Toro Power Max e24 User manual

FormNo.3450-407RevA
PowerMax®e2460VSnowthrower
39924
LanzanievesPowerMax®e2460V
39924
SoufeuseàneigePowerMax®e24de60V
39924
www.T oro.com.*3450-407*

FormNo.3450-403RevA
PowerMax®e2460VSnowthrower
ModelNo.39924—SerialNo.411343295andUp
Operator'sManual
Introduction
Thismachineisintendedtobeusedbyresidential
homeowners.Itisdesignedprimarilyforremoving
snowfrompavedsurfaces,suchasdrivewaysand
sidewalks,andothersurfacesfortrafconresidential
orcommercialproperties.Itisnotdesignedfor
removingmaterialsotherthansnow.Itisdesignedto
useToroFlex-Forcelithium-ionbatterypackModel
88675(2providedwithModel39924),88660,88650,
88640,88625,or88620.Thesebatterypacksare
designedtobechargedonlybybatterycharger
Models88602(providedwithModel39926),88605,
or88610.Usingthisproductforpurposesotherthan
itsintendedusecouldprovedangeroustoyouand
bystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.T oro.comforproductsafetyandoperation
trainingmaterials,accessoryinformation,helpnding
adealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.
g344085
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420Registeratwww.T oro.com.
OriginalInstructions(EN)
PrintedinMexico
AllRightsReserved*3450-403*

WARNING
CALIFORNIA
Proposition65Warning
Thepowercordonthisproductcontains
lead,achemicalknowntotheState
ofCaliforniatocausebirthdefects
orotherreproductiveharm.Wash
handsafterhandling.
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Contents
Introduction...............................................................1
Safety.......................................................................3
SafetyandInstructionalDecals..........................6
Setup........................................................................9
1MountingtheBatteryCharger
(Optional)........................................................9
2InstallingtheUpperHandle..............................9
3InstallingtheChute........................................10
4InstallingtheTraction-ControlLinkage...........10
5InstallingtheChute-ControlRod.....................11
6InstallingtheSnow-CleanoutT ool..................12
7CheckingtheTirePressure............................13
8CheckingtheSkidsandScraper....................14
9AdjustingtheAuger/ImpellerCable................14
10CheckingtheOperationoftheTraction
Drive.............................................................14
ProductOverview...................................................15
Specications..................................................16
Attachments/Accessories.................................16
Operation................................................................16
BeforeOperation.................................................16
InstallingtheBatteryPack................................16
CheckingtheStateofCharge...........................17
DuringOperation.................................................17
StartingtheMachine.........................................17
ActivatingECOMode.......................................17
ChargingtheBatteryPack................................18
OperatingtheTractionDrive.............................19
OperatingtheSpeedSelector...........................19
OperatingtheAuger/ImpellerDrive...................19
OperatingtheQuickStick®...............................20
ClearingaCloggedDischargeChute................21
OperatingTips.................................................21
AfterOperation....................................................22
ShuttingOfftheMachine..................................22
RemovingtheBatteryPackfromthe
Machine........................................................22
PreventingFreeze-upafterUse........................22
Maintenance...........................................................23
RecommendedMaintenanceSchedule(s)...........23
PreparingforMaintenance...............................23
CheckingandAdjustingtheSkidsand
Scraper.........................................................23
CheckingandAdjustingtheTraction
Cable............................................................24
CheckingandAdjustingtheAuger/Impeller
Cable............................................................25
CheckingtheAuger-Gearbox-OilLevel.............26
LubricatingtheHexShaft..................................26
AdjustingtheDischarge-ChuteLatch................27
ReplacingtheDriveBelts..................................27
Storage...................................................................28
StoringtheMachine..........................................28
Troubleshooting......................................................29
2

Safety
WARNING—Whenusinganelectricmachine,always
readandfollowbasicsafetywarningsandinstructions
toreducetheriskofre,electricshock,orinjury,
includingthefollowing:
READALLINSTRUCTIONS
WARNING—Whenusinganelectricalmachine,
basicsafetyprecautionsshouldalwaysbefollowed
toreducetheriskofre,electricshock,orinjury,
includingthefollowing:
I.Training
1.Theoperatorofthemachineisresponsiblefor
anyaccidentsorhazardsoccurringtoothersor
theirproperty.
2.Readandunderstandthecontentsofthis
Operator’sManualbeforeyoustartthemachine.
Ensurethateveryoneusingthismachineknows
howtouseit,knowshowtoshutitoffquickly,
andunderstandsthewarnings.
3.Donotallowchildrentouseorplaywiththe
machine,batterypack,orthebatterycharger;
localregulationsmayrestricttheageofthe
operator.
4.Donotallowchildrenoruntrainedpeopleto
operateorservicethisdevice.Allowonlypeople
whoareresponsible,trained,familiarwiththe
instructions,andphysicallycapabletooperate
orservicethedevice.
5.Beforeusingthemachine,batterypack,and
batterycharger,readalltheinstructionsand
cautionarymarkingsontheseproducts.
6.Becomefamiliarwiththecontrolsandproper
useofthemachine,batterypack,andbattery
charger.
II.Preparation
1.Keepbystandersandchildrenoutofthe
operatingarea.
2.Neverallowchildrentooperatethemachine.
3.Donotoperatethemachinewithoutallguards
andsafetydevicesinplaceandfunctioning
properlyonthemachine.
4.Inspecttheareawhereyouwillusethemachine
andremoveallobjectsthatcouldinterferewith
theoperationofthemachineorthatthemachine
couldthrow.
5.UseonlythebatterypackspeciedbyToro.
Usingotheraccessoriesandattachmentsmay
increasetheriskofinjuryandre.
6.Pluggingthebatterychargerintoanoutletthat
isnot120Vcancauseareorelectricshock.
Donotplugthebatterychargerintoanoutlet
otherthan120V.
7.Donotuseadamagedormodiedbattery
packorbatterycharger,whichmayexhibit
unpredictablebehaviorthatresultsinre,
explosion,orriskofinjury.
8.Ifthesupplycordtothebatterychargeris
damaged,contactanAuthorizedServiceDealer
toreplaceit.
9.Donotusenon-rechargeablebatteries.
10.Chargethebatterypackwithonlythebattery
chargerspeciedbyToro.Achargersuitablefor
1typeofbatterypackmaycreateariskofre
whenusedwithanotherbatterypack.
11.Chargethebatterypackinawell-ventilatedarea
only.
12.Donotexposeabatterypackorbatterycharger
toreortotemperatureshigherthan68°C
(154°F).
13.Followallcharginginstructionsanddo
notchargethebatterypackoutsideofthe
temperaturerangespeciedintheinstructions.
Otherwise,youmaydamagethebatterypack
andincreasetheriskofre.
14.Dressproperly—Wearappropriateclothing,
includingeyeprotection;longpants;substantial,
slip-resistantrubberboots;andhearing
protection.Tiebacklonghairanddonotwear
looseclothingorloosejewelrythatcanget
caughtinmovingparts.
III.Operation
1.Contactwiththemovingrotorwillcauseserious
injury.Keepyourhandsandfeetawayfromall
movingpartsofthemachine.Keepclearofany
dischargeopening.
2.Staybehindthehandlesandawayfromthe
dischargeopeningwhileoperatingthemachine.
3.Usingthismachineforpurposesotherthanits
intendedusecouldprovedangeroustoyouand
bystanders.
4.Preventunintentionalstarting—Ensurethatthe
electric-startkeyisremovedfromthekeyswitch
beforeconnectingthebatterypackandhandling
themachine.
5.Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
6.Disengageallclutchesandshiftintoneutral
beforestartingthemachine.
7.Stopthemachine,removetheelectric-startkey,
removethebatterypackfromthemachine,and
3

waitforallmovementtostopbeforeadjusting,
servicing,cleaning,orstoringthemachine.
8.Removethebatterypackandelectric-start
keyfromthemachinewheneveryouleaveit
unattendedorbeforechangingaccessories.
9.Donotforcethemachine—Allowthemachineto
dothejobbetterandsaferattherateforwhichit
wasdesigned.
10.Stayalert—Watchwhatyouaredoinganduse
commonsensewhenoperatingthemachine.
Donotusethemachinewhileill,tired,orunder
theinuenceofalcoholordrugs.
11.Operatethemachineonlyingoodvisibilityand
appropriateweatherconditions.
12.Useextremecautionwhenreversingorpulling
themachinetowardyou.
13.Keepproperfootingandbalanceatalltimes,
especiallyonslopes.Useextremecautionwhen
changingdirectionsonslopes.Donotoperate
themachineonexceedinglysteepslopes.Walk,
neverrunwiththemachine.
14.Whennotactivelyclearingsnow,disengage
powertotheauger.
15.Donotdirectthedischargematerialtoward
anyone.Avoiddischargingmaterialagainsta
wallorobstruction;materialmayricochettoward
you.Stopthemachinewhencrossinggravel
surfaces.
16.Exerciseextremecautionwhenoperatingthe
machineonorcrossinggraveldrives,walks,or
roads.Stayalertforhiddenhazardsortrafc.
17.Ifthemachinestrikesanobjectorstartsto
vibrate,immediatelyshutoffthemachine,
removethekey,removethebatterypack,and
waitforallmovementtostopbeforeexamining
themachinefordamage.Makeallnecessary
repairsbeforeresumingoperation.
18.Shutoffthemachinewheneveryouleavethe
operatingpositionforanyreason.
19.Shutoffthemachineandremovethekeybefore
uncloggingthemachineandalwaysuseastick
oracleanouttooltoremovetheclog.
20.Stopthemachineandremovetheelectric-start
keybeforeloadingthemachineforhauling.
21.Underabusiveconditions,thebatterypackmay
ejectliquid;avoidcontact.Ifyouaccidently
comeintocontactwiththeliquid,ushwith
water.Iftheliquidcontactsyoureyes,seek
medicalhelp.Liquidejectedfromthebattery
packmaycauseirritationorburns.
22.Neveroperatethemachineathightransport
speedsonslipperysurfaces.
IV.MaintenanceandStorage
1.Stopthemachine,removetheelectric-startkey,
removethebatterypackfromthemachine,and
waitforallmovementtostopbeforeadjusting,
servicing,cleaning,orstoringthemachine.
2.Donotattempttorepairthemachineexceptas
indicatedintheinstructions.HaveanAuthorized
ServiceDealerperformserviceonthemachine
usingidenticalreplacementparts.
3.Wearglovesandeyeprotectionwhenservicing
themachine.
4.Whenservicingtherotor,beawarethattherotor
canstillmoveeventhoughthepowersource
isoff.
5.Forbestperformance,useonlygenuineT oro
replacementpartsandaccessories.Other
replacementpartsandaccessoriescouldbe
dangerous,andsuchusecouldvoidtheproduct
warranty.
6.Maintainthemachine—Keephandlesdry,clean,
andfreefromoilandgrease.Keepguards
inplaceandinworkingorder.Useidentical
replacementpartsonly.
7.Checkallfastenersatfrequentintervalsfor
propertightnesstoensurethatthemachineisin
safeworkingcondition.
8.Checkthemachinefordamagedparts.Check
formisalignedandbindingmovingparts,broken
parts,mounting,andanyotherconditionthat
mayaffectitsoperation.Unlessindicatedinthe
instructions,haveanAuthorizedServiceDealer
repairorreplaceadamagedguardorpart.
9.Whenthebatterypackisnotinuse,keepit
awayfrommetalobjectssuchaspaperclips,
coins,keys,nails,andscrewsthatcanmakea
connectionfrom1terminaltoanother.Shorting
thebatteryterminalsmaycauseburnsorare.
10.Whenyouarenotusingthemachine,storeit
indoorsinadry,secureplaceoutofthereach
ofchildren.
11.Whenstoringthemachineformorethan30
days,refertoStorage(page28)forimportant
information.
12.CAUTION—Amistreatedbatterypackmay
presentariskofreorchemicalburn.Donot
disassemblethebatterypack.Donotheatthe
batterypackabove68°C(154°F)orincinerate
it.ReplacethebatterypackwithagenuineT oro
batterypackonly;usinganothertypeofbattery
packmaycauseareorexplosion.Keep
batterypacksoutofthereachofchildrenand
intheoriginalpackaginguntilyouarereadyto
usethem.
4

13.Donotdisposeofthebatteryinare.The
cellmayexplode.Checkwithlocalcodesfor
possiblespecialdisposalinstructions.
SAVETHESE
INSTRUCTIONS
5

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal94-8072
94-8072
decal121-6817
121-6817
1.Cutting/dismembermenthazardofhandorfoot,impeller
andauger—keepbystandersaway.
decal121-6823
121-6823
1.Fast3.Slow
2.Forwardspeeds4.Reversespeeds
decal137-6198
137-6198
1.Cutting/dismemberment
hazardofthengersor
hand,impeller—donot
placeyourhandinthe
chute.
2.Warning—shutoffthe
motorbeforeusingthetool
toclearthechute.
6

decal137-6249
137-6249
1.Squeezethelevertoengagethetractiondrive.4.Cutting/dismembermentofngersorhand,impeller
blade—keepawayfrommovingparts;keepallguardsand
shieldsinplace;removethekeyfromtheignitionbefore
servicingthemachine.
2.Warning—readtheOperator’sManual.5.Thrownobjecthazard—keepbystandersaway.
3.Cutting/dismembermentofngersorhand,impellerblade—do
notplaceyourhandinthechute;shutoffthemotorbefore
usingthetooltoclearthechute.
6.Squeezethelevertoengagetheimpeller.
decal137-9462
137-9462
decal137-9463
137-9463
1.Thebatterypackischarging.
2.Thebatterypackisfullycharged.
3.Thebatterypackisoverorundertheappropriatetemperaturerange.
4.Batterypackchargingfault
7

decal137-9456
137-9456
1.ReadtheOperator’s
Manual.
3.Donotexposetorain.
2.Keepawayfromopenre
orames.
decal137-9461
137-9461
1.Batterychargestatus
decal133-8061
133-8061
8

Setup
Important:Thebatterypackisnotfullychargedwhenyoupurchaseit.Beforeusingthemachinefor
thersttime,refertoChargingtheBatteryPack(page18).
1
MountingtheBatteryCharger(Optional)
Partsneededforthisprocedure:
2Mountinghardware(notincluded)
Procedure
Ifdesired,mountthebatterychargersecurelyonawallusingthewall-mountkeyholesonthebackofthe
charger.
Mountitindoors(suchasagarageorotherdryplace),nearapoweroutlet,andoutofthereachofchildren.
RefertoFigure3forassistanceinmountingthecharger.
Slidethechargerovertheappropriatelypositionedhardwaretosecurethechargerinplace(hardwarenot
included).
g290534
Figure3
9

2
InstallingtheUpperHandle
NoPartsRequired
Procedure
g344102
3
InstallingtheChute
NoPartsRequired
Procedure
g344087
10

4
InstallingtheTraction-ControlLinkage
NoPartsRequired
Procedure
g344089
11

5
InstallingtheChute-ControlRod
NoPartsRequired
Procedure
g344086
12

6
InstallingtheSnow-CleanoutTool
NoPartsRequired
Procedure
g344095
7
CheckingtheTirePressure
NoPartsRequired
Procedure
g344084
13

8
CheckingtheSkidsand
Scraper
NoPartsRequired
Procedure
RefertoCheckingandAdjustingtheSkidsand
Scraper(page23).
9
Adjustingthe
Auger/ImpellerCable
NoPartsRequired
Procedure
Checkandadjusttheauger/impellercablebefore
rstuse;refertoCheckingandAdjustingthe
Auger/ImpellerCable(page25).
10
CheckingtheOperationof
theTractionDrive
NoPartsRequired
Procedure
CAUTION
Ifthetractiondriveisnotproperlyadjusted,
themachinemaymoveinthedirection
oppositeofwhatyouintended,causinginjury
and/orpropertydamage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Startthemachine;refertoStartingtheMachine
(page17).
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector(page19).
3.Squeezetheleft(traction)levertothehandgrip
(Figure10).
g001011
Figure10
Themachineshouldmoverearward.Ifthe
machinedoesnotmoveormovesforward,
completethefollowing:
A.Releasethetractionleverandshutoffthe
machine;refertoShuttingOfftheMachine
(page22).
B.Disconnectthetrunnionfromthe
speed-selectorlever.
C.Turnthetrunniondownward(clockwise)on
thespeed-controlrod.
D.Connectthetrunniontothespeed-selector
lever.
4.Releasethetractionlever.
5.MovethespeedselectortoPosition1;referto
OperatingtheSpeedSelector(page19).
6.Squeezetheleft(traction)levertothehandgrip
(Figure10).
Themachineshouldmoveforward.Ifthe
machinedoesnotmoveormovesrearward,
completethefollowing:
A.Releasethetractionleverandshutoffthe
machine.
B.Disconnectthetrunnionfromthe
speed-selectorlever.
C.Turnthetrunnionupward(counterclockwise)
onthespeed-controlrod.
D.Connectthetrunniontothespeed-selector
lever.
7.Ifyoumadeanyadjustments,repeatthis
procedureuntilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthe
tractionleverisinthereleasedposition,checkthe
tractioncable;refertoCheckingandAdjusting
theTractionCable(page24)ortakethemachine
toanAuthorizedServiceDealerforservice.
14

ProductOverview
g372038
Figure11
1.Handgrip(2)10.Dischargechute
2.Auger/impellerlever11.Scraper
3.Lockswitch12.Auger
4.Speed-selectorlever13.Skid(2)
5.QuickStick®
discharge-chutecontrol
14.Controlpanel
6.Tractionlever15.Secondary
battery-compartment
lid
7.Mainbattery-compartment
lid
16.Snow-cleanouttool
8.Electric-startkey17.Headlight
9.Chutedeector
g347780
Figure12
1.Batterychargelights3.KeyswitchinOFFposition
2.ECObutton
g344092
Figure13
1.Snow-cleanouttool(attachedtothehandle)
g360884
Figure14
1.BatterychargerModel
88602(includedwith
Model39924)
3.BatterypackModel88625
(notincluded)
2.BatterypackModel88675
(includedwithModel
39924)
15

Specications
ModelWeightLengthWidthHeight
78kg142cm62.5cm111.8cm
39924(172lb)(56
inches)
(24.6
inches)
(44.0
inches)
BatteryPack
Model88675
7.5Ah
Batterypackcapacity405Wh
Batterymanufacturerrating=60Vmaximumand54Vnominal.
Actualvoltagevarieswithload.
BatteryCharger
Model88602
Type60VMAXLithium-IonBatteryCharger
Input120VAC50/60HzMax2.0A
Output60VMAXDC2.0A
AppropriateTemperatureRanges
Charge/storethebatterypack
at
5°C(41°F)to40°C(104°F)*
Usethebatterypackat-30°C(-22°F)to49°C(120°F)*
Usethemachineat-30°C(-22°F)to49°C(120°F)*
*Chargingtimewillincreaseifyoudonotchargethe
batterywithinthisrange.
Storethemachine,batterypack,andbatterycharger
inanenclosedclean,dryarea.
Attachments/Accessories
AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedT oro
distributororgotowww.T oro.comforalistofall
approvedattachmentsandaccessories.
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineToro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
BeforeOperation
InstallingtheBatteryPack
1.Ensurethattheventsonthebatterypacksare
clearofanydustanddebris.
2.Liftupthebattery-compartmentlid.
3.Lineupthecavityinthebatterypackwiththe
tongueonthemachineandslidethebattery
packintothecompartmentuntilitlockintoplace
(Figure9).
4.Closethebattery-compartmentlid.
5.Repeatfortheother2batterycavities(if
needed).
Note:Thecombinedamphoursofallthe
installedbatteriesmustaddupto6.0orgreater,
otherwisethemachinecannotstart.
Note:Ifthebattery-compartmentliddoesnot
closecompletely,thebatteryisnotfullyinstalled.
g348180
Figure15
16

CheckingtheStateof
Charge
Youcanviewtheexactstateofchargeofeach
installedbattery;turnthekeytotheACCESSORY
position(Figure16).Thepositionofeachsetoflights
correspondstotherelatedbatterycavity.Ifthebattery
stateofchargeistoolowandneedstobecharged,or
ifthereisnobatteryinthecorrespondingcavity,the
batterypresencelightdoesnotturnon.
g348182
Figure16
1.State-of-chargelights3.Keyswitchinthe
ACCESSORYposition
2.Batterypresencelights
DuringOperation
StartingtheMachine
Note:Usethebatterypackonlyintemperatures
thatarewithintheappropriaterange;referto
Specications(page16).
1.Ensurethatthebatterypack(s)areinstalledin
themachine;refertoInstallingtheBatteryPack
(page16).
2.Inserttheelectric-startkeyintothecontrolpanel
3.TurnthekeytotheRUNpositiontoturnonthe
machine(Figure17).
g347864
Figure17
1.KeyswitchinONposition
ActivatingECOMode
UsingECOmodemayextendbatterylifebyreducing
rotorspeed;useECOmodewheneveryouare
movinglightsnow,ormovingsnowashortdistance.
ActivateECOmodeusingtheECObuttonasshown
inFigure18.
g347866
Figure18
1.ECOmodebutton
17

ChargingtheBatteryPack
Important:Thebatterypackisnotfullycharged
whenyoupurchaseit.Beforeusingthetoolfor
thersttime,placethebatterypackinthecharger
andchargeituntiltheLEDdisplayindicatesthe
batterypackisfullycharged.Readallsafety
precautions.
Important:Chargethebatterypackonlyin
temperaturesthatarewithintheappropriate
range;refertoSpecications(page16).
Note:Atanytime,pressthebattery-charge-indicator
buttononthebatterypacktodisplaythecurrent
charge(LEDindicators).
1.Ensurethattheventsonthebatteryandcharger
areclearofanydustanddebris.
g290533
Figure19
1.Batterypackcavity5.LEDindicators(current
charge)
2.Batterypackventingareas6.Handle
3.Batterypackterminals7.ChargerLEDindicator
light
4.Battery-charge-indicator
button
8.Chargerventingareas
2.Lineupthecavityinthebatterypack(Figure19)
withthetongueonthecharger.
3.Slidethebatterypackintothechargeruntilitis
fullyseated(Figure19).
4.Toremovethebatterypack,slidethebattery
backwardoutofthecharger.
5.RefertothefollowingtabletointerprettheLED
indicatorlightonthebatterycharger.
Indicator
light
Indicates
OffNobatterypackinserted
Green
blinking
Batterypackischarging
GreenBatterypackischarged
RedBatterypackand/orbatterychargerisoverorunder
theappropriatetemperaturerange
Red
blinking
Batterypackchargingfault*
*RefertoTroubleshooting(page29)formore
information.
Important:Thebatterycanbeleftonthecharger
forshortperiodsbetweenuses.
Ifthebatterywillnotbeusedforlongerperiods,
removethebatteryfromthecharger;referto
Storage(page28).
18
