Topseed TSIJ-2401 User manual

1
/
9
TSIJ-2401
Topseed
RF
Remote
Control
UserManual
RFRemoteControl
ProductName:RFRemoteControl
ProductNo.: RCIJ0002AG-2401
Model No.: TSIJ-2401
Version:Ver.1.0
Date:2008/07/05

2
/
9
TSIJ-2401
Topseed
RF
Remote
Control
Description:
1.PreliminaryProductSpecification:
1.1Scope:
ThisSpec.proviesan overviewoftherequiredRFremotecontrolandreceiverfunctionalityfor
Customersystems.Theproductincludes:
-an RFRemoteControl(2.4GHz)
-an USBReceiverdangle
-2AA batteries.
1.2General:
1.2.1Batteries:2AAbatteriesaredesignedto beusedin RFremotetosupportatleast3
monthsnormalusage.
1.2.2RestrictedSubstancesandEnvironmentalRequirements:all thematerialsand
manufacturingprocess usedtoproduceRFremotemustcomplyto RoHS requirements.
1.2.3RoHS (wecanputsomeRoHS requirementshereandstatethatall thematerialsusedin
theproductspecification compliesto RoHS requirements).
1.3ErgonomicsRequirements:
Thisproductwas designedtobeergonomicsforall users.
1.3.1Theergonomicremotedesign istofitintousers palmstoreducethediscomfort caused
bylongtimeusage.
1.3.2Thesymmetricaldesign istobefitforbothleft-handedandright-handeduserstoreduce
thediscomfortorstrain causedto users.
1.3.3Everykey designedontheremoteistobedesignedeasyto reach forusersforeasy
usabilityandreducestrain.
1.4ProductFunctionalRequirements:
1.4.1Operation System:needstobefunctionalwhen workingunderCustomersystems.
1.4.2Interface:ReceiverneedstobeworkingunderUSB1.1and2.0Interface.
1.4.3RangeRequirements:thetransmission oftheremotecontrolshall beatleast30-50 meters
with opticalfilterin place.
1.4.4RFProtocol:UsingTopseedStandardRFprotocolwith HIDDriver.
1.4.5Frequency Range:2.4 to2.483 GHz(16 multi channelsand65535 ID channelsforRF
RemoteControl)
1.4.6BatteryLife:2 AA batteriestoprovideatleast3monthsnormalusage.
1.4.7Weight:125.8g
1.4.8 Operation Temperature:50

3
/
9
TSIJ-2401
Topseed
RF
Remote
Control
1.5DetailedProductSpecification –RFRemoteControl
1.5.1RFRemoteControl

4
/
9
TSIJ-2401
Topseed
RF
Remote
Control
1.5.2
PhysicalDescription andSpecification –2DDrawing

5
/
9
TSIJ-2401
Topseed
RF
Remote
Control
1.5.3RemoteControlButtons

6
/
9
TSIJ-2401
Topseed
RF
Remote
Control
1.5.3RemoteControlButtons(cont.)

7
/
9
TSIJ-2401
Topseed
RF
Remote
Control
1.5.3RemoteControlButtons(cont.)

8
/
9
TSIJ-2401
Topseed
RF
Remote
Control
1.5.3RemoteControlButtons(cont.)

9
/
9
TSIJ-2401
Topseed
RF
Remote
Control
Appendix:WarningStatement
FCC Guidelines
DeclarationofConformityforR&TTEdirective1999/5/EC
Thisdevice complieswithPart15 of theFCCRules. Operationissubjecttothefollowingtwoconditions:
(1) thisdevice maynotcauseharmfulinterference,and
(2) thisdevice mustacceptanyinterference received, includinginterference thatmaycauseundesiredoperation.
Anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance couldvoidthe
user sauthoritytooperatetheequipment.
Protectionrequirementsforelectromagneticcompatibility –Article3.1b
TestingforelectromagneticcompatibilityaccordingtoEN301 489-1,EN301489-3 hasbeenconducted.These
areconsideredrelevantandsufficient.
Effectiveuseoftheradiospectrum –Article3.2
Testingforradiotestsuitesaccording toEN300440-2hasbeenconducted.Theseareconsideredrelevantand
sufficient.
Hereby, [DongGuanJess-LinkElectronicsCo.,Ltd.],declaresthatthisdevice isincompliance withtheessential
requirementsandotherrelevantprovisionsof Directive1999/5/EC.
Essentialrequirements –Article3
Protectionrequirementsforhealthandsafety –Article3.1a
TestingforelectricsafetyaccordingtoEN60950-1hasbeenconducted.Theseareconsideredrelevantand
sufficient.
型式認證合格之低功率射頻電機，非 許可，公司、商號或使用者均不得擅自變更頻率、加大功率
或變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信； 發現有干擾現象時，應立即停用，並改
善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
