FormNo.3421-217RevB
18inTurfSeeder
ModelNo.23511—SerialNo.400000000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3421-217*B

ThisproductcomplieswithallrelevantEuropean
directives;fordetails,pleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemical
orchemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.
Introduction
Thismachineseedsturf.Itisintendedforsmall-to
medium-sizedlawnapplicationsinresidentialand
commercialproperties.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.com
forproductsafetyandoperationtrainingmaterials,
accessoryinformation,helpndingadealer,orto
registeryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure
1illustratesthelocationofthemodelandserial
numbersontheproduct.Writethenumbersinthe
spaceprovided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal
(ifequipped)orvisitwww.Toro.comtoaccess
warranty,parts,andotherproductinformation.
g020744
Figure1
1.Locationofthemodelandserialnumbers
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

Contents
Safety.......................................................................3
SafeOperatingPractices....................................3
SafetyandInstructionalDecals..........................5
Setup........................................................................8
UnfoldingtheHandle..........................................8
CheckingtheEngine-OilLevel............................8
ProductOverview.....................................................9
Controls.............................................................9
Specications..................................................12
Attachments/Accessories.................................12
Operation................................................................12
AddingFuel......................................................12
StartingtheEngine...........................................13
StoppingtheEngine.........................................13
OperatingtheMachine.....................................13
CleaningDebrisfromtheMachine....................13
OperatingTips.................................................14
Maintenance...........................................................15
RecommendedMaintenanceSchedule(s)...........15
Pre-MaintenanceProcedures..............................15
DisconnectingtheSpark-PlugWire..................15
EngineMaintenance...........................................16
ServicingtheAirCleaner..................................16
CheckingtheEngine-OilLevel..........................17
ChangingtheEngineOil...................................18
CleaningtheSedimentCup..............................18
ServicingtheSparkPlug...................................19
BeltMaintenance................................................20
CheckingtheBeltTension................................20
AdjustingtheBeltTension.................................20
BladeMaintenance..............................................21
ReplacingWornCuttingBlades........................21
Storage...................................................................22
RemovingtheMachinefromStorage................22
Safety
Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
SafeOperatingPractices
Training
•ReadtheOperator'sManualandothertraining
material.Iftheoperator(s)ormechanic(s)can’t
readEnglish,itistheowner'sresponsibilityto
explainthismaterialtothem.
•Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetysigns.
•Alloperatorsandmechanicsshouldbetrained.
Theownerisresponsiblefortrainingtheusers.
•Neverletchildrenoruntrainedpeopleoperateor
servicetheequipment.Localregulationsmay
restricttheageoftheoperator.
•Theowner/usercanpreventandisresponsible
foraccidentsorinjuriesoccurringtohimselfor
herself,otherpeopleorproperty.
Preparation
•Evaluatetheterraintodeterminewhataccessories
andattachmentsyouneedtoproperlyandsafely
performthejob.Useonlyaccessoriesand
attachmentsapprovedbythemanufacturer.
•Wearappropriateclothingincludingeyeprotection,
longplants,substantialslip-resistantfootwear,and
hearingprotection.Tiebacklonghairanddonot
wearlooseclothingorloosejewelry.
•Inspecttheareawhereyouwillusetheequipment
andremoveallobjectssuchasrocks,toys,and
wire,whichcanbecontactedbythemachine.
•Checkthattheoperator-presencecontrols,
safetyswitches,andshieldsareattachedand
functioningproperly.Donotoperateunlessthey
arefunctioningproperly.
3

FuelSafety
•Useextracarewhenhandlingfuel.Itisammable
anditsvaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.
•Useonlyanapprovedfuelcontainer.
•Donotremovethefuelcaporllthefueltank
whiletheengineisrunningorhot.
•Donotaddordrainfuelinanenclosedspace.
•Donotstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlight,such
asonawaterheaterorotherappliance.
•Ifyouspillfuel,donotattempttostarttheengine;
avoidcreatinganysourceofignitionuntilthefuel
vaporshavedissipated.
Operation
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Neverrunanengineinanenclosedarea.
•Operatethemachineonlyingoodlight,keeping
awayfromholesandhiddenhazards.
•Starttheengineonlyfromtheoperator’sposition.
•Neveroperatewithouttheshields,covers,orother
guardssecurelyinplace.Ensurethatallinterlocks
arefunctioningproperly.
•Donotchangetheenginegovernorsettingor
overspeedtheengine.
•Raisethecuttingblades,stopthemachine,and
shutofftheenginebeforeleavingtheoperator’s
positionforanyreason.
•Stopthemachine,shutofftheengine,waitfor
allmovingpartstostop,andinspectthecutting
bladesafterstrikinganobjectorifanabnormal
vibrationoccurs.Makenecessaryrepairsbefore
resumingoperation.
•Keepyourhandsandfeetawayfromthecutting
bladearea.
•Keepbystanders,especiallysmallchildren,outof
theoperatingarea.Stopthemachineifanyone
entersthearea.
•Bealert,slowdown,andusecautionwhenmaking
turns.Lookbehindandtothesidebeforechanging
directions.
•Slowdownandusecautionwhencrossingroads
andsidewalks.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Lightningcancausesevereinjuryordeath.If
lightningisseenorthunderisheardinthearea,do
notoperatethemachine;seekshelter.
•Useextremecarewhenloadingorunloadingthe
machineintoatrailerortruck.
•Usecarewhenapproachingblindcorners,shrubs,
trees,orotherobjectsthatmayobscurevision.
•Alwaysbeawareofobstaclesthatmaybeinthe
areaofoperation.Planyourpathtoavoidcontact
withanyobstaclebyyouorthemachine.
SlopeSafety
•Usethemachineacrossthefaceofslopes;never
upanddown.Useextremecautionwhenchanging
directiononslopes.
•Donotusethemachineonexcessivelysteep
slopes.Poorfootingcouldcauseaslip-and-fall
accident.
•Usethemachinewithcautionneardrop-offs,
ditches,orembankments.
MaintenanceandStorage
•Parkthemachineonalevelsurface,shutoffthe
engine,andwaitforallmovementtostopbefore
adjusting,cleaning,orrepairing.Raisethecutting
blades,stopthemachine,shutofftheengine,and
disconnectthespark-plugwire.
•Cleangrassanddebrisfromtheblades,drives,
mufers,andenginetohelppreventres.Clean
upoilorfuelspills.
•Lettheenginecoolbeforestoringanddonotstore
themachinenearaame.
•Shutoffthefuelwhilestoringortransportingthe
machineontrailers.Donotstorefuelnearames
ordrainindoors.
•Neverallowuntrainedpersonneltoservicethe
machine.
•Usejackstandsorsafetylatchestosupport
componentswhenrequired.
•Carefullyreleasepressurefromcomponentswith
storedenergy.
•Removethespark-plugwirebeforemakingany
repairs.
•Keepyourhandsandfeetawayfrommoving
parts.Ifpossible,donotmakeadjustmentswith
theenginerunning.
•Keepallpartsingoodworkingconditionandall
hardwaretightened.Replaceallwornordamaged
decals.
•Tobestprotectyourinvestmentandmaintain
optimalperformanceofyourT oroequipment,
countonT orogenuineparts.Whenitcomes
toreliability,T orodeliversreplacementparts
designedtotheexactengineeringspecications
ofourequipment.UseonlyTorogenuineparts.
4

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednear
anyareaofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal93-7321
93-7321
1.Warning—stayawayfrommovingparts;keepallguardsin
place.
decal98-4387
98-4387
1.Warning—wearhearingprotection.
decal117-4979
117-4979
1.Entanglementhazard,belt—keepawayfrommovingparts;
keepallguardsandshieldsinplace.
decal119-4655
119-4655
decal125-3897
125-3897
1.Warning-stayawayfrommovingparts;keepallguardsand
shieldsinplace.
decal125-3917
125-3917
1.Seederon2.Seederoff
5

decal127-4061
127-4061
1.Cuttingblades4.Holdthehandletostart
theengine.
2.Fast5.Releasethehandletoshut
offtheengine.
3.Slow
decal130-8322
130-8322
1.Useonlygasolinethat
contains10%ethanolby
volume(E10)orless.
3.Donotusegasolinethat
containsmorethan10%
ethanolbyvolume(E10).
2.ReadtheOperator's
Manual.
decal133-8056
133-8056
6

decal125-3809
125-3809
1.Warning—readtheOperator’sManual.5.Thrownobjecthazard—keepbystandersawayfromthe
machine.
2.Warning—donotoperatethismachineunlessyouaretrained.6.Warning—shutofftheenginebeforewalkingawayfromthe
machine.
3.Thrownobjecthazard—shutofftheengineandremoveany
debrisfromyourpath.
7.Warning—shutofftheengineanddisconnectthesparkplug
wirebeforeperformingmaintenanceonthemachine.
4.Warning—stayawayfrommovingparts;keepallguardsin
place.
decal116-8537
116-8537
7

Setup
UnfoldingtheHandle
1.Raisethehandletotheoperatingposition
(Figure3).
g023004
Figure3
2.Slidetheovallockingringsdowneachsideof
theupperhandleoverthelowerhandle(Figure
3),lockingthehandlesectionstogether.
CheckingtheEngine-Oil
Level
Themachinecomesfromthefactorywithoilinthe
enginecrankcase;however,youmayneedtoaddoil.
RefertoCheckingtheEngine-OilLevel(page17).
AddonlyenoughoiltoraisetheleveltotheFullmark
onthedipstick.
8

ProductOverview
g023003
Figure4
1.Operator-presencebail5.Fueltank
2.Handlebar6.Seedingrategauge
3.Throttlecontrollever7.Depth-controllever
4.Seed-gatecontrollever8.Recoil-starterrope
Controls
g023178
Figure5
1.Recoil-starterhandle4.Chokelever
2.Sedimentcup5.Throttlelever
3.Fuel-shutoffvalve
Recoil-StartHandle
Tostarttheengine,pulltherecoil-starthandle(Figure
5)quicklytoturntheengineover.RefertoStartingthe
Engine(page13)forthecorrectstartingprocedure.
Fuel-ShutoffValve
Closethefuel-shutoffvalvewhentransportingor
storingthemachine(Figure5).
ChokeLever
Beforestartingacoldengine,movethechokelever
forward.Aftertheenginestarts,regulatethechoke
tokeeptheenginerunningsmoothly.Assoonas
possible,movethechokeleverallthewayrearward.
Note:Awarmenginerequireslittleornochoking.
9

ThrottleLever
Movethecontrolforwardtoincreasetheenginespeed
andrearwardtodecreasespeed;refertoFigure6.
g241996
Figure6
1.Throttlelever
Operator-PresenceBail
Theoperator-presencebailallowsthemachineto
startandrun.
•Tostartthemachine,holddownthe
operator-presencebail(Figure7).Continueto
holddowntheoperator-presencebailtoallowthe
machinetorun.
g241994
Figure7
1.Operator-presencebail
•Tostopthecuttingblades,releasethe
operator-presencebail.
Depth-ControlLever
Thedepth-controlleverallowsyoutosetthedepthof
thecuttingbladesin10cuttingpositionsalongwith
1positionfortransportation.Toadjustthedepth,
removethehairpincotter,pullthelockingpinout,and
movetheleverforwardorrearwardtothedesired
depthsetting(Figure8).
Important:Donotpulltheleversidetosideas
thiswillbendit.
g019441
Figure8
1.Depth-controllever3.Hairpincotter
2.Transport-positionhole4.Lockingpin
10

Seeding-RateGauge
Usetheseeding-rategaugetosettheseedowrate.
Itiscalibratedwiththemachinespeedtogiveyou
anevenseedingrateatanyspeed.T ochangethe
seedingrate,loosentheknobonthegaugeandmove
thegaugepointertothedesiredposition,thentighten
theknobtoholditinplace.
g013146
Figure9
Refertotheseedinggraphlocatedonthemachine
todeterminethecorrectgaugesettingforthetype
ofgrassyouareplantingandthethicknessinwhich
youwanttoplantit.
Seed-Gate-ControlLever
Pushtheseed-gate-controllever(Figure10)forward
tostarttheseedow,andpullitrearwardtostopthe
seedow.
Note:Themachineisdesignedsothattheseedow
slowsand/orstopswhenyoustopthemachineor
slowforaturn.Toreduceseedloss,raisethefront
wheelsasthemachineisturned.Thereisnoneedto
turntheseedowonandoffforeachturn.
g241995
Figure10
1.Seed-gate-controllever
11

Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Width70cm(27.5inches)
Length(operating)130cm(51inches)
Length(withhandlestored)96.5cm(38inches)
Height(operating)94cm(37inches)
Height(withhandlestored)63.5cm(25inches)
Weight77kg(170lb)
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesisavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.Toro.comforalistofallapprovedattachments
andaccessories.
Important:UseonlyToroapprovedattachments.
Otherattachmentsmaycreateanunsafeoperating
environmentordamagethemachine.
Tobestprotectyourinvestmentandmaintainoptimal
performanceofyourT oroequipment,countonToro
genuineparts.Whenitcomestoreliability,Toro
deliversreplacementpartsdesignedtotheexact
engineeringspecicationofourequipment.Useonly
Torogenuineparts.
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
AddingFuel
FuelSafety
•Useextracarewhenhandlingfuel.Itisammable
anditsvaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.
•Useonlyanapprovedfuelcontainer.
•Donotremovethefuelcaporllthefueltank
whiletheengineisrunningorhot.
•Donotaddordrainfuelinanenclosedspace.
•Donotstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlight,such
asonawaterheaterorotherappliance.
•Ifyouspillfuel,donotattempttostarttheengine;
avoidcreatinganysourceofignitionuntilthefuel
vaporshavedissipated.
RecommendedFuel
•Forbestresults,useonlyclean,fresh(lessthan
30daysold),unleadedgasolinewithanoctane
ratingof87orhigher((R+M)/2ratingmethod).
•Ethanol:Gasolinewithupto10%ethanol
(gasohol)or15%MTBE(methyltertiarybutyl
ether)byvolumeisacceptable.Ethanoland
MTBEarenotthesame.Gasolinewith15%
ethanol(E15)byvolumeisnotapprovedforuse.
Neverusegasolinethatcontainsmorethan
10%ethanolbyvolume,suchasE15(contains
15%ethanol),E20(contains20%ethanol),orE85
(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/or
enginedamagewhichmaynotbecoveredunder
warranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorfuel
containersoverthewinterunlessyouuseafuel
stabilizer.
•Donotaddoiltogasoline.
UsingStabilizer/Conditioner
Useafuelstabilizer/conditionerinthemachineto
providethefollowingbenets:
•Keepsfuelfreshduringstorageof90daysorless
(drainthefueltankwhenstoringthemachinefor
morethan90days)
12

•Cleanstheenginewhileitruns
•Eliminatesgum-likevarnishbuildupinthefuel
system,whichcauseshardstarting
Important:Donotusefueladditives
containingmethanolorethanol.
Addthecorrectamountoffuelstabilizer/conditioner
tothefuel.
Note:Afuelstabilizer/conditionerismost
effectivewhenmixedwithfreshfuel.T ominimize
thechanceofvarnishdepositsinthefuelsystem,
usefuelstabilizeratalltimes.
FillingtheFuelTank
1.Parkthemachineonalevelsurface,disengage
thecuttingblades,stoptheengine,waitforall
movingpartstostop,andturntheengineswitch
totheOFFposition.
2.Allowtheenginetocool.
3.Cleanaroundthefuel-tankcapandremoveit
(Figure11).
Note:Thecapistetheredtothefueltank.
g013315
Figure11
4.Addunleadedfueltothefueltankuntilthelevel
isjustinsidethemeshlterbasket.
Important:Thisspaceinthetankallows
fueltoexpand.Donotllthefueltank
completelyfull.
5.Installthefuel-tankcapsecurely.
6.Wipeupanyspilledfuel.
StartingtheEngine
1.Movethechokelevertotheleftifyouare
startingacoldengine.
2.Movethethrottlelevermidwaybetweenthe
SLOW(turtle)andFAST(rabbit)positions.
Note:Awarmorhotenginemaynotrequire
choking.
3.Holddowntheoperatorpresencebailwithone
hand.
4.Pulltherecoilhandlesharplytostarttheengine.
5.Aftertheenginestarts,graduallymovethe
choketotheright.
Note:Iftheenginestallsorhesitates,movethe
chokeleftagainuntiltheenginewarmsup.
6.Movethethrottlelevertothedesiredsetting.
StoppingtheEngine
1.Releasetheoperator-presencebail.
2.Closethefuelvalve.
3.Waitforallmovingpartstostop.
OperatingtheMachine
1.Movethedepthcontrollevertothedesired
setting.
2.Starttheengine.
3.Pushdownonthehandletoraisethefront
wheelsofftheground.
4.Pullthecutting-blade-controllevertothehandle,
andslowlylowerthefrontwheelstotheground,
allowingthebladestograduallyworkintothe
grassandsoil.
5.Whennished,releasethecutting-blade-control
lever,shutofftheengine,andraisethecutting
bladestothetransportsetting.
CleaningDebrisfromthe
Machine
ServiceInterval:Beforeeachuseordaily
1.Disengagethecuttingblades,shutoffthe
engine,waitforallmovingpartstostop,andturn
theengineswitchtotheOFFposition.
2.Brushdirtanddebrisawayfromtheaircleaner
andengineopenings.
13

OperatingTips
•Asseedowvariesgreatlybetweendifferentseed
types,llthehopperwithaminimalamountof
seed,andrunatrialportionoftheyardtoensure
youhavethedesiredseedoutput.
•Foroptimalcoverage,reducetheseedowto
1/2thedesiredamountandseedtheentireyard
in1direction,thencompleteasecondcoverage
perpendiculartotherst.
PowerSeeding
•Setthecuttingblades3to6mm(1/8to1/4inch)
intotheearth(belowthezeroposition).
•Mowthelawnshorterthannormalmowinglength
beforeseeding.
•Seedthelawnbeforeprimegrassgrowingseason.
•Givethelawnextrawateringafterseeding.
PowerRaking/Renovating
Tobreaknewgroundortillanexistinglawn,setthe
cuttingblades6to12mm(1/4to1/2inch)intothe
earth(belowthezeroposition).Allowthemachineto
moveatitsownpacethroughthesoil,goingforward
andbackwardovertheareatobeleveled,ormaking
multiplepassesfromdifferentdirections.
14

Maintenance
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst25hours•Changetheengineoil.
Beforeeachuseordaily
•Cleandebrisformthemachine.
•Inspecttheair-cleanerelements.
•Checktheengine-oillevel.
•Checkthebelttension.Iftheengineisworkingbutthecuttingbladesseem
underpowered,checkthebelttension.
•Checkthebladesforwearordamage.
•Checkforloosefasteners.
Every50hours•Cleantheair-cleanerelements.Cleanthemmorefrequentlyindustyoperating
conditions.
Every100hours
•Changetheengineoil.
•Cleanthesedimentcup.
•Inspect,clean,andadjustthesparkplug;replaceitifnecessary.
Every200hours•Replacethesparkplug.
Every300hours•Replacethepaperair-cleanerelement.Replaceitmorefrequentlyindusty
operatingconditions.
Yearlyorbeforestorage•Touchupchippedpaint.
Pre-Maintenance
Procedures
Disconnectingthe
Spark-PlugWire
Beforeperforminganymaintenanceontheengine,
belts,orcuttingblades,disconnectthespark-plug
wirefromthesparkplug(Figure12).
g019426
Figure12
1.Spark-plugwire
15

EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Beforeeachuseordaily—Inspect
theair-cleanerelements.
Every50hours—Cleantheair-cleaner
elements.Cleanthemmorefrequentlyindusty
operatingconditions.
Every300hours/Yearly(whichevercomes
rst)—Replacethepaperair-cleanerelement.
Replaceitmorefrequentlyindustyoperating
conditions.
Important:Donotoperatetheenginewithout
theairlterassembly;extremeenginedamage
willoccur.
1.Parkthemachineonalevelsurface,disengage
thecuttingblades,shutofftheengine,andwait
forallmovingpartstostop,andturntheengine
switchtotheOFFposition.
2.Disconnectthewirefromthesparkplug.
3.Removethenutthatsecuresthecover(Figure
13).
g019427
Figure13
1.Nut3.Paperelement
2.Cover4.Foamelement
4.Removethecover.
Note:Becarefultopreventdirtanddebrisfrom
fallingintothebase.
5.Removethenutrestrainingairlterassembly.
6.Removethefoamandpaperelementsfromthe
base(Figure13).
7.Removethefoamelementfromthepaper
element(Figure13).
8.Inspectthefoamandpaperelements,and
replacethemiftheyaredamagedorexcessively
dirty.
9.Ifthepaperelementisexcessivelydirty,replace
it.
Note:Nevertrytobrushdirtoffthepaper
element;brushingforcesthedirtintothebers.
10.Cleanthefoamelementinwarm,soapywater
orinanonammablesolvent.
Note:Donotusefueltocleanthefoamelement
becauseitcouldcreateariskofreorexplosion.
11.Rinseanddrythefoamelementthoroughly.
12.Dipthefoamelementincleanengineoil,then
squeezeouttheexcessoil.
Note:Excessoilinthefoamelementrestricts
theairowthroughtheelementandmayreach
thepaperlterandclogit.
13.Wipedirtfromthebaseandthecoverwitha
moistrag.
Note:Becarefultopreventdirtanddebrisfrom
enteringtheairductleadingtothecarburetor.
14.Installtheair-cleanerelementsandensurethat
theyareproperlypositioned.
15.Securetheair-cleanerelementswiththe
previouslyremovednut.
16.Securelyinstallthecoverwiththepreviously
removednut.
16

CheckingtheEngine-Oil
Level
ServiceInterval:Beforeeachuseordaily
1.Parkthemachineonalevelsurface,disengage
thecuttingblades,shutofftheengine,andwait
forallmovingpartstostop,andturntheengine
switchtotheOFFposition.
Note:T oensureamoreaccuratemeasurement,
adjustthedepthcontrolleveruntiltheengine
isalsolevel.
2.Cleanaroundthedipstick(Figure14)sothatdirt
cannotfallintothellerholeanddamagethe
engine.
g019540
Figure14
1.Dipstick
3.Unscrewthedipstickandwipetheendclean
(Figure14).
4.Insertthedipstickfullyontothellertube.Do
notscrewin.(Figure14).
5.Removethedipstickagainandlookattheend.
Iftheengineoillevelislow,slowlypouronly
enoughoilintothellertubetoraisethelevelto
theupperlimitofthedipstickorthebottomedge
ofthellertube(Figure15).
g241983
Figure15
1.Fillertube4.Lowerlimit
2.Dipstick5.Oil-drainbolt
3.Upperlimit
Important:Donotoverllthecrankcase
withengineoilandruntheengine;engine
damagemayresult.
17

ChangingtheEngineOil
ServiceInterval:Aftertherst25hours
Every100hours
WARNING
Oilmaybehotaftertheenginehasbeenrun,
andcontactwithhotoilcancausesevere
personalinjury.
Avoidcontactingthehotengineoilwhenyou
drainit.
OilType:Detergentoil(APIserviceSJorhigher)
CrankcaseCapacity:1.1L(37oz)
Viscosity:Seetablebelow
g013375
Figure16
1.Parkthemachineonalevelsurface,disengage
thecuttingblades,shutofftheengine,andwait
forallmovingpartstostop,andturntheengine
switchtotheOFFposition.
2.Disconnectthewirefromthesparkplug.
3.Raisethefrontwheelsafewinchesoffthe
groundandplaceapanunderthedrainplugto
catchtheoil.
4.Removethedrainplug(Figure17).
g019428
Figure17
1.Drainplug
5.Whentheoilhasdrainedcompletely,lowerthe
frontwheelstotheground,replacethedrain
plug,andtorqueto17N∙m(13ft-lb).
Note:Disposeoftheusedoilatacertied
recyclingcenter.
6.Removethedipstickandslowlypouroilintothe
llerholeuntiltheoillevelreachesthemiddleof
thedipstick(Figure15).
7.Replaceandsecurethedipstick.
8.Wipeupanyspilledoil.
9.Connectthewiretothesparkplug.
CleaningtheSedimentCup
ServiceInterval:Every100hours
DANGER
Incertainconditions,fuelisextremely
ammableandhighlyexplosive.Areor
explosionfromfuelcanburnyouandothers
andcandamageproperty.
•Shutofftheengineandkeepheat,sparks,
andameaway.
•Handlefuelonlyoutdoors.
•Wipeupspillsimmediately.
•Donotsmokewhilehandlingfuel.
1.Parkthemachineonalevelsurface,disengage
thecuttingblades,shutofftheengine,andwait
forallmovingpartstostop,andturntheengine
switchtotheOFFposition.
2.Disconnectthewirefromthesparkplug.
3.MovethefuelshutoffvalvetotheOffposition.
18

4.RemovethesedimentcupandO-ring(Figure
18).
g020282
Figure18
1.O-ring2.Sedimentcup
5.Washthesedimentcupinanonammable
solventanddryitthoroughly.
6.PlacetheO-ringinthefuelvalveandinstallthe
sedimentcup,tighteningitsecurely.
7.MovethefuelshutofflevertotheOnposition.
Ifanyfuelleaks,repeatthisprocedureand
replacetheO-ring.
ServicingtheSparkPlug
ServiceInterval:Every100hours—Inspect,clean,
andadjustthesparkplug;replaceit
ifnecessary.
Every200hours—Replacethesparkplug.
Type:NGKBPR6ESorequivalent.
AirGap:0.76mm(0.03inch)
RemovingtheSparkPlug
1.Parkthemachineonalevelsurface,disengage
thecuttingblades,shutofftheengine,andwait
forallmovingpartstostop,andturntheengine
switchtotheOFFposition.
2.Disconnectthewirefromthesparkplug.
3.Cleantheareaaroundthebaseoftheplug(s)to
keepdirtanddebrisoutoftheengine.
4.Removethesparkplug(s)asshowninFigure
19.
g027478
Figure19
CheckingtheSparkPlug
Important:Donotcleanthesparkplug(s).
Alwaysreplacethesparkplug(s)whenithasa
blackcoating,wornelectrodes,anoilylm,or
cracks.
Ifyouseelightbrownorgrayontheinsulator,the
engineisoperatingproperly.Ablackcoatingonthe
insulatorusuallymeanstheaircleanerisdirty.
Setthegapto0.76mm(0.03inch).
g206628
Figure20
InstallingtheSparkPlug
1.Carefullyinstallthesparkplugbyhand(toavoid
crossthreading)untilitishandtight.
2.Tightenthesparkpluganadditional1/2turnif
itisnew;otherwise,tightenitanadditional1/8
to1/4turn.
Important:Aloosesparkplugcanbecome
veryhotandcandamagetheengine;
overtighteningasparkplugmaydamagethe
threadsinthecylinderhead.
3.Connectthewiretothesparkplug.
19

BeltMaintenance
CheckingtheBeltTension
ServiceInterval:Beforeeachuseordaily—Check
thebelttension.Iftheengineis
workingbutthecuttingblades
seemunderpowered,checkthebelt
tension.
1.Parkthemachineonalevelsurface,disengage
thecuttingblades,shutofftheengine,andwait
forallmovingpartstostop,turntheengine
switchtotheOFFposition,andraisethecutting
bladestothetransportposition.
2.Disconnectthewirefromthesparkplug.
3.Stopthemachineonalevelsurface,stopthe
enginebyreleasingtheoperatorpresencebail,
disconnectthespark-plugwire,
4.Removethe4boltssecuringthebeltcoverto
theleftsideofthemachineandremovethe
cover(Figure21).
g020749
Figure21
1.Belt3.Bolts
2.Cover
5.Checkthetensionofthebelt(Figure21).
Note:Thebeltshouldnotexmorethana12
mm(1/2inch)withmoderatengerpressure
appliedtothespanjustabovethemachine
frame.
6.Ifthebelttensionisloose,refertoAdjustingthe
BeltT ension(page20).
7.Installthebeltcoverbeforeoperatingthe
machine.
AdjustingtheBeltTension
1.Totightenthebelt,loosenthe4mountingnuts
securingtheenginetotheframe.
g019740
Figure22
1.Mountingnuts
2.Movetheenginetotightenthebelttotheproper
tension.
3.Securethe4mountingnutsandbolts.
Note:T orquetheboltsthatsecuretheengine
totheframe271N∙m(200in-lb).
20
Other manuals for 23511
1
Table of contents
Other Toro Seeder manuals
Popular Seeder manuals by other brands

Sumo
Sumo Rippa Operator's manual

Terradonis
Terradonis JP3 user manual

John Shearer
John Shearer Pasture Renovation Drill Operator's manual

LELY
LELY LOTUS 460 Stabilo Operator's manual

Gaspardo
Gaspardo PENTA PE Series Use and maintenance

Meridian
Meridian Bulk Seed Tender Seed Express 225RST Operator's manual

Seederman
Seederman GS2 Owners Manual and Operating Guide

Land Pride
Land Pride FPS48 Specifications & Capacities

Gaspardo
Gaspardo CHRONO 300 Use and maintenance

Prodana Seeds
Prodana Seeds Proseeder HP600 operating instructions

Gaspardo
Gaspardo DAMA Use and maintenance

Field Tuff
Field Tuff ATV-CBP owner's manual
