FormNo.3417-978RevA
ZMaster®Professional7500-DSeriesRidingMower
With96inTURBOFORCE®RearDischargeMower
ModelNo.74096—SerialNo.400000000andUp
SetupInstructions
Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Addfueltothemachine.
2Nopartsrequired–Checktheengine-oillevel.
3Nopartsrequired–Checkthetirepressure.
4Nopartsrequired–Checkthehydraulic-uidlevel.
5Nopartsrequired–Checkthedeckgearbox-uidlevel.
6Nopartsrequired–Checkthewheellugnuttorque.
J-bolt2
Wingnut2
7Hold-downclamp1
Installthebattery.
8Nopartsrequired–Raisetherolloverprotectionsystem
(ROPS).
9Nopartsrequired–Checkthemachinebeforedeliveryto
thecustomer(Allmachines).
Operator'sManual1
Engineowner'smanual1
Registrationcard1
Operatortrainingmaterial1
10
Key2
Deliveringthemachinetothecustomer.
©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3417-978*A

1
AddingFueltotheMachine
NoPartsRequired
Procedure
Addfueltothemachinebeforestartingit.Refer
toyourOperator’sManualforthecorrectfueland
procedure.
2
CheckingtheEngine-Oil
Level
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,
checktheoillevelintheenginecrankcase;referto
theOperator'sManual.
3
CheckingtheTirePressure
NoPartsRequired
Procedure
Frontandreartiresairpressurespecication:124
kPa(18psi).
Note:Checkthetirepressurebeforestartingthe
machine.RefertoyourOperator’sManualforthe
correcttiretype,correctairpressureneeded,and
procedure.
4
Checkingthe
Hydraulic-FluidLevel
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake.
2.Movethemotion-controlleverstothe
NEUTRAL-LOCKpositionandstarttheengine.
Note:Runtheengineatthelowestpossible
rpmtopurgeanyairinthesystem.
Important:DonotengagethePTO.
3.Raisethedecktoextendtheliftcylinders,shut
offtheengine,andremovethekey.
4.Raisetheseattoaccessthehydraulic-uidtank.
5.Removethehydraulic-tankcap(Figure1).
g227849
Figure1
1.Hydraulic-tankcap3.Fillerneck
2.Dipstick
6.Removethedipstickandwipeitwithacleanrag
(Figure1).
7.Placethedipstickintothellerneck,removeit,
andchecktheuidlevel(Figure2).
Note:Ifthelevelisnotwithinthenotchedarea
ofthedipstick,addenoughhigh-qualityhydraulic
uidtoraisetheleveltowithinthenotchedarea.
Important:Donotoverll.
2

g228816
Figure2
1.Fullline2.Addline
8.Replacethedipstickandthreadthellcap
nger-tightontothellerneck.
9.Checkallhosesandttingsforleaks.
5
CheckingtheDeck
Gearbox-FluidLevel
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Lowerthemowerdecktothe2.5cm(1inch)
heightofcut.
3.Disengagetheblade-controlswitch,movethe
motion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
4.Shutofftheengineandremovethekey.
5.Raisethedeck-liftpedaltoexposethetopofthe
mowerdeck.
6.Removethedipstick/llplugfromthetopofthe
gearboxandensurethatthelubricantisbetween
themarksonthedipstick(Figure3).
g231764
Figure3
1.Dipstick/llplug
7.Iftheuidlevelislow,adduiduntilthelevelis
betweenthemarksonthedipstick.
Important:Donotoverllthegearbox;
overllingthegearboxmaydamageit.
6
CheckingtheWheelLug
NutTorque
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,
checkthewheellugnuttorque;refertoCheckingthe
WheelLugNutsintheOperator'sManual
3

7
InstallingtheBattery
Partsneededforthisprocedure:
2J-bolt
2Wingnut
1Hold-downclamp
Procedure
Important:Thisprocedureonlyappliesto
machinesthatdonotcomewithabattery
installed.
Purchasea12Vbatteryandinstallitintothemachine.
Theenginerequiresaminimumof540A(cold
cranking).
Usethehardwareincludedtoinstallthenewbattery.
RefertoInstallingtheBatteryintheOperator's
Manual.
8
RaisingtheRollover
ProtectionSystem(ROPS)
NoPartsRequired
Procedure
1.Pulltheknobandrotate90°totheunlatched
position(Figure4).
2.Raisetherollbartotheoperateposition,and
rotatetheknobssothattheymovepartiallyinto
thegrooves(Figure4).
3.Raisetherollbartothefulluprightpositionwhile
pushingontheupperrollbarandthepinssnap
intopositionwhentheholesalignwiththepins
(Figure4).
Important:Alwaysusetheseatbeltwiththe
rollbarintheraisedposition.
g243267
Figure4
1.Upperpartoftherollbar4.Rotatetheknobout90°
toholditintheunlatched
position.
2.Knobinthelatched
position
5.Knobintheunlatched
position
3.Pulltheknobtounlatch.
4.Pushontherollbarandensurethatbothpins
areengaged(Figure5).
4

g008619
Figure5
1.Engagedposition2.Partiallyengaged—do
notoperatethemachine
withtherollbackinthis
position.
5

9
CheckingtheMachineBeforeDeliverytotheCustomer
(AllMachines)
NoPartsRequired
Procedure
Beforedeliveringthemachinetothecustomer,ensurethatyouperformorhaveperformedtheprocedures
listedinthefollowingtableandinitialeachwhennished.RefertotheOperator'sManualforinstructionson
performingtheseprocedures.
InitialCheckProcedure
Checkthetirepressure.
Checkthelevelofthemachine.
Checkthatallspindlesaregreased.
Checktheengine-oillevel.
Checkthehydraulic-uidlevel.
CheckROPSissecure.
Onliquidcooledmachines,checkthelevelofthecoolantintheradiatorandoverowbottle.
Checktheadjustmentoftheparkingbrake.
Ensurethatthemachinetrackscorrectly;refertotheOperator'sManualfortheadjustmentprocedure.
Checkthesafetyinterlocksystem;refertotheOperator'sManual.
EnsurethatthePTOworks.
Checkallfastenersthatyouinstalledtoensurethattheyaretight.
Whenyounishsettingupthemachine,signanddateinthespaceprovidedbelow:
Signature:Date:
6

10
DeliveringtheMachinetotheCustomer
Partsneededforthisprocedure:
1Operator'sManual
1Engineowner'smanual
1Registrationcard
1Operatortrainingmaterial
2Key
Procedure
Atdelivery,llinthemodelandserialnumber,completetheitemslistedinthefollowingtable,andinitial
eachwhennished.
ModelNo.SerialNo.
7

DealerInitialCustomerInitialCheckProcedure
Showthecustomerwherethefollowingfeaturesarelocatedandhowtheyfunction:
•Fueltank
•Oilllcap/Oildipstick
•Engine-oillter
•Engine-oildrain
•Fuelgauge,valveandhose
•Airlter
•Radiatorcoolant(ifapplicable)
•Hydraulic-uidreservoir
•Hydrauliclter
•Battery
•Keyswitch
•Throttlelever
•Choke(ifapplicable)
•Powertakeoffswitch(PTO)
•Motion-controllevers
•Parkingbrake
•Heightofcut
•Lift-assistlever(ifapplicable)
•Adjustableseat
•Hydraulic-bypassvalves
•RolloverProtectionSystem(ROPS)
•Deck-owbafe
RefertotheOperator'sManualtopointoutsafetyprocedures,operation,and
maintenanceprocedures.
ReviewthewarrantystatementasshownintheOperator'sManual.
Describethepostsaleserviceproceduresforyourstore.
Assistthecustomerinllingoutandmailingtheregistrationcardorregisteronlineat
www.Toro.com
EnsurethatthecustomerreceivestheOperator'sManual,engineowner’smanual,
SetupInstructions,andoperatortrainingmaterial.
EnsurethatthecustomerknowsthePartsCatalogisavailableatwww.T oro.com.
Assistthecustomerinloadingthemachineusingafull-widthtrailerramp.
Note:Whenyou,thedealerrepresentative,havenisheddeliveringthemachinetothecustomer,signand
dateinthespaceprovidebelowandkeepacopyofthispagefordealerrecords.Also,thedealermustremind
thecustomertouseafull-widthtrailerramptoloadthemachine.
Signature:Date:
Signature:Date:
