TOPMAQ 36215 User manual

Walk-Behind Blower
Operator’s Manual
MODEL NUMBER : 36215
SERIAL NUMBER :
Both model number and serial number may be found on the main label.
You should record both of them in a safe place for future use.
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE
OPERATING MACHINE
Save This Manual for Future Reference
Original Instruction

Walk-Behind Blower
2
GB TABLE OF CONTENTS
Specifications
INTRODUCTION
Introduction 2
Environmental 2
Symbols 3
Safety 4
General Safety Rules 4
Specific Safety Rules 5
Contents supplied 7
Assembly 8
Know your machine 11
Features & Controls 11
Operation 13
Maintenance 16
Storage 17
Trouble Shooting 19
Parts Schedule 20
Your new walk-behind blower will more
than satisfy your expectations. It has been
manufactured under stringent quality standards
to meet superior performance criteria. You will
find it easy and safe to operate, and with proper
care, it will give you many years of dependable
service.
Carefully read through this entire
operator’s manual before using your
new snow thrower. Take special care
to heed the cautions and warnings.
Your walk-behind blower has many features
that will make your job faster and easier. Safety,
performance, and dependability have been
given to top priority in the development of this
machine, making it easy to maintain and operate.
The Engine manufacturer is responsible
for all engine-related issues with regards to
performance, power rating, specifications,
warranty and service. Please refer to the Engine
Manufacturer’s owner’s/operator’s manual,
packed separately with your unit, for more
information.
This operator’s manual covers
several models. Not all features in
this manual are applicable to all
snow thrower models and the snow
thrower depicted may differ from
yours.
RECYCLING AND DISPOSAL
This marking indicates that this
product should not be disposed with
other household wastes. To prevent
possible harm to the environment
or human health from uncontrolled
waste disposal, recycle it responsibly
to promote the sustainable reuse of
material resources. To return your
used device, please use the return
and collection systems or check with
your local authority or local stores
for advice of environmental safe
recycling.
Model Number 36215
Displacement 209cc
Max. Air Volume 2040 m3/h
Max. Air Speed 240 km/h
Impeller Diameter 330mm
Swivel Caster 200mm
Rear Wheel 300mm
Weight 37.4kg

Walk-Behind Blower 3
GB
Keep children and bystanders at
least50 feet (15m) away.
Stop engine and remove ignition
key prior to leaving the operator's
position.
Do not allow the directional
discharge chute to point in the
direction of bystanders or pets.
Thrown objects can result in
personal injury or property
damage
Use extra caution on slopes.
The machine is heavy and can
speed up when going downhill.
Be prepared to maintain control
of the machine. To avoid loss of
control, operate across slopes, not
up and down. When turning, turn
uphill, not down. Do not operate
on slopes greater than 15 degrees.
There are rotating blades inside the
blower. Please keep your hands,
feet or tools out of intake and
discharge opening while machine is
running.
Do not let long hair uncovered.
Use a hair net.
Keep safety devices (Guards,
Shields, etc.) in place and working.
Do not operate without shields
and guards in place.
Do not operate when children or
other are around.
SYMBOLS
The rating plate on your machine may
show symbols. These represent important
information about the product or instructions
on its use.
MAX.15°
STOP STOP
DANGER!
WARNING!
CAUTION!
Read these instructions carefully.
Wear approved hearing
protection.
Wear eye protection with side
shields marked to comply with
ANSI Z87.1.
Do not touch parts that are hot
from operation. Serious burns may
result.
Engine parts, especially the
muffler, become extremely hot
during operation. Allow engine and
muffler to cool before touching.
Do not remove or tamper with the
protection and safety devices.
Never start or run the engine
inside a closed area or in poorly
ventilated area. The engine exhaust
contains carbon monoxide, and
odorless and deadly gas.
Shut off the engine, disconnect
spark plug wire, and make certain all
moving parts have stopped before
cleaning, repairing, or inspecting the
unit.
Gasoline and its vapors are
extremely flammable and
explosive. Never fuel the machine
indoors or while the engine is hot
or running. Wipe up any gasoline
that spills. Keep away from any
inflammables when operating the
engine.

Walk-Behind Blower
4
GB SAFETY
General Safety Rules
UNDERSTAND YOUR MACHINE
Read this manual and all labels affixed to the machine
to understand limitations and potential hazards
before attempting to assemble this machine. Read,
understand, and follow all instructions on the machine
and in the manuals before operation.
Become thoroughly familiar with the controls and their
proper operation. Know how to stop the machine and
disengage the controls quickly.
Make sure to read and understand all the instructions
and safety precautions as outlined in the Engine
Manufacturer’s manual packed separately with your
unit. Do not attempt to operate the machine until you
fully understand how to properly operate and maintain
the engine and how to avoid accidental injuries and/or
property damage.
Keep this manual and engine manual in a safe place
for future and regular reference.
If the unit is to be used by someone other than
original purchaser (or is loaned, rented, or sold),
always provide this manual and any needed safety
training before operation. The user can prevent and is
responsible for accidents or injuries that may occur to
themselves, other people, and property.
This machine is not a toy, and is to be used only for
its intended purpose. Therefore, exercise extreme
caution at all times. This machine has been designed
to perform one job: blow debris and leaves from lawns,
driveways, parking lots, etc. Do not use it for any other
purpose.
Do not force the machine. Use the correct machine for
your application. The correct machine will do the job
more efficiently and safely at the rate it was designed.
PERSONAL SAFETY
Do not permit children to operate this machine at any
time.
Keep children, pets, and other people not using the
unit away from the work area. Be alert and shut off the
unit if anyone enters work area. Keep children under
the watchful care of a responsible adult.
Do not operate the machine while under the influence
of drugs, alcohol, or any medication that could affect
your ability to use it properly.
Dress properly: Wear long, heavy pants, work boots,
and work gloves. Do not wear loose clothing, short
pants, or jewelry of any kind. Secure long hair so
it is above shoulder level. Keep your hair, clothing,
and gloves away from moving parts. Loose clothes,
jewelry, or long hair can be caught in moving parts.
Protect eyes, face, and head from objects that may be
thrown from the unit. Always wear safety goggles or
safety glasses with side shields when operating.
Wear appropriate hearing protection.
Always keep hands and feet away from all moving
parts during operation. Moving parts can cut or crush
body parts.
Always keep hands and feet away from all pinch
points.
Do not touch parts that might be hot from operation.
Allow parts to cool before attempting to maintain,
adjust, or service.
Stay alert, watch what you are doing, and use common
sense when operating the machine.
Do not overreach. Do not operate the machine
while barefoot or when wearing sandals or similar
lightweight footwear. Wear protective footwear that
will protect your feet and improve your footing on
slippery surfaces. Keep proper footing and balance at
all times. This enables better control of the machine in
unexpected situations.
INSPECT YOUR MACHINE
Check your machine before starting it. Keep guards in
place and in working order. Make sure all nuts, bolts,
etc., are securely tightened.
Never operate the machine when it is in need of repair
or is in poor mechanical condition. Replace damaged,
missing, or failed parts before using it. Check for fuel
leaks. Keep the machine in safe working condition.
Do not use the machine if the engine’s switch does
not turn off the engine when running. Any gasoline
powered machine that can’t be controlled with the
engine switch is dangerous and must be replaced.
Regularly check to see that keys and adjusting
wrenches are removed from the machine area before
starting it. A wrench or a key that is left attached to
a rotating part of the machine may result in personal
injury.
Avoid accidental starting. Be sure the engine’s switch
is off before transporting the machine or performing
any maintenance or service on the unit. Transporting
or performing maintenance or service on a machine
with its switch on invites accidents.
If the machine should start to vibrate abnormally, stop
the engine (motor) and check immediately for the
cause. Vibration is generally a warning sign of trouble.
ENGINE SAFETY
If a spark arrestor is used, it should be maintained in
effective working order by the operator. In the State of
California the above is required by law (Section 4442
of the California Public Resources Code). Other states
may have similar laws. Federal laws apply on federal
lands.

Walk-Behind Blower 5
GB
Never start or run the engine inside a closed area.
The exhaust fumes are dangerous, containing carbon
monoxide, an odorless and deadly gas. Operate this
unit only in a well-ventilated outdoor area.
Do not tamper with the engine in an effort to get it to
run at higher speeds. The maximum engine speed is
preset by the manufacturer and is within safety limits.
See engine manual.
Keep a Class B fire extinguisher on hand when
operating this machine in dry areas as a precautionary
measure.
FUEL SAFETY
Fuel is highly flammable, and its vapors can explode
if ignited. Take precautions when using to reduce the
chance of serious personal injury.
When refilling or draining the fuel tank, use an
approved fuel storage container while in a clean,
well-ventilated outdoor area. While adding fuel or
operating the unit, do not smoke, and stay away from
sparks, open flames, or other sources of ignition near
the area of operation. Never fill the fuel tank indoors.
To avoid sparking or arcing, keep grounded
conductive objects – such as tools – away from
exposed, live electrical parts and connections. These
events could ignite fumes or vapors.
Always stop the engine and allow it to cool before
filling the fuel tank. Never remove the cap of the fuel
tank or add fuel while the engine is running or when
the engine is hot. Do not operate the machine with
known leaks in the fuel system.
Loosen the fuel tank cap slowly to relieve any pressure
in the tank.
Never overfill the fuel tank. Because engine heat
can cause fuel to expand, never fill the tank to more
than 1/2” below the bottom of the filler neck. This will
provide space for fuel expansion.
Replace all fuel tank and container caps securely and
wipe up spilled fuel. Never operate the unit without
the fuel cap securely in place.
Avoid creating a source of ignition for spilled fuel.
If fuel is spilled, do not attempt to start the engine.
Instead, move the machine away from the area of
spillage and avoid creating any source of ignition until
fuel vapors have dissipated.
When fuel is spilled on yourself or your clothes, wash
your skin and change clothes immediately.
Store fuel in containers specifically designed and
approved for fuel storage.
Store fuel in a cool, well-ventilated area, safely away
from sparks, open flames, or other sources of ignition.
Never store fuel – or a machine with fuel in the tank –
inside a building where fumes may reach a spark, open
flame, or any other source of ignition (such as a water
heater, furnace, or clothes dryer). Allow the engine to
cool before storing in any enclosure.
PRODUCT LIABILITY
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not
from the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
SPECIFIC SAFETY RULES
Identify hazards and take preventive steps to avoid
accidents and minimize risk. Possible hazards include,
but are not limited to, moving parts, thrown objects,
weight of the machine and components, and the
operating environment.
PRIOR TO STARTING
Thoroughly inspect the area in which you are working.
Do not operate the blower in standing water, puddles,
mud, gravel, stones or sand.
Before starting your blower: make sure the shields,
guards, and safety devices are properly affixed to
machine, check the oil level, and make sure all nuts and
bolts are tight.
Move the machine at least 10 feet away from the
refueling point before starting engine.
OPERATION SAFETY
Never operate the blower without good visibility or
light.
Always make sure you have secure footing. If you slip
of fall, stop immediately.
Never place any part of your body where it would be
in danger if movement should occur during assembly,
installation, operation, maintenance, repair, or moving.
Keep all bystanders, children, and pets at least 50
feet (15m) away. If you are approached, stop the unit
immediately.
Blower will propel debris at high speed and can cause
damage. Avoid pushing your leaf blower over any
areas with loose stones or gravel as they may become
projectiles. Before use, check that area is free from
breakable objects, such as house windows, auto glass,
greenhouses, etc.
Do not stand or put your hands, or any part of your
body in front of the discharge opening. Always pay
attention to the direction of the discharge opening.

Walk-Behind Blower
6
GB Never allow discharge opening to point towards
bystanders, pets, or valuable property. Wind can also
change discharge direction, so be aware.
There are rotating blades inside the blower which
can cause serious injury. Please keep your hands, feet
or tools out of intake and discharge opening while
machine is running.
Never operate machine without directional discharge
chute and plastic impeller guard properly affixed
to machine, These devices shield the operator from
accidental contact with the rotating impeller.
Keep combustible substance away from the engine
when it is hot.
Do not tilt the machine while the engine is running.
Never operate the blower at high transport speeds on
slippery surfaces.
Exercise extreme caution when operating on or
crossing gravel drives, walks, or roads. Stay alert for
hidden hazards or traffic.
Never leave the operating position when the engine
is running. Always shut down the engine, and ensure
the engine is switched to “off” to prevent accidental
starting and wait for all moving parts to come to a
complete stop before leaving.
To reduce exposure to vibration, limit the hours
of operation and take periodic breaks to minimize
repetition and rest your hands. Reduce the speed and
force in which you do the repetitive movement. Try
to fill each day with jobs where operating hand-held
power equipment is not required.
MACHINE USE AND CARE
Do not force the machine. Use the correct machine for
your application. The correct machine will do the job
better and safer at the rate for which it is designed.
This equipment was designed specifically for the
purpose of blowing leaves and debris. Do not use this
equipment for any other purpose.
Do not change the engine governor settings or over-
speed the engine. The governor controls the maximum
safe operating speed of the engine.
Do not run the engine at high speed when you are not
working.
Avoid contact with hot fuel, oil exhaust fumes and
hot surfaces. Do not touch the engine or muffler.
These parts get extremely hot from operation. They
remain hot for a short time after you turn off the unit.
Allow the engine to cool before doing maintenance or
making adjustments.
If the machine should start to make an unusual noise or
vibration, immediately shut off the engine, disconnect
the spark plug wire, and check for the cause. Unusual
noise or vibration is generally a warning of trouble.
Use only attachments and accessories approved
by the manufacturer. Failure to do so can result in
personal injury.
Keep the engine and muffler free of grass, leaves,
excessive grease of carbon build up to reduce the
chance of a fire hazard.
Never douse or squirt the unit with water or any other
liquid. Keep handles dry, clean and free from debris.
Clean after each use.
Observe proper disposal laws and regulations for gas,
oil, etc. to protect the environment.
When storing machine out of the reach of the children
and do not allow persons unfamiliar with the machine
or these instructions to operate it. This machine can
be dangerous when used by an untrained user.
MAINTAINING YOUR MACHINE
Some parts of this machine are made of plastic or
rubber and should be kept away from chemicals.
Never cover the machine while the muffler is still hot.
Do not alter or adjust any part of the blower or
its engine that is sealed by the manufacturer or
distributor. Only a qualified service technician may
adjust parts that increase or decrease governed
engine speed.
To maintain your machine, check for any misalignment
of binding of any moving parts. Parts that are broken
or worn down that may affect the machine’s operation.
If damage or worn parts are identified, they should be
repaired before use. Many accidents are caused by
poorly maintained equipment.

Walk-Behind Blower 7
GB
Your walk-behind blower comes partially assembled and contains the following:
CONTENTS SUPPLIED
1. Main Machine
2. Upper Handle
3. Front Swivel Caster Tube
4. Front Swivel Caster
5. Front Discharge Chute
6. Frame Tube
7. Rear Wheel ( 1 pair)
8. Operator's Manual & Engine Manual
9. Tools for Spark Plug Assembly
10. Hardware Bag, including
9
10
8
7
5
2
3
4
6
1
A
B
C
D
M8 X 40 X 4 A
X 2 B
X 1 C
M8 X 45 X 2 D

Walk-Behind Blower
8
GB
2.
1.
1.
2.
2.
3.
3.
1.
4.
ASSEMBLY
X 2 B
X 1 C
Front Swivel Caster Tube
Frame Tube
M8 X 40 X 4 A
WHEELS
Slide the wheel onto the axle.
Secure the wheel in place with a flat
washer and a cotter pin on the outside.
Bend and spread the cotter pin prongs in
opposite directions.
Repeat these steps to install the 2nd wheel.
SWIVEL CASTER
Install one bushing onto the underside
(bottom side) of the swivel caster bracket
opening, with the smaller end of the
bushing facing up.
Install the caster by pushing the caster
tube up through the bracket opening.
Install the 2nd bushing onto the shaft and
insert it into the top of the caster bracket
opening, with the smaller end of the
bushing facing down.
Secure the swivel caster to the caster tube
using a flat washer, spring washer and
acorn nut. Tighten securely using a 16mm
wrench.
This walk-behind blower was partially
assembled at the factory. To assemble your
machine follow the below instructions.
Insert the end of the front swivel caster
tube into the opening of the frame tube,
and align the holes.
Attach the tubes to the engine deck with
M8x40 bolt, arc washer, spring washer and
lock nut in four places. Tighten securely
using two 13mm wrenches.
FRAME

Walk-Behind Blower 9
GB
2.
2.
1.
1.
1
2
2
M8 X 45 X 2 D
Hook the upper handle tabs into the holes
on the frame tube. Use the bottom hole for
the lower handle position. Use the middle
hole for the high handle position.
Secure the handle on the frame tube with
the carriage screws and star knobs.
Mount the throttle control lever onto the
right upper handle with M5x25 screw and
lock nut. Tighten securely using a 8mm
wrench and a Phillips screwdriver.
Secure the throttle control cable on the
handle with cable clamp.
UPPER HANDLE THROTTLE CONTROL LEVER
There are two positions in which
the handle can be attached - a high
position and a lower position.

Walk-Behind Blower
10
GB
Loosen the knob located on top of the
discharge chute.
Orient the attachment so the "THIS SIDE
UP DURING USE" is up.
Slide the attachment over the discharge
chute. The slot on the top of the
attachment will mate with the bolt of the
attachment knob.
Hand-tighten the attachment knob to
secure the attachment.
FRONT DISCHARGE CHUTE
Attach the Z type end of the cable into the
lever as shown.
Secure the buckle on the cable onto the
upper handle.
Secure the cable on the frame tube with
cable clamp.
FLOW ANGLE ADJUSTMENT
CONTROL CABLE
1
3
2
3
1.
1.
2.
2.
3.
3.
4.
The front discharge chute is used to
redirect the air flow to the front of
the blower. Attach it when needed.
When properly assembled, the
attachment knob will fit inside of
the round emboss on the top of the
attachment.

Walk-Behind Blower 11
GB
Throttle Control Lever Upper Handle
Flow Angle Adjustment
Control Lever
Frame Tube
Front Discharge Chute
Flow Angle Adjustment
Index Lever
Fan Housing
Intake Guard
Front Swivel Caster
Discharge Chute
KNOW YOUR MACHINE
Features and Controls

Walk-Behind Blower
12
GB
Adjusts the direction of air flow between 7 positions.
Regulates the speed of engine. Moving towards
FAST to speed up the engine. Moving towards
LOW to lower the engine speed.
Contains the fan.
Prevents fingers, hands, or large debris from entering
the fan housing and contacting the fan blades.
360 degree swiveling caster to allow for
maneuverability.
Directs air flow to the left side of the unit from machine
operator’s position.
Redirects the air flow toward the front of the unit.
Used to pull-start the engine.
The choke control is used to choke the carburetor and
assist in starting the engine. The choke control is slides
between the CHOKE and RUN positions. The CHOKE
position enriches the fuel mixture for starting a cold
engine.
The RUN position provides the correct fuel mixture
for operation after starting, and for restarting a warm
engine.
The fuel valve opens and closes the passage between
the fuel tank and the carburetor.
The fuel valve lever must be in the ON position for the
engine to run.
When the engine is not in use, leave the fuel valve
lever in the OFF position to prevent carburetor
flooding and to reduce the possibility of fuel leakage.
Transits the movement from control lever to the air
flow louver.
Flow Angle Adjustment Control Lever
Throttle Control Lever
Fan Housing
Intake Guard
Front Swivel Caster
Discharge Chute
Front Discharge Chute
Recoil Starter Handle
Choke Control
Fuel Valve Lever
Flow Angle Adjustment Index Lever
Spark Plug
Choke Lever
Carburetor
Air Cleaner
Oil Drain Plug
Muffler
Ignition Switch
Fuel Filler Cap
Fuel Tank
Oil Filler Cap / Dipstick
Fuel Valve Lever
Recoil Starter Handle

Walk-Behind Blower 13
GB
1. Make sure the walk-behind blower is on a
flat, level surface.
ADD OIL TO ENGINE
3. Using a funnel, add oil up to the FULL
mark on the dipstick. (See engine manual
for oil capacity, oil recommendation, and
location of fill cap.)
1. The engine must be off and allowed to cool
at least two minutes before adding fuel.
2. Remove the fuel filler cap and fill the tank.
(See engine manual for fuel capacity, fuel
recommendation, and location of fuel cap.)
ADD GASOLINE TO ENGINE
2. Remove the oil fill
cap/dipstick to add
oil.
3. Reinstall the fuel cap and tighten. Always
clean up spilled fuel.
OPERATION
Keep all bystanders, especially
CHILDREN, away during operation.
Never start or run the engine inside
a closed area or in poorly ventilated
area. The engine exhaust contains
carbon monoxide, and odorless and
deadly gas.
The engine is shipped without oil.
Do not start the engine before
adding oil. Please refer to your
engine manual for the proper grade
of oil to add.
Gasoline is highly flammable and
explosive. You can be burned or
seriously injured when handling fuel.
Use extreme care when handling
gasoline.
IMPORTANT: DO NOT OVERFILL!
This equipment and/or its engine
may include evaporative emissions
control system components,
required to meet EPA and/
or CARB regulations, that will
only function properly when the
fuel tank has been filled to the
recommended level. Overfilling
may cause permanent damage
to evaporative emissions control
system components. Filling to
the recommended level ensures
a vapor gap required to allow for
fuel expansion. Pay close attention
while filling the fuel tank to ensure
that the recommended fuel level
inside the tank is not exceeded. Use
a portable gasoline container with
an appropriately sized dispensing
spout when filling the tank. Do not
use a funnel or other device that
obstructs the view of the tank filling
process.
DO NOT OVERFILL THE OIL. Check
engine oil level daily and add as
needed.
Fill the fuel tank outdoors, never
indoors. Gasoline vapors can ignite
if they collect inside an enclosure.
Explosion can result.
FILLER CAP/DIPSTICK
UPPER LIMIT
LOWER LIMIT

Walk-Behind Blower
14
GB
Do not move the choke control to
CHOKE position to stop the engine.
Backfire or engine damage may
occur.
To restart a warm
engine, leave the
choke lever in the
RUN position.
STARTING ENGINE
1. Move the fuel valve
lever to the ON
position.
2. Move the choke
lever to the CHOKE
position.
SLOWFAST
OPENCLOSED
ONOFF
3. Move the throttle control
lever slightly forward
to about 1/4 of the way
(slightly toward the fast
position).
4. Turn the engine switch to
the ON position.
5. Pull the recoil starter until
the engine starts. Return
the recoil to the home
position after each pull.
Repeat the steps as needed.
Once engine has started,
set the throttle to the FAST
position before you operate
the unit.
6. If the choke lever has been moved to
the CHOKE position to start the engine,
gradually move it to the RUN position as
the engine warms up.
IDLE SPEED
When not actively blowing debris while engine
is running, set the throttle control level to the
SLOW position during the idle time. Lowering
the engine speed will help extend the life of
the engine, as well as conserve fuel and reduce
noise level.
STOP ENGINE
To stop the engine in an emergency, turn
the engine switch to the OFF position. Under
normal conditions, use the following procedure:
1. Move the throttle lever to the SLOW
( ) position.
2. Let the engine idle for one or two minutes.
3. Turn the engine switch to the OFF position.
4. Turn the fuel valve lever to the OFF ( )
position.
• The air flow direction can be adjusted
between 20 degrees upward to 20 degrees
downward, total 7 positions.
• Direction adjustment is achieved by using
the flow angle adjustment control lever to
move the air flow louver.
• Move the lever upward (away from you) to
direct airflow downward or move the lever
downward (toward you) to direct airflow
upward.
ADJUSTING THE AIR FLOW DIRECTION
Rapid retraction of the starter cord
(kickback) can occur, which may
pull your hand and arm toward the
engine faster than you can let go.
Broken bones, fractures, bruises, or
sprains could result.
1
3
2
3

Walk-Behind Blower 15
GB
Before attaching/storage the
attachment, move the ON/OFF
Engine Switch to OFF position.
The front discharge chute is used to
redirect the air flow to the front of the
blower. Attach it when needed.
1. Loosen the knob located on top of the
discharge chute.
2. Orient the attachment so the "THIS SIDE UP
DURING USE" is up.
3. Slide the attachment over the discharge
chute. The slot on the top of the attachment
will mate with the bolt of the attachment
knob.
4. Hand-tighten the attachment knob to secure
the attachment.
ATTACH THE FRONT DISCHARGE CHUTE
1
2
THIS SIDE UP
DURING USE
1
2
THIS SIDE UP
FOR STORAGE
When not in use, the front discharge chute
can be stored under the frame at the rear of
the blower. Take follow steps to secure the
attachment for storage.
1. Orient the attachment so the "THIS SIDE UP
FOR STORAGE" is up. Insert the attachment
with this direction under the frame of unit.
It will be supported by a bracket under the
frame.
2. Secure the attachment by rotating it so the
pin on the frame will insert into the slot on
the attachment.
STORAGE OF THE FRONT DISCHARGE
CHUTE

Walk-Behind Blower
16
GB MAINTENANCE
Maintaining your walk-behind blower will ensure
long life to the machine and its components.
PREVENTIVE MAINTENANCE
1. Turn off the engine. The engine must be
cool.
2. Keep the engine’s throttle lever in the
SLOW position and remove the spark
plug wire from the spark plug and secure.
3. Inspect the general condition of the blower.
Check for loose screws, misalignment
of binding of moving parts, cracked or
broken parts, and any other condition that
may affect its safe operation.
4. Remove all debris from the blower with
Never use a pressure washer to clean
your blower. Water can penetrate
tight areas of the unit and cause
damage to spindles, pulleys, bearings,
or the engine.
Refer to the engine manual packed
separately with your unit for detailed
information and a maintenance
schedule.
Shut down the engine, wait for all
moving parts to come to a complete
stop, remove the spark plug wire,
and then wait five minutes before
performing maintenance on the
blower.
a soft brush, vacuum, or compressed air.
Then use a premium quality lightweight
machine oil to lubricate all moving parts
5. Replace the spark plug wire.
The service intervals shown are the maximum
under normal operating conditions. Increase
frequencies under extremely dirty or dusty
conditions.
REGULAR MAINTENANCE CHECKLIST
REGULAR MAINTENANCE CHECKLIST
Interval Item Service
Before each use
1. Engine oil level
2. General equipment condition
3. Debris from unit
1. Check
2. Check
3. Clean
Every Month or 10
Hours of Operation
1. All fasteners are tight and
secured
2. All pivot points
1. Check
2. Lubricate
1st Month or 20 hours 1. Engine oil 1. Change
Every 50 Hours
1. All fasteners are tight and
secured
2. All pivot points
3. Engine oil
4. Air filter and precleaner
1. Check
2. Lubricate
3. Change
4. Inspect or replace
Every Season or 100
Hours
1. Combustion deposits from
cylinder, piston, and valves 1. Clean

Walk-Behind Blower 17
GB
Do not use strong detergents or
petroleum-based cleaners when
cleaning plastic parts. Chemicals can
damage plastics.
Do not store the machine with fuel
in a non-ventilated area where fuel
fumes may reach flame, sparks, pilot
lights or any ignition sources.
If the walk-behind blower will not be used for
a period longer than 30 days, follow the steps
below to prepare your unit for storage.
1. Drain the fuel tank completely. Stored fuel
contains ethanol or MTBE, and can start to
go stale in 30 days. Stale fuel has high gum
content and can clog the carburetor and
restrict fuel flow.
2. Start the engine and run until it stops. This
helps prevent gum deposits from forming
inside the carburetor , which may cause
engine damage.
3. While the engine is still warm, drain the oil
from the engine. Refill with fresh oil of the
grade recommended in the Engine Manual.
4. Use clean cloths to clean off the outside of
the machine and to keep the air vents free
of obstructions.
5. Inspect for any loose or damaged parts.
Repair or replace damaged parts and
tighten loose screws, nuts or bolts.
6. Store your unit on flat ground in a clean,
dry building that has good ventilation.
STORAGE
Before Each Season
1. Engine oil level
2. General equipment condition
3. Debris from unit
4. All fasteners are tight and
secured
5. All pivot points
6. Spark plug
7. Air filter and precleaner
1. Check and change
2. Check
3. Clean
4. Check
5. Lubricate
6. Inspect or replace
7. Inspect or replace
Before Storage
1. Debris from unit
2. All fasteners are tight and
secured
3. All pivot points
4. Engine oil
1. Clean
2. Check
3. Lubricate
4. Change

Walk-Behind Blower
18
GB TROUBLE SHOOTING
Problem Cause Remedy
Engine fails to start
1. Spark plug wire is disconnected
2. Out of fuel or stale fuel
3. Throttle control lever or fuel
valve lever is not in the run
position
4. Choke lever is not in CLOSE
position
5. Blocked fuel line
6. Fouled spark plug
7. Engine flooding
8. Not enough oil in engine
1. Attach spark plug wire
securely to spark plug
2. Drain old fuel and fill with
clean, fresh gasoline
3. Move the throttle control lever
slightly to the fast position,
and move the fuel valve lever
to the ON position
4. Choke level must be in CLOSE
position for a cold start
5. Clean fuel line
6. Clean, adjust gap, or replace
7. Wait a few minutes to restart
the engine
8. Add oil more oil to engine
Engine runs
erratically
1. Spark plug wire is loose
2. Unit running with choke lever
in CLOSE position
3. Blocked fuel line or stale fuel
4. Vent plugged
5. Water or dirt in fuel system
6. Dirty air cleaner
7. Improper carburetor
adjustment
1. Connect and tighten spark
plug wire
2. Move choke lever to OPEN
position
3. Clean fuel line, and fill tank
with clean, fresh gasoline
4. Clear vent
5. Drain fuel tank, then refill
with fresh fuel
6. Clean or replace air cleaner
7. Refer to engine manual
Engine overheats
1. Engine oil level low
2. Dirty air cleaner
3. Air flow restricted
4. Carburetor not adjusted
properly
1. Fill crankcase with proper oil
2. Clean air cleaner
3. Remove housing and clean
4. Refer to engine manual
Engine speed
does not increase
properly when
throttle control is
adjusted.
1. Debris interfering with throttle
inkage.
2. Improper throttle linkage
djustment
1. Clean dirt and debris
2. Refer to Engine Manual to
check and adjust throttle
linkage

Walk-Behind Blower 19
GB
Excessive vibration
or noise
1. Loose parts
2. Damaged impeller
3. Debris in housing
4. Engine problems (above)
1. Tighten all fasteners
2. Contact an authorized service
dealer
3. Contact an authorized service
dealer
4. Refer to engine solutions
(above)

Walk-Behind Blower
20
GB PARTS SCHEDULE
