Tool Shed TSHG2 User manual

HEAT GUN 2000W
DIGITAL
www.thetoolshed.co.nz
TSHG2

23
OPERATION MANUAL OPERATION MANUAL
WWW.THETOOLSHED.CO.NZWWW.THETOOLSHED.CO.NZ
TABLE OF CONTENTS PRODUCT DETAILS
Product Model ToolShed Heat Gun 2000W Digital
Product Code TSHG2
DISTRIBUTED BY:
Product Details 3
Specications 4
Product Identication 5
Safety Guidelines 6
Operation 10
Maintenance 12
Note:
This manual is for your reference only. Due to the continuous improvement of
the ToolShed products, changes may be made at any time without obligation or
notice.
Warranty:
This product may be covered under The ToolShed warranty. For more information, see
our Terms & Conditions at www.thetoolshed.co.nz
Thank You
For the purchase of this ToolShed product. We try our hardest to supply customers like you
with the best quality products available, at the best price possible. We cant wait to continue
working together in the future.
Please contact us for any servicing, replacement parts, or questions you might have about
your ToolShed product by visiting our website, or calling: 0800 948 665.

45
OPERATION MANUAL OPERATION MANUAL
WWW.THETOOLSHED.CO.NZWWW.THETOOLSHED.CO.NZ
SPECIFICATIONS PRODUCT IDENTIFICATION
Voltage 220–240 Volts | 50 Hertz
Power Supply 2000 Watts
Air Supply (Setting 1) 50°C | 250–500 LPM
Air Supply (Setting 2) 50–650°C | 250–500 LPM
1Heat Nozzle
2Ventilation Slots
3On/O/Mode Switch (O/I/II)
4Temperature and Air Flow Adjusting Button
5LCD Digital Display
6Spoon Reector Nozzle
7Cone/Reducer Nozzle
8Glass Protector Nozzle
9Fish Tail Surface/Flat Nozzle
10 Paint Scraper
1
6 7 8 9
10
2
5
4
3

67
OPERATION MANUAL OPERATION MANUAL
WWW.THETOOLSHED.CO.NZWWW.THETOOLSHED.CO.NZ
SAFETY GUIDELINES SAFETY GUIDELINES
• DO NOT use the power tool or machinery
in rainy conditions or wet areas where the
power tool or machinery could get wet.
Water in this power tool or machinery can
lead to electric shock.
• Only use the power tool or machinery
when the plug correctly matches the
power outlet. Modifying plugs greatly
increases the risk of electric shock.
• Keep the power cord away from anything
that could damage it such as sharp edges,
moving parts or heat. A damaged power
cord increases the risk of electric shock.
• Only operate outdoors with the use of an
outdoor extension lead. Not all extension
leads are suited to outdoor use and using
one which is not can greatly increase the risk
of electric shock.
• Avoid body contact with grounded or
earthed surfaces. Surfaces such as radiators,
ranges, pipes, and refrigerators can increase
the risk of electric shock due to your body
being earthed or grounded.
• Never carry the power tool by the cord,
or yank the cable from the power outlet.
This can damage the internal wiring and may
become a hazard.
WARNING
Electric shock can cause serious injury
or, in some cases be fatal.
Electrical Safety
• Use the correct tool for the job. Forcing
a tool to do a job it was not designed for
increases the risk of accident or injury.
• Disconnect tools and machinery from
power, or remove batteries before doing
any maintenance or adjustments, or
before storing the tools and machinery.
This reduces or removes the risk of a power
connection that causes the tool or machinery
to accidentally re, which can help prevent
injury or accident.
• Check the general condition of the power
tool for damage or any problems that
could aect the way the tool or machine
works. An unrepaired tool or machine can
lead to accident and injury. Only have your
tool or machine repaired with genuine parts
from The ToolShed.
• Only use the power tool and machinery
with genuine parts or accessories that are
designed to be used with this power tool
and machinery. Failure to do so could result
in accident or injury or damage your tool or
machinery.
• Store your tool or machinery out of reach
of children, and away from untrained
personnel when not in use. Use by some-
body untrained, or a child, could lead to
accident or serious injury.
Power Tool & Machinery Use &
Care
• Always wear personal protective equip-
ment (PPE). Eye protection, ear protection,
dust masks, and other protective equipment
will help to reduce the risk of personal injury
or long-term illnesses.
• Dress appropriately. DO NOT wear loose
clothing that can get caught in moving
parts. Keep hair, loose clothing, jewellery,
and anything else that could be of risk, away
READ ALL SAFETY WARNINGS &
INSTRUCTIONS. Failure to follow
instructions and warnings could lead to
serious injury, electric shock, or re.
from moving parts in the machine, or they
could become caught therein.
• Always remain alert and DO NOT operate
power tools or machinery under the inu-
ence of any substances such as alcohol
or drugs, including prescription medica-
tions. Lack of focus could lead to injury or
accidents while operating these power tools
and machinery.
• Always ensure proper footing and
balance. Overreaching can lead to slipping
and falling which can result in injury or acci-
dent.
• Ensure the power switch is in the OFF
position before connecting any battery,
or power source to the power tool or
machinery. This can cause injury as tools
and machinery can suddenly re incidentally
when live, causing accidents.
• Use all provided dust collection and
extraction attachments, if included. This
equipment, along with the use of PPE dust
masks, can help keep you safe from dust, and
keep your work site clear from hazards.
• Ensure loose parts such as wrenches
or adjusting keys are removed before
starting the power tool or machinery.
WARNING
Work Area Safety
Personal Safety
• Ensure that your work area is kept clean
and well lit. Lack of visibility and clutter
greatly increase the risk of accident when
using tools.
• Keep bystanders, pets, and children
clear when operating this power tool or
machine. They can cause distraction or risk
injury to themselves.
• Ensure you are not operating the power
tool or machinery in the presence of dust,
liquids, ammable gases, or anything
that can create an explosive atmosphere.
Power tools and machinery can create sparks
which can lead to ignition and re hazards in
working environments.

89
OPERATION MANUAL OPERATION MANUAL
WWW.THETOOLSHED.CO.NZWWW.THETOOLSHED.CO.NZ
SAFETY GUIDELINES SAFETY GUIDELINES
Heat Gun Specic SafetyService
Removing Paint
• Have your tools and machinery serviced
at The ToolShed with ToolShed replace-
ment parts. This will ensure that the safety
of the power tool or machine is maintained.
• Do not use this tool to remove paint that
contains Lead. The peelings, residue, and
vapours of paint may contain lead, which
is poisonous. Any pre-1960’s building may
have been painted in the past with paint
containing lead, and covered with additional
layers of paint.
• Once deposited on surfaces, hand to mouth
contact can result in the ingestion of lead.
• Heat may be conducted to combustible
materials that are out of sight. Do not use
in a damp atmosphere, where ammable
gasses may be present, or near combustible
materials.
• Allow the heat gun to fully cool down before
storing it away in its carry case, and away in
storage.
• Ensure it is used in an adequately ventilated
area as toxic fumes may be produced.
• NEVER direct the hot air blast at other
people, animals, or any body part.
• NEVER use this heat gun as a hair dryer.
• Do not place your hand over the air vents or
block the vents in any way.
• Do not leave the tool unattended while it is
switched on.
• Do not obstruct either the air intake, or the
nozzle outlet, as this may cause excessive
heat build up, resulting in damage to the
tool.
• Do not touch the metal nozzle as it becomes
very hot during use and may remain hot for
a period up to, or more than 30 minutes after
use.
• Do not touch the outlet nozzle against
anything while using, or immediately after
use, as this will create a re hazard.
• Do not poke anything into any outlet of the
heat gun as you could receive an electric
shock.
• Do not look down the nozzle while it is in
operation duetothe very high heatproduced
from that end.
• Do not apply heat the same area for
extended periods of time.
• Do not allow paint to adhere to the nozzle or
scraper as it could ignite after some time
• The nozzle and accessories of this tool
become extremely hot during use. Let these
parts cool down before touching.
• Always switch the tool o before putting it
down at any time.
• A re may arise if the appliance is not used
with care.
WARNING
WARNING
WARNING
WARNING
WARNING
The warnings and precautions
discussed in this manual cannot cover
all possible conditions and situations
that may occur. It must be understood
by the operator that common sense
and caution are factors which cannot
be built into this product, but must be
supplied by the operator.
If not used properly, this tool has the
high potential to become a re hazard.
Please take care while using, and take
care in the time after the tool has been
turned o.
Lead-based paint should only be
removed by a professional and should
not be removed using a heat gun.
Use only one hand to hold the heat gun,
do not place your other hand over the
air vents.
To reduce the risk of injury, always
unplug the heat gun before attaching
or removing accessories or making
adjustments.
To reduce the risk of injury, do not
remove or attach accessory tips
until the tool has cooled to room
temperature.
• It is not possible to cover every conceivable
situation you can face. Always exercise care
and use your common sense. If you get into
a situation where you feel unsafe, stop and
seek expert advise. Contact your dealer,
service agent, or an experienced user. Do not
attempt any task you feel unsure of!
Always Use Common Sense
• Exposure even to low levels of lead can cause
irreversible damage to the brain and nervous
system. Young and unborn children are
particularly vulnerable.
• When removing paint, ensure that the work
area is enclosed. Always wear a dusk mask
and goggles as a minimum PPE requirement.
• Do not burn the paint. Use the scraper and
keep the nozzle at least 25mm away from the
painted surface. When working in a vertical
direction, start from the top and work your
way downwards to prevent paint from falling
into the tool and burning.
• Dispose of all paint debris safely and ensure
that the work area, as well as all your tools,
are thoroughly cleaned after completing the
work.
• Your heat gun has been designed for strip-
ping paint, soldering pipes, shrinking PVC,
welding and bending plastic, as well as
general drying and thawing purposes.

10 11
OPERATION MANUAL OPERATION MANUAL
WWW.THETOOLSHED.CO.NZWWW.THETOOLSHED.CO.NZ
OPERATION OPERATION
WARNING
An incorrect or defective nozzle can
lead to heat accumulation and damage
the unit. Use only original nozzles
according to the information below
that are suitable for your unit.
Glass Protection Nozzle
Scraper
Spoon Reector Nozzle
Cone/Reducer Nozzle
Fish Tail Surface/Flat Nozzle
• Used to protect windows
whenstripping frames,keeps
direct heat o the glass.
• Used for stripping paint
and varnish.
• Used for soldering pipes.
Wraps around a metal pipe
to distribute the heat evenly
around the pipe surface.
• Used for welding, and shrink
sleeving. Works by concen-
trating heat over a small area.
• Used for drying or
thawing, for spreading
the hot air over a
narrow area that is
wide.
Recommended Applications:
Setting 1 (Low)
Recommended Applications:
Setting 2 (High)
• Drying paint, varnish, ller, adhesives,
construction joints,and stucco forms.
• Drying wet timber prior to lling.
• Removing Stickers.
• Joining adhesives–large surface gluing with
contact adhesives, activation of pressure
sensitive adhesives, acceleration of bonding
processes, releasing of bonding points, as
well as releasing or bonding of edge band or
veneers.
• Waxing, and de-waxing.
• Shrinking PVC wrap and insulation tubes.
• Defrosting of icy steps, door locks, trunk
lids, car doors, or water pipes, as well as for
defrosting refrigerators and ice boxes.
• Welding of thermoplastic polymer, ooring
materials of PVC and linoleum, PVC coated
fabric, tarpaulins, and foils.
• Bending plastic pipes and sheets.
• Soldering plumbing joints, tin, silver solder,
SMD elements, and cable lugs.
• Loosening rusted or over tight nuts and bolts.
• Removing old and thick coats of oil paint,
lacquer, varnish, and synthetic plaster.
• To switch the tool on, set the On/O switch
to the I/II position. Some smoke may be
emitted after switching on; a small amount of
smoke initially does not indicate a problem.
• To switch the tool o, adjust the lowest
temperature to cool o, then set the On/O
switch to position 0. Let the tool cool down
for at least 30 minutes before changing
accessories, moving, or storing it.
• Mount the appropriate accessory.
• Sent the heat gun to the higher air tempera-
ture setting.
• Switch the tool on.
• Direct the hot air onto the paint needing to
be removed.
• When the paint softens, scrape the paint
away using a hand scraper (Included).
This heat gun also has the ability to be used in
stationary mode:
• Place the tool onto the workbench.
• Secure the cable to prevent puling the heat
gun o the workbench.
• Carefully switch the tool on.
• The nozzle and accessory becomes very hot
during use. Ensure it has properly cooled
down before attempting to move or store
the heat gun.
• To reduce the cooling time, switch the tool to
position Iwhich is at the lowest air tempera-
ture, and adjust the air ow to Max. Allow the
tool to run for a few minutes at this setting.
• Switch the tool o, and let it cool down for at
least 30 minutes.
• Turn the On/O switch to the I/II position,
depending on your desired temperature.
Press any of the adjusting buttons and the
heat gun will start to buzz. Now you can
increase or decrease the outlet temperature
and air ow gradually by pressing the buttons
(shown below).
• The LCD will display the temperature in digits,
and air ow in a ladder pattern. Temperature
in digits increase or decrease by increments
of 10°C.
Switching On & O Stripping Paint
Stationary Use
Cooling Down
Temperature Settings WARNING
Do not strip metal window frames,
as the heat may be conducted into
the glass and crack it. When stripping
other window frames, use the Glass
Protection Nozzle.

12
OPERATION MANUAL
WWW.THETOOLSHED.CO.NZ
MAINTENANCE
• Before cleaning or performing any mainte-
nance, you must ensure the tool is switched
o and disconnected from the power supply.
• Compressed air is the most eective
way to clean this tool. Always wear PPE
safety goggles when cleaning tools with
compressed air.
• Check the carbon brushes of the machine in
the event of excessive sparking.
• Ventilation openings and switch levers must
be kept clean. DO NOT attempt to clean by
inserting pointed objects through openings.
• Do not use harsh chemicals or solvents when
cleaning this tool.
• If you discover any damaged or broken parts,
consult your nearest ToolShed for replace-
ments and advise.
• Your power tool has been designed to
operate over a long period of time with
minimum maintenance requirements.
Continuous satisfactory operation depends
upon proper tool care and regular cleaning.
WARNING
WARNING
Do not keep the heat gun directed at
one spot for too long as this will cause
your work piece to ignite.
Avoid collecting paint on the scraper
accessory, this may cause a re hazard.
If necessary, carefully remove paint
debris from the scraper accessory using
a knife.
Cleaning
• Keeptheventilationslotsclearandcleanthem
regularly with a soft cloth or compressed air.
• Keep the ventilation slots of the heat gun
clean to prevent overheating of the engine.
• Regularly clean the machine housing with a
soft cloth, preferably after each use.
• Always keep the ventilation slots free from
dust and dirt.
• If the dirt does not initially come o, use a
soft cloth moistened with soapy water.
