TOBOQ TAA-V1 User manual

User Manual| V 1.0
AQUARIUMVAC.COM
Aqua Alarm Kit.

1
Table of Contents
Features................................................................................................Page 3
Operating Instructions.........................................................................Page 4
Bracket Instructions............................................................................ Page 5
Trubleshooting.....................................................................................Page 10
Maintenance........................................................................................Page 10
Safety Instructions...............................................................................Page 10
Warranty Information........................................................................Page 11

2
Aqua Alarm Kit
A One of a kind tool for aquarium lovers in the market. It always happened to aquarium
fans, while tank water runs on lower level without notice, by accident, Air tubes or water
filter systems with leaking tubes that creates mess of water on cabinet or house floors and
that can’t be ignored.
No more time wasted! No more mess!
Almost everyone loves to have a beautiful aquarium but reluctant to owning because of
the hassle in cleaning and maintenance. With our newly designed, easy- to-use TOBOQ
Aqua alarm all the nuisance is gone.
This IS the only model of its kind in the market –there is no other!
The Aqua alarm is designed for aquarium owners to notify any low level water accident
with Flashing LED and Beep buzzer.
OTHER AREAS OF USE:
The unit has a wide range of uses in residential and commercial locations such as:
Scientific and Research Laboratories, Educational Labs, Campers, Boats, Ponds, Pools
and more…Our products let you do things conveniently than before, or some things that
simply weren’t possible before.
Warranty Period: One year from purchase date. Extended
warranty is available.
Read the Entire Important Safety information Section at beginning of this manual
including all text under subheadings therein before setup or use of this product.
Owner’s Manual for TOBOQ Model TAA-V1

3
TOBOQ Aqua alarm is a remarkably efficient Device.
Built using a durable, plastic housing.
Designed with precision quality components for durable quality
Low power consumption
Integrated waterproof controls switch and plug.
Technical Specifications:
Material: Engineered Plastic
Chassis: Durable Plastic
Drive: Battery
Voltage: DC 9V
Highest Heat Resistance: 131° Fahrenheit / 55° Celsius
Approx. Size:
Length: 6 Inches / 15Cm
Width: 2.5 Inches / 6.5Cm
Height: 1 Inches / 2.5Cm
Weight: 5oz. / 130g
Package Weight: 1 lbs.
Package includes:
One Aqua alarm
One Water level sensor
Three Ft. of connector wire (1 meter)
One 9V Battery
One Main Top Flat Bracket
One Short L shape Bracket (30mm)
One Long L Shape Bracket (70mm)
One 8X15mm Screw with nut
One sticky Hook and Loop Double-sided Tape (1”)
Two Wire-ties Plus Two Clips
One User Manual
Aqua Alarm Holder (Optional)
Note: This Device is certified and tested for water only; use with any other
liquids is at your risk and not covered under warranty.
WARNING! NOT for use with flammable liquids.
Features:

4
Front Panel Layout
(Picture 1)
1. ON /OFF Switch
2. Input Sensor plug
3. Warning Flash Led
4. 9V DC Battery (pic 2)
1-ON /OFF
Switch
2- Input Sensor
plug
3-Flash
Led
Operating Instructions

5
(PIC 2)
This is the main Aqua Alarm Bracket designed for hold Water Float Sensor Switch on
Aquarium edge trim. Top screw integrated for hold bracket on place and tides the bracket
on tank glass. Side screw will be use when plan to use L shaped brackets.
Float Switch PP Water Liquid Level Sensor module with 18" wire attached is included.
Made with PETG plastic.
(PIC 3)
1-Level sensor switch
2-Main Top Flat Bracket
3-Adjustable Screw
4-Long L Shape Bracket (70mm)
5-Short L shape Bracket (30mm)
6-Sensor 2 Pins connector
4- DC 9V Battery
Location.
Aqua Alarm Bracket with Float Sensor

6
(PIC 3)
1- By your Choose select one of three available brackats that matches for your
Aquarium water level.
2- Choose a position on you aquarium top area (usually in one of back corner).
3- Untight Adjustable Screw (3) to be able to move aquarium glass holder A and B .
4- Place position on A-Side on aquarium top adge and press B-Side until rich the on
aquarium glass by holding it then tight in Adjustable Screw (3).
5-Short L
shape
Bracket
1-Level sensor
switch
3-Adjustable
Screw
2-Main
Top Flat
Bracket
4- Long L
Shape
Bracket
6- 2 Pins
connector
A-Side
B-Side
Bracket Setup Instructions

7
5- Connect 2-Pins connectore to integraded extantion cable.
6- Connect 3.5mm plug extantion cable in to Aqua Alarm sensor female plug.
7- Turn on Aqua Alarm,
8- The Level sensor Float switch always should be under water level.
9- Testing; Press Float switch on end bottom position, Aqua Alarm will sounds
warning Beep and flashing LED.
You may disasssamble main brackets and using provided 8X15mm Screw with nut to
install other L Shape brackets anytimes in deppends on your applcation.
The (PIC 3, PIC 4, PIC 5) are basic idea for three styles.
Style #1 (PIC 3)
Bracket Setup Diagrams

8
Style #2 (PIC 4)
Style #3 (PIC 5)

9
For Best Result; Always Position the Level Sensor Float Switch Moveable Ball
below of Aquarium water level.
*WARNING: PLEASE KEEP AQUA ALARM IN A DRY AREA. THIS IS NOT Fully
WATER RESISTANT.

10
1-After connecting Bracket attached Sensor to Aqua Alarm unit nothing
happens and LED display is OFF:
Check 9V Battery with voltage tester.
Check 2-pins Sensor wire is connected to cable correctly.
Check ON/OFF Switch positions.
*Extended Warranty is available for purchase. Please visit AquariumVac.com for more
information regarding our warranty and support.
After Use; after while press water sensor ball in to water to make sure alarm is
functioning correctly.
***Always Keep AQUA ALARM in Dry Area and
Separate from other power devices ***
Visit our website at: www. Aquariumvac.com for more information.
Maintenance
Safety Instructions
Troubleshooting

11
Unit Model:
Unit Serial Number:
Date of Purchase:
Registration Products:
AquariumVac.com management encourages all Buyers to register purchased
Products at AquariumVac.com website by filling out the registration form
online.
Additional Extended Warranty Applied on Unit Serial Number.
Limited Warranty and Return Policy
All TOBOQ brand products, herein known as “Products”, sold on AquariumVac.com are covered by a 12-
month Limited Manufacturer’s Warranty.
TOBOQ.com warrants its Products free from defects in material and workmanship for a period of twelve
(12) months from the date of purchase.
The warranty does not apply to failures of the product due to improper use, installation, handling or
breakage of the Product. The warranty does not cover instances resulting from improver care, accidents,
and alterations, modifications, tampering in any way or negligence. The warranty is void if the product has
been repaired or serviced by an unauthorized person/company.
The warranty is not transferable and void if/when the product is sold to a third party.
The warranty does not apply to damages caused during shipping or caused by force majeure or an Act of
God.
The warranty does not cover accessories included with the product, such as cables, tubes, or any other
items that may be included and shipped with the main unit.
LIMITATION OF LIABILITY:
TOBOQ.com and Aquariumvac.com shall not under any circumstances be liable for incidental damages or
special or consequential damages. Buyer’s remedies as set forth herein are exclusive, and the liability of
TOBOQ to user with respect to Products, including the performance or breach of any contract, or from the
manufacture, sale, delivery, installation, or use of any Product covered by or furnished under this warranty,
whether arising out of contract, negligence, strict tort, or under any warranty or otherwise, shall not, except
as expressly provided herein, exceed the price of the goods upon which such liability is based. This
Limitation of Liability applies to original Products and replacement goods.
Under no circumstance will TOBOQ.com and AquariumVac.com be held liable for any physical or
property damages resulting from liquid chemicals, filters while using the Products.
Return Policy
AquariumVac.com will accept returns of undamaged Products in original packaging within 30 days of
receipt.
All returns / exchanges must be made within 30 days of receipt of the merchandise.
Refund or exchange transaction will be competed upon receipt of the package in our warehouse.
Warranty Information

12
Sales are final after 30 days and AquariumVac.com will not issue any credit or refunds for returned
Products.
A 20% Restocking Fee applies to returned products.
All shipping and handling fees are not refundable. Return shipping charges are the responsibility of the
sender.
Special Orders:
*Return of special customized orders is not acceptable and not refundable.
DOA (“Dead-On-Arrival”):
Upon receipt of a Product, Buyer should promptly turn on the Product to make sure it is working
properly. If the Product does not power up, or if the Product appears to malfunction, Buyer should
immediately contact AquariumVac.com technical support to obtain an RMA and shipping
instructions. Upon receipt of the RMA, Buyer should return the “defective” Product to the Company,
accompanied by the RMA number issued by AquariumVac.com. At its own discretion, the Company will
either repair or replace the Product. AquariumVac.com will only accept DOA Products if returned to the
Company within the Product’s twelve (12) month warranty period. (Within 30 days from receipt).
Normal Products Operation and Usage:
After the 30-day grace period, should a Product suddenly stop functioning properly, Buyer should
communicate with AquariumVac.com technical support team to resolve the issue. If the issues cannot be
resolved remotely with the aid of the Company’s technical support, AquariumVac.com personnel will issue
the Buyer an RMA and shipping instructions so that Buyer can return the Product to AquariumVac.com for
repair or exchange only. AquariumVac.com will only accept Products if returned to the Company within
the Product’s twelve (12) month warranty period.
AquariumVac.com will only accept Product returns with an RMA. To obtain an RMA, or to communicate
with the Company about any other issue and to make any inquiries, please email AquariumVac.com at
[email protected]m. The Company will issue an RMA number and instructions for returning the product
within two (2) business days after receiving a request.
AquariumVac.com management encourages all Buyers to register purchased Products at
AquariumVac.com website by filling out the registration form online.
Disassembling Products and tempering with the security seal without a proper authorization from
AquariumVac.com technical support team will void this warranty.
AquariumVac.com management appreciates your business.
Warranty Period: One year from purchase date.
Extended warranty is available.
Contact Us:
Sales at: [email protected]
Information and Supports at: [email protected]
Copyright. All Rights Reserved. AquariumVac.com © 20122
