FormNo.3388-705RevA
e-Cycler20-inchCordlessLawnMower
ModelNo.20360—SerialNo.315000001andUp
Operator'sManual
IMPORTANTSAFETY
INSTRUCTIONS
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Whenusinganelectricalappliance,basicprecautionsshould
alwaysbefollowed,includingthefollowing:
WARNING
READALLINSTRUCTIONS
BEFOREUSINGTHISAPPLIANCE
SAVETHESEINSTRUCTIONS
Toreducetheriskofre,electricshock,orinjury,followthese
safetyinstructions.
ThismachinemeetsorexceedsCPSCbladesafetyrequirements
forwalk-behindrotarymowersandtheB71.1specications
oftheAmericanNationalStandardsInstitute,ineffectattime
ofproduction.However,improperuseormaintenancebythe
operatororownercanresultininjury.T oreducethepotential
forinjury,complywiththesesafetyinstructionsandalwayspay
attentiontothesafetyalertsymbol,whichmeansCAUTION,
WARNINGorDANGER—“personalsafetyinstruction.”Failure
tocomplywiththeinstructionmayresultinpersonalinjury.
WARNING:Toreducetheriskofre,electricshock,andpersonal
injurywhenusingelectriclawnmowers,alwaysfollowthesebasic
safetyprecautions.
SAVETHESEINSTRUCTIONS
SafeOperatingPractices
Thismachineiscapableofamputatinghandsandfeetandof
throwingobjects.Alwaysfollowallsafetyinstructionstoavoid
seriousinjuryordeath.
Thismachineisdesignedforcuttingandmulchinggrassor,when
equippedwithagrassbag,forcatchingcutgrass.Anyusefor
purposesotherthanthesecouldprovedangeroustoyouorto
bystanders.
GeneralOperation
•Readthismanualcarefullybeforeoperatingthemachine.
Becomefamiliarwiththecontrolsandproperuseofthe
machine.Neverallowchildrenunder16yearsofageto
operatethemachine.Neverallowadultstooperatemachine
withoutproperinstructions.
•Theoperatorofthemachineisresponsibleforkeeping
everyone,especiallychildrenandpets,awayfromarea
ofoperation.Theoperatorisresponsibleforaccidentsor
hazardsoccurringtootherpeopleortheirproperty.
•Thoroughlyinspectareawherethemachinewillbeused,
andremovesticks,stones,wire,anddebristhatcouldbe
pickedupandthrownbymachine.Watchforforeignobjects
whilemowing.Objectsstruckbythebladecancausesevere
injuriestopeople.
•Wearlongpantsandsubstantialshoes.Donotoperate
themachinewhilewearingopen-toedshoes,jewelry,loose
clothingorwhenbarefoot.Userubberglovesandfootwear
whenworkingoutdoors.
•Keepallguards,shields,safetydevices,grasscatcheror
optionalsidedischargechuteinplace.Repairorreplace
damagedparts,includingdecals.Nevertamperwithsafety
devices.Checktheirproperoperationregularly.
•Themotorandbladearedesignedtostopwithin3seconds
afterreleasingthecontrolbail.Ensurethatthecontrolbail
functionsproperlybeforeeachuseofmachine.Iftheblade
doesnotstopwithin3seconds,orifthereisagrindingor
scrapingmetal-to-metalnoisewhenyoureleasethecontrol
bail,contactanAuthorizedT oroServiceDealerforproper
On/Offandblade-brakeadjustmentorreplacement.
•Beforeusing,alwaysvisuallyinspecttoseethattheblades,
bladefasteners,andcutterassemblyarenotwornor
damaged.Replacewornordamagedbladesandfasteners
insetstopreservebalance.
•Useonlythoseaccessoriesandattachmentsdesigned
forthismachine.Usinganyaccessoryorattachmentnot
designedforthisproductmayincreasetheriskofinjury.See
theinstructionsfortheproperoperationandinstallationof
accessories.
SafeOperatingPractices
•Donotinsertthekeyintotheplugreceptacleuntilyouare
readytomow.
•Donotoperatethemachineingaseous,explosive
atmospheres.Normalsparkingofthemotorcouldignite
fumes.
•Startthemotorcarefullyaccordingtoinstructions,withfeet
wellawayfromtheblade.
•Usetherightappliance—Donotusethemachineforanyjob
exceptthatforwhichitisintended.
•Stayalert—Watchwhatyouaredoing.Donotoperatethe
machinewhenyouaretiredorundertheinuenceofdrugs,
alcohol,ormedication.
•Bealertandturnthemachineoffifchildrenenterthearea.
©2014—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3388-705*A

•Useextracarewhenapproachingblindcorners,shrubs,
trees,orotherobjectsthatmayobscurevision.
•Donotmowneardrop-offs,ditches,orembankments.You
couldloseyourfootingorbalance.
•Avoiddangerousenvironments.Neveroperatethemachine
inwetgrassordamplocations.Donotusethemachinein
therain.
•Alwaysmaintainsecurefooting.Keeparmgriponthe
handleandwalk;neverrun.Mowonlyindaylightoringood
articiallight.
•Mowacrossthefaceofslopes;neverupanddown.Use
extremecautionwhenchangingdirectiononslopes.Donot
mowexcessivelysteepslopes.Wearskid-resistantshoes
onslopes.
•Don’toverreach–Keepproperfootingandbalanceatall
times.
•Donotforcethemachine.Itoperatesbestandsafestatthe
rateforwhichitwasdesigned.
•Alwayswearsafetyglassesoreyeshieldsduringoperationto
protecteyesfromforeignobjectsthatmaybethrownfromthe
machine.Regulareyeglassesarenotsafetyglasses.
•Alwayswearanapproveddustmaskwhenusingthemachine
industyconditions.
•Keepyourface,hands,andfeetawayfromthemachine
housingandthebladewhilethemotorisrunning.Theblade
caninjurehandsandfeet.Staybehindthehandleuntilthe
motorstops.
•Neverdirectdischargedmaterialtowardanyone.Avoid
dischargingmaterialagainstawallorobstruction.Material
mayricochetbacktowardyou.Stopthebladewhencrossing
gravelsurfaces.
•Useextremecautionwhenreversingorpullingthemachine
towardyou.Beforeandwhilemovingbackward,lookbehind
anddown.
•Sincethebladerotatesforafewsecondsafteryoureleasethe
controlbar,staybehindthehandleuntilallmovingpartsstop.
•Afterstrikingaforeignobjectorifthemachinevibrates
abnormally,stopthemotorandremovethekeyfromtheplug
receptacle.Checkthemachinefordamageandmakeall
repairsbeforeusingthemachineagain.Ifmajorrepairsare
everneededorifassistanceisdesired,contactanAuthorized
ToroServiceDealer.
•Donotoperatethemachineifithasbeendroppedor
damagedinanyway.Repairanydamagebeforeoperating
themachine.
•Stopthemotor,waitforallmovingpartstostop,andremove
thekeyfromtheplugreceptaclebeforeadjustingthe
height-of-cut.
•Stopthemotorwhenpushingthemachineoutsidethelawn
area.
•Stopthemotorandremovethekeyfromtheplugreceptacle
beforeremovingthegrasscatcher.
•Stopmotorbeforeleavingtheoperator’sposition—behind
thehandle.Removethekeyfromtheplugreceptacleifthe
machinewillbeunattended.
•Ifyoumustliftortransportthemachine,stopthemotor,stay
behindthehandleuntilallmovingpartsstopandremovethe
keyfromtheplugreceptacle.
MaintenanceandStorage
•Performonlythosemaintenanceinstructionsdescribedinthis
manual.Ifmajorrepairsareeverneededorifassistanceis
desired,contactanAuthorizedT oroServiceDealer.
•Beforeyouclean,inspect,service,oradjustthemachine,
stopthemotorandwaitforallmovingpartstostop.Remove
thekeyfromtheplugreceptacle.
•Donotchargethemachineinrainorinwetlocations.
•Topreventelectricshockwhilecharging,repairorreplaceany
damagedelectricalcordsimmediately.
Note:Thebatterychargerisneededonlytorechargethe
battery.Itisnotusedformowingwiththemachine.
•Don’tabusethecordwhilecharging.Donotyankthecordto
removeitfromplugreceptacle.Keepthecordawayfrom
heat,oilandsharpedges.
•Removekeybeforeservicing,cleaning,orremovingmaterial
fromthemachine.
•Donotdisposeofthebatteryinare;thecellmayexplode.
Checkwithlocalcodesforspecialdisposalinstructions.
•Donotopenormutilatethebattery.Releasedelectrolyteis
corrosiveandmaycausedamagetotheeyesorskin.Itmay
betoxicifswallowed.
•Exercisecareinhandlingbatteriesinordernottoshortthe
battery(contactbothpositiveandnegativebatteryposts)with
conductingmaterialssuchasrings,bracelets,andkeys.The
batteryorconductormayoverheatandcauseburns.
•Toensurethatthemachineisinsafeoperatingcondition,
frequentlycheckandkeepallnuts,bolts,andscrewstight.
Ensurethatthebladeboltistightenedto40to50ft-lb(54to
68N-m).
•Alwayskeepasharpbladeonyourmachine.Whenservicing
theblade,refertotheblademaintenancesectionfor
correctinstallationandservicingprocedures.Useidentical
replacementbladesonly.
•Toreducerehazard,keepthemotorfreeofexcessivegrass,
leaves,andaccumulationsofdirt.
•Checkthegrasscatcherbagfrequentlyforwearor
deterioration.Replaceawornordamagedbagwithan
identicalT ororeplacementbagonlyforyourprotection.
•Whenyouarenotusingthemachine,removethekeyand
storethemachineindoorsinadry,locked-upplaceoutof
thereachofchildren.Allowthemotortocoolbeforestoring
themachineinanenclosure.
•Atthetimeofmanufacture,thismachineconformedtothe
safetystandardsineffectforrotarymowers.Toassure
bestperformanceandcontinuedsafetycerticationof
themachine,usegenuineTororeplacementpartsand
accessories.Replacementpartsandaccessoriesmadeby
othermanufacturersmayresultinnon-conformancewiththe
safetystandards,andthatcouldbedangerous.
SAVETHESE
INSTRUCTIONS
2

SafetyandInstructionalDecals
Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamagedorlostdecals.
Manufacturer'sMark
1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.
119-3760
1.Movethecontrollever
awayfromthestarter.
2.Holdthecontrolleverto
thehandletoengagethe
blades.
119-3761
1.Keyin–engineenergized2.Keyout—nopower,locked
119-3812
3

119-3818
119-7023
Setup
1
UnfoldingtheHandle
NoPartsRequired
Procedure
CAUTION
Foldingorunfoldingthehandleimproperlycandamage
thecables,causinganunsafeoperatingcondition.
•Donotdamagethecableswhenfoldingorunfolding
thehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Loosenthehandleknobs(Figure1).
4

Figure1
1.Handleknob(2)
2.Movethehandletotheoperatingposition(Figure2).
Figure2
3.Tightenthehandleknobsrmlybyhand.
2
ChargingtheBattery
NoPartsRequired
Procedure
WARNING
Contactwithwaterwhilechargingthebatteryor
operatingthemachinecancauseanelectricshock,
leadingtopersonalinjuryordeath.
Donothandlethechargerplugorthemachinewithwet
handsorwhilestandinginwater.
Important:Forbestperformance,useonlyaToro
36-voltcharger(PartNo.119-0269or120-1909).
Ittakesapproximately12to16hourstochargeafullydischarged
battery.Fullychargethebatterybeforetherstmowingofthe
season,aftereveryuse,andbeforeoff-seasonstorage.Failingto
chargethebatteryaftereveryuseshortensthebatterylife.Charge
thebatteryevenifyourunthemachineforonlyafewminutes.
Note:Thebatteryischargedatthefactory.However,before
usingthemachineforthersttime,chargethebatteryand
ensurethatithasafullchargebeforeoperating.
Tochargethebattery,dothefollowing:
Important:Alwayschargethebatteryinadryarea
protectedfromtheweather.Also,keepthemachine
awayfromwaterandammablesubstances.
1.Ifthekeyisintheplugreceptacle,removeit(Figure3).
Figure3
1.Key(removeitbeforechargingthebattery)
5

WARNING
Thebatterychargercordcanbedamagedand
couldcauseashockorre.
Thoroughlyinspectthebatterychargercord
beforechargingtheunit.Ifthecordisdamaged,
donotchargethebattery.Replaceorrepaira
damagedcordimmediately.ContactanAuthorized
ServiceDealerforassistance.
2.Insertthechargercordintothechargingplugreceptacle
(Figure4),andconnecttheotherendtoastandard120-volt
householdoutlet.
Figure4
1.Chargingplugreceptacle
Note:Yourbatterychargerhasa2-colorLEDdisplay
thatindicatesthefollowingstatesofcharging:
•Aredlightindicatesthatthechargerischargingthe
battery.
•Agreenlightindicatesthatthebatteryisfullycharged;
thechargeristrickle-chargingthebatterytomaintain
thebatterycharge.
3.Chargethebatteryforatleast16hours.
4.Unplugthechargercordfromthestandardoutletandthe
chargingplugreceptacleonthemachine.
Note:Donotunplugthechargercordbypullingonit.
Tounplugthecord,grasptheplug,notthecord.
Important:Thismachinehasabatterycharger
thatchecksthechargestateofthebatteryand
chargesthebatteryonlywhennecessary.Unplug
thechargerafter24hoursofcharging,thoughyou
mayleavethechargerpluggedintothemachine
longerwithoutharmingthesystem.Duringthe
non-mowingseason,youcanunplugandstorethe
machineforupto3monthsifthebatteryisfully
chargedandthemachineisstoredinacool,dry
place.
3
AssemblingtheGrassBag
NoPartsRequired
Procedure
1.SlipthegrassbagovertheframeasshowninFigure5.
g027257
1
23
Figure5
1.Handle3.Grassbag
2.Frame
Note:Donotslipthebagoverthehandle(Figure5).
2.Hookthebottomchannelofthebagontothebottomofthe
frame(Figure6).
6

g027258
Figure6
3.Hookthetopandsidechannelsofthebagontothetopand
sidesoftheframe,respectively(Figure6).
Operation
Eachtimebeforeyouusethemachine,ensurethatthecontrolbar
operatesproperly.Whenyoureleasethecontrolbar,themotor
andthebladeshouldstop.Iftheydonot,contactanAuthorized
ServiceDealer.
UsingtheKey
Thismachineoperatesonlywhenthekeyisfullyseatedinthe
plugreceptacle(Figure5).T opreventaccidentalstartingor
unauthorizeduseofthemachine,alwaysremovethekeyfromthe
plugreceptaclewheneveryouleavethemachineunattended.
Storethekeyoutofthereachofchildren.
Figure7
1.Key
StartingtheMachine
1.Pushthemachineontoaatconcreteorasphaltsurface.
Note:Startingthemachineinthickgrasscouldcause
themachinetoclog.
2.Insertthekeyfullyintotheplugreceptacle(Figure7).
3.Insertacoupleofngersintotheopeningofthestarterand
pushthecontrollevertowardthehandle(Figure6).
Figure8
1.Controllever
4.Squeezethecontrollevertothehandle(Figure9).
7

Figure9
Note:Keepthemachinerunningwhenturningthe
machine.Turningthemachineoffwhenmakingaturn
doesnotsavebatteryenergy.
StoppingtheMachine
1.Releasethecontrollever.
WARNING
Whenthekeyisintheplugreceptacle,themachine
isoperational.Someonecouldaccidentallystart
themachineandseriouslyinjureyouorother
bystanders.
Alwaysremovethekeyfromtheplugreceptacle
whenleavingthemachineunattended,evenfor
ashortperiodoftime.
2.Removethekeyfromtheplugreceptacleifthemachinewill
beunattendedforanyperiodoftime.
Note:Storethekeyinaplaceoutofthereachof
children.
3.Chargethebattery.
Important:Alwayschargethebatteryimmediately
afterusingthemachine.Ifyoudonotchargethe
batteryaftereachuse,youwillshortenthebattery
life.See2ChargingtheBattery(page5).
AdjustingtheCuttingHeight
WARNING
Adjustingthecuttingheightmaybringyouintocontact
withthemovingblade,causingseriousinjury.
•Stoptheengineandwaitforallmovingpartsto
stop.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
Adjustthecuttingheightasdesired.Setall4wheelstothesame
height(Figure10).
Note:Movethecutting-heightleversforwardtoraisethe
machine;movethecutting-heightleversrearwardtolower
themachine.
Figure10
1.Frontcutting-heightlever
(2)
2.Rearcutting-heightlever
(2)
Note:Thecutting-heightsettingsare25mm(1inch);38mm
(1-1/2inches);51mm(2inches);64mm(2-1/2inches);76
mm(3inches);89mm(3-1/2inches);and102mm(4inches).
8

BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
WARNING
Aworngrassbagcouldallowsmallstonesandother
similardebristobethrowntowardyouorbystanders,
resultinginseriouspersonalinjuryordeath.
Checkthegrassbagfrequently.Ifitisdamaged,install
anewTororeplacementbag.
InstallingtheGrassBag
1.Liftupthereardeector(Figure11).
Figure11
1.Reardeector
2.Insetthegrassbaghandleontothenotchesonthehandle
brackets(Figure12).
Figure12
RemovingtheGrassBag
1.Liftupthereardeector.
2.Liftthegrassbaghandleoutfromthenotchesonthehandle
bracketsandremovethebagfromthemachine.
3.Closethereardeector.
ResettingtheCircuitBreaker
Ifthemachineisrunundertoomuchload,thecircuitbreakerwill
trip.Followtheseinstructionstoresetthecircuitbreaker.
Important:Neverresetthecircuitbreakerwhenthekey
isinthereceptacleandthecontrolleverissqueezedto
thehandle.
1.Removethekeyfromtheplugreceptacle(Figure3).
2.Wait30seconds,thenpushinthecircuitbreakerbutton
(Figure11).
Figure13
1.Key(removebefore
resettingthecircuit
breaker)
2.Circuitbreaker
3.Installthekeyintheplugreceptacle.
4.Resumecuttingunderalighterload.
Note:Ifthecircuitbreakerrepeatedlytrips,raise
thecuttingheightorusethegrassbagoroptional
side-dischargechute.
OperatingTips
BatteryRunTime
Withabattery-poweredmower,theconditionofthegrassandthe
waythatyoumowwillaffecthowlongthebatterywillrunona
singlechargeateachmowing.
Thefollowingaresomethingsthatwillaffectbatteryruntime:
•Moisturecontentofthegrass—Themoremoisturethereisin
thegrass,thefasterthebatterywillrundown.
•Walking/mowingspeed—Thefasteryouwalk,thefasterthe
batterywillrundown.
•Modeofoperation—Mulchingthegrassrequiresthemost
batteryenergy.Baggingrequiresthesecondhighestamount
ofbatteryenergy,andsidedischargingusestheleast.
•Cuttingheight—Ifthebatteryisrunningdowntoofast,raise
thecuttingheightanotch.
GeneralMulchingTips
Torodesignedyourmachinetomulchgrasswhenthemulch
dooriscompletelyclosed.Forthebestcuttingresultsandlawn
9

appearance,followtheseinstructionswhethercuttinggrassor
leaves:
•Maintainasharpbladethroughoutthecuttingseason.
Periodicallyledownanynicksontheblade.
•Onlymowdrygrassorleaves.Wetgrassandleavestendto
clumpontheyardandmaycausethemachinetoplugupor
themotortostall.
WARNING
Wetgrassorleavescancauseyoutoslipand
contracttheblade,causingaseriouspersonal
injury.
Mowonlyindryconditions.
•Removethekeyfromthereceptacleandcleantheclippings
orleavesfromtheundersideofthemachineaftereach
mowing.Useawoodentool,notametalone.
•Grassgrowsatdifferentratesatdifferenttimesoftheyear.
Intheheatofsummer,itisgenerallybesttocutgrassatthe
64mm(2-1/2inch),76mm(3-inch),or89mm(3-1/2inch)
cutting-heightsettings.Cutonlyaboutathirdofthegrass
blade.Donotcutbelowthe64mm(2-1/2inch)settingunless
thegrassissparse,oritislatefallwhengrassgrowthbegins
toslowdown.
•Whenchangingthecuttingheightfromanestablishedsetting
toahighercuttingheight,thegrassmayappearraggedor
unevenuntilthegrassadjuststothenewestablishedcutting
heightandregainsitsnormalappearance.
•Whencuttinggrassover15cm(6inches)tall,youmaywant
torstmowusingthegrassbagortheoptionalsidedischarge
chute,ortrythehighestcutting-heightsettingandaslower
walkingspeed;thenmowagainatalowersettingforthebest
lawnappearance.Ifthegrassistoolong,leavingclumpson
topofthelawn,themachinemayplugandcausethemotor
tostall.
•Alternatethemowingdirection.thishelpstodispersethe
clippingsoverthelawnforevenfertilization.
Ifthenishedcutlawnappearanceisunsatisfactory,try1ormore
ofthefollowing:
•Sharpentheblade.
•Walkataslowerpacewhilemowing.
•Raisethecuttingheightonyourmachine.
•Cutthegrassmorefrequently.
•Overlapcuttingswathsinsteadofcuttingafullswathwith
eachpass.
•Setthecuttingheightonthefrontwheelsanotchlowerthan
thatoftherearwheels.Forexample,setthefrontwheels
atthe76mm(2-1/2inch)settingandtherearwheelsatthe
64mm(3-inch)setting.
CuttingLeaves
•Whencuttingiscomplete,alwaysbesurethathalfofthelawn
showsthroughthecutleafcover.Thismayrequiremorethan
asinglepassovertheleaves.
•Forlightleafcoverage,positionallthewheelsatthesame
cutting-heightsetting.
•Walkataslowermowingspeediftheleavesarenotcutup
nelyenoughtobehiddendowninthegrass.
Maintenance
WARNING
Whenthekeyisintheplugreceptacle,themachine
isoperational.Someonecouldaccidentallystart
themachine,causingseriousinjurytoyouorto
bystanders.
Removethekeyfromtheplugreceptaclewhenyou
leavethemachineunattended,evenforashortperiod
oftime.
CleaningtheMachine
Beforecleaningthemachine,stopthemotor,waitforallmoving
partstostop,andremovethekeyfromtheplugreceptacle.
Important:Donotsprayorpourwateronthemachine
whencleaning.Moisturecangettrappedinthemachine
andcausecorrosionofinternalparts.
CleaningtheMachineafterEachUse
•Cleanunderthemachine.Beparticularlycarefultokeepthe
frontcavityclearofallgrassclippingsanddebris.Remove
dirtandgrassclippingswithahardwoodscraper.Avoidburrs
andsharpedges.
•Brushallgrassclippingsanddebrisoffthetopofthemachine
housingaftereveryuse.
CleaningtheMachineafterEach
Season
•Removethetopshroudandcleanoutanygrassclippings
anddebrisfromunderneathitandaroundthebatterywith
compressedair,avacuumcleaner,orabrush.
Important:Donotusemetalobjectstocleanaround
thebattery.Ifmetalobjectscontactthepositive
andnegativepostsatthesametime,thismayshort
outthebattery.Thebatteryortheconductormay
overheatandcauseburns.
•Checkforanydiscoloredorcharredwiresandbatteryand
switchcontacts.Ifanyaredamaged,contactanAuthorized
ServiceDealerforrepair.
MaintainingtheBlade
Alwaysmowwithasharpblade.Asharpbladecutscleanlyand
withouttearingorshreddingthegrassbladeslikeadullblade
does.
WARNING
Ifthekeyispluggedintotheplugreceptacle,someone
couldaccidentallystartthemachine,causingserious
personalinjury.
Donotattempttoinspect,remove,orreplacetheblade
withoutrstremovingthekeyfromtheplugreceptacle.
10

WARNING
Thebladeissharp;contactingthebladecancause
seriouspersonalinjury.
Alwayswearglovesorwrapthesharpedgesofthe
bladewitharag.
1.Stopthemotorandwaitforallmovingpartstostop.
2.Removethekeyfromtheplugreceptacle.
3.Tipthemachineontoitsside.
4.Removethebladebyturningthebladeboltcounterclockwise
(Figure14).
Note:Grasptheendofthebladeusingaragora
thicklypaddedglove.
Figure14
1.Blade2.Bladeboltandwasher
5.Removethebladebolt,thewasher,andtheblade.
6.Installasharp,balancedblade,withthewasherandthe
bladeboltthatyoupreviouslyremoved.
7.Tightenthebladeboltto40to50ft-lb(54to68N-m).
8.Returnthemachinetotheoperatingposition.
ReplacingtheBatteryPack
Toreplacethebatterypack,contactanAuthorizedT oroService
Center.
DisposingoftheOldBatteryPack
Important:Donotplaceusedbatteriesinyour
householdtrash!
Important:Thissealedlead(acid)batterymustbe
collected,recycled,ordisposedofinanenvironmental
soundmanner.
Incinerating,landlling,ormixingsealedlead(acid)batterieswith
themunicipalsolidwastestreamisprohibitedbylawinsome
states.
Returnthisbatterytoanapprovedsealedlead(acid)battery
recycler.Thismaybewhereyoupurchasedthemachine.
Contactyourlocalwastemanagementofcialsforother
informationregardingtheenvironmentallysoundcollection,
recycling,anddisposalofthisbattery.
Service
Torohasdesignedthisproducttogiveyouyearsoftrouble-free
use.Shoulditneedservice,bringtheproducttoanAuthorized
ToroServiceDealerwhoisspeciallytrainedtorepairToro
productsandwillensurethatyourT orostaysallToro.
ProductInformation
Amodelandserialnumberdecalislocatedunderthereardoor
ofthemachine.Alwaysrefertospecicnumbersonthedecalin
correspondenceorwhenyouneedreplacementparts.
Storage
Storethemachineinacool,clean,anddryplacesuchasan
unheatedgarage.Donotstoreabattery-poweredmowerin
awarmbasement.Coverthemachinetokeepitcleanand
protected.
1.Cleanthemachinehousing.RefertoCleaningtheMachine
(page10).
2.Removeglassclippings,dirt,andgrimefromexternalparts
oftheshroudingandthetopofthemachinehousing.
3.Checktheconditionoftheblade.RefertoMaintainingthe
Blade(page10).
4.Tightenallloosenuts,bolts,andscrews.
Important:Thismachinehasabatterychargerthat
checksthechargestateofthebatteryandchargesthe
batteryonlywhennecessary.Unplugthechargerafter
24hoursofcharging,thoughyoumayleavethecharger
pluggedintothemachinelongerwithoutharmingthe
system.Duringthenon-mowingseason,youcanunplug
andstorethemachineforupto3monthsifthebattery
isfullychargedandthemachineisstoredinacool,dry
place.
11

20inCordless
Mowers
TheToroTotalCoverageGuarantee
A2-YearFullWarranty(NotApplicableforCommercialUse)
ConditionsandProductsCovered
TheT oroCompanyanditsafliate,ToroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetorepairtheT oroProducts
listedbelowifusedforresidentialpurposes*ifitisdefectiveinmaterialsor
workmanshiporifitstopsfunctioningduetothefailureofacomponent.
Thiswarrantycoversthecostofpartsandlabor,butyoumustpay
transportationcosts.
Thefollowingtimeperiodsapplyfromthedateofpurchase:
ProductsWarrantyPeriod
20inCordlessMowers2-yearfullwarranty
Battery2-yearfullwarranty
InstructionsforObtainingWarrantyService
IfyouthinkthatyourToroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:
1.ContactanyAuthorizedToroServiceDealertoarrangeserviceattheir
dealership.T olocateadealerconvenienttoyou,refertotheYellow
Pagesofyourtelephonedirectory(lookunder“LawnMowers”)or
accessourwebsiteatwww.T oro.com.Youmayalsocallthenumbers
listedinitem#3tousethe24-hourT oroDealerlocatorsystem.
2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.Thedealerwilldiagnosetheproblemanddetermineif
itiscoveredunderwarranty.
3.IfforanyreasonyouaredissatisedwiththeServiceDealer’s
analysisorwiththeassistanceprovided,contactusat:
CustomerCareDepartment,RLCDivision
TheT oroCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
Tollfreeat866-214-9807(U.S.customers)
Tollfreeat866-214-9808(Canadiancustomers)
OwnerResponsibilities
YoumustmaintainyourT oroProductbyfollowingthemaintenance
proceduresdescribedintheOperator'sManual.Suchroutinemaintenance,
whetherperformedbyadealerorbyyou,isatyourexpense.
ItemsandConditionsNotCovered
Thereisnootherexpresswarranty:
•Costofregularmaintenanceserviceorparts,suchasbladesharpening
orwornblades
•Anyproductorpartwhichhasbeenalteredormisusedandrequires
replacementorrepairduetoaccidentsorlackofpropermaintenance
•Pickupanddeliverycharges
•Operationalmisuse,neglect,oraccidents
•RepairsorattemptedrepairsbyanyoneotherthananAuthorizedToro
ServiceDealer
•Repairsnecessaryduetoimproperbatterycare,electricalsupply
irregularities,orfailuretoproperlypreparethemowerpriortoany
periodofnon-use.
GeneralConditions
AllrepairscoveredbythesewarrantiesmustbeperformedbyanAuthorized
ToroServiceDealerusingT oro-approvedreplacementparts.Repairbyan
AuthorizedT oroServiceDealerisyoursoleremedyunderthiswarranty.
NeitherTheToroCompanynorToroWarrantyCompanyisliablefor
indirect,incidental,orconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythesewarranties,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletionof
repairsunderthesewarranties.
Somestatesdonotallowexclusionsofincidentalorconsequential
damages,sotheaboveexclusionsmaynotapplytoyou.
Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveother
rightswhichvaryfromstatetostate.
CountriesOtherthantheUnitedStatesorCanada
CustomerswhohavepurchasedT oroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirT oroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheT oroimporter.Ifallotherremediesfail,youmaycontactusatToroWarrantyCompany.
*Residentialpurposesmeansuseoftheproductonthesamelotasyourhome.Useatmorethanonelocation,orinstitutionalorrentaluse,isconsidered
commercialuse,andnowarrantywouldapply.
374-0255RevA
