Toro 4383 User manual

Operator’s Manual
English (EN, GB)
Form No. 3351–805
Greensmaster3250-D
Traction Unit
Model No. 04383—240000001 and Up

2
All Rights Reserved
Printed in the USA
2004 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of its constituents
are known to the State of California to cause
cancer, birth defects, and other reproductive harm.
Warning
Important The engine in this product is not equipped
with a spark arrester muffler. It is a violation of California
Public Resource Code Section 4442 to use or operate this
engine on any forest-covered, brush-covered, or
grass-covered land as defined in CPRC 4126. Other states
or federal areas may have similar laws.
This spark ignition system complies with Canadian
ICES-002.
Ce système d’allumage par étincelle de véhicule est
conforme à la norme NMB-002 du Canada.
Contents
Page
Introduction 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safe Operating Practices 3. . . . . . . . . . . . . . . . . . . .
Toro Riding Mower Safety 5. . . . . . . . . . . . . . . . . . .
Sound Pressure Level 6. . . . . . . . . . . . . . . . . . . . . . .
Sound Power Level 6. . . . . . . . . . . . . . . . . . . . . . . .
Vibration Level 6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and Instruction Decals 7. . . . . . . . . . . . . . . . .
Specifications 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 11. . . . . . . . . . . . . . . . . . . . . .
Optional Equipment 11. . . . . . . . . . . . . . . . . . . . . . . .
Setup 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loose Parts 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Front Wheels 13. . . . . . . . . . . . . . . . . .
Installing the Rear Wheel 13. . . . . . . . . . . . . . . . . . . .
Mounting the Seat 13. . . . . . . . . . . . . . . . . . . . . . . . .
Activating and Charging the Battery 13. . . . . . . . . . .
Installing the Steering Wheel 15. . . . . . . . . . . . . . . . .
Installing the Breather Extension and
Reservoir Cap 15. . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting the Front Rollers 15. . . . . . . . . . . . . . . . . .
Adjusting Carrier Frame Rollers 16. . . . . . . . . . . . . .
Installing the Cutting Units 16. . . . . . . . . . . . . . . . . .
Adjusting the Transport Height 19. . . . . . . . . . . . . . .
Before Operating 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Engine Oil 20. . . . . . . . . . . . . . . . . . . .
Page
Filling the Fuel Tank 20. . . . . . . . . . . . . . . . . . . . . . .
Checking the Cooling System 21. . . . . . . . . . . . . . . .
Servicing the Hydraulic System Fluid 21. . . . . . . . . .
Draining Water from the Fuel Filter/Water
Separator 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Tire Pressure 23. . . . . . . . . . . . . . . . . .
Checking the Reel-to-Bedknife Contact 23. . . . . . . .
Checking the Torque of the Wheel Nuts 23. . . . . . . .
Operation 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Think Safety First 24. . . . . . . . . . . . . . . . . . . . . . . . . .
Controls 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In Period 26. . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting and Stopping the Machine 26. . . . . . . . . . . .
Bleeding the Fuel System 27. . . . . . . . . . . . . . . . . . . .
Testing the Safety Interlock System 27. . . . . . . . . . . .
Setting the Reel Speed 28. . . . . . . . . . . . . . . . . . . . . .
Preparing the Machine for Mowing 28. . . . . . . . . . . .
Training Period 29. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before Mowing 29. . . . . . . . . . . . . . . . . . . . . . . . . . .
Mowing Procedures 29. . . . . . . . . . . . . . . . . . . . . . . .
Transport Operation 30. . . . . . . . . . . . . . . . . . . . . . . .
Inspection and Clean-Up After Mowing 30. . . . . . . .
Towing the Traction Unit 30. . . . . . . . . . . . . . . . . . . .
Maintenance 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Maintenance Schedule 31. . . . . . . . .
Daily Maintenance Checklist 32. . . . . . . . . . . . . . . . .
Lubrication 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the Radiator Screen 34. . . . . . . . . . . . . . . . .
Engine Oil 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Filter/Water Separator 35. . . . . . . . . . . . . . . . . .
Adjusting the Throttle Control 35. . . . . . . . . . . . . . . .
Adjusting the Idle Speed 35. . . . . . . . . . . . . . . . . . . .
Hydraulic Oil 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Hydraulic Lines and Hoses 36. . . . . . .
Adjusting the Brakes 36. . . . . . . . . . . . . . . . . . . . . . .
Adjusting the Transmission for Neutral 37. . . . . . . . .
Adjusting the Transport Speed 37. . . . . . . . . . . . . . . .
Adjusting the Mowing Speed 38. . . . . . . . . . . . . . . . .
Adjusting the Cutting Unit Lift/Drop 38. . . . . . . . . . .
Adjusting the Belt 38. . . . . . . . . . . . . . . . . . . . . . . . .
Servicing the Battery 39. . . . . . . . . . . . . . . . . . . . . . .
Storing the Battery 40. . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Backlapping Operation 40. . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic 41. . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Schematic 42. . . . . . . . . . . . . . . . . . . . . . .
The Toro General Commercial Products Warranty 44. . .

3
Introduction
Read this manual carefully to learn how to operate and
maintain your product properly. The information in this
manual can help you and others avoid injury and product
damage. Although Toro designs and produces safe
products, you are responsible for operating the product
properly and safely.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Service
Dealer or Toro Customer Service and have the model and
serial numbers of your product ready. Figure 1 illustrates
the location of the model and serial numbers on the
product.
1
Figure 1
1. Location of the model and serial numbers
Write the product model and serial numbers in the space
below:
Model No.
Serial No.
This manual identifies potential hazards and has special
safety messages that help you and others avoid personal
injury and even death. Danger, Warning, and Caution are
signal words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
Danger signals an extreme hazard that will cause serious
injury or death if you do not follow the recommended
precautions.
Warning signals a hazard that may cause serious injury or
death if you do not follow the recommended precautions.
Caution signals a hazard that may cause minor or moderate
injury if you do not follow the recommended precautions.
This manual uses two other words to highlight information.
Important calls attention to special mechanical
information and Note: emphasizes general information
worthy of special attention.
Safety
This machine meets or exceeds CEN standard EN
836:1997, ISO standard 5395:1990, and ANSI
B71.4-1999 specifications in effect at the time of
production when 40 lb. of ballast is added to the rear
wheel.
Improper use or maintenance by the operator or owner
can result in injury. To reduce the potential for injury,
comply with these safety instructions and always pay
attention to the safety alert symbol, which means
CAUTION, WARNING, or DANGER—“personal
safety instruction.” Failure to comply with the
instruction may result in personal injury or death.
Safe Operating Practices
The following instructions are from the CEN standard EN
836:1997, ISO standard 5395:1990, and ANSI B71.4-1999.
Training
•Read the Operator’s Manual and other training material
carefully. Be familiar with the controls, safety signs,
and the proper use of the equipment.
•Never allow children or people unfamiliar with these
instructions to use or service the mower. Local
regulations may restrict the age of the operator.
•Never mow while people, especially children, or pets
are nearby.
•Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
•Do not carry passengers.
•All drivers and mechanics should seek and obtain
professional and practical instruction. The owner is
responsible for training the users. Such instruction
should emphasize:
– the need for care and concentration when working
with ride-on machines;
– control of a ride-on machine sliding on a slope will
not be regained by the application of the brake. The
main reasons for loss of control are:
•insufficient wheel grip;
•being driven too fast;
•inadequate braking;
•the type of machine is unsuitable for its task;
•lack of awareness of the effect of ground
conditions, especially slopes;
•incorrect hitching and load distribution.

4
•The owner/user can prevent and is responsible for
accidents or injuries occurring to himself or herself,
other people, or property.
Preparation
•While mowing, always wear substantial footwear, long
trousers, hard hat, safety glasses, and ear protection.
Long hair, loose clothing, or jewelry may get tangled in
moving parts. Do not operate the equipment when
barefoot or wearing open sandals.
•Thoroughly inspect the area where the equipment is to
be used and remove all objects which may be thrown by
the machine.
•Warning—Fuel is highly flammable. Take the
following precautions:
– Store fuel in containers specifically designed for this
purpose.
– Refuel outdoors only and do not smoke while
refuelling.
– Add fuel before starting the engine. Never remove
the cap of the fuel tank or add fuel while the engine
is running or when the engine is hot.
– If fuel is spilled, do not attempt to start the engine
but move the machine away from the area of
spillage and avoid creating any source of ignition
until fuel vapors have dissipated.
– Replace all fuel tanks and container caps securely.
•Replace faulty silencers.
•Evaluate the terrain to determine what accessories and
attachments are needed to properly and safely perform
the job. Only use accessories and attachments approved
by the manufacturer.
•Check that operator’s presence controls, safety switches
and shields are attached and functioning properly. Do
not operate unless they are functioning properly.
Operation
•Do not operate the engine in a confined space where
dangerous carbon monoxide fumes can collect.
•Mow only in daylight or in good artificial light.
•Before attempting to start the engine, disengage all
blade attachment clutches, shift into neutral, and engage
the parking brake.
•Remember there is no such thing as a safe slope. Travel
on grass slopes requires particular care. To guard
against overturning:
– do not stop or start suddenly when going up or
downhill;
– machine speeds should be kept low on slopes and
during tight turns;
– stay alert for humps and hollows and other hidden
hazards;
– never mow across the face of the slope, unless the
mower is designed for this purpose.
•Stay alert for holes in the terrain and other hidden
hazards.
•Watch out for traffic when crossing or near roadways.
•Stop the blades rotating before crossing surfaces other
than grass.
•When using any attachments, never direct discharge of
material toward bystanders nor allow anyone near the
machine while in operation.
•Never operate the machine with damaged guards,
shields, or without safety protective devices in place. Be
sure all interlocks are attached, adjusted properly, and
functioning properly.
•Do not change the engine governor settings or
overspeed the engine. Operating the engine at excessive
speed may increase the hazard of personal injury.
•Before leaving the operator’s position:
– stop on level ground;
– disengage the power take-off and lower the
attachments;
– change into neutral and set the parking brake;
– stop the engine and remove the key.
•Disengage drive to attachments when transporting or
not in use.
•Stop the engine and disengage drive to attachment
– before refuelling;
– before removing the grass catcher/catchers;
– before making height adjustment unless adjustment
can be made from the operator’s position.
– before clearing blockages;
– before checking, cleaning or working on the mower;
– after striking a foreign object or if an abnormal
vibration occurs. Inspect the mower for damage and
make repairs before restarting and operating the
equipment.
•Reduce the throttle setting before stopping engine and,
if the engine is provided with a shut-off valve, turn the
fuel off at the conclusion of mowing.
•Keep hands and feet away from the cutting units.

5
•Look behind and down before backing up to be sure of
a clear path.
•Slow down and use caution when making turns and
crossing roads and sidewalks. Stop reels if not mowing.
•Do not operate the mower under the influence of
alcohol or drugs
•Use care when loading or unloading the machine into a
trailer or truck
•Use care when approaching blind corners, shrubs, trees,
or other objects that may obscure vision.
Maintenance and Storage
•Keep all nuts, bolts and screws tight to be sure the
equipment is in safe working condition.
•Never store the equipment with fuel in the tank inside a
building where fumes may reach an open flame or
spark.
•Allow the engine to cool before storing in any
enclosure.
•To reduce the fire hazard, keep the engine, silencer,
battery compartment and fuel storage area free of grass,
leaves, or excessive grease.
•Check the grass catcher frequently for wear or
deterioration.
•Keep all parts in good working condition and all
hardware and hydraulic fittings tightened. Replace all
worn or damaged parts and decals.
•If the fuel tank has to be drained, do this outdoors.
•Be careful during adjustment of the machine to prevent
entrapment of the fingers between moving blades and
fixed parts of the machine.
•On multi-reel machines, take care as rotating one reel
can cause other reels to rotate.
•Disengage drives, lower the cutting units, set parking
brake and stop engine. Wait for all movement to stop
before adjusting, cleaning or repairing.
•Clean grass and debris from cutting units, drives,
mufflers, and engine to help prevent fires. Clean up oil
or fuel spillage.
•Use jack stands to support components when required.
•Carefully release pressure from components with stored
energy.
•Disconnect battery before making any repairs.
Disconnect the negative terminal first and the positive
last. Reconnect positive first and negative last.
•Use care when checking the reels. Wear gloves and use
caution when servicing them.
•Keep hands and feet away from moving parts. If
possible, do not make adjustments with the engine
running.
•Charge batteries in an open well ventilated area, away
from spark and flames. Unplug charger before
connecting or disconnecting from battery. Wear
protective clothing and use insulated tools.
Toro Riding Mower Safety
The following list contains safety information specific to
Toro products or other safety information that you must
know that is not included in the CEN, ISO, or ANSI
standard.
This product is capable of amputating hands and feet and
throwing objects. Always follow all safety instructions to
avoid serious injury or death.
Use of this product for purposes other than its intended use
could prove dangerous to user and bystanders.
•Know how to stop the engine quickly.
•Do not operate the machine while wearing tennis shoes
or sneakers.
•Wearing safety shoes and long pants is advisable and
required by some local ordinances and insurance
regulations.
•The operator must be skilled and trained in how to drive
on hillsides. Failure to use caution on slopes or hills
may cause loss of control and cause the vehicle to tip or
roll, possibly resulting in personal injury or death.
•Handle gasoline carefully. Wipe up any spills.
•Check the safety interlock switches daily for proper
operation. If a switch should fail, replace the switch
before operating the machine. After every two years,
replace all four interlock switches in the safety system,
regardless if they are working properly or not.
•Before starting the engine, sit on the seat, depress the
lift pedal, and release it to ensure that the cutting units
are disengaged. Verify that the traction system is in
neutral and the parking brake is set.
•Using the machine demands attention. To prevent loss
of control:
– Do not drive close to sand traps, ditches, creeks, or
other hazards.
– Reduce speed when making sharp turns. Avoid
sudden stops and starts.
– When near or crossing roads, always yield the
right-of-way.
– Apply the service brakes when going downhill to
keep forward speed slow and to maintain control of
the machine.

6
•The grass baskets must be in place during operation of
the reels or thatchers for maximum safety. Shut the
engine off before emptying the baskets.
•Raise the cutting units when driving from one work
area to another.
•Do not touch the engine, muffler, or exhaust pipe while
the engine is running or soon after it has stopped
because these areas could be hot enough to cause burns.
•Stay clear of the rotating screen at the side of the engine
to prevent direct contact with your body or clothing.
•If the engine stalls or loses headway and cannot make it
to the top of a slope, do not turn the machine around.
Always back slowly, straight down the slope.
•When a person or pet appears unexpectedly in or near
the mowing area, stop mowing. Careless operation,
combined with terrain angles, ricochets, or improperly
positioned guards can lead to thrown object injuries. Do
not resume mowing until the area is cleared.
•Before getting off of the seat, move the functional
control lever to neutral (N), raise the cutting units and
wait for the reels to stop spinning. Set the parking
brake. Stop the engine and remove the key from the
ignition switch.
•Whenever the machine is left unattended, make sure
that the cutting units are fully raised and the reels are
not spinning, the key is removed from the ignition
switch, and the parking brake is set.
Maintenance and Storage
•Make sure all hydraulic line connectors are tight and all
hydraulic hoses and lines are in good condition before
applying pressure to the system.
•Keep your body and hands away from pin hole leaks or
nozzles that eject hydraulic fluid under high pressure.
Use paper or cardboard, not your hands, to search for
leaks. Hydraulic fluid escaping under pressure can have
sufficient force to penetrate the skin and cause serious
injury.
•Before disconnecting or performing any work on the
hydraulic system, all pressure in the system must be
relieved by stopping the engine and lowering the cutting
units and attachments to the ground.
•Check all fuel lines for tightness and wear on a regular
basis. Tighten or repair them as needed.
•If the engine must be running to perform a maintenance
adjustment, keep hands, feet, clothing, and any parts of
the body away from the cutting units, attachments, and
any moving parts, especially the screen at the side of the
engine. Keep everyone away.
•The engine must be shut off before checking the oil or
adding oil to the crankcase.
•To ensure safety and accuracy, have an Authorized Toro
Distributor check the maximum engine speed with a
tachometer. Maximum governed engine speed should be
2900 RPM.
•If major repairs are ever needed or if assistance is
desired, contact an Authorized Toro Distributor.
•Use only Toro-approved attachments and replacement
parts. The warranty may be voided if used with
unapproved attachments.
Sound Pressure Level
This unit has an equivalent continuous A-weighted sound
pressure at the operator ear of: 84 dBA, based on
measurements of identical machines per Directive
98/37/EC and amendments.
Sound Power Level
This unit has a guaranteed sound power level of: 105 dBA,
based on measurements of identical machines per Directive
200/14/EC and amendments.
Vibration Level
Hand-Arm
This unit does not exceed a vibration level of 2.5 m/sat
the hands based on measurements of identical machines per
ISO 5349 procedures.
Whole Body
This unit does not exceed a vibration level of 0.5 m/sat
the posterior based on measurements of identical machines
per ISO 2631 procedures.

7
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger. Replace any decal that is damaged or lost.
106-6379
93-8068
1. Read the operator’s manual for instructions on how to lock and
unlock the steering arm.
104-7728
93-6686
1. Hydraulic oil 2. Read the Operator’s
Manual.
93-9051
1. Read the operator’s manual.
93-6681
1. Cutting/dismemberment hazard—stay away from moving parts.
93-8069
1. Hot surface hazard—stay away.

8
100-3183
1. Engine start
2. Engine preheat/on
3. Engine stop
4. Read the operator’s manual.
5. Lowers the reels and
engages them
6. Raises the reels
7. Engine coolant temperature
8. High temperature override
9. Water in the fuel indicator
light
10. Headlights on
11. Headlights off
12. Functional control lever
13. Use for transport.
14. Use for mowing.
15. Neutral—use for
backlapping reels.
16. Throttle—slow
17. Throttle—variable speed
18. Throttle—fast
93-7275
1. Read the operator’s manual—do not use starting fluid to start
the engine.
93-6689
1. Danger—do not sit on the plastic shroud.
104-7729 (for CE)
1. Danger—read the
operator’s manual before
performing any
maintenance.
2. Cutting hazard to hands
or feet—wait until all
machine components
have stopped before
touching them.
106-5976
1. Engine coolant under
pressure
2. Explosion hazard—read
the
Operator’s Manual.
3. Warning—do not touch
the hot surface.
4. Warning—read the
Operator’s Manual.

9
104-2053
93-8063
1. Warning—read the Operator’s Manual.
2. Tipping hazard—do not use the machine on a slope greater
than 15 degrees.
3. Thrown object hazard—stay a safe distance from the machine.
4. Cutting hazard of hand or foot—stay away from moving parts.
5. Warning—lock the parking brake, stop the engine, and remove
the ignition key before leaving the machine.
104-2052
Battery Symbols
Some or all of these symbols are on your battery.
1. Explosion hazard
2. No fire, open flames, or
smoking.
3. Caustic liquid/chemical
burn hazard
4. Wear eye protection
5. Read the Operator’s
Manual.
6. Keep bystanders a safe
distance from the battery.
7. Wear eye protection;
explosive gases can
cause blindness and
other injuries
8. Battery acid can cause
blindness or severe
burns.
9. Flush eyes immediately
with water and get
medical help fast.
10. Contains lead; do not
discard.
93-8062
1. To lock the parking brake, press the brake pedal and parking
brake.
2. To unlock the parking brake, press the brake pedal.
3. Locks the parking brake

10
105-8324
1. Height of cut
2. 8 blade reel 3. 11 blade reel 4. Reel—mowing speed 5. Fast 6. Continuous variable setting 7. Slow

11
Specifications
General Specifications
Width of cut 59 in. (150 cm)
Wheel tread 50.5 in. (128 cm)
Wheel base 48.6 in. (123 cm)
Overall length (w/baskets) 93.9 in. (238 cm)
Overall width 68 in. (173 cm)
Overall height 50.5 in. (128 cm)
Weight w/reels
(8 Blade 4 Bolt) 1338 lb. (608 kg)
Optional Equipment
8 Blade DPA Cutting Unit Model No. 04610
11 Blade DPA Cutting Unit Model No. 04611
Thatching Reels Model No. 04493
Spiker Model No. 04494
Tri-Roller Model No. 04495
Turf Guardian Leak Detector Model No. 04497
Three Wheel Drive Kit Model No. 04553
ROPS Model No. 04552
Light Kit Model No. 04551
Arm Rests Model No. 30707
Spark Arrester Part No. 94-8157
Hose Adapter Kit Part No. 100-6430
Tie Down Kit Part No. 94-6379
Oil Cooler Kit Part No. 104-7701
Traction Tire Part No. 99-4506

12
Setup
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
Description Qty. Use
Wheel nuts
Wheels 8 2Mounting the front wheels
Wheel hub
Wheel nuts
Wheel
Wheel bolt
Locknut
Spacers
1
4
1
1
1
2
Mounting the rear wheel
Seat
Nut, 5/16 in. 1 4Mounting the seat to the seat base
Steering wheel
Cap
Screw
1
1
1Mounting the steering wheel
Pull link 2Mounting the front rollers
Gauge bar
Screw, #10 x 5/8 in.
Nut, #10
1
1
1Setting the height-of-cut
Breather extension 1Mount to the hydraulic reservoir.
Lift link (chain link)
Mounting bracket 1 1Mount to cutting unit Models 04610 & 04611.
Capscrews 2Use to mount lift link to cutting unit Models
04610 & 04611.
Grass Basket 3Mount to the pull frame.
Ignition key 2
Service decal 11 Affix appropriate language decal over English
service decal (100-3150).
Operator’s manual (traction unit)
Operator’s manual (engine) 2 1Read before operating the machine.
Operator video 1Watch before operating the machine.
Parts Catalog
Certificate of compliance
Pre-delivery sheet
Noise certificate
1
1
1
1
Note: Mounting fasteners for the Greensmaster 3250-D cutting units are included with the cutting units.

13
Installing the Front Wheels
Mount the front wheels and torque the mounting nuts to
70–90 ft.-lb.
Installing the Rear Wheel
1. Mount the wheel hub to the rear wheel rim with 4
mounting nuts (Fig. 2). Torque the nuts to 70–90 ft.-lb.
2. Remove the wheel bolt and locknut from the wheel
mounting holes in the rear castor fork (Fig. 2).
3. Install the rear wheel into the castor fork. Insert the
wheel bolt into one of the castor fork mounting holes,
install a spacer (supplied in loose parts), and slide the
bolt through the wheel.
4. Install another spacer onto the bolt and route the bolt
through the remaining castor fork mounting hole.
1
2
3
4
5
6
Figure 2
1. Rear wheel
2. Hub
3. Nut
4. Rear castor fork
5. Wheel bolt
6. Spacer (2)
5. Position the bend of the wheel bolt head under the
bottom edge of the adapter plate (Fig. 2). Install and
tighten the locknut to secure the wheel to the castor
fork. Do not overtighten the locknut as the wheel must
rotate freely.
6. Wipe the grease fitting clean on the wheel assembly.
Pump grease into the wheel hub until grease is seen
exiting at both hub bearings. Wipe up excess grease.
Mounting the Seat
Note: Mount the seat slides in the front set of mounting
holes to gain an additional 3 in. (7.6 cm) in the forward
adjustment, or in the rear mounting holes for an additional
3 in. (7.6 cm) in the rearward adjustment.
1. Remove the locknuts securing the seat slides to the
plywood shipping base. Discard the locknuts.
2. Connect the wire harness to the seat switch.
3. Secure the seat slides to the seat support with 4 locknuts
(5/16 in.) supplied in the loose parts (Fig. 3).
1
2
Figure 3
1. Seat support 2. Seat slide
Activating and Charging the
Battery
Use only electrolyte (1.265 Specific Gravity) to fill battery
initially.
1. Remove the battery from the machine.
Important Do not add electrolyte while the battery is in
the machine. You could spill it, causing corrosion.

14
2. Clean the top of the battery and remove the vent caps
(Fig. 4).
1
Figure 4
1. Vent caps
3. Carefully fill each cell with electrolyte until the plates
are covered with about 1/4 inch (6 mm) of fluid.
1
Figure 5
1. Electrolyte
4. Allow approximately 20 to 30 minutes for the
electrolyte to soak into the plates. Refill as necessary to
bring the electrolyte to within about 1/4 inch (6 mm) of
the bottom of the fill well (Fig. 5).
Charging the battery produces gasses that can
explode.
Never smoke near the battery and keep sparks and
flames away from battery.
Warning
5. Connect a 3 to 4 amp battery charger to the battery
posts. Charge the battery at a rate of 3 to 4 amps until
the specific gravity is 1.250 or higher and the
temperature is at least 60F (16C) with all sells gasing
freely.
6. When the battery is charged, disconnect the charger
from the electrical outlet and battery posts.
Note: After the battery has been activated, add only
distilled water to replace normal loss, although
maintenance–free batteries should not require water under
normal operating conditions.
CALIFORNIA
Proposition 65 Warning
Battery posts, terminals, and related accessories
contain lead and lead compounds, chemicals
known to the State of California to cause cancer
and reproductive harm. Wash hands after
handling.
Warning
Battery terminals or metal tools could short
against metal tractor components causing sparks.
Sparks can cause the battery gasses to explode,
resulting in personal injury.
•When removing or installing the battery, do not
allow the battery terminals to touch any metal
parts of the tractor.
•Do not allow metal tools to short between the
battery terminals and metal parts of the tractor.
Warning
7. First, install the positive cable (red) to the positive (+)
terminal and then the negative cable (black) to the
negative (–) terminal of the battery and secure them
with the bolts and nuts (Fig. 6). Slide the rubber boot
over the positive terminal to prevent a possible short
from occurring.

15
Incorrect battery cable routing could damage the
tractor and cables causing sparks. Sparks can
cause the battery gasses to explode, resulting in
personal injury.
•Always disconnect the negative (black) battery
cable before disconnecting the positive (red)
cable.
•Always connect the positive (red) battery cable
before connecting the negative (black) cable.
Warning
1
2
Figure 6
1. Negative (–) 2. Positive (+)
Installing the Steering Wheel
1. Slide the steering wheel onto the steering shaft.
1
2
3
Figure 7
1. Steering wheel
2. Jam nut 3. Cap
2. Secure the steering wheel to the shaft with the jam nut
(Fig. 7) and tighten it to 20–26 ft.-lb.
3. Install the cap to the steering wheel with the screw
(Fig. 7).
Installing the Breather
Extension and Reservoir Cap
1. Remove the breather cap from the hydraulic reservoir
(Fig. 8).
1
24
3
Figure 8
1. Hydraulic reservoir
2. Breather cap 3. Breather extension 4. Reservoir cap
2. Thread the breather extension into the reservoir (Fig. 8).
3. Thread the breather cap into the breather extension
(Fig. 8).
4. Remove and discard the shipping cap from the
hydraulic reservoir. Install the cap secured to the
machine.
Mounting the Front Rollers
1. Mount an anti-scalp roller and a pull link assembly to
the outer end of each front carrier frame with a roller
shaft, spacer, washer, and screw (Fig. 9). Make sure the
nylon bushing is in the pull link.
1456
23
Figure 9
1. Pull link assembly
2. Pull link extension
3. Ball joint receiver
4. Nylon bushing
5. Spacer
6. Washer
2. Make sure all tires are inflated to 8–12 psi.

16
Adjusting Carrier Frame
Rollers
1. Position the traction unit on a level surface and lower
the cutting unit carrier frames to the floor.
2. Verify that there is 1/2 in. (13 mm) clearance between
the carrier frame rollers and the floor.
3. If an adjustment is required, loosen the jam nut on the
carrier frame stop screw (Fig. 10) and rotate the screw
up or down to raise or lower the carrier frame. Tighten
the jam nut after adjustment is attained.
1
2
Figure 10
Right Front Shown
1. Carrier frame roller 2. Carrier frame stop screw
Note: If you are operating the machine in hot climates,
where ambient temperatures range from 70F (20C) to
120F (49C), or using it for heavy-duty use (mowing
other than greens, such as fairways or verticutting), install
of a Hydraulic Oil Cooler Kit, Part No. 104–7701, to the
traction unit.
Installing the Cutting Units
For Cutting Unit Models 04610 and 04611
Note: When sharpening, setting the height-of-cut, or
performing other maintenance procedures on the cutting
units, store the cutting unit reel motors in the support tubes
on the front of the frame to prevent damage to the hoses.
Important Do not raise the suspension to the transport
position when the reel motors are in the holders in the
traction unit frame. Damage to the motors or hoses could
result.
Important Whenever the cutting unit has to be tipped
to expose bedknife/reel, prop up rear of cutting unit to
make sure nuts on back end of bedbar adjusting screws are
not resting on work surface (Fig. 11).
12
Figure 11
1. Prop (not provided) 2. Bedknife adjusting screw
nut (2)
1. Remove the cutting units from the cartons. Assemble
and adjust them per the Operator’s Manual for the
cutting units. Use the Height Gauge bar from the Loose
Parts Kit to adjust the height of cut.
2. Install the chain link (Fig. 12) to the top of the cutting
unit with the mounting bracket and (2) capscrews.
Torque the capscrews to 25–30 ft–lbs. (34–40 N⋅m).
The large end of the link is to hook onto the traction
unit suspension.
1
2
Figure 12
1. Chain link 2. Mounting bracket

17
Note: An optional Lift Hook, Toro Part No. 106–6938 may
be used in place of the chain link, if desired (Fig. 13). It
may be obtained from your local Toro Distributor.
1
Figure 13
1. Lift hook
A. All cutting units are shipped with the counter weight
mounted to the left end and the motor mount and
drive coupler mounted to the right end of the cutting
unit. To mount the cutting unit in the right front
position, proceed as follows:
B. Remove the 2 capscrews securing the counter
weight to the left end of the cutting unit. Remove
the counter weight (Fig. 14).
1
Figure 14
1. Counter weight
C. On right end of cutting unit, remove plastic plug
from bearing housing (Fig. 15).
D. Remove the 2 allen head screws securing the motor
mount to the right end of the cutting unit. Remove
the motor mount (Fig. 15).
1
2
3
Figure 15
1. Motor mount
2. Plastic plug 3. Allen head screw (2)
E. Remove the snap ring securing the drive coupler in
the reel tube (Fig. 16). Remove the drive coupler.
12
Figure 16
1. Snap ring 2. Drive coupler
F. Apply grease to the inside diameter of the drive
coupler. Install the drive coupler to the left end of
the cutting unit reel tube with a snap ring.
G. Install the motor mount to the left end of the cutting
unit with the (2) allen head screws previously
removed. Torque screws to 12–15 ft–lbs. (16–20
N⋅m).
H. Install the counter weight to the right end of the
cutting unit with the screws previously removed.
3. The cutting unit is shipped without a front roller. Obtain
a roller (Model No. 04625, 04626 or 04627) from your
local Toro Distributor. Install the roller using the loose
parts supplied with the cutting unit and installation
instructions included with the roller.

18
4. Thread a ball stud into each end of the cutting unit front
roller (Fig. 17).
1
Figure 17
1. Ball stud
5. Slide the cutting unit under the pull frame while
hooking the lift roller onto the lift arm. To facilitate
installation of the rear cutting unit, the pull frame can
be rotated and latched into a service position:
A. Lower the suspension system completely (cylinders
extended).
B. Lift the carrier frame by hand until the anti-scalp
rollers clear the brake linkage.
C. Lift up on the slotted link and rotate the pull frame
into the wire hook (Fig. 18).
1
2
Figure 18
1. Slotted link 2. Wire hook
D. With the cutting unit in position, release the wire
hook and rotate the pull frame to the operating
position.
E. The slotted link locks automatically.
F. Attach the motor and pull links.
Important Do not operate the lift system when the
center cutting unit is in the service position. Damage could
result to the pull frame and clevis assembly.
6. Slide the sleeve back on each ball joint receiver and
hook the receiver onto the cutting unit ball stud
(Fig. 19).
1
6.62 in. (168 mm)
3
2
Figure 19
1. Pull link extension
2. Pull arm 3. Ball joint receiver
Note: The pull link assemblies are preset at the factory. If
they ever need to be disassembled, reassemble them to the
dimensions shown in Figure 19.
7. Mount the basket onto the carrier frame.
8. Adjust the pull links until there is 1/4 to 3/8 in. (6 to
9 mm) clearance between the lip of the basket and the
reel blades. Make sure the basket lips are equidistant
from the reel blades all the way across the reel blades.
9. Assemble the mounting screws for the reel drive motor
to each cutting unit. Leave approximately 1/2 in.
(13 mm) of the threads exposed on each mounting
screw (Fig. 20).

19
1
2
Figure 20
1. Screws 2. Drive motor
10.Remove the protective covers from the cutting units and
the reel drive motor shafts.
Note: Retain the protective covers for the cutting units.
Install them whenever the reel drive motors are removed to
protect the cutting unit bearings from contamination.
11. Coat the spline shaft of the motor with clean grease and
install the motor by rotating the motor clockwise so the
motor flanges clear the studs. Rotate the motor
counterclockwise until the flanges are encircling the
studs and tighten the mounting capscrews (Fig. 20).
12.Using a hand pump grease gun, fill the cavity at the end
of the cutting unit with #2 general purpose grease.
Adjusting the Transport Height
Check the transport height (Fig. 21) and adjust, if required,
as follows:
1. Position the tractor on a level surface.
2. Verify that the distance from the top of the carrier frame
adjusting screw (Fig. 21) and the back of the carrier
frame is 7/8 in. (22 mm).
3. Loosen the transport plate mounting screws (Fig. 21).
4. Raise the cutting units to the transport position.
Important Do not raise the suspension to the transport
position when the reel motors are in the holders in the
traction unit frame. Damage to the motors or hoses could
result.
5. Ensure each carrier frame is at the same height from the
ground. If they are, proceed to step 7.
6. If the carrier frames are not at the same height, loosen
the jam nut on the carrier frame adjusting screw
(Fig. 21). Rotate the screw outward to raise and inward
to lower. Tighten the jam nut after the proper height is
obtained.
7. Rotate the transport plate until it locks the pull frame.
Tighten the screws.
Right Front Shown
7/8 in.
(22 mm)
1
2
3
Figure 21
1. Transport plate
2. Adjusting screw 3. Transport plate mounting
screw

20
Before Operating
Checking the Engine Oil
The engine uses any high-quality detergent oil having the
American Petroleum Institute (API) service classification
of CD, CE, CF or CF-4 or CG-4 or higher. The
recommended viscosity (weight) is SAE 10W30.
The engine is shipped with 3.5 quarts (w/ filter) (3.3 l) of
oil in the crankcase; however, the level of oil must be
checked before and after the engine is first started.
1. Position the machine on a level surface.
2. Remove the dipstick and wipe it with a clean rag
(Fig. 23). Push the dipstick into the tube and make sure
it is seated fully. Remove the dipstick from the tube and
check the level of oil. If the oil level is low, remove the
filler cap from the valve cover and slowly add enough
oil to raise the level to the Full mark on the dipstick.
Add the oil slowly and check the level often during this
process. Do not overfill.
Important Make sure that the dipstick is removed
while filling the engine with oil.When adding engine oil or
filling oil, there must be clearance between the oil fill
device and the oil fill hole in the valve cover as shown in
figure 22. This clearance is necessary to permit venting
when filling, which prevents oil from overrunning into
breather.
Figure 22
1
2
Figure 23
1. Dipstick 2. Filler cap
3. Replace the dipstick.
4. Start and run the engine at idle for 30 seconds, then shut
the engine off. Wait 30 seconds, then repeat steps 2–3.
Important Check the level of oil every 8 operating
hours or daily. Change the oil and filter initially after the
first 50 hours of operation, thereafter change the oil every
50 hours and the filter every 100 hours. However, change
the oil more frequently when the engine is operated in
extremely dusty or dirty conditions.
5. Install the filler cap and dipstick firmly in place.
Filling the Fuel Tank
The engine runs on No. 2 diesel fuel.
The fuel tank capacity is approximately 6 gallons (22.7 l).
1. Clean the area around the fuel tank cap (Fig. 24).
1
Figure 24
1. Fuel tank cap
