Toro Customer Bulletin
Greensmaster 1000 Series
GR #01-04 EN (3439-976 Rev A)
Maximum Fuel Tank Level
Page 1of 2
May 28, 2020
Customer Bulletin
Commercial Products May 28, 2020
Maximum Fuel Tank Level
Greensmaster 1000 Series
Bulletin Type
Status
Affected Units
Information Only
Final Release
Situation Important Information
Exceeding the maximum fuel level in the fuel tank could cause the following
to occur:
• Failure of the evaporative-emission-control (EEC) system (i.e., the
charcoal canister in the tank cap)
• Fuel leaking from the cap vent when the machine is tipped
Corrective Action When filling the fuel tank, do not add fuel beyond the full-tank level; referto
Service Instructions (Page 2).
Safety Awareness Follow reasonable and customary safety precautions.
References Download the latest versions of the Operator's Manual, Parts Catalog,
Service Manual, Electrical Schematic, and Hydraulic Schematic by visiting
www.Toro.com and searching for your machine from the Manuals link on
the home page.
Resource
Search Term
Operator’s Manual Model and serial number for the
machine.
Model
Number(s)
Serial Number(s)
04820
400000000 through 999999999
04830
04840
04850
04860
Greens Reels #01-04

Toro Customer Bulletin
Greensmaster 1000 Series
GR #01-04 EN (3439-976 Rev A)
Maximum Fuel Tank Level
Page 2of 2
May 28, 2020
Service Instructions
Preparing the Machine 1. Park the machine on a level surface.
2. Engage the parking brake.
3. Shut off the engine.
Filling the Fuel Tank 1. Clean around the fuel-tank cap and remove the cap from the tank.
2. Add the recommended fuel to the full level (i.e., to the bottom of the
fuel gauge) in the fuel tank.
Important: Do not fill the tank above this level.
Figure 2
1. Fuel gauge 2. Full-tank level
3. Install the fuel-tank cap and wipe up any spilled fuel.
Filling the Fuel Tank Animation
