Bartell Global Morrison UNI-SCREED User manual

UNI-SCREED MANUAL
OWNER’S MANUAL AND PARTS LIST
www.BARTELLGLOBAL.com
Doc. # OIPB-B19040
Orig. Rel. –01/2017
Curr. Rev. - 05

UNI-SCREED MANUAL
AND PARTS LIST
1
OIPB –B19040
Bartell Morrison Inc.
170 Traders Blvd E
Mississauga, Ontario, Canada
L4Z 1W7
Tel: [phone]
Fax: [phone]
Bartell Morrison USA LLC
200 Commerce Drive, Unit A
Freehold, NJ, USA
07728
Tel: [phone]
Fax: [phone]
SPE International Ltd
Honeyholes Lane
Dunholme, Lincoln, England
LN2 3SU
Tel: [phone]
Fax: [phone]
Innovatech
4701 Allmond Ave
Louisville, Kentucky, USA
40209
Tel: [phone]
Fax: [phone]
ORIGINAL LANGUAGE OPERATING MANUAL FOR
SCREED EQUIPMENT
© 2019 Bartell Morrison Inc.
No part of this work may be reproduced or transmitted in any form or by any means, electronic
or mechanical, including photocopying and recording, or by any information storage or retrieval
system without the prior written permission of Bartell Morrison Inc. unless such copying is
permitted by federal copyright laws.
Address inquiries or reference permissions care of:
Bartell Morrison Inc., 170 Traders Blvd., Mississauga, Ontario, Canada, L4Z 1W7
REV.
DATE
DESCRIPTION
APPROVED BY:
1
10/2017
Updated item 35 P/N: 11792 was 23007
AN
2
11/2017
Updated item 2 P/N: 11914 was 11069
AN
3
12/2017
Updated item 12 P/N: 10670 was 23046, Updated item 18
P/N: 23156 was 11053, Updated item 41 P/N: 23157
AN
4
01/2018
Updated throttle cable installation instructions
AN
5
08/2019
Updated Item 19 P/N: 11051 was 23019, Update Address
AN
www.BARTELLGLOBAL.com

UNI-SCREED MANUAL
AND PARTS LIST
2
OIPB –B19040
SAFETY PRECAUTIONS
DANGER
EXPLOSION HAZARD
Never operate the machine in an explosive
atmosphere, near combustible materials, or
where ventilation does not clear exhaust fumes.
WARNING
BURN HAZARD
Never come into contact with the engine or
muffler when engine is operating or shortly after it
is turned off. Serious burns may occur.
CAUTION
MOVING PARTS
Before starting the machine, ensure that all
guards and safety devices are in place and
functioning properly.
ATTENTION
READ OWNER’S MANUAL
Read and understand owner’s manual before
using this machine. Failure to follow operating
instructions could result in serious injury or death.

UNI-SCREED MANUAL
AND PARTS LIST
3
OIPB –B19040
Personal Protective Equipment (PPE)
Hearing Protection
Wear earplugs or ear muffs to protect hearing
from potentially damaging noise levels
Eye Protection
Wear eye protection to protect eyes from blowing
dust, splattering concrete, and other foreign
objects
Safety Footwear
Wear safety footwear to protect feet from falling
objects, compression and punctures or cuts from
surrounding and below
Hand Protection
Protect exposed skin surfaces when working with
fresh concrete to avoid skin irritation or chemical
burns

UNI-SCREED MANUAL
AND PARTS LIST
4
OIPB –B19040
TABLE OF CONTENTS
QUALITY ASSURANCE/ MACHINE BREAK IN 5
WARRANTY INFORMATION 6
SPECIFICATIONS 7
PREVENTATIVE MAINTENANCE AND ROUTINE SERVICE PLAN 8
oROUTINE SERVICE SCHEDULE 9
UNISCREED INFORMATION 10
oGENERAL HEALTH AND SAFETY TIPS 10
oMAINTENANCE AND CLEANING 11
oASSEMBLY INSTRUCTIONS 12
oOPERATION OF THE UNISCREED 13
ASSEMBLY DRAWING AND PARTS LIST 14
oASSEMBLY DRAWING 15
oPARTS LIST 16
DECLARATION OF CONFORMITY 18

UNI-SCREED MANUAL
AND PARTS LIST
5
OIPB –B19040
QUALITY ASSURANCE/ MACHINE BREAK IN
The Morrison Uni-screed is the product of extensive engineering development designed
to give long life and unmatched performance. You can help ensure that your Uni-screed will
perform at top levels by observing a simple routing on first use. Consider that your new Uni-
screed is like a new car. Just as you would break in a new car to the road or any new machine
to the job, you should start gradually and build up to full use. Learn what your machine can do
and how it will respond. Refer to the engine manufacturer’s manual for run-in times. Full throttle
and control may be used after this time period, as allowed by material. This will serve to further
break in the machine on your specific application, as well as provide you with additional
practice using the machine.
We thank you for the confidence you have placed in us by purchasing a Morrison Uni-
screed and wish you many years of satisfied use.

UNI-SCREED MANUAL
AND PARTS LIST
6
OIPB –B19040
WARRANTY INFORMATION
Bartell Morrison Inc. agrees to furnish without charge, F.O.B. our plant, a replacement
for any part or portion thereof, comprising the base unit of the Morrison Uni-screed, consisting
of the drive shaft assembly and the clutch assemblies, save and except power units and/or
bearing or electrical controls which prove upon our examination, to be defective in either
material or workmanship within a period of twelve (12) months from date of purchase, provided
that notice of such defective part or portion thereof is given to Bartell Morrison Inc. within the
twelve month warranty period. No further or other guarantee or warranty expressed or implied
in connection with the sale of the Morrison Uni-screed is given and our sole liability consists in
replacing defective parts or portions thereof. We shall not be responsible for any special,
indirect or consequential damages arising in any manner whatsoever.
This guarantee is for the sole benefit of the original purchaser as end user. Our
responsibility under this guarantee ends in the case the original purchaser transfers ownership
of the Morrison Uni-screed, makes any changes or adds any parts or devices not of our
manufacture to the Uni-screed.

UNI-SCREED MANUAL
AND PARTS LIST
7
OIPB –B19040
SPECIFICATIONS
Handle (fully adjustable)
28lbs (12.7kg)
Blades
4’ (1.2m)
6.41lbs (2.9kg)
6’ (1.8m)
9.6lbs (4.4kg)
8’ (2.4m)
12.8lbs (5.8kg)
10’ (3.0m)
16.0lbs (7.3kg)
12’ (3.7m)
19.2lbs (8.7kg)
14’ (4.5m)
22.4lbs (10.2kg)
16’ (4.9m)
25.6lbs (11.6kg)
Engine
1.3hp, 35cc, recoil start, air cooled,
single overhead cam cylinder
Fuel Capacity
0.17 gal (0.65L)
Estimated Running Time
1.1hrs @ 7000rpm
Weight (dry)
27.9lbs +blade (12.7kg +blade)
Sound Power
29.6lbs +blade (13.5kg +blade)
Weight (operating)
50 Dba
Vibration
<9 m/s²

UNI-SCREED MANUAL
AND PARTS LIST
8
OIPB –B19040
PREVENTATIVE MAINTENANCE AND ROUTINE SERVICE PLAN
This MORRISON UNI-SCREED has been assembled with care and will provide years of
service. Preventative maintenance and routine service are essential to the long life of your
Screed. Your dealer is interested in your new machine and has the desire to help you get the
most value from it. After reading through this manual thoroughly, you will find that you can do
some of the regular maintenance yourself. However, when in need of parts or major service, be
sure to see your Bartell Morrison dealer. For your convenience, we have provided this space to
record relevant data about your MORRISON UNI-SCREED. When in need of parts or service
be prepared to provide your Screed serial number. Locate the serial number now and record in
the space below.
Date Purchased:
Type of Machine:
Dealer Name:
Model:
Dealer Phone:
Serial Number:
Replacement Parts Used
Maintenance Log:
Part No.
Quantity
Cost
Date
Date
Operation

UNI-SCREED MANUAL
AND PARTS LIST
9
OIPB –B19040
ROUTINE SERVICE SCHEDULE
Routine Service Intervals
Each
Use
First
months
or 10 hrs
Every 3
months
or 25 hrs
Every 6
months
or 50 hrs
Every
year or
100 hrs
Every 2
years or
300 hrs
General Inspection
Warning Stickers
Check
O
O
O
O
O
O
Test run:
Operation
O
O
O
O
O
Engine
Engine Oil
Check level
O
Change
O
O
Spark Plug
Check-adjust
O
Replace
O
Timing Belt
Check
After every 300 hrs (2) (3)
Cooling Fins
Check
O
Air Cleaner (2)
Check-clean
O (1)
O
Replace
O
Air Intake Line
Check
O
Replace
2 yrs
Nuts, bolts,
fasteners
Check (Retighten
if necessary)
O
Clutch Shoes
Check
O (2)
Idle Speed
Check-adjust
O (2)
Valve Clearance
Check-adjust
O (2)
O
Combustion
Chamber
Clean
After every 300 hrs (2)
Fuel Filter
Clean
O (2)
Fuel Tank
Clean
O (2)
Fuel Tubes
Check
Every 2 years (Replace if necessary) (2)
Oil Tube
Check
Every 2 years (Replace if necessary) (2)
(1) Service more frequently in dusty areas
(2) Refer to engine owner’s manual for servicing instructions and a detailed maintenance
schedule. Some items should be serviced by your servicing dealer, unless you have the
proper tools and are mechanically proficient. Refer to the Honda shop manual for service
procedures
(3) Check that there is no crack and abnormal wear-out in the belt, and replace if it is
abnormal

UNI-SCREED MANUAL
AND PARTS LIST
10
OIPB –B19040
UNISCREED INFORMATION
GENERAL HEALTH AND SAFETY TIPS
•Do not use the Morrison Uni-screed, fitted with a gasoline engine, indoors or in poorly
ventilated areas. Ensure there is sufficient ventilation to avoid inhaling exhaust gasses,
as they may be harmful.
•Avoid touching the electrical cables or spark plug cap while the engine is running to
avoid electric shock.
•Check the fuel tank and lines for leaks before starting engine.
•Wear appropriate personal protective equipment while operating the Morrison Uni-
screed.
•Protective footwear, safety glasses, hearing protection, padded gloves, and a dust mask
are highly recommended.
•Wear work gloves and safety glasses while refueling the Morrison Uni-screed.
•Ensure sufficient ventilation during refueling to avoid a build-up of dangerous fumes.
•Refuel the Morrison Uni-screed only after the engine has cooled after use.
•Avoid smoking or open ignition sources such as furnaces, welders or torches during
refueling.
•Avoid contact of limbs with the vibrating blade or base unit during operation. Use only
the handles to control the Morrison Uni-screed.
•Some vibration in the control handles during operation is normal. Take appropriate
measures dictated by your workplace regulations to minimize health effects of vibration
exposure.
•Regular maintenance and inspection of the Morrison Uni-screed can prevent injuries
caused by worn-out or damaged equipment and will extend the useful life of your unit.
•Carry the Morrison Uni-screed by the carry handle, lifting carefully to avoid back injury.
•NEVER carry the Morrison Uni-screed while the engine is running.
•Always avoid direct skin contact with fresh concrete.

UNI-SCREED MANUAL
AND PARTS LIST
11
OIPB –B19040
MAINTENANCE AND CLEANING
Due to the nature and environment of use, the Uni-screed is exposed to severe operating
conditions.
•Some general maintenance guidelines will extend the useful life of your trowel.
•It is highly recommended that all maintenance and repairs are carried out by approved
Bartell Morrison dealers.
•Always use genuine Bartell Morrison replacement parts; use of foreign parts may void
your warranty and result in injury or damage to property.
•Refer to your engine manual for details of engine cleaning, maintenance, and your
engine’s warranty coverage.
•Clean concrete, dust, and residue from the blade and base unit daily. Failure to do so
will result in decreased performance and premature failure.
•The blade and lower base unit (i.e. below the engine) can be cleaned with a water
sprayer.
•Avoid getting water inside the engine housing or into the on/off switch on the handle.
•Clean the engine ventilation openings using a brush or damp cloth. Dirt, grease, or
concrete entering the ventilation openings will reduce engine cooling, leading to
premature engine wear and failure. Refer to your engine manual for more information.
•Inspect the Morrison Uni-screed at the end of each working day for signs of wear or
damage.
•Store the Morrison Uni-screed in a clean, dry, and dust free place.

UNI-SCREED MANUAL
AND PARTS LIST
12
OIPB –B19040
ASSEMBLY INSTRUCTIONS
INITIAL SETUP OF THE UNI-SCREED
Upon removing the Morrison Uni-screed from its box for the first time, you will find the
base unit with the handles removed. The left handle is detached in the box, while the right
handle is attached to the base unit by its electrical cable and throttle control cable. The throttle
cable is not connected to the throttle lever or engine to avoid damage to the cable, lever or
engine during shipping.
Set up the handles using the clamps and hex key provided. Set the length and rotation to suit
the operator. Then to set up the throttle cable, follow the steps
below:
•Squeeze throttle lever open to expose the throttle cable
carrier
•Place the ball of the cable in the carrier (Fig #1) and line
the cable through the slot in the carrier, housing, barrel
and barrel locking nut
•Release the lever and turn the barrel and locking nut so
the slots do not align, and lock the barrel in place with the
locking nut
•Open the Honda engine air filter cover by gently
squeezing the clip on the front of the black filter housing
and remove the cover
•Pull the throttle cable over to the
engine throttle wheel.
•Rotate the silver throttle wheel so
that the larger hole is pointing toward
the top of the engine.
•Slide the stainless-steel throttle cable through the slot in the silver
throttle wheel. Make sure the throttle cable nipple is above the silver
throttle wheel.
•Pull throttle cable down to slide nipple into the larger hole in the
throttle wheel
•Place the threaded fitting of the throttle cable conduit into the clamp
below the throttle wheel. With a washer on either side
•Tighten the nuts of the threaded fitting onto the clamp to lock the
conduit in place. Adjust the tension and length of the throttle cable by
moving these nuts
•With the throttle grip at the end of the right operator handle
released, the throttle wheel on the Honda engine should be at the
zero position.
•After verifying the operation of the throttle cable by squeezing the
throttle grip a few times, replace the air filter cover on the Honda
engine. Your Morrison Uni-screed is now ready to use!
Fig #2: Correctly installed cable in throttle wheel
Fig #1: Ball installed in carrier

UNI-SCREED MANUAL
AND PARTS LIST
13
OIPB –B19040
OPERATION OF THE UNISCREED
OPERATING PRINCIPLE
An eccentric weight mounted on the exciter shaft contained within the vibration housing
is driven at high speed by a clutch drive system. This high-speed shaft revolution causes the
rapid vibratory motion of the blade as well as imparting a forward motion. The Morrison Uni-
screed is designed to run at an engine speed (engine take off shaft) of 3600 rpm. (Normally
considered full throttle). Running the engine at lower rpm’s will result in a decrease of
consolidation force and lower travel speed. It will create excessive “out-of-synch” vibrations
resulting in poor consolidation, maneuverability, excessive wear to the machine, and discomfort
to the operator.
STARTING PROCEDURE: WARM CLIMATE
Open fuel valve on gas tank. Set throttle lever to “Fast” idle position, set choke to closed
position, start engine. Open choke slightly to prevent flooding. Move to “Open” or “Run” position
when engine is warm, increase throttle to maximum operation position (3600 rpm).
STARTING PROCEDURE: COLD CLIMATE
Follow same procedure as above but allow longer warm-up period –3 to 5 minutes. In
cold weather, oil is much heavier to move and requires more time to work its way into the
moving parts. If maximum power is not attained, allow further warm-up time. Fill fuel tank with
clean gasoline, use safety approved gas containers. DO NOT MIX OIL WITH GASOLINE –
USE UNLEADED GAS ONLY.
STOPPING PROCEDURE
1. Throttle engine down.
2. Depress or turn off stop switch.
OPERATION
1. On level surfaces the Uni-screed moves forward or backward rapidly, depending on the tilt of
the handle. On uneven surfaces or inclines, light forward pressure on handle may be required
to assist the Uni-screed in moving. Lean the handle up or away from you to make the Uni-
screed travel toward you (i.e. forward). Lean the handle down or toward you to make the Uni-
screed travel away from you (i.e. backward).
2. ALWAYS OPERATE THE MACHINE AT FULL THROTTLE. If excessive vibration is felt
through the handle, do not operate until the engine is checked and set at its maximum running
speed of 3600 rpm.
3. The handle has four (4) adjustment clamps to allow the operator to use the Uni-screed more
comfortably. Ensure that the screws of all the clamps are tightened to securely hold the handle
sections rigidly. A loose clamp will cause that section to rotate and/or slide away from the
desired position.
LUBRICATION- ENGINE OIL- Always check engine oil before starting and at regular intervals
thereafter. Use proper engine oil as recommended. Keep engine oil clean, change accordingly.
Fill crankcase to levels as recommended in manufacturer’s engine manual.

UNI-SCREED MANUAL
AND PARTS LIST
14
OIPB –B19040
ASSEMBLY DRAWING AND PARTS LIST

UNI-SCREED MANUAL
AND PARTS LIST
15
OIPB –B19040
ASSEMBLY DRAWING

UNI-SCREED MANUAL
AND PARTS LIST
16
OIPB –B19040
PARTS LIST
Item #
Part #
Description
QTY
Remarks
1
22905
22904
22903
22902
22901
22906
22907
SCREED BLADE, 4 FT (SHOWN)
SCREED BLADE, 6 FT
SCREED BLADE, 8 FT
SCREED BLADE, 10 FT
SCREED BLADE, 12 FT
SCREED BLADE, 14 FT
SCREED BLADE, 16 FT
1
2
11914
THROTTLE CABLE
1
3
23001
VIBRATION BASE
1
4
10993
FLAT WASHER, M12
4
5
14268
LOCK NUT, M12-1.25.
2
6
10992
HEX HEAD BOLT, M12-1.25x60MM LG.
2
7
11049
VIBRATION ISOLATION MOUNT
4
8
12464
BEARING, 62203-2RS1, LOWER BASE
1
10
23005
SHAFT W/ COUNTERWEIGHT
1
11
12449
BEARING, 5202-2RS, UPPER BASE
1
12
10670
OIL SEAL, SHAFT, 15 X 30 X 7
1
13
23006
FLANGE, UPPER CONNECTOR
1
14
11028
HEX SOCKET CAP SCREW, M6 X 30MM LG,
4
15
10997
HEX HEAD BOLT, M8-1.25 X 20MM LG
4
16
10998
LOCK WASHER, M8
4
17
23002
BASE UNIT HANDLE, CHROME PLATED
1
18
23156
RUBBER CLIP, KICKSTAND
1
19
11051
VIBRATION ISOLATION SHAFT
1
20
11000
FLAT WASHER, M8
8
21
11054
LOCK NUT, M8
9
22
11059
RETAINING RING, EXTERNAL SHAFT
1
23
12466
BEARING, 6201-ZZ, LOWER DRIVE SHAFT
2
24
23003
DRIVE SHAFT
1
25
11060
RUBBER CAP, KICKSTAND
1
26
11055
PLASTIC WASHER, KICKSTAND
2
27
23004
KICK STAND, CHROME PLATED
1
29
10999
HEX HEAD BOLT, M8 X 20MM LG
1
30
11058
HANDLE CLAMP
4
32
23000
HOUSING, SHAFT
1
33
12467
BEARING, 6201-LLU, UPPER DRIVE SHAFT
1
34
11061
CLUTCH DRUM
1
35
11792
HANDLE SECTION, RIGHT, PUSHBUTTON TYPE
1
36
23008
HANDLE SECTION, LEFT
1
37
23009
HANDLE GRIP SECTION
2
38
11056
HAND GRIPS, HANDLE, PAIR
1
39
21365
ENGINE, HONDA GX35, 1.3 HP, 7000 RPM
1
Continued Next Page

UNI-SCREED MANUAL
AND PARTS LIST
17
OIPB –B19040
41
23157
ON/OFF ROUND TOGGLE SWITCH
1
ALUM HOUSING FOR SWITCH
1
ON/OFF SWITCH WIRE
1
43
11064
THROTTLE HANDLE
2
45
23013
GASKET
1
46
23150
SQUARE BUSHING, ALUMINUM
1
47
23153
GROMMET
2
48
14448
LOCK WASHER, M6
2
49
11495
HEX SOCKET CAP SCREW, M6-1.0 X 40MM LG
4
50
14447
FLAT WASHER, M6
4
55
23151
CARRY HANDLE
1
56
23030
SHAFT HOUSING ASSEMBLY (ITEMS 22, 23, 24,
32, 33, 34)
1
57
23031
EXCITER ASSEMBLY (ITEMS 3, 8, 10, 11, 13, 12,
14, 45)
1

UNI-SCREED MANUAL
AND PARTS LIST
18
OIPB –B19040
DECLARATION OF CONFORMITY
Declaration of Conformity / Certificat de conformité / Gelijkvormigheids certificaat Declaración de
Conformidad/Declaração de Conformidade/Dichiarazione Di Conformita
We: Bartell Morrison Inc.
170 Traders Blvd E.
Mississauga, Ontario, Canada
L4Z 1W7
Tel: [phone]
Fax: [phone]
EN Declare under our sole responsibility that the product to which this declaration relates is in
conformity with the following standard(s) or other normative documents.
FR Déclarons sous notre responsabilité que le produit cette déclaration est conforme aux normes
suivantes ou d’autres documents habituels.
NL Verklaren onder onze verantwoordelijkheid dat het product naar welke de verklaring verwijst
conform de volgende standaards of anders gebruikelijke documenten is.
ES Declaramos bajo nuestra única responsabilidad que el producto en lo que esta declaración
concierne, es conforme con la siguiente normativa u otros documentos.
PT Declara sob sua responsabilidade que o produto a quem esta declaração interessar, está em
comformidade com os seguintes documentos legais ou normas directivas.
DE Dichiariamo sotto la ns. unica responsibilita che il prodotto al quale questa dichiarazione si riferisce,
è fabbricato in conformità ai seguenti standard e documenti di normative.
EN 349:1993 Safety of Machinery - Minimum gaps to avoid crushing of parts of the human
body.
EN ISO 13850:2006 Safety of Machinery - Emergency stop equipment - Principles for design
EN ISO 12100 Safety of Machinery - General principles for design –Risk assessment and risk
reduction
EN ISO 3744 Acoustics - Determination of sound power levels and sound energy levels of noise
sources using sound pressure - Engineering methods for an essentially free field
over a reflecting plane
EN ISO 5349-1:2001 Mechanical vibration. Measurement and evaluation of human exposure to hand-
transmitted vibration. General requirements
EN ISO 5349-2:2001 Mechanical vibration. Measurement and assessment of human exposure to hand-
transmitted vibration. Practical guidance for measurement at the workplace.
Following the provisions of Directive(s):
Suivant les directive(s) déterminées:
Volgens de vastgestelde richtlijnen:
Siguiendo las directiva(s):
No sequimento das clausulas da Directiva(s):
Seguendo quanto indicato dalla Direttiva(s):
2006/42/EC Machinery Directive
2000/14/EC Noise Directive
2001/95/EC General Product Safety Directive
2002/95/EC Reduction of Hazardous Waste Directive
