FormNo.3388-201RevA
TimeCutter®RidingMowers
ForAllTimeCutter®RidingMowersSetupInstructions
Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Connectthebattery.
Rearhitch1
Bolt(5/16x1inch)2
2Locknut(5/16inch)2
Installtherearhitch.
3Nopartsrequired–Setupthemotion-controllevers.
4Nopartsrequired–Connecttheseat-holdbar.
5Nopartsrequired–Checkthemoweradjustment.
Ignitionkey1
Hosecoupling(notincludedwithCE
models)1
Operator'sManual1
EngineOperator'sManual1
6
Operatortrainingmaterial1
Completethesetup.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
©2014—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved*3388-201*A
1
ConnectingtheBattery
NoPartsRequired
Procedure
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
1.Locatethebatteryandnegativebatterycable.
2.Removetheplasticcapfromthenegativebatterypost.
3.Removethefastenersonthenegativebatterycable,
andusethemtosecurethenegativebatterycableto
thenegativebatterypost(Figure1).
G018395
2
1
4
3
6
5
Figure1
1.Negativebatterycable4.Negativebatterypostcap
2.Wingnut5.Carriagebolt
3.Washer6.Negativebatterypost
2
InstallingtheRearHitch
Partsneededforthisprocedure:
1Rearhitch
2Bolt(5/16x1inch)
2Locknut(5/16inch)
Procedure
InstallthebrackettotheframeasshowninFigure2and
Figure3.
g015397
1
2
Figure2
Beforeassembly
1.Bolts2.Locknuts
Figure3
Afterassembly
2
3
SettingUptheMotion-control
Levers
NoPartsRequired
Procedure
1.Locatethemotion-controlleversattached,butfolded
downonthemachine.
2.Removetheupperbolt(3/8x1inch)andwasher;
loosenthelowerbolt(3/8x1inch).
3.Raisethemotioncontrolleverstotheuprightposition.
4.Aligntheholesinthemotion-controlleverwiththe
holesinthecontrol-armshaft,andinstallthebolt
andwasherremovedpreviously.Repeatthisforboth
controlslevers.
Note:Handtightenallfasteners.
5.Movethemotion-controlleverstotheparkposition,
raisetheseat,andmovethecontrolleversbacktothe
centerposition(neutral).
6.Verifythatthemotion-controlleversareproperly
aligned.
Note:Adjustasnecessary.Tightenallfasteners.
4
ConnectingtheSeat-holdBar
NoPartsRequired
Procedure
Note:UseFigure4andFigure5todeterminewhich
seat-holdbarisonyourmachine.Followtheappropriate
instructions.
1.IfyourseatlatchisasshowninFigure4,locatethe
seat-holdbarontheframeofthemachine.
2.Removethefasteners.
3.Installtheseat-holdbartotheseatframe.
4.Securethebarwiththewasherandcotterpinremoved
previously(Figure4).
g027213
123
4
5
Figure4
1.Cotterpin4.Seatholdbar
2.Washer5.Holeforpin,seatholdbar
3.Seat
5.Ifyourseat-holdbarisasshowninFigure5,ensure
theseatlatchisabovetheweldedtabthersttimeitis
putintotheuserposition.
Note:Ensuretheseatlatchworksandpreventsthe
seatfromrotatingfullyforward.
g027214
1
2
Figure5
1.Seatlatch2.Weldedtab
3
5
CheckingtheMower
Adjustment
NoPartsRequired
Procedure
Adjusttheside-to-sidelevelandthefront-to-rearbladeslope.
UsetherelevantproceduresintheOperator'sManualtoverify
thatthedeckislevel,andmakeanyadjustmentsasnecessary.
RefertotheOperator'sManualformoreinformation.
6
CompletingtheSetup
Partsneededforthisprocedure:
1Ignitionkey
1Hosecoupling(notincludedwithCEmodels)
1Operator'sManual
1EngineOperator'sManual
1Operatortrainingmaterial
Procedure
CheckingtheTirePressure
Checkthefrontandreartiresforproperination;referto
CheckingtheTirePressureintheOperator'sManualforthe
recommendedinationpressure.
CheckingtheSide-DischargeChute
Removethepackingrestraintholdingthesidedischargechute
upandlowerthechuteintoplace.
CheckingtheEngine-OilLevel
Beforeyoustarttheengineandusethemachine,checkthe
oillevelintheenginecrankcase;refertoCheckingtheOil
LevelintheOperator'sManual.
Keepallthefollowingitemswiththemachine:
•Ignitionkey
•Hosecoupling(notincludedinCEmodels)
•Operator'sManual
•EngineOperator'sManual
•ViewtheOperatortrainingmaterialbeforeoperatingthe
machine.
4
