Toro TurfMaster 22200 User manual

FormNo.3381-349RevA
30inTurfMasterWalk-BehindLawnMower
ModelNo.22200—SerialNo.314000001andUp
Operator'sManual
Introduction
Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyresidentialhomeownersorprofessional,
hiredoperators.Itisdesignedprimarilyforcuttinggrass
onwell-maintainedlawnsonresidentialorcommercial
properties.Itisnotdesignedforcuttingbrushorfor
agriculturaluses.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.Writethenumbers
inthespaceprovided.
G023543
1
Figure1
1.Themodelandserialnumberplateisinoneofthese2
locations.
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Important:Thisengineisnotequippedwithaspark
arrestermufer.ItisaviolationofCaliforniaPublic
ResourceCodeSection4442touseoroperatetheengine
onanyforest-covered,brush-covered,orgrass-covered
land.Otherstatesorfederalareasmayhavesimilarlaws.
ThissparkignitionsystemcomplieswithCanadianICES-002.
TheenclosedEngineOwner’sManualissuppliedfor
informationregardingtheUSEnvironmentalProtection
Agency(EPA)andtheCaliforniaEmissionControl
Regulationofemissionsystems,maintenance,and
warranty.Replacementsmaybeorderedthroughthe
enginemanufacturer.
NetTorque:Thegrossornettorqueofthisenginewas
laboratoryratedbytheenginemanufacturerinaccordance
withtheSocietyofAutomotiveEngineers(SAE)J1940.
Asconguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclassofmower
willbesignicantlylower.Gotowww .Toro.comtoview
specicationsonyourmowermodel.
©2013—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3381-349*A

Contents
Introduction..................................................................1
GeneralLawnMowerSafety.....................................2
SafetyandInstructionalDecals.................................4
Setup............................................................................6
1InstallingtheHandle.............................................6
2AdjustingtheHandleHeight..................................6
3FillingtheCrankcasewithOil.................................7
ProductOverview..........................................................8
Controls................................................................8
Operation.....................................................................9
CheckingtheEngineOilLevel..................................9
FillingtheFuelTankwithGasoline............................9
AdjustingtheCuttingHeight....................................10
StartingtheEngine.................................................11
StoppingtheEngine...............................................11
OperatingtheSelf-propelDriveandEngagingthe
CuttingBlades....................................................11
CheckingtheBlade-stopSystemOperation................12
RecyclingtheClippings...........................................12
BaggingtheClippings.............................................13
Side-dischargingtheClippings..................................14
OperatingTips......................................................15
Maintenance.................................................................16
RecommendedMaintenanceSchedule(s)......................16
ServicingtheAirFilter............................................16
ChangingtheEngineOil.........................................17
ChangingtheOilFilter............................................18
ServicingtheSparkPlug..........................................18
CheckingtheConditionoftheBelts..........................18
EmptyingtheFuelTankandCleaningthe
Filter.................................................................19
ChangingtheFuelFilter..........................................19
ServicingtheBlade-driveSystem..............................19
ServicingtheCuttingBlades.....................................20
ChangingtheBlade-Brake-Clutch(BBC)
Belt...................................................................22
AdjustingtheSelf-propelCable................................23
AdjustingtheBlade-brakeCable...............................23
ChangingtheBlade-driveBelt..................................24
CleaningundertheMachineHousing........................24
Storage........................................................................25
GeneralInformation...............................................25
PreparingtheFuelSystem.......................................25
PreparingtheEngine..............................................25
RemovingtheMachinefromStorage.........................26
Troubleshooting...........................................................27
Safety
ThislawnmowermeetsorexceedstheCPSCblade
safetyrequirementsforwalk-behindrotarylawnmowers
andtheB71.4specicationsoftheAmericanNational
StandardsInstituteineffectatthetimeofproduction.
Improperlyusingormaintainingthislawnmowercan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructions.
Torodesignedandtestedthislawnmowerforreasonably
safeservice;however,failuretocomplywiththefollowing
instructionsmayresultinpersonalinjury.
WARNING
Engineexhaustcontainscarbonmonoxide,an
odorless,deadlypoisonthatcankillyou.
Donotruntheengineindoorsorinanenclosed
area.
Toensuremaximumsafety,bestperformance,and
togainknowledgeoftheproduct,itisessentialthat
youandanyotheroperatorofthemachinereadand
understandthecontentsofthismanualbeforethe
engineiseverstarted.Payparticularattentiontothe
safetyalertsymbol(Figure2)whichmeansCaution,
Warning,orDanger—“personalsafetyinstruction.”
Readandunderstandtheinstructionbecauseithasto
dowithsafety.Failuretocomplywiththeinstruction
mayresultinpersonalinjury.
GeneralLawnMowerSafety
Thislawnmoweriscapableofamputatinghandsandfeetand
ofthrowingobjects.Failuretoobservethefollowingsafety
instructionscouldresultinseriousinjuryordeath.
Thefollowinginstructionshavebeenadaptedfromthe
ANSI/OPEIstandardB71.4-2012.
Training
•ReadtheOperator’sManualandothertrainingmaterial.
•Iftheoperator(s)ormechanic(s)cannotreadEnglishitis
theowner’sresponsibilitytoexplainthismaterialtothem.
•Becomefamiliarwiththesafeoperationoftheequipment,
operatorcontrols,andsafetysigns.
•Alloperatorsandmechanicsshouldbetrained.The
ownerisresponsiblefortrainingtheusers.
•Neverletchildrenoruntrainedpeopleoperateorservice
theequipment.Localregulationsmayrestricttheageof
theoperator.
•Theownerand/orusercanpreventandisresponsible
foraccidentsorinjuriesoccurringtothemselves,other
people,orproperty.
Preparation
•Evaluatetheterraintodeterminewhataccessoriesand
attachmentsareneededtoproperlyandsafelyperform
thejob.
•Onlyuseaccessoriesandattachmentsapprovedbythe
manufacturer.
2

•Wearappropriateclothing,includingsafetyglassesand
hearingprotection.Longhair,looseclothing,orjewelry
maygettangledinmovingparts.
•Inspecttheareawheretheequipmentistobeusedand
removeallobjectssuchasrocks,toys,andwirewhichcan
bethrownbythemachine.
•Checkthatoperator’spresencecontrols,safetyswitches
andshieldsareattachedandfunctioningproperly.Donot
operatethemunlesstheyarefunctioningproperly.
Operation
•Neverrunanengineinanenclosedarea.
•Onlyoperateingoodlight,keepingawayfromholesand
hiddenhazards.
•Onlystartenginefromtheoperator’sposition.
•Besureofyourfootingwhileusingpedestrian-controlled
equipment,especiallywhenbackingup.
•Walk,don’trun.
•Neveroperateonwetgrass.Reducedfootingcouldcause
slipping.
•Slowdownanduseextracareonhillsides.Besureto
travelintherecommendeddirectiononhillsides.
•Usecautionwhileoperatingneardrop-offs.
•Slowdownandusecautionwhenmakingturnsandwhen
changingdirectionsonslopes.
•Neverraisethedeckwiththebladesrunning.
•Neveroperatewiththedischargedeectorraised,
removedoraltered,unlessusingagrasscatcher.
•Donotchangetheenginegovernorsettingoroverspeed
theengine.
•Stoponlevelgroundandshutoffenginebeforeleaving
theoperator’spositionforanyreasonincludingemptying
thecatchersoruncloggingthechute.
•Stopequipmentandinspectbladesafterstrikingobjects
orifanabnormalvibrationoccurs.Makenecessary
repairsbeforeresumingoperation.
•Keephandsandfeetawayfromthecuttingunits.
•Lookbehindanddownbeforebackinguptobesureof
aclearpath.
•Beawareofthemowerdischargedirectionanddonot
pointitatanyone.
•Donotoperatethemowerwhileundertheinuenceof
alcoholordrugs.
•Usecarewhenloadingorunloadingthemachineintoa
trailerortruck.
•Usecarewhenapproachingblindcorners,shrubs,trees,
orotherobjectsthatmayobscurevision.
SafeHandlingofFuels
•Toavoidpersonalinjuryorpropertydamage,use
extremecareinhandlinggasoline.Gasolineisextremely
ammableandthevaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andothersources
ofignition.
•Useonlyanapprovedfuelcontainer.
•Neverremovefuelcaporaddfuelwiththeengine
running.
•Allowenginetocoolbeforerefueling.
•Neverrefuelthemachineindoors.
•Neverstorethemachineorfuelcontainerwherethereis
anopename,spark,orpilotlightsuchasonawater
heateroronotherappliances.
•Neverllcontainersinsideavehicleoronatruckor
trailerbedwithaplasticliner.Alwaysplacecontainerson
thegroundawayfromyourvehiclebeforelling.
•Removeequipmentfromthetruckortrailerandrefuelit
ontheground.Ifthisisnotpossible,thenrefuelsuch
equipmentwithaportablecontainer,ratherthanfroma
fueldispensernozzle.
•Keepthenozzleincontactwiththerimofthefueltank
orcontaineropeningatalltimesuntilfuelingiscomplete.
•Donotuseanozzlelockopendevice.
•Iffuelisspilledonclothing,changeclothingimmediately.
•Neveroverllfueltank.Replacefuelcapandtighten
securely.
Hauling
•Usecarewhenloadingorunloadingthemachineintoa
trailerortruck.
•Tiethemachinedownsecurelyusingstraps,chains,cable,
orropes.Bothfrontandrearstrapsshouldbedirected
downandoutwardfromthemachine.
MaintenanceandStorage
•Waitforallmovementtostopbeforeadjusting,cleaning
orrepairing.
•Cleangrassanddebrisfromcuttingunit,mufer,and
enginetohelppreventres.
•Cleanupoilorfuelspills.
•Letenginecoolbeforestoringanddonotstorenear
ame.
•Donotstorefuelnearamesordrainindoors.
•Neverallowuntrainedpersonneltoservicemachine.
•Usecarewhencheckingtheblades.
•Wrapthebladesorweargloves,andusecautionwhen
servicing.
•Onlyreplaceblades.Neverstraightenorweldthem.
•Keephandsandfeetawayfrommovingparts.
•Ifpossible,donotmakeadjustmentswiththeengine
running.
3

•Keepallpartsingoodworkingconditionandallhardware
tightened.
•Replaceallwornordamageddecals.
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotentialdanger.Replace
anydecalthatisdamagedorlost.
Manufacturer'sMark
1.Indicatesthatthebladeisidentiedasapartfromthe
originalmachinemanufacturer.
93-7009
1.Warning—don'toperatethemowerwiththedeectorupor
removed;keepthedeectorinplace.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.
94-8072
1.Warning—cutting/dismembermenthazardofhandorfoot,
cuttingmechanism.
103-6328
1.Choke4.Slow
2.Fast5.Engine—stop
3.Continuousvariable
setting
116-7127
116-7581
1.Cutting/dismembermenthazardofhandorfoot,mower
blade-stayawayfrommovingparts.ReadtheOperator’s
Manualbeforeadjustingservicing,orcleaning.
4

116-7583
1.Warning–ReadtheOperator’sManual.Donotoperatethis
machineunlessyouaretrained.
4.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts;keepallguardsinplace.
2.Thrownobjecthazard—keepbystandersasafedistancefrom
themachine.
5.Warning—wearhearingprotection.
3.Thrownobjecthazard—Donotoperatethemowerwithoutthe
reardischargeplugorbaginplace.
6.Cutting/dismembermenthazardofhandorfoot,mower
blade—Donotoperateupanddownslopes;operatesideto
sideonslopes;stoptheenginebeforeleavingtheoperating
position—pickupobjectsthatcouldbethrownbytheblades;
andlookbehindyouwhenbackingup.
117–2718
120-9570
1.Warning—stayawayfrommovingparts;keepallguards
andshieldsinplace.
121-1449
1.Warning—donotparkonslopesunlesswheelsarechocked
orblocked.
5

Setup
1
InstallingtheHandle
NoPartsRequired
Procedure
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Removethe2boltsfromthemachineframeinthe
locationshowninFigure3.
G019802
1
2
Figure3
1.Bolt(2)2.Nutonhandlesupport
bracket(2)
2.Rotatethehandlerearwardtotheoperatingposition.
3.Securethehandletothemachinewiththeboltsthat
youremovedinstep1
4.Tightenthefastenersthatsupportthehandleonboth
sidesofthemachineasshowninFigure4.
G021273
2
1
3
Figure4
1.Cabletie3.Bolt(4)
2.Nutonhandlesupport
bracket(2)
5.Useacabletietosecurethecablestothelowerhandle
inthelocationshowninFigure4.
6.Securethecabletieonthehandleandtrimoffthe
excessmaterialfromthetie.
2
AdjustingtheHandleHeight
NoPartsRequired
Procedure
1.Standintheoperatingpositiontodeterminethemost
comfortablehandleheight.
2.Removethehandleboltandinsertitin1ofthe3holes
locatedatthebottomofthehandlebracket(Figure5).
6

G021 150
1
2
3
Figure5
1.Lowesthandleheight
setting
3.Highesthandleheight
setting
2.Middlehandleheight
setting
3.Tightenthehandleboltuntilitissnug.
4.Repeatthestepsabovefortheothersideofthe
machine.
3
FillingtheCrankcasewithOil
NoPartsRequired
Procedure
Important:Thismachinedoesnotcomewithoilinthe
engine.Beforestartingtheengine,lltheenginewith
oil.
1.Movethemachinetoalevelsurface.
2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout.
3.Ifthecrankcaseisempty,addabout3/4ofthe
crankcasecapacityofoilintotheoil-lltube(Figure6).
Note:Max.ll:29oz.(0.85l)withoillter;22oz.
(0.65l)withoutoillter;type:SAE30orSAE10W30
weightdetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.
G01981 1
4
Figure6
1.Dipstick3.Addmark
2.Fullmark4.Oil-lltube
4.Wipethedipstickcleanwithacleancloth.
5.Insertthedipstickintothellerneck,thenremoveit.
Note:Toensureanaccurateoillevelreading,install
thedipstickfully.
6.Readtheoillevelonthedipstick(Figure6).
•IftheoillevelisbelowtheAddmark,addasmall
amountofoilslowlytotheoil-lltube,thenrepeat
steps4through6untiltheoillevelisattheFull
markonthedipstick.
•IftheoillevelabovetheFullmark,drainthe
excessoiluntiltheoillevelisattheFullmarkon
thedipstick;refertoChangingtheEngineOil
(page17).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
7.Insertthedipstickintothellerneckandrotatethecap
clockwiseuntilitistight.
7

ProductOverview
1
234
5
6
7
89
10
11
12
13
14
G019803
15
Figure7
1.Sparkplug(underbrush
guard)
9.Grassbag
2.Airlter10.Rearcutting-heightlever
3.Oilll/dipstick11.Fuelshut-offvalve
4.Throttlelever12.Oillter
5.Fuel-tankcap13.Beltcover
6.Reardeector14.Frontcutting-heightlever
7.Handle15.Belt-cover-accesspanel
8.Controlbar
g019644
1
2
3
4
Figure8
1.Grassbag3.Side-dischargechute
2.Rear-dischargeplug4.Side-dischargedeector
Controls
g019652
1 2 34
Figure9
Throttle(Throttlelevernotshownforthesakeofclarity)
1.Choke3.Slow
2.Fast4.Stop
1
2
G019669
Figure10
Controlbar
1.Handle2.Controlbar
8

Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
Eachtimebeforeyoumow,ensurethattheself-propeldrive
andthecontrolbaroperateproperly.Whenyoureleasethe
controlbar,thebladesandtheself-propeldriveshouldstop.
Iftheydonot,contactanAuthorizedServiceDealer.
CAUTION
Thismachineproducessoundlevelsinexcessof
85dBAattheoperator’searandcancausehearing
lossthroughextendedperiodsofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
Figure11
1.Warning—wearhearingprotection.
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Beforeeachuse,ensurethattheoillevelisbetweentheAdd
andFullmarksonthedipstick(Figure12).
G01981 1
4
Figure12
1.Dipstick3.Addmark
2.Fullmark4.Oil-lltube
1.Movethemachinetoalevelsurface.
2.Cleanaroundthedipstick(Figure12).
3.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout.
4.Wipethedipstickcleanwithacleancloth.
5.Insertthedipstickintothellerneck,thenremoveit.
Note:Toensureanaccurateoillevelreading,install
thedipstickfully.
6.Readtheoillevelonthedipstick(Figure12).
•IftheoillevelisbelowtheAddmark,addasmall
amountofoilslowlytotheoil-lltube,thenrepeat
steps4through6untiltheoillevelisattheFull
markonthedipstick.
•IftheoillevelabovetheFullmark,drainthe
excessoiluntiltheoillevelisattheFullmarkon
thedipstick;refertoChangingtheEngineOil
(page17).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
7.Insertthedipstickintothellerneckandrotatethecap
clockwiseuntilitistight.
FillingtheFuelTankwith
Gasoline
RecommendedFuel:
•Forbestresults,useonlyclean,fresh(lessthan30days
old),unleadedgasolinewithanoctaneratingof87or
higher((R+M)/2ratingmethod).
•Ethanol:Gasolinewithupto10%ethanol(gasohol)
or15%MTBE(methyltertiarybutylether)byvolume
isacceptable.EthanolandMTBEarenotthesame.
Gasolinewith15%ethanol(E15)byvolumeisnot
approvedforuse.Neverusegasolinethatcontains
morethan10%ethanolbyvolume,suchasE15
(contains15%ethanol),E20(contains20%ethanol),or
E85(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/orengine
damagewhichmaynotbecoveredunderwarranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorfuelcontainers
overthewinterunlessafuelstabilizerisused.
•Donotaddoiltogasoline.
Important:Toreducestartingproblems,addfuel
stabilizertothefuelallseason,mixingitwithgasoline
lessthan30daysold;runthemachinedrybeforestoring
itformorethan30days.
Donotusefueladditivesotherthanafuel
stabilizer/conditioner.Donotusefuelstabilizers
withanalcoholbasesuchasethanol,methanol,or
isopropanol.
9

DANGER
Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.
•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
directlyonthegroundbeforelling,notina
vehicleoronanobject.
•Fillthetankoutdoorswhentheengineiscold.
•Wipeupspills.
•Donothandlegasolinewhensmokingoraround
anopenameorsparks.
•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.
1.Cleanaroundthefuel-tankcap(Figure13).
g019643
1
Figure13
1.Fuel-tankcap
2.Removethecapfromthetank.
3.Fillthefueltankwithunleadedgasolinetowithin1/4
to1/2inch(6to13mm)fromthetopofthetank.Do
notllintothellerneck.
Important:Donotllthetankmorethan1/4
inch(6mm)fromthetopofthetankbecausethe
gasolinemusthaveroomtoexpand.
4.Installthefueltankcapandwipeupanyspilled
gasoline.
AdjustingtheCuttingHeight
DANGER
Adjustingthecuttingheightleverscouldbringyour
handsintocontactwithamovingbladeandresult
inseriousinjury.
•Stoptheengineandwaitforallmovementto
stopbeforeadjustingthecuttingheight.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
Thecuttingheightsrangefrom1-1/2inches(38mm)to5
inches(127mm)in1/2-inch(13mm)increments.
1
2
4
678
3
5
G01991 1
Figure14
Viewfromfrontleft-handsideofthemachine
1.1-1/2in(38mm)5.3-1/2in(89mm)
2.2in(51mm)6.4in(102mm)
3.2-1/2in(64mm)7.4-1/2in(114mm)
4.3inch(76mm)8.5in(127mm)
Thecuttingheightiscontrolledwithafrontleverandarear
lever,bothontheleftsideofthemachine(Figure15and
Figure16).Toraiseorlowerthemachine,engagethelever,
raiseorlowerthemachine,andthendisengagethelever.
10

g019653
1
Figure15
Frontcuttingheightlever
1.Squeezethelevertodisengageit.
g019645
Figure16
Rearcuttingheightlever
StartingtheEngine
1.Connectthewiretothesparkplug(Figure7).
2.Openthefuelshut-offvalve(Figure17).
Note:Whenthefuelshut-offvalveisopen,thelever
isparallelwiththefuelline.
g019650
1
g019651
1
Figure17
1.Fuelshut-offvalve
3.MovethethrottlecontroltotheChokeposition
(Figure9).
4.Pullthestarterhandlelightlyuntilyoufeelresistance,
thenpullitsharply.
5.MovethethrottlecontrollevertotheFastposition
whentheenginestarts(Figure8).
Note:Iftheenginefailstostartafter3pulls,repeat
steps3through5.
StoppingtheEngine
1.MovethethrottlecontroltotheOffpositionandwait
forallmovingpartstostop.
2.Closethefuelshut-offvalveanddisconnectthewire
fromthesparkplugifyoudonotusethemachineor
leaveitunattended.
OperatingtheSelf-propel
DriveandEngagingthe
CuttingBlades
•Tooperatetheself-propeldrivewithoutengagingthe
blades,raisethecontrolbartothehandle(Figure18).
11

G019671
1
Figure18
1.Raisethecontrolbartothehandle.
•Tooperatetheself-propeldriveandengagetheblades,
slidethecontrolbarallthewaytotherightandraiseit
tothehandle(Figure18).
G019672
2
1
Figure19
1.Slidethecontrolbartothe
right.
2.Raisethecontrolbarto
thehandle.
•Todisengagetheself-propeldriveandtheblades,release
thecontrolbar.
Note:Youcanvarythegroundspeedbyincreasingor
decreasingthedistancebetweenthecontrolbarandthe
handle.Lowerthecontrolbartoreducethespeedwhenyou
makeaturnorifthemachineismovingtoofast.Ifyoulower
thecontrolbartoofar,themachinestopsself-propelling.
Squeezethecontrolbarclosertothehandletoincreasethe
groundspeed.Whenyouholdthecontrolbartightagainst
thehandle,themachineself-propelsatthemaximumground
speed.
CheckingtheBlade-stop
SystemOperation
Beforeeachuse,checkthatthebladesstopwithin3seconds
ofreleasingthecontrolbar.
UsingtheGrassBag
ServiceInterval:Beforeeachuseordaily—Checkthe
blade-stopsystemoperation.Theblades
shouldstopwithin3secondsofreleasing
thecontrolbar;iftheydonot,contactan
AuthorizedServiceDealer.
Youcanusethegrassbagtochecktheblade-stopsystem.
1.Removetherear-dischargeplug.
2.Installtheemptygrassbagonthemachine.
3.Starttheengine.
4.Engagetheblades.
Note:Thebagshouldbegintoinate,indicatingthat
thebladesarerotating.
5.Whilewatchingthebag,releasethecontrolbar.
Note:Ifthebagdoesnotdeatewithin3secondsof
releasingthecontrolbar,theblade-stopsystemmaybe
deterioratingand,ifignored,couldresultinanunsafe
operatingcondition.Havethemachineinspectedand
servicedbyanAuthorizedServiceDealer.
6.Stoptheengineandwaitforallmovingpartstostop.
NotUsingtheGrassBag
1.Movethemachineontoapavedsurfaceinanon-windy
area.
2.Setall4wheelstothe3-1/2inch(89mm)cutting
heightsetting.
3.Takeahalfsheetofnewspaperandcrumpleitintoa
ballsmallenoughtogounderthemachine(about3
inchesor75mmindiameter).
4.Placethenewspaperballabout5inches(13cm)in
frontofthemachine.
5.Starttheengine.
6.Engagetheblades.
7.Releasethecontrolbarandbegincountingout3
seconds.
8.Onthecountof3,pushthemachinequicklyforward
overthenewspaper.
9.Stoptheengineandwaitforallmovingpartstostop.
10.Gotothefrontofthemachineandcheckthe
newspaperball.
Note:Ifthenewspaperballdidnotgounderthe
machine,repeatsteps4through10.
Important:Ifthenewspaperisunravelledor
shredded,thebladesdidnotstopproperly,which
couldresultinanunsafeoperatingcondition.
ContactanAuthorizedServiceDealer.
RecyclingtheClippings
Thismachinecomesfromthefactoryreadytorecyclegrass
andleafclippingsbackintothelawn.Topreparethemachine
torecycle:
12

•Iftheside-dischargechuteisonthemachine,removeit
andinstalltheside-dischargedeector;refertoRemoving
theSide-dischargeChute(page14).
•Ifthegrassbagisonthemachine,removeit;referto
RemovingtheGrassBag(page14).
•Iftherear-dischargeplugisnotinstalled,gripitbythe
handle,raisethereardeector,andinsertitintothe
rear-dischargechuteuntilthelatchlocksintoplace;refer
toFigure20.
G019812
Figure20
1.Rear-dischargeplug2.Reardeector
WARNING
Ensurethattherear-dischargeplugisinplace
beforeyourecycletheclippings.Neverengagethe
bladeswithouteithertherear-dischargeplugorthe
grassbaginstalled.
BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
WARNING
Aworngrassbagcouldallowsmallstonesandother
similardebristobethrowntowardtheoperatoror
bystandersandresultinseriouspersonalinjuryor
death.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
Iftheside-dischargechuteisonthemachine,removeit
andinstalltheside-dischargedeectorbeforebaggingthe
clippings;refertoRemovingtheSide-dischargeChute(page
14).
WARNING
Thebladesaresharp;contactingthebladescan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
InstallingtheGrassBag
1.Raiseandholdupthereardeector(Figure21).
1
G019798
2
Figure21
1.Bagrod2.Reardeector
2.Removetherear-dischargeplugbypullingdownonthe
latchwithyourthumbandpullingtheplugoutfrom
themachine(Figure20).
3.Installthebagrodintothenotchesatthebaseofthe
handle,androckthebagbackandforthtoensurethat
13

therodisseatedatthebottomofbothnotches;refer
toFigure21.
4.Lowerthereardeectoruntilitrestsonthegrassbag.
MowingwiththeGrassBag
WARNING
Aworngrassbagcouldallowsmallstonesand
othersimilardebristobethrownintheoperator’sor
bystander’sdirectionandresultinseriouspersonal
injuryordeathtotheoperatororbystanders.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
RemovingtheGrassBag
Toremovethebag,reversethestepsinInstallingtheGrass
Bagabove.
DANGER
Themachinecanthrowgrassclippingsand
otherobjectsthroughanopendischargetunnel.
Objectsthrownwithenoughforcecouldcause
seriouspersonalinjuryordeathtotheoperatoror
bystander.
Neveropenthedooronthedischargetunnelwhen
theengineisrunning.
Side-dischargingtheClippings
Usethesidedischargeforcuttingverytallgrass.
WARNING
Thebladesaresharp;contactingthebladescan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
DANGER
Anuncovereddischargeopeningwillallowobjects
tobethrowninthedirectionoftheoperatoror
bystanders.Also,contactwiththebladescould
occur.Thrownobjectsorbladecontactcancause
seriousinjuryordeath.
Neveroperatethemachinewithoutthe
side-dischargedeectororside-dischargechutein
placeandworkingproperly.
InstallingtheSide-dischargeChute
Important:Ensurethattherear-dischargeplugisin
placebeforeyourecycletheclippings.
1.Stoptheengineandwaitforallmovingpartstostop.
2.Removethegrassbagifitisinstalledonthemachine;
refertoRemovingtheGrassBag(page14).
3.Inserttherear-dischargeplug;refertoRecyclingthe
Clippings(page12).
4.Removetheside-dischargedeectorbypullingup
onthespringthatholdsthedeectorinplaceand
removingthedeector(Figure22).
G019649
12
3
Figure22
1.Topoftheside-discharge
deector
3.Side-dischargedeector
2.Spring
5.Installtheside-dischargechute(Figure23)bypulling
uponthespring,placingthechuteovertheopening,
andloweringthespringoverthetabsontopofthe
dischargechute.
g019647
1
Figure23
1.Side-dischargechute
RemovingtheSide-dischargeChute
Toremovetheside-dischargechute,reversethestepsin
InstallingtheSide-dischargeChute.
14

OperatingTips
GeneralTips
•Reviewthesafetyinstructionsandreadthismanual
carefullybeforeoperatingthemachine.
•Cleartheareaofsticks,stones,wire,branches,andother
debristhatthebladescouldhitandthrow.
•Keepeveryone,especiallychildrenandpets,awayfrom
theareaofoperation.
•Avoidstrikingtrees,walls,curbs,orothersolidobjects.
Neverdeliberatelymowoveranyobject.
•Ifthemachinestrikesanobjectorstartstovibrate,
immediatelystoptheengine,disconnectthewirefrom
thesparkplug,andexaminethemachinefordamage.
•Maintainsharpbladesthroughoutthecuttingseason.
Periodicallyledownnicksontheblades.
•ReplacethebladeswhennecessarywithoriginalToro
replacementblades.
•Mowonlydrygrassorleaves.Wetgrassandleavestend
toclumpontheyardandcancausethemachinetoplug
ortheenginetostall.
WARNING
Wetgrassorleavescancauseseriousinjuryif
youslipandcontacttheblades.
Mowonlyindryconditions.
•Cleantheundersideofthemachinedeckaftereach
mowing.RefertoCleaningundertheMachineHousing
(page24).
•Keeptheengineingoodrunningcondition.
•Settheenginespeedtothefastestpositionforthebest
cuttingresults.
WARNING
Operatingamachinewithitsenginerunning
ataspeedgreaterthanthefactorysettingcan
causethemachinetothrowapartofabladeor
engineintotheoperator’sorbystander’sarea
andresultinseriouspersonalinjuryordeath.
–Donotchangetheenginespeedsetting.
–Ifyoususpecttheenginespeedisfaster
thannormal,contactanAuthorizedService
Dealer.
•Cleantheairlterfrequently.Mulchingstirsupmore
clippingsanddustwhichclogstheairlterandreduces
engineperformance.
CuttingGrass
•Grassgrowsatdifferentratesatdifferenttimesofthe
year.Inthesummerheat,itisbesttocutgrassatthe
2-inch(51mm),2-1/2-inch(64mm),or3-inch(83mm)
cuttingheightsettings.Cutonlyaboutathirdofthegrass
bladeatatime.Donotcutbelowthe2-inch(51mm)
settingunlessthegrassissparseoritislatefallwhen
grassgrowthbeginstoslowdown.
•Whencuttinggrassover6inches(15cm)tall,rstmow
atthehighestcuttingheightsettingandwalkslower;then
mowagainatalowersettingforthebestlawnappearance.
Ifthegrassistoolongandtheleavesclumpontopofthe
lawn,themachinemayplugandcausetheenginetostall.
•Alternatethemowingdirection.Thishelpsdispersethe
clippingsoverthelawnforevenfertilization.
Ifthenishedlawnappearanceisunsatisfactory,tryoneor
moreofthefollowing:
•Sharpentheblades.
•Walkataslowerpacewhilemowing.
•Raisethecuttingheightonyourmachine.
•Cutthegrassmorefrequently.
•Overlapcuttingswathsinsteadofcuttingafullswath
witheachpass.
•Setthecuttingheightonthefrontwheelsanotchlower
thantherearwheels.Forexample,setthefrontwheels
at2inches(51mm)andtherearwheelsat2-1/2inches
(64mm).
CuttingLeaves
•Aftercuttingthelawn,ensurethathalfofthelawnshows
throughthecutleafcover.Youmayneedtomakemore
thanonepassovertheleaves.
•Forlightleafcoverage,setallthewheelsatthesame
cuttingheightsetting.
•Iftherearemorethan5inches(12.7cm)ofleavesonthe
lawn,setthefrontcuttingheight1or2notcheshigher
thantherearcuttingheight.Thismakesiteasiertofeed
theleavesunderthemachinedeck.
•Slowdownyourmowingspeedifthemachinedoesnot
cuttheleavesnelyenough.
15

Maintenance
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst5hours•Changetheengineoilwithouttheoillter.
•Servicetheblade-drivesystem.
Beforeeachuseordaily
•Checktheengineoillevel.
•Checktheblade-stopsystemoperation.Thebladesshouldstopwithin3secondsof
releasingthecontrolbar;iftheydonot,contactanAuthorizedServiceDealer.
•Inspecttheairlter.
•Checkthecuttingbladesandservicethem,ifnecessary.
•Inspecttheblades.
•Cleanunderthemachinehousing.
Every25hours•Cleanthefoampre-cleaner(morefrequentlyindustyconditions).
Every50hours
•Changetheengineoil(moreoftenindustyconditions).
•Checktheconditionofthebelts.
•Checkthefuelhoseandreplaceitifnecessary.
•Removedebrisfromunderthebeltcover.
•Servicetheblade-drivesystem.
Every100hours
•Changetheoillter.
•Checkthesparkplug.
•Cleanthefueltanklter.
•Changethefuellter.
Every250hours•Changetheblade-brake-clutchbelt.
Every300hours•Replacethepaperairlter(morefrequentlyindustyconditions).
Yearlyorbeforestorage•Emptythefueltankbeforerepairsasdirectororbeforestorage.
Important:RefertoyourEngineOperator’sManualforadditionalmaintenanceprocedures.
CAUTION
Ifyouleavethewireonthesparkplug,someonecouldaccidentlystarttheengineandseriouslyinjure
youorotherbystanders.
Disconnectthewirefromthesparkplugbeforeyoudoanymaintenance.Setthewireasidesothatitdoes
notaccidentlycontactthesparkplug.
ServicingtheAirFilter
ServiceInterval:Beforeeachuseordaily
Every25hours—Cleanthefoampre-cleaner(more
frequentlyindustyconditions).
Every300hours—Replacethepaperairlter(more
frequentlyindustyconditions).
Important:Donotoperatetheenginewithouttheair
lterassembly;extremeenginedamagewilloccur.
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthewirefromthesparkplug.
3.Removethecoverandcleanitthoroughly(Figure24).
16

Figure24
1.Cover3.Air-lterbase
2.Foampre-lterandpaper
lter
4.Removethefoampre-lterandpaperlter(Figure24).
5.Removethefoampre-lterfromthepaperlter(Figure
24),andreplacethepaperlterifitisexcessivelydirty.
Important:Donottrytocleanapaperlter.
6.Washthefoampre-cleanerwithamilddetergentand
water,thenblotitdry.
Note:Donotaddoiltothefoampre-cleaner.
7.Installthefoampre-cleanerontothepaperlter.
8.Installtheair-lterassembly.
9.Installthecover.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours—Changetheengine
oilwithouttheoillter.
Every50hours—Changetheengineoil(moreoften
industyconditions).
1.Runtheenginetowarmtheengineoil.
Note:Warmoilowsbetterandcarriesmore
contaminants.
WARNING
Oilmaybehotafterenginehasbeenrun,and
contactwithhotoilcancauseseverepersonal
injury.
Avoidcontactingthehotengineoilwhenyou
drainit.
2.Stoptheengineandwaitforallmovingpartstostop.
3.Disconnectthewirefromthesparkplug.
4.Placeasuitabledrainpanundertherightsideofthe
machine.
5.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout.
6.Tipthemachine,withtheairlterup,todraintheoil
intothedrainpan(Figure24).
G019648
Figure25
Note:Youcanalsoremovetheoilfromthecrankcase
usinganoilextractor.
7.Returnthemachinetotheoperatingposition.
8.Insertthedipstickintothellerneckandrotatethecap
clockwiseuntilitistight.
9.Recycletheusedoilaccordingtolocalcodes.
10.FillthecrankcasetotheFulllineonthedipstickwith
freshoil.Referto3FillingtheCrankcasewithOil
(page7).
11.Wipeupanyspilledoil.
17

ChangingtheOilFilter
ServiceInterval:Every100hours
1.Runtheenginetowarmtheoil.
WARNING
Oilmaybehotaftertheenginehasbeenrun,
andcontactwithhotoilcancausesevere
personalinjury.
Avoidcontactingthehotengineoilwhenyou
drainit.
2.Stoptheengineandwaitforallmovingpartstostop.
3.Disconnectthewirefromthesparkplug.
4.Draintheengineoil;refertoChangingtheEngineOil
(page17).
5.Placearagundertheoilltertocatchanyoilthatmay
leakoutasyouremovethelter.
6.Removetheoillter(Figure26).
g019650
1
Figure26
1.Oillter
7.Useyourngertocoatthegasketonthenewlter
withoil(Figure27).
Figure27
1.Gasket
8.Installthenewlteruntilthegasketcontactsthelter
base,thenhandtightenthelteranadditional2/3turn.
9.FillthecrankcasetotheFulllineonthedipstickwith
freshoil;referto3FillingtheCrankcasewithOil(page
7).
10.Connectthewiretothesparkplug.
11.Runtheengineforabout3minutes.
12.Stoptheengine,waitforallmovingpartstostop,and
checkforoilleakagearoundthelter.
13.Addoiltocompensatefortheoilintheoillter;refer
toCheckingtheEngineOilLevel(page9)
14.Recycletheusedoillteraccordingtolocalcodes.
ServicingtheSparkPlug
ServiceInterval:Every100hours
UseanNGKBPR5ESsparkplugorequivalent.
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthewirefromthesparkplug.
3.Cleanaroundthesparkplug.
4.Removethesparkplugfromthecylinderhead.
Important:Replaceacracked,fouled,ordirty
sparkplug.Donotcleantheelectrodesbecause
gritenteringthecylindercandamagetheengine.
5.Setthegapontheplugto0.030in.(0.76mm);refer
toFigure28.
Figure28
1.Center-electrodeinsulator3.Airgap(nottoscale)
2.Sideelectrode
6.Installthesparkplugandthegasketseal.
7.Torquetheplugto17ft-lb(23N-m).
8.Connectthewiretothesparkplug.
CheckingtheConditionofthe
Belts
ServiceInterval:Every50hours
1.Stoptheengineandwaitforallmovingpartstostop.
18

2.Removethebeltcover(Figure7)byremovingthe4
boltsthatholdittothemachinehousing.
3.Checkthebeltsforanycracks,frayededges,burn
marks,oranyotherdamage.
4.Replacealldamagedbelts.
5.Ifyoureplacetheblade-drivebelt,youmustadjustit.
RefertoServicingtheBlade-driveSystem(page19).
6.Installthebeltcoverwiththe4boltsthatyouremoved
instep2.
EmptyingtheFuelTankand
CleaningtheFilter
ServiceInterval:Every50hours—Checkthefuelhoseand
replaceitifnecessary.
Every100hours—Cleanthefueltanklter.
Yearlyorbeforestorage—Emptythefueltankbefore
repairsasdirectororbeforestorage.
Note:Thefueltanklter(screen)elementislocatedinside
thefueltankattheoutlet.Thislterisapartofthefueltank
andcannotberemoved.
1.Stoptheengineandwaitforittocooldown.
Important:Draingasolinefromacoldengine
only.
2.Disconnectthewirefromthesparkplug.
3.Closethefuelshut-offvalve.
4.Disconnectthefuellinebylooseningthetubeclampat
thecarburetor.
5.Openthefuelshut-offvalveanddrainthegasoline
completelyfromthetankandfuellineintoanapproved
fuelcontainer.
6.Removethefueltankfromthemachine.
7.Pourasmallamountoffuelinthefueltank,move
thefuelaroundinthetank,andpouritoutintoan
approvedfuelcontainer.
8.Installthefueltankandthefuelline.
ChangingtheFuelFilter
ServiceInterval:Every100hours
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthewirefromthesparkplug.
3.Closethefuelshut-offvalve(Figure29).
g019650
1
g019924
1
2
Figure29
1.Fuellter2.Fuelshut-offvalve
4.Removethefuellter(Figure29)fromthefuellineby
looseningthetubeclampssurroundingthefuellter.
5.Installanewfuellterinthefuellineusingthetube
clampsthatyouremovedinstep4.
ServicingtheBlade-drive
System
ServiceInterval:Aftertherst5hours
Every50hours—Removedebrisfromunderthebelt
cover.
Every50hours—Servicetheblade-drivesystem.
1.Loosenthe2screwsonthebelt-cover-accesspaneland
removethepanel(Figure30).
g019641
1
2
34
5
6
7
8
Figure30
1.Belt-tensionspring5.Blade-drivebelt
2.Adjustingbolt6.Wall
3.Gap7.Beltcover
4.Adjustingnut8.Belt-cover-accesspanel
19

2.Brushorblowoutdebrisfromtheinsideofthebelt
coverandaroundalltheparts.
3.Holdafeelergaugesetbetween0.005and0.03inches
(0.13and0.76mm)againstthewallandslideitdown
behindthebelttensionspring;refertoFigure31.
Figure31
Note:Ifthereisavisiblegapbetweenthegaugeand
thespring,tightentheadjustingboltandthenutuntil
thefeelergaugebarelyslidesfreelyinandoutofthe
gap(Figure30).
Important:Donotovertightentheadjustingbolt.
Thiscoulddamagetheblade-drivebelt.
4.Installthebelt-cover-accesspanel.
ServicingtheCuttingBlades
ServiceInterval:Beforeeachuseordaily
Important: Y ou will need a torque wr ench to install the
blades pr oper l y . Ifyoudonothaveatorquewrenchor
areuncomfortableperformingthisprocedure,contact
anAuthorizedServiceDealer.
Examinethebladesforsharpnessandanywearordamage
wheneveryourunoutofgasoline;refertoInspectingthe
Blades(page20).Ifthebladeedgeisdullornicked,haveit
sharpenedorreplaceit.Ifthebladesareworn,bent,damaged
orcracked,replacethemimmediatelywithagenuineToro
replacementblades.
DANGER
Awornordamagedbladecanbreak,andapiece
ofthebladecouldbethrowntowardtheoperator
orabystander,resultinginseriouspersonalinjury
ordeath.
•Inspectthebladesperiodicallyforwearor
damage.
•Replacewornordamagedblades.
Note:Maintainsharpbladesthroughoutthecuttingseason,
becausesharpbladescutcleanlywithouttearingorshredding
thegrassblades.Tearingandshreddingturnsgrassbrownat
theedges,whichslowsgrowthandincreasesthechanceof
disease.
PreparingtoServicetheCuttingBlades
Tipthemachineontoitsside,withtheairlterupintheair,
untiltheupperhandlerestsontheground.
WARNING
Thebladesaresharp;contactingabladecould
resultinseriouspersonalinjury.
•Disconnectthewirefromthesparkplug.
•Weargloveswhenservicingtheblades.
InspectingtheBlades
ServiceInterval:Beforeeachuseordaily
1.Inspectthecuttingedges(Figure32).Iftheedgesare
notsharporhavenicks,removethebladesandhave
themsharpenedorreplacethem.
g017223
Figure32
1.Curvedarea3.Wear/slotforming
2.Cuttingedge4.Crack
2.Inspectthebladesthemselves,especiallythecurved
area(Figure42).Ifyounoticeanydamage,wear,or
aslotforminginthisarea(Figure32),immediately
replacethemwithnewblades.
DANGER
Ifyouallowabladetowear,aslotwillform
betweenthesailandatpartoftheblade.
Eventuallyapieceoftheblademaybreak
offandbethrownfromunderthehousing,
possiblyresultinginseriousinjurytoyouor
bystanders.
•Inspectthebladesperiodicallyforwearor
damage.
•Nevertrytostraightenabladethatisbent
orweldabrokenorcrackedblade.
•Checkforbentblades;refertoChecking
forBentBlades(page20).
CheckingforBentBlades
1.Rotatethebladesuntiltheyarepositionedasshown
inFigure33.
20
