Torch Lighting Systems 4009 High Beamer Max User manual

For more information: www.magnum.ws
Bulb
Halogen 6V – 2.4W
1. TORCH High Beamer Max is water-resistant. Although light body is water-
resistant (under normal weather conditions of rain, etc.) never intentionally
submerge it under water.
2. If the light body or parts become dirty or have been exposed to any
containments or dirt, gently clean with soft towel using mild soap and water
only. Lubricate and maintain the light body with silicon based grease on the
O-rings. Never use harsh chemicals to clean the lighting system as damage
to the housing and lens will occur.
3. Safely and properly dispose of the old batteries according to your local
regulations.
4. Never place this lighting system within a child’s reach.
5. For ultimate safety, the High Beamer Max should be used in conjunction with
a rear safety LED, reflectors, and possible additional front lighting deemed
necessary.
6. Always wear an approved bicycle helmet, when riding.
7. Riding a bicycle at night is dangerous and could result in injury or possible
death.
8. In addition to its brightness, the beam is widely diffused. In case you need
to use this light on public roads, be sure to adjust the angle downward so as
not to blind oncoming traffic.
SAFETY NOTES
BRACKET INSTALLATION
Strap
release tab
LIGHT MOUNTING LIGHT REMOVAL
Off
High
Low
SWITCH BUTTON
LIGHTING SYSTEMS
4009 High Beamer Max
Rechargeable lighting system User’s Guide
BULB REPLACEMENT LIGHT MODE
Slide untill
it clicks into
position
Push to
release the
light

For more information: www.magnum.ws
FOR SAFE OPERATION (IMPORTANT)
• Nevershort-circuittheterminalofthebatteryandtheplugofthebatterycharger.Itmaycausethebatterytooverheat,resultinginreordamageofthe
components.
• Securelyconnecttheplugsothatthelightwillnothinderriding.
• Ifthecordofthebatterycharger,thebatterycordorbatteryunitisdamaged,itmustonlybereplacedbytheshopwherethislightingsystemwaspurchased,
because special purpose tools are required.
• Useonlytheincludedbatterychargerforcharging.
• Safelyandproperlydisposeoftheoldbatteryaccordingtoyourlocalregulationswhenitcomestotheendofitsusefullife.
• Thislampkitisnotintendedforusebyyoungchildrenorinrmpersonswithoutsupervision;youngchildrenshouldbesupervisedtoensurethattheydonotplay
with this appliance.
BEFORE FIRST USE
Before first use, charge the battery fully following the instructions on (HOW TO CHARGE).
Before every use, charge the battery fully following the instructions on (HOW TO CHARGE).
Whenthebatterykitisnotinuseforalongperiod,thelightingsystemoperationtimewillbeshortenedduetotheself-dischargeofthesealed-lead-acidbattery.
HOW TO MOUNT
Before connecting the cords, mount the battery unit and lamp unit onto the right places.
Installing the Battery Unit
Insert the battery unit into your bottle cage. Secure it with the battery belts.
NOTE: The battery unit might jump out of the bottle cage during ride. Be sure that it is tightly
and firmly fixed.
NOTE: The battery unit may not fit all kinds of bottle cages.
The battery unit also can be attached under the top tube or along the seat post using the battery belt.
HOW TO CHARGE
Useonlytheprovidedbatterycharger.Thechargerisonlyforindooruse.
1. Unplugthebatteryunit.
2. Connect the plug of the battery unit with the battery charger. Plug the battery charger with the home
power outlet.
• Standardchargingtimeis8to10hours.(Dependingonthecapacityofthebattery,thechargingtime
willvary.)Becarefulnottochargeitformorethan10hours.Overchargewilldamagethebattery.
NOTE: The charging time and the operation time may vary depending on the use environment.
IMPORTANT
Precautions on seald-lead-acid battery
• Ifthelightiskeptonuntilthepoweriscompletelygone,theperformanceofthebatteryisloweredduetotheoverdischargeofthesealed-lead-acidbattery.When
the light gets dim, turn off the lamp immediately and charge the battery.
• Alongperiodofnon-usewilllowerthevoltageofthebatteryduetonaturalself-discharge.Ifthelightiskeptonuntilthepoweriscompletelygone(whichis
called“overdischarge”),itmayshortenthebatterylife.Evenwhenyoudonotusethelampkit,chargethebatteryeveryfewmonths.
• Donotchargethebatteryformorethan10hours.
• Ifthelampsetdoesnotservetheproperrunningtimeeventhoughthebatteryisfullycharged,thebatterymayhavereachedtheendofitsusefullife.Replaceit
with a new battery unit.
HOW TO REPLACE THE FUSE
A fuse will cut the circuit when malfuction occurs. Remove the malfuction.
NOTE: If the fuse continues to burn, call the appropriate service center for assistance.
1. Loosen the screws of the battery unit and carefully open the battery case.
2.Openthefusecaseinside.replacethefuse(10A)withanewone.
NOTE: Do not pull the cord inside of the battery forcibly.
NOTE: Do not short-circuit the terminal of the battery.
BATTERY UNIT
CAUTION
• Toensurethecordcannotvibrateloosefromthesocketwhileriding,securethecordtothehandlebarwiththesuppliedvelcro-strap.
• Ifthevelcro-strapistoolong,cutthestraptoyourdesiredlength.
battery unit
bottle cage
battery
belt
FASTEN
MOUNTING OPTIONS
battery belt
battery belt
