TOPPIN Comfy Air C1 User manual

©Libro Corp. All Rights Reserved.
Manufacturer: Shenzhen Libro Technology Co., Ltd.
Address: Building 3, Cloud Park,
Shenzhen, China, 518129
Made in China
Please read this User Guide thoroughly before use of the product and retain for
future reference.
Comfy Air C1 HEPA Air Purifier
User Guide
Model: TPAP002
TPAP002_V1.0
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
SUNSEA 商事
株式会社 Intertek
3136602
CM

SAFETY PRECAUTIONS - 1
PRODUCT FEATURES - 3
PRODUCT DIAGRAM - 3
OPERATIONS AND FUNCTION - 5
Pre-Operation Instructions - 5
Power / UV Light Button - 5
Fan Speed / Decorative Light Button - 6
Replacing the Filter - 6
CLEANING AND CARE - 8
General Maintenance - 8
Maintaining the Filter - 8
UV-C Light Care - 9
SPECIFICATIONS - 9
WHAT’S IN THE BOX - 10
TROUBLESHOOTING - 10
WARRANTY - 11
Contents
THANK YOU
FOR CHOOSING TOPPIN

Page 1 Page 2
DO NOT operate any appliance with a damaged cord or plug, if the motor
fan fails to rotate, after the appliance malfunctions, or if it has been
dropped or damaged in any manner. Send to Customer Service for
assistance.
Use appliance only for intended household purposes as described in this
manual. Any other use is not recommended that may cause fire, electric
shock, or injury to persons.
DO NOT use outdoors.
DO NOT place anything on top of the unit.
NEVER block the air openings, grille / outlets or place the unit on a soft
surface such as a bed or sofa, as this could cause the unit to tip over,
blocking the air inlet or outlet.
DO NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void your warranty. The inside of the
unit contains no user serviceable parts. All servicing should be
performed by qualified personnel only.
Keep the appliance on a level surface.
DO NOT look directly at UV light.
Plastic film can be dangerous. To avoid danger of suffocation, keep
away from children.
•
•
•
•
•
•
•
•
•
This product should be used only in accordance with the specifications outlined
in this manual.
Usage other than what has been specified here may result in serious injury.
When using electrical appliances, basic precautions should always be followed
to reduce the risk of fire, electric shock, and injury to persons, including the
following:
WARNING: NOT SUITABLE FOR USE WITH SOLID-STATE SPEED CONTROLS.
AVERTISSEMENT: NE CONVIENT PAS À DES RÉGULATEURS DE VITESSE À
SEMICONDUCTEURS.
The 8 hr TWA Ozone for this product is 0.0002 ppmv when tested in a 30
m³ chamber.
Refer to safety instructions in manual for more information.
This product complies with the maximum allowable concentration of ozone
of 0.050 parts per million by volume (ppmv) in a 24-hour period.
The Health Canada Guideline 2010 recommends that the maximum
exposure limit, based on an averaging time of 8 hours, is 0.020 ppmv or
less when tested in a sealed, controlled room approximately 30 m³.
Ce produit est conforme avec la concentration maximale permise d’ozone
de 0,050 parties par million par volume (ppmv) pendant une période de 24
heures. La Ligne directrice (2010) de Santé Canada recommande un niveau
maximal d'exposition, basé sur un moyen de 8 heures, soit 0,020 ppmv ou
moins dans une chambre de teste étanchée et contrôlée de 30 m³.
Read all instructions before using the appliance.
To avoid fire or shock hazard, plug the appliance directly into a right AC
electrical outlet.
Keep the cord out of heavy traffic areas. To avoid fire hazard, NEVER
put the cord under rugs, near heat registers, radiator, stoves, or
heaters.
To protect against electrical hazards, DO NOT immerse in water or
other liquids. Do not use near water or in a damp or wet location.
Children cannot recognize the hazards associated with the usage of
electrical appliances. For this reason, always supervise children when
they are near the unit.
Always unplug the air purifier before moving it, opening the grille,
changing filters, cleaning or whenever the air purifier is not in use. Be
sure to pull by the plug, not the cord.
NEVER drop or insert any objects into any openings.
DO NOT run the cord under carpeting.
DO NOT cover the cord with throw rugs or similar coverings.
DO NOT route the cord under furniture or appliances. Arrange the cord
away from traffic area and where it will not be tripped over.
•
•
•
•
•
•
•
•
•
•
SAFETY PRECAUTIONS
READ AND SAVE THESE INSTRUCTIONS

Page 3 Page 4
1 - Air Outlet
2 - Speed Level Indicators
3 - Turbo / Decorative Light Button
4 - Power / UV Light Indicator
5 - Power / UV Light Button
6 - Air Inlet
7 - H11 HEPA Type Filter
8 - Base Cover
9 - Power Input Port
10 - Decorative Light*
11 - Twist Handle
12 - Anti-skid Mads
3-Stage Filtration: Pre-filter captures larger airborne particles
such as human hair, pet dander and dust particles; activated
carbon filter removes large dust particles, pet dander, and
household odor; H11 HEPA filter traps up to 95% of pollutants as
small as 0.3μm or larger pollen and dust mites, and filters air
pollution of PM 2.5.
UV-C Light: Inactivate airborne pathogens and microorganisms
like mold, bacteria and viruses.
3 Fan Speeds
Decorative Light
•
•
•
•
The Toppin Comfy Air C1 HEPA Air Purifier is designed to capture 95%
of dust, pollen, pet dander, smoke, mold spores, and household
odors so you can breathe easily. It features:
Warning:
The UV light inside the unit is not a user serviceable part. DO NOT try
to replace.
*The Decorative Light is used for decoration only, not for lighting.
PRODUCT FEATURES
PRODUCT DIAGRAM
UV Light (Built-in)
(Bottom view)
2
3
4
5
9
10
11
12
1
6
7
8

Page 5 Page 6
Fan Speed / Decorative Light Button
Carefully remove your air purifier from the packaging box and
plastic bag.
Remove the filter from the air purifier (see Replacing the Filter on
page 6), remove the protective plastic, and then insert the filter
into the unit.
Place it on a firm, level and flat area.
*For proper air flow, locate the unit at least 1ft / 30cm away from
any wall or furniture.
*Make sure none of the grilles are blocked.
Plug the power adapter into an appropriate voltage AC outlet. A
beep will be heard, and all lights will light up and stay solid on for
3s until the device enters the standby mode.
• When the purifier is on, press to adjust 3 levels of the fan speed and
cycle through 1-Low, 2-Medium, and 3-High settings.
• Press and hold for 3s to turn on / off the Decorative Light.
Note: The corresponding speed level indicator will light up when a
speed level is selected.
IMPORTANT
! When the unit is not in use, please switch it off and unplug from
power.
1.
2.
3.
4.
Press to turn on / off the unit, the Power indicator and
corresponding speed level indicator will turn on / off.
When the device is on, press and hold for 3s to turn on / off the
UV light, and the UV Light indicator will light up.
Note:
By default, each time the device is powered on, initially the fan
speed is at the 2-Medium level and UV light is on.
All LED indicators are blue when lighting up.
When UV Light is turned off, the UV Light indicator will also go out.
•
•
1.
2.
3.
IMPORTANT:
! When moving the air purifier, always lift the unit firmly by both
hands and set down gently on a flat and level surface.
! Do not use any other AC adapter other than the one provided with
the unit.
1. Turn your machine OFF and unplug
the device.
2. Unlock the base cover by rotating
the base counterclockwise.
Pre-Operation Instructions
Replacing the Filter
Power / UV Light Button
OPERATIONS AND FUNCTION

Page 7 Page 8
6. Grip the twist handle, align the
locking notches on the base cover to
the air purifier, push in and firmly
turn clockwise until it clicks into
locking place.
Note: Filter life varies based on run time and existing air conditions.
It is recommended to replace the filter once every 3-6 months.
General Maintenance
Clean the purifier at least once every month with a clean, dry, soft
cloth or a vacuum.
More frequent cleaning may be required depending on environmen-
tal conditions.
Note:
• Do NOT stick any foreign objects or your fingers inside of the unit.
• Do NOT use gasoline, benzene, and other abrasive or harsh
cleaners, etc. on and/or in the unit while cleaning as they will
damage the product.
• NEVER use alcohol or other solvents.
Maintaining the Filter
It’s recommended to clean the filter once each month by lightly
brushing off any visible dust or dirt (take care to avoid disturbing
the delicate network of interior fibers).
3. Remove the base cover to access
the filter. Remove the dirty filter.
4. Remove the protective plastic
from the new filter.
5. Insert the new filter into the air
purifier and place the base cover.
CLEANING AND CARE

Page 9 Page 10
UV-C Light Care
The replacement of the UV-C light must be undertaken at an
authorized Toppin service center. Please contact Toppin Customer
Service Centre for further support.
1 x Toppin Comfy Air C1 HEPA Air Purifier
1 x H11 HEPA TYPE filter (Pre-installed)
1 x Power Adapter
1 x User Guide Kit
*Internal test result.
IMPORTANT
! The filter is not washable. Do not immerse any part of the air purifier in water as it
will cause damage.
Note:
• Filters should be replaced at least once each 3-6 months. More frequent cleaning
and replacing may be required depending on environmental conditions.
• The air purifier works the best in a closed environment. Its performance may be
compromised in a well-ventilated room.
• Air the filters under the sun for an hour before using it again if the purifier has not
been used for a long time.
Operating Condition
Storage Condition
Dimensions (Filter)
Dimensions (Product)
Net Weight
0°C -40°C / 32°F-104°F
(20%-90%, non-condensing)
-10°C-40°C / 14°F-104°F
(20%-90%, non-condensing)
132.5 x 132.5 x 116mm / 5.2 x 5.2 x 4.6in
160 x 160 x 235mm / 6.3 x 6.3 x 9.3in
1053g / 37.1oz
SPECIFICATIONS*
WHAT’S IN THE BOX
TROUBLESHOOTING
Model
Power
Input
Adaptor Input
Adaptor Output
Noise Level
CADR
TPAP002
12W
DC 12V
120V~, 60Hz
12VDC, 1.0A
≤58 dB (@3-High speed level)
51 m³/h (30 CFM)
Before carrying out any of the following service checks, unplug the
unit from the mains.
Problem
Unit will not start.
Unit accidentally
powers off.
Insufficient air
flow.
Possible Solution
•
•
•
Check that the power plug is connected to a
power outlet and the outlet is turned on.
Check that air purifier is assembled
correctly.
Check that the filter is fitted correctly in place.
•The air purifier restarts automatically and
goes to the previous mode when the power
resumes.
•
•
Check that the filters are clean.
Check for any obstructions in the air inlet
and/or outlet.

Page 11
12-month warranty
Life-time support
Please contact our customer service at [email protected]
for warranty extension or any questions about the product.
WARRANTY
•
•
Problem
Excessive noise.
UV Light not
illuminating
The air purifier
produces an
unpleasant smell.
Possible Solution
•
•
•
•
Check for any foreign objects that may be in
contact with the fan.
Check if the filter is clogged and ready for
replacement.
Check that the air purifier has been
assembled correctly and the locking knob
has been tightened.
Check that the unit is on a level surface.
•
•
•
Contact our customer service for UVC light
replacement.
The first few times you use the air purifier, it
may produce a plastic smell. This is normal.
The air purifier may also produce an
unpleasant smell when the filter is dirty. In
this case, clean or replace the appropriate
filter.
However, if the appliance produces a burnt
smell even if removing filter, stop using and
contact our customer service immediately.
