking data, and to sync this data with other biometric da-
ta streams.
Pro SDK
tobiipro.com/product-listing/tobii-pro-sdk/
Pro SDK offers a broad set of tools that makes it simple to
develop a variety of niche applications or scripts across
multiple platforms, using a wide range of programming lan-
guages. This SDK gives the researcher access to the full
set of relevant gaze data streams, such as 3D eye coordi-
nates, raw data, pupil data, etc.
Third-party software
This term refers to any application built on Pro SDK.

3
3 Safety
Mobile Testing Accessory User’s manual v.1.1 - en-US
3 Safety
The Mobile Testing Accessory is designed for use with Tobii Pro Nano eye tracker. No other eye trackers should be used
with the Mobile Testing Accessory. The Mobile Testing Accessory is only intended for use in office environments. Read this
User Manual carefully before assembling or using the Mobile Testing Accessory. Please read the TobiiPro Nano User
Manual for safety precautions pertaining to the Pro Nano eye tracker. Youcan find it on the Tobii Pro Nano webpage.
3.1 Mounting
Mobile Testing Accessory is designed to be used on a table. Be careful when mounting the mobile device and us-
ing the Mobile Testing Accessory to avoid injury to the user or the product. Ensure that the stand is assembled
correctly and that the eye tracker is properly attached to the Device Holder before use to avoid damaging the De-
vice Holder, the eye tracker, or the test participant.
3.2 Proper Use
Please follow the instructions in this User Manual carefully. Should the Mobile Testing Accessory for any reason
harm someone or damage something due to falling or any other incident, neither Tobii Pro AB nor any of its rep-
resentatives will be responsible nor liable for any damages or injuries that may occur. Mounting and use of the
product is done entirely at the user’s own risk.
3.3 Emergency
The Mobile Testing Accessory is designed for research purposes only. Be aware that due to the low, but possible
risk of failure or distraction, the Mobile Testing Accessory should not be relied upon or used in dangerous or oth-
erwise critical situations.
3.4 Magnetic field
The Mobile Testing Accessory contains magnets. Magnetic fields may interfere with the function of cardiac pace-
makers and implantable cardioverter defibrillators. As a general rule, maintain a minimum distance of 15 centi-
meters (6 inches) between any item with magnets and your heart device.
3.5 Child safety
The Mobile Testing Accessory is composed of numerous separate, assembled parts. In the hands of a child,
some parts could become separated from the device, possibly resulting in a choking hazard or other danger to
the child. Young children should not have access to, nor use the device, without parental or guardian
supervision.
Magnets should be kept out of reach of children.
Do not place the magnet in any body orifice such as ear, nose or mouth.
3.6 Electricity
The Screen Capture device is an electronic device that may have multiple AC power cords installed. All power
sources should be disconnected before doing any service work to avoid shock hazard
Do not attempted to open or disable the Screen Capture device; it has no user-serviceable parts.

4
4 Overview of the Mobile Testing Accessory
Mobile Testing Accessory User’s manual v.1.1 - en-US
4 Overview of the MobileTesting
Accessory
4.1 What’s in the box
Figure 4.1 What’s in the box
The Mobile Testing Accessory contains the following parts:
Number
Item
More information
1
Device Holder with onepre-attached
Mounting Bracket and oneMounting
Plate
Positions the eye tracker correctly in
relation to the mobile device
2
Mounting Arm
Holds the Device Holder at the proper
height
3
Magnetic Plate
Magnetically attaches the Device
Holder to the Mounting Arm
4
Additional Mounting Plates
Extra plates for magnetically attaching
the Device Holder to the Mounting
Arm

5
4 Overview of the Mobile Testing Accessory
Mobile Testing Accessory User’s manual v.1.1 - en-US
5
Additional Mounting Brackets
Extra mounting brackets for attaching
the eye tracker to the Device Holder
6
Female 3/8” to female 1/4” Adapter
Used to attach the Mounting Arm to
the Base
7
Base
Weighted foot that holds the arm
steady when placed on a table
8
2 Sticky Pads
Temporarily hold the mobile device on
the Device Holder
9
Lightning to HDMI cable
Connects an iPhone to the Screen
Capture device
10
USB Type-C to HDMI cable
Connects an Android phone to the
Screen Capture device
11
Screen Capture device and cable
Connects the mobile device and the
computer to convert the screen into a
camera feed
4.2 How the Mobile Testing Accessoryworks
The mobile device is attached to the Device Holder using a sticky pad. The arm and base are used to support and stabilize
the Device Holder for better data quality. The Device Holder is attached to the arm using the Magnetic Plate. The Pro Nano
eye tracker sits on the Device Holder and is positioned 5 cm behind the device screen for optimal eye tracking. The Screen
Capture device is connected to the mobile device and to the computer and captures what’s on the device screen. This
makes it possible to then use TobiiPro Lab or other analytical software to merge the participant’s gaze (where the partici-
pant looks) and what is shown on the device screen. In this way, UX researchers and others can analyze and understand
the user’s experience on a mobiledevice.
4.3 Next steps
Set the Mobile Testing Accessory box aside for the moment. You will assemble it after using your computer to calibrate and
set up the display for the mobile device.

6
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
5 Set up your display
At the end of this setup, you will have a verified installation that is ready for use.
5.1 Download and install Tobii Pro Eye Tracker Manager
The first step is to get the free software, Pro Eye Tracker Manager on your computer. Setting up your Pro Nano eye tracker
involves installing the necessary drivers and software on your computer. Pro Eye Tracker Manager makes this easy.
You can skip this step if you already have the latest version of Tobii Pro Eye Tracker Manager installed.
Your eye tracker does not need to be connected to the computer to install Pro Eye Tracker Manager.
1. Before starting, double-check the hardware and system requirements, 2 System Requirements , page 2 Youshould
also check the requirements for your analysis software, for example, Tobii Pro Lab.
2. Download Pro Eye Tracker Manager from Tobii Pro’s product page.
3. Open Pro Eye Tracker Manager and follow the prompts to finish installation.
Read more about setting up and installing your Pro Nano eye tracker the Tobii Pro website.
5.2 Calibrate your eyetracker
Next you need to calibrate your Tobii Pro Nano eye tracker. Tobii Pro recommends that you calibrate the Pro Nano eye
tracker for each participant using a computer before attaching it to the Mobile Testing Accessory Device Holder.
This step can be skipped if you already have calibrated the eye tracker for the participant. Read more about setting up and
installing your Pro Nano eye tracker on the Tobii Pro website.
5.3 Display setup in Tobii Pro Eye Tracker Manager
Now the algorithms in the eye tracker need to understand where the eye tracker is in relation to the mobile device screen
in order to map the gaze points accordingly. This is done in Tobii Pro Eye Tracker Manager on a computer when the Tobii
Pro Nano is connected to thePC.
1. Make sure you have calibrated your eye tracker on a computer before continuing with the screen setup.
2. Open Tobii Pro Eye Tracker Manager on your computer and select your Pro Nano eye tracker
3. On the drop-down menu, clickNew.
4. Select Advanced setup and click the Next button.

7
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
5. Screen size: Enter the size of the device (X and Y) of the mobile device in mm. Click Next.
Figure 5.1 Measure the mobile device screen
6. Eye tracker angle: Set the Eye tracker angle to zero (0) and click Next.
Figure 5.2 Enter the angle of your eye tracker

8
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
7. Distance to eye tracker: Set the Distance to eye tracker to minus 58 (–58). This is a pre-calculated value deter-
mined by Tobii Pro. It’s a negative number because the eye tracker sits on top of and behind the screen. Click Next.
Figure 5.3 Enter the distance between the front of the eye tracker and the screen
8. Height difference: The height difference is calculated from the top of the eye tracker to the bottom of the screen.
Since the length can vary between different mobile devices you must measure the distance from the top of the mo-
bile device to the bottom of the screen value Z (as shown in the image below).
Add 30 mm (the eye tracker distance) to the measured value, ex. -value =-( Z+30).
Figure 5.4 Height difference

9
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
As mentioned previously, the number you enter will be a negative one since the eye tracker is positioned on top of
and behind the screen. For example: if the measured value is 119 mm, then the entered value will be -149 mm (the
sum of –119 + –30). Enter your calculated value and click Next.
Figure 5.5 Enter the height difference between the top of the eye tracker to the bottom of your screen

10
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
9. Eye tracker angle: Set the eye tracker angle to zero (0). Click Next.
Figure 5.6 Enter the angle of your tracker
10. Enter a name and click Save. Your mobile device settings will be saved under that name on your eye tracker.

11
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
5.4 Assemble the Mobile TestingAccessory
Now it’s time to put your Mobile Testing Accessory together. It will look like this when it is assembled:
Figure 5.7 The fully assembled Mobile Testing Accessory
1. Remove the protective plastic from a Sticky Pad and attach it to the Device Holder by pressing gently. If the Sticky
pad is not sticky, clean it with some water.
2. Attach the mobile device to the Device Holder by placing the mobile on the sticky pad and pressing gently. Make
sure that the mobile is aligned with the top of the Device Holder.
Figure 5.8 The mobile device attached to the Sticky Pad on the Device Holder
The Sticky Pads are made for reuse. If you find that one of the Sticky Pads is not holding the mobile de-
vice securely, clean it with cold water to remove any particles.
You can easily remove the mobile device whenever you want by pulling the mobile device gently away
from the Sticky Pad attached to the Device Holder. Thereshould be no residue stickiness left on the mo-
bile device. If the Sticky Pad is dirty, clean it with cold water only. This will reactivate the adhesive and re-
move any unwanteddirt.

12
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
3. Attach the eye tracker to the magnetic Mounting Bracket located at the top of the Device Holder.
Figure 5.9 The mobile device and the Pro Nano eye tracker attached to the Sticky Pad on the Device Holder
4. Connect the eye tracker via USB to a computer.
5. Plug the mobile device into the Screen Capture device. Use the iPhone lightning to HDMI for iPhone or the USB to
HDMI cable forAndroid.
If using an iPhone, make sure that the USB Type-C cable is connected to a power supply or the com-
puter’s USB port.

13
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
6. Plug in the HDMI end of the cable into the Screen Capture device.
Figure 5.10 The Screen Capture device
7. Attach the Screen Capture device to the computer via USB.
8. Mount the Mounting Arm on the Base using the female 3/8” to female ¼” Adapter.
9. Screw the Magnetic Plate to the Mounting Arm.
10. Snap the Device Holder to the Mounting Arm.
To remove the Device Holder from the Mounting Arm, gently twist it to one side.
11. Adjust the arm to the desired position and tighten the knob.

14
5 Set up yourdisplay
Mobile Testing Accessory User’s manual v.1.1 - en-US
12. Confirm that the eye tracker can detect the participant’s eyes using Pro Eye Tracker Manager on the computer. En-
able the Position Guide at the bottom left of Pro Eye Tracker Manager. Once activated, you should be able to see
two “eyes” in a face contour.
Figure 5.11 Position Guide in Pro Eye tracker Manager
If the eye tracker doesn’t find the participant’s eyes, make sure that you have calibrated the eye tracker first on a
computer screen. Pro Eye Tracker Manager only looks for gaze that falls into the defined area, e.g. the mobile
device screen. If the eye tracker is not calibrated for each participant’s eyes, the offset can be too big and the
green head will not show up when looking at the mobile device screen. If you have calibrated the eye tracker be-
fore attaching it to the Device Holder, the eye tracker will have a lower offset and it will then be able to detect the
gaze in the defined screen setup.
5.5 Detach the eye tracker from the Mobile Testing Accessory
To remove the eye tracker, gently pull it away from the Mounting Bracket and leave the Mounting Bracket in place. Do not
remove the bracket from the DeviceHolder.
You can purchase additional mounting brackets. See the Tobii Pro Accessories webpage.

15
6 Start Experimenting
Mobile Testing Accessory User’s manual v.1.1 - en-US
6 Start Experimenting
Recording and analyzing data with Mobile Testing Accessory can be done in an analytical software such as Tobii
Pro Lab using the screen camera projects. Tobii Pro Lab gives you the possibility to calibrate the eye tracker on the
mobile device and record and analyze it. Find out more about using the Mobile Testing Accessory together with Tobii
Pro Lab on the Tobii Pro Learning Center webpages.

16
Appendix A Support, Learning Center, and Warranty
Mobile Testing Accessory User’s manual v.1.1 - en-US
Appendix A Support, LearningCenter,
and Warranty
A1 Customer Support
If you need help, please contact Customer Support at Tobii Pro.
A1.1 Get help online
Many questions can be answered by visiting Tobii Pro Connect. It contains the latest information about contacting Support,
links to our Learning Center, and much more. Log in or register to see information about your account and to reach Cus-
tomer Support at Tobii ProConnect.
A2 Learning Center
If you are new to eye tracking, or want to extend your knowledge about eye tracking research, sign up for one of our learn-
ing programs and events, or browse through our extensive article library in our Learning Center.
For further product information and other support resources, please visit www.tobiipro.com.
A3 Warranty information
Read more about Tobii Pro Care on Service Description.

17
Appendix B ComplianceInformation
Mobile Testing Accessory User’s manual v.1.1 - en-US
Appendix B Compliance Information
Mobile Testing Accessory is CE-marked, indicating compliance with applicable health and safety legal
requirements set out in the European Union and EEA.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference re-
ceived, including interference that may cause undesired operation.
Mobile Testing Accessory is allowed to be sold in:
• European Economic Area
• USA
• Canada
• Japan
• China
B1 CE Statement
Mobile Testing accessory is CE-marked, certifying compliance with the legal requirements for health, safety and environ-
mental protection requirements for the European market. Mobile Testingaccessory complies with the following directives:
• 2011/65/EU (RoHS 2) - Restriction of Hazardous Substances Directive
• 2014/30/EU (EMC) - Electromagnetic CompatibilityDirective
B2 VCCI
Mobile Testing accessory is Approved for the Japanese technical EMC standards V 3/2014.04 for limits
and methods of measurement of electromagneticinterference.
B3 Industry Canada Statement
Mobile Testing accessory has been tested and found to comply with ICES-003:2016, Issue 6, Class A devices.
B4 EMC
Mobile Testing accessory is CE-marked, certifying compliance with the legal requirements for health, safety and environ-
mental protection requirements for the European market. Mobile TestingAccessory complies with the following directives:
• EN 55032:2015 +AC:2016 (ClassA)
• EN 55022:2010 +AC:2011
• EN 55024:2010 +A1:2015
• FCC 47 CFR Part 15, SubpartB
• ICES-003 Issue ClassA
• VCCI: V-3/2014.04
B5 Sustainability
Mobile Testing Accessory complies with the following standards and directives:
• IEC 62321-3-2:2013
• IEC 62321-4:2013
• IEC 62321-5:2013
• IEC 62321-6:2015
• IEC62321-7-1:2015
• IEC62321-7-2:2015
• IEC62321-8-1:2017
