Toro TimeCutter SW series Manual

FormNo.3415-319RevA
TimeCutter®SWRidingMowers
ForAllTimeCutter®SWRidingMowers
SetupInstructions
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCalifornia
tocausecancer,birthdefects,orreproductiveharm.
Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Connectthebattery.
Rearhitch1
Bolt(5/16x1inch)2
2Locknut(5/16inch)2
Installtherearhitch.
Steeringwheel1
Topcover1
Locknut1
Rearcover1
3
Screws2
Installthesteeringwheel.
Shoulderbolt(seatswithoutadetached
cushiononly)2
Seat(seatswithoutadetachedcushion
only)1
Hexbolt2
Washer2
Seatpan1
Seatassembly(seatswithadetached
cushiononly)1
Bottomcushion(seatswithadetached
cushiononly)1
4
Flange-hexbolt(seatswithadetached
cushiononly)2
Installtheseattotheseatpan(machines
shippedinasteelcrateonly).
Seatassembly1
Seatrod1
Hairpincotters2
5Spacers(certainmodelsonly)2
Installtheseatassembly.
6Grassdeector(ifnotinstalled)1Installthegrassdeector.
©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3415-319*A

ProcedureDescriptionQty.Use
7Nopartsrequired–Checkthemoweradjustment.
Ignitionkey1
Hosecoupling(notincludedwithCE
models)1
Operator'sManual1
EngineOwner’sManual(non-Toro
engines)1
8
KeyChoice®key(blue)1
Completethesetup.
1
ConnectingtheBattery
NoPartsRequired
Procedure
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandlead
compounds,chemicalsknownto
theStateofCaliforniatocause
cancerandreproductiveharm.Wash
handsafterhandling.
1.Locatethebatteryandnegativebatterycable.
2.Removetheplasticcapfromthenegative
batterypost.
3.Removethefastenersonthenegativebattery
cable,andusethemtosecurethenegative
batterycabletothenegativebatterypost(Figure
1).
G018395
2
1
4
3
6
5
g018395
Figure1
1.Negativebatterycable4.Negativebatterypostcap
2.Wingnut5.Carriagebolt
3.Washer6.Negativebatterypost
2

2
InstallingtheRearHitch
Partsneededforthisprocedure:
1Rearhitch
2Bolt(5/16x1inch)
2Locknut(5/16inch)
Procedure
1.Installthebrackettotheframeasshownin
Figure2.
2.Torquetheboltsbetween19.8and25.4N∙m
(175and225in-lb).
g028437
Figure2
1.Bolt(2)2.Locknut(2)
3
InstallingtheSteering
Wheel
Partsneededforthisprocedure:
1Steeringwheel
1Topcover
1Locknut
1Rearcover
2Screws
Procedure
1.Rotatethesteeringcolumnuptotheuser
position(Figure3).
g027703
Figure3
2.PositionthesteeringwheelasshowninFigure5.
3.Installthesteeringwheelandtopcovertothe
steeringcolumnwiththelocknut(Figure4).
4.Torquethelocknutbetween36.6and44.7N∙m
(27and33ft-lb).
5.Installthesteering-wheelcover.
3

g027737
Figure4
1.Steering-wheelcover4.Topcover
2.Locknut5.Column
3.Steeringwheel
6.Installtherearcovertothebackofthefootrest
withthetabsatthebottominsidethefootrest
andthe2screwsinthetop(Figure5).
Note:Ensurethetabsoftherearcoverare
insidethefootrest.
g027887
Figure5
1.Backcover2.Screws
4
InstallingtheSeattothe
SeatPan
MachinesShippedinaSteelCrate
Only
Partsneededforthisprocedure:
2Shoulderbolt(seatswithoutadetachedcushiononly)
1Seat(seatswithoutadetachedcushiononly)
2Hexbolt
2Washer
1Seatpan
1Seatassembly(seatswithadetachedcushiononly)
1Bottomcushion(seatswithadetachedcushiononly)
2Flange-hexbolt(seatswithadetachedcushiononly)
Procedure
1.Iftheseatdoesnothaveadetachedcushion,
installtheseattotheseatpanusing2shoulder
bolts,2hexbolts,and2washers.
g213714
Figure6
1.Shoulderbolt(2)2.Hexboltandwasher(2)
2.Iftheseatdoeshaveadetachedcushion,
continueasfollows:
A.Installthebottomcushiontotheseat
assemblyusing2ange-hexbolts(Figure
7).
4

B.Placetheseatontotheseatpan,aligning
theattachedseatboltswiththefront
keyholes,andslidetheseatback.
C.Securetheseattotheseatpanusing2hex
boltsand2washers(Figure7).
g213797
Figure7
1.Flange-hexbolt(2)4.Bottomcushion
2.Bolt(5/16x1inch)and
washer(2)
5.Seatpan
3.Seatassembly6.Frontkeyhole
5
InstallingtheSeat
Assembly
Partsneededforthisprocedure:
1Seatassembly
1Seatrod
2Hairpincotters
2Spacers(certainmodelsonly)
Procedure
1.Installtheseatassemblytotheframewith
theseatrod,2hairpincotters,and2spacers
(certainmodelsonly)asshowninFigure8.
g027723
Figure8
1.Seatassembly3.Hairpincotter
2.Spacers4.Seatrodwithhairpincotter
installed
2.Connecttheseatswitch(Figure9).
5

g027695
g027695
Figure9
3.Routethewireharnesstotherightsideofthe
machineandpushtheplasticconnectorintothe
seatframehole(Figure10).
g028383
1 2
g028383
Figure10
1.Plasticconnectorinseat
framehole
2.Wireharness
6
InstallingtheGrass
Deector
Partsneededforthisprocedure:
1Grassdeector(ifnotinstalled)
Procedure
Ifthegrassdeectorisnotinstalled,removeitfrom
thepackagingandinstallitontothemowerdeck.
RefertoyourOperator’sManualforthecorrect
proceduretoinstallthegrassdeector.
7
CheckingtheMower
Adjustment
NoPartsRequired
Procedure
Adjusttheside-to-sidelevelandthefront-to-rearblade
slope.UsetherelevantproceduresintheOperator's
Manualtoverifythatthedeckislevel,andmakeany
adjustmentsasnecessary.RefertotheOperator's
Manualformoreinformation.
6

8
CompletingtheSetup
Partsneededforthisprocedure:
1Ignitionkey
1Hosecoupling(notincludedwithCEmodels)
1Operator'sManual
1EngineOwner’sManual(non-T oroengines)
1KeyChoice®key(blue)
Procedure
CheckingtheTirePressure
Checkthefrontandreartiresforproperination;
refertoCheckingtheTirePressureintheOperator's
Manualfortherecommendedinationpressure.
CheckingtheSide-DischargeChute
Removethepackingrestraintholdingtheside
dischargechuteupandlowerthechuteintoplace.
CheckingtheEngine-OilLevel
Beforeyoustarttheengineandusethemachine,
checktheoillevelintheenginecrankcase;referto
CheckingtheOilLevelintheOperator'sManual.
Keepallthefollowingitemswiththemachine:
•Ignitionkey
•KeyChoicekey(blue)
•Hosecoupling(notincludedinCEmodels)
•Operator'sManual
•EngineOwner’sManual(non-T oroengines)
7
