Tool Shed TSDBS User manual

Electric Drill Bit Sharpener
TSDBS
www.thetoolshed.co.nz

2
OPERATION MANUAL
www.thetoolshed.co.nz
PRODUCT DETAILS
PRODUCT
MODEL NO.
Electric Drill Bit Sharpener
TSDBS
D
ISTRIBUTED BY
NOTE:
This manual is only for your reference. Due to the continuous improvement of the ToolShed
products, changes may be made at any time without obligation or notice.
WARRANTY
This product may be covered under the ToolShed warranty. For more information see our Terms
& Conditions at www.thetoolshed.co.nz

3
OPERATION MANUAL
www.thetoolshed.co.nz
C O N T E N T S:
Specifications ...................................................................................................................................... 4
General Safety ..................................................................................................................................... 5
Operation ............................................................................................................................................ 7
Cleaning ............................................................................................................................................. 10
Parts List ............................................................................................................................................ 10

4
OPERATION MANUAL
www.thetoolshed.co.nz
SPECIFICATIONS
Voltage 230v / 50Hz
Power 80W
Speed 4200RPM
Stone 80 grit diamond
Drill Sizes 3mm - 13mm
Min. Length 85mm

5
OPERATION MANUAL
www.thetoolshed.co.nz
IMPORTANT INFORMATION
GENERAL SAFETY GUIDELINES
WARNING READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS. Failure to follow
instructions and warnings could lead to serious injury, electric shock, or fire. Save ALL warnings
and instructions for future reference.
WORK AREA SAFETY
- Ensure that your work area is kept well-lit and clean. Lack of visibility and clutter greatly
increase the risk of accident.
- Keep bystanders and children clear when operating a power tool or machine. They can
cause distraction or risk injury themselves.
- Ensure you are not operating the power tool or machinery in the presence of flammable
gases, dust, liquids, or anything that creates an explosive atmosphere. Power tools and
machinery can create sparks which can lead to ignition in these environments.
PERSONAL SAFETY
- Always wear personal protective equipment. Eye protection, ear protection, dust masks
and other protective equipment will help to reduce the risk of personal injury.
- Dress appropriately. Do NOT wear jewellery or loose clothing that can get caught in
moving parts. Keep hair, loose clothing, jewellery, and anything else that could be of risk
away from moving parts or they could be caught.
- Always remain alert and do NOT operate the power tool or machinery under the
influences of any substances (drugs, medication, alcohol). Losing focus could lead to injury
while operating power tools and machinery.
- Always keep proper footing and balance. Overreaching can lead to slipping and falling
which can result in injury.
- Ensure the power switch is in the off position before connecting any battery or power
source to the power tool or machinery. This can lead to accidents as tools and machinery
can fire suddenly when it is not expected and lead to accident.
- Use all provided dust collection and extraction attachments if included. This with the use
of dust masks can help keep you safe from dust and keep your work site clear while working.
- Ensure loose parts such as a wrench or adjusting key are removed before starting the
power tool or machinery. Failure to remove these can result in serious injury.
ELECTRICAL SAFETY
- Do NOT use the power tool or machinery in raining conditions or wet areas where the
power tool or machinery could get wet. Water in the power tool or machinery can lead to
electric shock.
- Only use the power tool or machinery when the plug correctly matches the power outlet.
Modifying plugs greatly increases the risk of electric shock.
- Keep the power cord away from anything that could damage it such as sharp edges,
moving parts or heat. A damaged power cord increases the risk of electric shock.
- Only operate outdoors with the use of an outdoor extension lead. Not all extension leads
are suited to outdoor use and using one which is not can greatly increase the risk of electric
shock.

6
OPERATION MANUAL
www.thetoolshed.co.nz
- Avoid body contact with grounded or earthed surfaces. Surfaces such as radiators, ranges,
pipes, and refrigerators can increase risk of electric shock due to your body being earthed or
grounded.
POWER TOOL AND MACHINERY USE AND CARE
- Use the correct tool for the job. Forcing a tool to do a job it was not designed for increases
the risk of accident or injury.
- Disconnect power tools and machinery from power or remove batteries before storing
tools and machinery or making any changes or adjustments to them. This reduces or
removes the risk of power the tool or machinery accidentally firing which can help prevent
injury or accident.
- Check the power tool for damage or any condition that could affect the way the tool or
machine works. An unrepaired tool or machine can lead to accident and injury. Only have
your tool or machine repaired with genuine parts from The ToolShed.
- Only use the power tool and machinery with genuine parts or accessories that are
designed to be used with the power tool and machinery. Failure to do so could result in
accident or injury or damage your tool or machinery.
- Store your tool or machinery out of reach of children and away from untrained personnel
when not in use. Use by somebody untrained or a child could lead to accident or serious
injury.
SERVICE
- Have your tools and machinery serviced at The ToolShed with ToolShed replacement
parts. This will ensure that the safety of the power tool or machine is maintained.
ADDITIONAL SAFETY FOR ELECTRIC DRILL BIT SHARPENER
- Be careful of bits when sharpening. Bits will become hot. Be careful when handling and
allow tips to cool for some time before storing.
- Sharpening head may become hot while using. Be careful when handling.

7
OPERATION MANUAL
www.thetoolshed.co.nz
OPERATION
1. Loosely insert your drill bit into the positioning sleeve.
2. Hold back the toggle and position the sleeve into the depth adjustment cylinder. Push the
drill bit in as far as it will go.

8
OPERATION MANUAL
www.thetoolshed.co.nz
3. Release the toggle while rotating the drill bit so that it grips the flutes of the drill bit firmly.
4. Tighten the rear of the sleeve to hold the bit in position
5. Turn the sharpener on and place the sleeve into the sharpening cylinder.

9
OPERATION MANUAL
www.thetoolshed.co.nz
6. Rotate the sleeve back and forth until there is minimal contact with the grinding wheel.
7. Remove the sleeve from the cylinder, rotate it 180°, put it back into the cylinder, and repeat
the process.
FOR SPLIT POINT SHARPENING
1. Repeat the drill bit alignment process.
2. Place the sleeve into the cylinder on top of the drill bit sharpener.
3. Rotate until minimum contact, take out and rotate 180°, place back in and repeat the
process.

10
OPERATION MANUAL
www.thetoolshed.co.nz
CLEANING
- Make sure to keep the surface of your unit free of grit, dirt, and grease. Use soapy water or
non-toxic solvents. Do not use petroleum-based solvents.
- Keep air vents free of foreign matter at all times.
PARTS LIST

11
OPERATION MANUAL
www.thetoolshed.co.nz
Part No.
De
scription
Qty.
Part No.
Description
Qty.
1
Top Housing
1
26
Cover
1
2
Button
1
27
Cushion
4
3
Screw
2
28
Base
1
4 Spring Leaf 2 29 Screw 11
5 Screw 2 30 Dust Cap 1
6
Terminal
1
31
Cord
1
7 Fixing Shelf 1 32 Connector Board 1
8 Screw 2 33 Clamp Spring 1
9 Pad 1 34 Screw 4
10 Grinding Wheel 1 35 Bracket 1
11 Connector 1 36 Stand Socket 1
12 Screw 1 37 Positioner for Blade 1
13 Screw 2 38 Blade Holder 6
14 Positioner 1 39 Steel Spring 6
15 Screw 5 40 Transition Tube 1
16 Motor 1 41 Locknut 1
17 Wire Restraining 1 42 Hold Accessory (incl.#35-39)
18 Screw 2 43 Screw 2
19 Switch 1 44 Small Cover 1
20 PCB 1 45 Nut 2
21
Fuse Block
1
46
Pressure Spring
2
22
Nut
f
or Fuse
1
47
Cover Support
1
23 Fuse 1 48 Big Cover 1
24
Inductance
1
49
Cover Support
1
25
Locknut
f
or
F
use
1
50
