Topfield TRF-7260 User manual

TRF-7260
User Manual
High Definition
Digital Terrestrial Receiver
Personal Video Recorder
Default PIN: 0000

.
2

- The TF RCU app for iPhone
The RCU application is available to download from the App Store.
(currently for iPhone only)
Download the TF RCU app to control this unit with your smart phone.
* iPhone and App Store are registered trademarks of Apple, Inc.
- Compatible RCU support
The TRF-7260 supports compatible RCU usage for the PVR set.
Menu >Settings >Miscellaneous >Type of RCU
* The RCU code is required for this feature.
** Please visit http://topfield.com.au/ for more information.
3

Precautions
• Clean with a dry cloth only.
• Do not block any of the ventilation openings.
• When placed in a cabinet, make sure there is a minimum space of 10
centimetres around it.
• Do not install near any heat sources or in direct sunlight as this will
impair cooling.
• Do not operate this product near water.
• Do not try to change the plug or defeat its safety purpose.
• This product is designed for indoor use only.
• Place the digital receiver on a firm and level surface.
• Do not lay any objects such as magazines on this unit.
• Do not overload power outlets. Doing so may result in a risk of fire or
electrical shock.
• Never open this unit’s casing under any circumstances, or the warranty
will be void.
• Unplug this unit during lightning storms or when unused for long pe-
riods of time.
• Refer all servicing to qualified service personnel. Reverse engineering
or disassembly is prohibited.
• Batteries, including those which contain no heavy metals, may not be
disposed with other household wastes. Please dispose of used batter-
ies in an environmentally sound manner. Find out the legal regulations
which apply in your area.
• The mains plug shall remain readily operable so that it can be removed
easily to disconnect the power.
• Operate the digital receiver at temperatures between 0 to 45 ◦C.
• The mains voltage must range between 90 and 250 volts. Check it be-
fore plugging the digital receiver to the wall socket. For the power
specification, refer to the table below.
Input voltage 90 to 250 V AC, 50/60 Hz
Power consumption 30 W at maximum in active
Under 5 W in passive standby
4

Front Panel
CHANNEL VOLUME
STANDBY
MENU
STANDBY
STANDBY light lights up while the digital receiver is in standby mode.
switches the digital receiver between standby mode and active mode.
MENU displays the main menu. Also, returns to previous menu from a sub-
menu.
c
,
a
CHANNEL switch to the previous or next service.
Also, navigate in menus and interactive screens.
b
,
d
VOLUME decrease or increase the volume. Also, change values for menu options.
OK displays the services list. Also, selects a menu item.
5

Rear Panel
VIDEOR - AUDIO - L
S/PDIF
ANT OUT
ANT IN
PbPr Y
HDMI USB
LAN
ANT IN Terrestrial broadcasting signal input socket
(5V, Max.100mA)
ANT OUT Terrestrial broadcasting signal output socket through the ANT IN socket for
other receiver
VIDEO Composite video output socket for the television set
(yellow)
AUDIO R/L Stereo audio output socket for television or audio receiver
(white/red)
Y/Pb/Pr Component video output socket for the television set
(green/blue/red)
S/PDIF Digital audio output socket for the audio-video receiver
HDMI Audio and video output socket for high definition television set
LAN Local area network port
USB USB port for firmware update and data transfer
(USB 2.0 Host, 5V DC, 500mA Max.)
6

Connecting the TV
Connect any components before plugging the power cord into the wall outlet.
If you encounter any problems setting up your product, please contact your local retailer.
1. Connect the antenna cable to the ANT IN socket.
2. Choose a setup that matches the connection ports on your TV.
– We recommend using the HDMI connection for the highest quality HD picture.
– For a higher quality use the component connection.
– For a basic connection to your television use the composite connection.
a) HDMI connection (HDMI)
b) Component connection (YPbPr)
c) Composite connection (VIDEO)
7

Remote control
NOTE
The actual images or number of buttons may be t depending on the type of remote
control provided by the manufacturer.
8
1switches the digital receiver between standby mode and active mode.
2mutes the sound. Press again to switch it back on.
3V.Format changes video resolution.
4A/R changes aspect ratio.
5AUX not used in this model.
6switches over between television services and radio services.
7Numeric buttons are used to enter a service number for service change or to
to specify values for menu options.
8switches over between the current service and the previously viewed one.
9displays the service information box.
displAlso, ays more information about a programme.
10 selects audio track or sound mode.
11 not used in this model.
12 selects a subtitle track.
13 sets sleep timer in 10 minute increments.
14 MENU displays the main menu.
Also, returns to the previous menu from a submenu.
15 GUIDE displays the electronic programme guide.
16 , allow you to choose an item from the menu.
Also, navigate through the electronic programme guide or
interactive services.

NOTE
In order to use the T d RCU for your TV, refer to the Universal RCU setup for TV
guide: Menu >Information.
9
17 , allow you to change the options for a menu item.
nAlso, avigate through the electronic programme guide or interactive services.
18 displays the services list. Also, selects menu items.
19 EXIT exits a menu or hides on-screen information.
20 LIST
21 V−,V+decrease or increase the volume.
22 P−,P+switch to the previous/next service.
23 starts reverse playback. Subsequent presses increase the rewind speed.
24 pauses live television or playback of a recorded programme.
25 resumes normal playback speed, or displays the progress bar for navigation
on playback or time-shift. To play a recorded programme, see button 30 .
26 starts fast forward playback. Subsequent presses increase the playback speed.
27 starts recording.
28 stops playback, recording, or jumps back to live television from time-shifted
television.
29 starts slow motion playback. Subsequent presses change the playback speed.
30 displays the list of recorded programmes that are stored in the internal
hard drive.
31 has t functions per menu.
32 jumps back to the beginning of the recording on playback.
33 jumps to the end of the recording on playback.
34 SAT displays connected device list.
35 F1 has t functions per menu.
36 F2 makes a bookmark on playback or time-shift.
37 F3 jumps to next bookmark position.
38 F4 edits a recording.
39 not used in this model.
40 FAV displays the favourite list.
Functions of the colour buttons will be guided on the screen.
OK
LIST
displays the list of recorded programmes that are stored in the internal
hard drive.

First Time Installation
1 After having connected the appropriate cables from the digital receiver to your TV, make
sure the power cord of the digital receiver is plugged into a wall socket and turn the unit
ON using the switch on the back of the unit.
2 Check that your TV set is turned on.
3 Check that your TV set is on the correct video channel so that you can see the Menu from
the Digital Receiver.
4 Insert the batteries into the remote control.
5 Press the button on the remote control or the Circular button on the front face of the
unit to turn the Digital Receiver on.
6 The main menu will appear on your screen.
Now it’s time to scan your channels, using
your remote highlight Installation.
7 Now highlight Searching and press 



OK
button.
10

8 Set the Search Mode to Quick Scan then
move down to Start Search and press 



OK
button.
9 Once all the channels have been searched
you will be told how many channels have
been found. Press 



OK button and then




EXIT button.
11

Watching TV
1. Now that the service search is complete,
press the 



OK button to view the services
list.
2. On the services list, press the 



P+or 



P−
button to navigate your desired service.
You can also switch to your desired service
by entering its service number with the nu-
meric buttons.
3. To select a service to watch, press the 



OK
button.
Electronic programme guide
1. Press the 



GUIDE button to display the elec-
tronic programme guide (EPG).
2. To see detailed information of a desired
programme, put the highlight bar on the
programme with the 



V+or 



V−button and
press the button.
3. To switch to another service, press the 



P+
or 



P−button.
NOTE
The free to air EPG (Electronic Program Guide) guide does not automatically populate.
To populate the EPG guide on every channel you must visit each service/channel at least
once a week for a few minutes or until the guide has fully populated for the full seven
days. EPG updates can also occur while you are watching TV and jumping from channel
to channel.
12

Recording and Playback
Instant recording
1. Press the 



F1 button on the live screen to
start recording.
2. When recording has started, press the 



F1
again to set the recording duration as
shown in the left figure.
3. While recording, you can watch or record
another service. To record another service,
switch to the service and press the 



F1 .
•Duration: Set the desired recording duration with the 



V−and 



V+buttons and press
the 



OK button; the recording will end at the specified time.
•After this program: If the information about the next programme is provided by the
electronic programme guide, the current recording will stop at the time when the
current programme is scheduled to end.
•After next program: The current recording will stop at the time when the next pro-
gramme is scheduled to end.
To stop recording, press the 



EXIT button; then
a box like the left figure appears, which shows
the programmes currently being recorded. Se-
lect recording by using navigation buttons
then press 



OK button to stop the recording.
13

Timer Recording




MENU >PVR >Reservation >



F1
You can set a programme to be recorded at a
specific time.
1. To add a new timer event, press the 



F1 but-
ton, and a box like the left figure appears.
2. Set the options as you desire and select the
OK. The new timer event will be saved to
the timer list.
Playback




MENU >PVR >Recorded Program (or ) >



OK >Play
1. Select a desired recording and press the 



OK
button.
2. To play from beginning, set the Starting Po-
sition option to Beginning; to play from the
point that you have stopped at the last time,
set it to Continuing.
3. Select the Play to start playback.
NOTE
This recorder can record four channels simultaneously, however, this is controlled by the
channel frequency. Each channel has other programmes under the one frequency (E.g.
Channel Nine has 9, 9HD, GO, GEM) (Channel ABC has ABC News 24, ABC1, ABC2,
ABC3, etc.). This recorder can record two programmes on each channel frequency simuta-
neously. (E.g. 10.TEN Digital plus 11.One HD and 90.GEM plus 99.Go!) While recording
the above combination of programmes you can also playback a pre-recorded show.
14

.
15

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
Correct disposal of this product
This marking shown on the product or its literature indicates that it should not be dis-
posed with other household wastes at the end of its working life. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please sep-
arate this from other types of wastes and recycle it responsibly to promote the sustain-
able reuse of material resources. Household users should contact either the retailer where
they purchased this product or their local government office for details of where and how
they can dispose this product for environmentally safe recycling. Business users should
contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
At any time during the life of a product Topfield Co., Ltd. may change or modify the hardware or
software on any product to introduce new features or improve the functionality of the product.
Copyright © 2012, Topfield Co., Ltd. All rights reserved. English version
http://www.i-topfield.com 110T-V8A78-Q01-0
