Torus Power AVR Series User manual

AVR Series Manual
Audio / Video Power Isolation Units
with Automatic Voltage Regulation
19” Pro Series Rack Mount (RK) Faceplate
17” Consumer Series (C) Faceplate
Available in Black (B) and Silver (S) Colours
™
Isolate.
Protect.
Inspire!

Table of Contents
Table of Contents
Torus Power AVR Series Power Conditioners -
User Notes and Manual
Front Panel Display
Rear Panel Connections and AVR Software
AVR Software - Menu Selection
Block Diagram - AVR System
Schematic North American Model
Schematic International Model
North American Model Numbers
International Model Numbers
Typical front Panel Layout of
North American and International Models
Electrical Specifications North American Models
Mechanical Specifications North American Models
Line Cords and Wall Receptacles for
North American Models
Rear Panel Layout of North American Models
Electrical Specifications International Models
Mechanical Specifications International Models
Page 1
Page 3
Page 4
Page 5
Page 6,7,8
Page 9
Page 10
Page 10
Page 11
Page 11
Page 12
Page 12
Page 12
Page 13
Page 13
Page 14
Page 14
Page 1
Rear Panel Layout of International Models Page 15
Important Safety Instructions Page 2
Shipping Carton & Packing Material Page 2
Home Automation Interface Page 16
Warranty Page 16
Layout Page 9
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Important Safety Instructions
Please keep the original shipping box and all packing material.
This will ensure the AVR is protected in future transport.
In the unlikely event you have a problem and must return it for
service you must use the original packing material.
Ship the AVR only in the original packing material, as the unit
is not insurable by carriers otherwise.
Shipping Carton & Packing Material
CAUTION!
CAUTION!
CAUTION!
CAUTION!
To reduce the risk of electric shock and fire, do not remove the cover of this device. There
are no user serviceable parts inside. Please refer all servicing to licensed service technicians.
The international symbol of a lightning bolt inside a triangle is intended to alert the user to
uninsulated “dangerous voltage” within the device’s enclosure. The international symbol of an
exclamation point inside a triangle is intended to alert the user to the presence of important
operating, maintenance and servicing information in the manual accompanying the device.
To prevent electrical shock, match wide blade of plug to wide slot, fully insert.
To reduce the risk of electrical shock, do not expose this equipment to rain or moisture.
1. Read Instructions—All safety and operating instructions
should be read before operating the device.
2. Retain Instructions—The safety and operating
instructions should be retained for future reference.
3. Heed Warnings—All warnings on the device and in the
operating instructions should be adhered to.
4. Follow Instructions—All operating and safety instructions
should be followed.
5. Water & Moisture—The device should never be used in,
on or near water for risk of fatal shock.
6. Ventilation—The device should always be located in such
a way that it maintains proper ventilation. It should never
be placed in a built-in installation or anywhere that may
impede the flow of air through its ventilation slots.
7. Heat—Never locate the device near heat sources such as
radiators, floor registers, stoves or other heat-generating
devices.
8. Power Cord Protection—Power cables should be routed
so they are not likely to be stepped on or crushed by items
placed on them or against them. Special attention should
be paid to areas where the plug enters a socket or fused
strip and where the cord exits the device.
9. Periods Of Non-Use—The device should be unplugged
when not being used for extended periods.
10. Dangerous Entry—Care should be taken that no foreign
objects or liquids fall or are spilled inside the device.
11. Damage Requiring Service—The device should be
serviced by licensed technicians when:
• The plug or power supply cord has been damaged.
• Objects have fallen or liquid has spilled inside the device.
• The device has been exposed to moisture.
• The device does not appear to be operating properly or
exhibits a marked change in performance.
• The device has been dropped or the enclosure becomes
damaged.
12. Service—The device should always be serviced by
licensed technicians. Only replacement parts specified by
the manufacturer should be used. The use of unauthorized
substitutions may result in fire, shock, or other hazards.
13. Do not position the equipment so that it is difficult to
operate the disconnecting device (power cord).
14. If the equipment is used in a manner not specified by
the manufacturer, the protection provided by the
equipment may be impaired.
16. Some units can be very heavy, please use
safe practices when lifting.
15. The power switch should be in the “off” position when
connecting or disconnecting equipment from a Torus Power
unit.
CAUTION
³18 kg (39.7 lb) ³32 kg (70.5 lb) ³55 kg (121.2 lb)
Page 2
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Torus Power AVR Series Power Conditioners - User Notes and Manual
Placement and ventilation
Allow 1” distance on all sides when positioning the AVR for proper ventilation, and allow 6” behind the
AVR for adequate wiring space. Do not place heat-generating devices directly below the AVR.
Connecting components and using the AVR
Using the AVR is as simple as plugging in audio and video components to the outlets on the rear panel.
The order and position in which you connect your components will not affect the performance of the
AVR or your components. Connect the AVR to the wall outlet, and switch it on. Turn on the
components individually.
While the AVR has built-in software that can be accessed via the Ethernet connection, there is no need
for you to use this software. The AVR system provides all the standard features, performance, and
benefitsoutoftheboxbysimplypluggingitinasdescribedinthissection. YoucanusetheAVR
software to monitor the voltage conditions via your computer, and for such additional features as being
able toturn your system on/off remotely and change the duration of the displays backlight.
Torus AVR – Description
Torus Power AVR (Automatic Voltage Regulation) is a full-feature state-of-the-art power conditioner,
isolating and protecting your system. Like all Torus Power products, the AVR series provides true
isolation (using massive toroidal transformers) and protects all connected equipment from the risk of
severe power line surges using series-mode surge suppression. In addition, Torus AVR provides stable
voltage to keep equipment running in the optimal range of 115VAC to 125VAC for any input voltage
from 90V to 130VAC. (International units operate within nominal input voltage such as 220V, 230V,
240V; Torus AVR keeps them operating within a range of +/- 10V. ) See table on Page 9 for more
details.
Torus Power AVR series uses a micro-processor to monitor and control the power provided to
connected components. The front panel display on the Torus Power AVR indicates input and output
voltages, and displays output current, as well as displaying fault conditions.
The Torus Power AVR is pre-programmed to power down the system when a high or low fault
conditions occurs (user can over-ride).
There are multiple interfaces built into the Torus Power AVR:
1) Ethernet interface with built-in web server allows any computer to view voltage and current
readingsandturntheAVRunitonoroff.
2) RS-232 is provided for connection to media control systems.
3) Two 12V triggers are provided.
Does your system need automatic voltage regulation?
Under ideal conditions, when the supplied power line is stable and dependable, you may not need
voltage regulation. In such an ideal situation, your equipment can operate within the normal tolerance
ofthelinevoltage.
In reality, the power supplied to most areas is less than ideal due to 0utdated power grids. In most
areas, the power regularly drops or rises above the acceptable range (in North America +/– 5V,
Europe/Asia/Australia +/- 10V) . These voltage sags, brownouts, and surges can stress components
and shorten equipment life. In the worst case, catastrophic events can destroy valuable equipment. In
such real-world conditions, Torus Power AVR can protect your equipment, and improve the quality and
enjoyment of your audio and video experience.
Page 3
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Front Panel Display
Page 4
(If ethernet connection is used)
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Rear Panel Connections and AVR Software
Figure 1: AVR Rear Panel connections.
Ethernet
Allows access tothe AVR and internal software. See AVR Software section for more details.
RS232
Allows access to automation and external control. See Home Automation Interface commands at end
of manual.
12V Trigger On/Off
TheAVRcanbeturnedonandoffbya12volttriggerinput. Applying12voltsturnsontheAVRand
removing the 12 volts turns it off.
12V Fault Output
The AVR provides a 12 volt fault output through a jack on the back panel. The output goes to 12 volts
when a relay or voltage fault is detected. The maximum current that can be drawn from this output is
75 mA.
AVR Software
AVR software is resident in the microprocessor on the internal control board. There are two methods
to access the software.
1) Connect the AVR to the Ethernet port. Open a browser window on a PC that is connected to the
same network through another Ethernet port. Enter AVR (or the I.P address displayed on the LCD)
into the browser window. Press ENTER and the software will open.
2) Use a three way Hub, which is connected to an existing network. You then connect both PC and
AVR to the same Hub. Open a browser window from the PC. Type AVR, (or the I.P address displayed
on the LCD) into the browser window. Press ENTER and the software will open.
Username and Password
ThepasswordisrequiredtochangethesetupoftheTorusunit.
Username is admin This is factory set and cannot be changed
Password is avr This is the default password, and can be changed.
In case you forget your password, the AVR can be restored to the factory default password avr
by pressing and holding the button on the front panel for at least 10 seconds.
Page 5
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Page 6
AVR Software - Menu Selections
AVR Menu Selections
AVR Status
Switch Power
Setup
Email Configuration
Set Password
Torus Power Home (website)
Network configuration
Below is a screen by screen description of software options.
To access AVR software, enter user
name and password.
User name :
admin
is factory set and cannot be changed
Default Password :
avr
You can change your password.
Select Set Password
AVR Status
This screen indicates the overall status
of the system, showing Voltage In,
Voltage Out, and Current output.
It also reports if the system is
functioning normally or whether there
is a fault condition.
AVR Power Control
This screen allows ON or OFF control
of the AVR unit.
Press SET button to implement your
selection.
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Page 7
AVR Software - Menu Selections (continued)
AVR Setup
This screen allows the user to configure
two AVR parameters.
1. Shutdown on Low or High line
voltage. (The factory default is YES –
to shut down in case of fault
conditions.) Unselecting this button
will override, and the AVR will remain
on even if voltage drops or rises beyond
the acceptable range.
2. LCD Display. Always ON is the
defaultsetting. Ifyoudon’twantthe
display on all the time, you can select a
time from 0 to 255 seconds. When
you have made your selections, press
SAVE SETUP.
Email Fault Alert Notification
In the unlikely event your AVR
experiences an issue the AVR will shut
down and send an email notification if
this section is configured. After
entering the configuration parameters
use the ‘Send Test Email’ button to
confirm your settings are correct.
Set Password
If you wish to change the password, use
this screen.
In case your forget your new
password, you can restore the AVR to
factory default password by pressing
the button on the front of the AVR unit
and HOLDING it down for at least 10
seconds. The default password is avr
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

AVR Software - Menu Selections (continued)
Page 8
Each AVR unit has a unique MAC
Address which is factory assigned.
The IP address assigned to the AVR is
dynamically assigned and is displayed
on this screen as well as on the front
panel LCD of the AVR.
TheAVRcanbeprogrammedthrough
the web browser to automatically get an
IP address from the network switch or
router and this is the default setting
andshouldworkonmostnetworks.
Some networks require each PC or
device to use a fixed IP address and the
AVRalsosupportsthisoption.
Notes:
1. The output current (Amps) displayed on the LCD is the RMS reading of the load. It does
not indicate the peak current loads.
2. There is a 20-second delay built into the AVR system, to prevent nuisance switching. The
AVR will take approximately 20-seconds to change relay taps to switch to the proper
output voltage s etting.
3. North American models (15A, 20A):Torus AVR will keep the output constant within the
range of 115Volts to 125Volts, with an input voltage of 90V to 130V. Between 85V to
90V, and between 130V and 135V, the regulation will be reduced.
4. North American models (20A BAL):Torus AVR will keep the output constant within the
range of 115Volts to 125Volts, with an input voltage of 170V to 270V. Between 160V to
170V, and between 260V and 270V, the regulation will be reduced.
5. International models (4A, 8A and 16A):Torus AVR will keep the output constant within the
range of 240 ± 10Volts, with an input voltage of 170V to 270V. Between 160V to 170V,
and between 260V and 270V, the regulation will be reduced.
6. A drop in the Input voltage is normal when increasing the load on the Torus AVR. This is
a result of the impedance of the power line, and is a function of the distance from the
electrical panel.
Switch On Delay Feature
The Automatic Voltage Regulation (AVR) feature is designed to handle normal utility fluctuations
to provide the connected equipment with an optimal voltage supply. It is common when utility
power is restored after a blackout that the voltage supply is unstable for a few seconds. To
further protect connected equipment your AVR is equipped with a start up delay feature. When
the power switch is turned on or when the power switch is on and utility power is restored,
power will not be connected to the output receptacles until the delay time has passed.
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Block Diagram - AVR System
Layout
Note:
Layout drawing is
provided for reference
only, Torus Power AVR
units have no serviceable
parts inside. Please return
unit to manufacturer for
repair and service when
required.
Page 9
Power
Transformer
Potential
Transformer #1
Current
Transformer
Relay Board #1 (Top)
+
Relay Board #2 (Bottom)
Controller Board
Surge Protection Board
Power ON/OFF Switch
(Circuit Breaker)
IEC Inlet
Medical Grade Outlets
Input: 240V
Output: 120V 3.0A
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
Potential
Transformer #2
7
7
Available Models:
Model Nominal
Input
Operable
Input
Range
Output
North American 120V 85V-135V 120V±5V
International 220V 150V-250V 220V±10V
International 220V 160V-250V 230V±10V
International 230V 160V-260V 230V±10V
International 240V 170V-270V 240V±10V
North American
Balanced 240V 170V-270V 120V±5V
UST
REV.04/19/2012

Schematic North American Model
Schematic International Model
Note:
Schematic drawings are provided for reference only, Torus Power AVR
units have no serviceable parts inside. Please return unit to
manufacturer for repair and service when required.
Page 10
INPUT
120VAC
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

North American Model Numbers
19” Pro Series
Rack Mount(RM)
AVR 15 RK
AVR 20 RK
AVR 20 BAL RK
Description
Single 15A
Single 20A
Balanced 20A
Input
(Nominal)
120V
120V
240V
Output
Connector
10 outlets
Medical-grade
15A
10 outlets
Medical-grade
20A
10 outlets
Medical-grade
20A
17” Consumer
Series (CS)
AVR 15 CS
AVR 15 CB
AVR 20 CS
AVR 20 CB
AVR 20 BAL CS
AVR 20 BAL CB
International Model Numbers
19” Pro Series
Rack Mount(RM)
AVR4UKRK
AVR4CERK
AVR 4 AUS RK
AVR8UKRK
AVR8CERK
AVR 8 AUS RK
AVR 16 UK RK
AVR 16 CE RK
AVR 16 AUS RK
Description
International 4A
United Kingdom
International 4A
Continental Europe
International 4A
Australian
International 8A
United Kingdom
International 8A
Continental Europe
International 8A
Australian
International 16A
United Kingdom
International 16A
Continental Europe
International 16A
Australian
Input
(Nominal)
230V
230V
240V
230V
230V
240V
230V
230V
240V
Output
Connector
3 outlets
UK panel mount
socket
4 outlets 16A/250V
Ivory Continental
European Socket
3 outlets
Australian
Interpower Socket
5 outlets
UK panel mount
socket
5 outlets 16A/250V
Ivory Continental
European Socket
5 outlets
Australian
Interpower Socket
6 outlets
UK panel mount
socket
8 outlets 16A/250V
Ivory Continental
European Socket
5 outlets
Australian
Interpower Socket
17” Consumer Series
(CS)
AVR4UKCS
AVR4UKCB
AVR4CECS
AVR4CECB
AVR 4 AUS CS
AVR 4 AUS CB
AVR8UKCS
AVR8UKCB
AVR8CECS
AVR8CECB
AVR 8 AUS CS
AVR 8 AUS CB
AVR 16 UK CS
AVR 16 UK CB
AVR 16 CE CS
AVR 16 CE CB
AVR 16 AUS CS
AVR 16 AUS CB
Page 11
Output
(Nominal)
120V
120V
120V
*Note: For the Nominal Output Voltages of the International models please see table at the top of
page 9 under Block Diagram - AVR System.
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Electrical Specifications North American Models
Input Voltage
Nominal
Selectable 240VAC
(2 x 120VAC, balanced)
Factory wired for 240VAC 60Hz
Range +/- 10% voltage
57-63Hz
120VAC, 60Hz
Range +/- 10% voltage
57-63Hz
Model Number
AVR 20 BAL RK
AVR 20 BAL CS
AVR 20 BAL CB
AVR20RK
AVR20CS
AVR20CB
AVR15RK
AVR15CS
AVR15CB
Input
Current
Limiting
10A
Circuit Breaker
Front Panel
20A
Circuit Breaker
Front Panel
16A
Circuit Breaker
Front Panel
Input Current
Rating
(see note above)
10A
16A
12A
½ cycle
100A
400A
300A
Load Current Capability
1 second
80A
200A
150A
10 seconds
30A
100A
75A
Mechanical Specifications North American Models
Model Number
AVR 20 BAL RK
AVR 20 BAL CS
AVR 20 BAL CB
AVR20RK
AVR20CS
AVR20CB
AVR15RK
AVR15CS
AVR15CB
Input
Connector
(Rear Panel)
IEC 320-C20
Inlet
IEC 320-C20
Inlet
IEC 320-C14
Inlet
Line Cord
(included)
N6/15, 14AWG
C19, 15A/250V
N5/20, 12AWG
C19, 20A/125V
N5/15, 14AWG
C13, 15A/125V
Suggested
Wall
Receptacle
NEMA 6-15R
15A - 250V
NEMA 5-20R
20A - 125V
NEMA 5-15R
15A - 125V
Output
Connector
(Rear Panel)
Qty 5 (10 outlets)
Medical-grade
duplex 20A
Qty 5 (10 outlets)
Medical-grade
duplex 20A
Qty 5 (10 outlets)
Medical-grade
duplex 15A
Weight
45.7kg
100.5lbs
45.0kg
99lbs
45.7kg
100.5lbs
45.0kg
99lbs
20.9kg
46lbs
20.2kg
44.5lbs
Size (mm)
Size (inch)
(wxdxh)
483x565x159
19 x 22.25 x 6.25
432x556x162
17x22x6.4
483x565x159
19 x 22.25 x 6.25
432x556x162
17x22x6.4
483x489x102
19 x 19.25 x 4
432x480x105
17 x 18.9 x 4.13
Height includes rubber mounting feet
The front panel power switch is also a circuit breaker. As a circuit
breaker, it prevents excessive current from entering the AVR.
When the power is on, the Switch is illuminated. When the breaker
trips, the switch returns to its “off” position.
Circuit Protection
Torus AVRs will shut-down if internal unit
temperature reaches excessive levels.
Thermal Protection
Per UL, CSA and National Electrical codes, devices with
line cords and plugs must not consume more than 80%
of a branch circuit’s rating.
While Torus Power AVR Units are designed to handle
well beyond these limits, they must be marked with a
maximum input current that satisfies the requirements.
Input Current Rating
Typical Front Panel Layout of North American and International Models
19” Pro Series Rack Mount (RK)
Faceplate
17” Consumer Series (C) Faceplate
available in Black (B) and Silver (S)
LCD Display
Illuminated ON/OFF Switch / Circuit Breaker
Page 12
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Torus AVRs are high-power products. The outlets they are
plugged into should be sufficient to provide the current to operate
them without tripping circuit breakers within your junction panel.
Dedicated circuits are recommended. Balanced input products,
240VAC, require dual 120V phases (2 pole, 3-wire). Wall outlets
for 240VAC are rated at 250V and will likely require special
installation. Dedicated outlets, or any household or facility wiring
should be installed by a licenced electrician to local codes.
Pictured below are suggested receptacle types for installation.
NEMA 6-15R
for Balanced
20A unit
NEMA 5-20R
for Single
20A unit
NEMA 5-15R
for Single
15A unit
Line Cords and Wall Receptacles for North American Models
Standard 15A 240/208V
Used on: ,
AVR
Equipment end:
Plug:
Cord:
Length:
Model Numbers AVR 20 BAL RK
IEC C19
6-15P, Straight Blade, 2 pole,
3-wire grounding, 15A 250V
3 x 14AWG
2.5 m
20 BAL CS and AVR 20 BAL CB
Standard 20A 120V
Used on: ,
Equipment end:
Plug:
Cord:
Length:
Model Number AVR 20 RK
AVR
IEC C19
5-20P, Straight Blade, 2 pole,
3-wire grounding, 20A 125V
3 x 12AWG
2.5 m
20 CS and AVR 20 CB
Standard 15A 120V
Used on:
Equipment end:
Plug: -
Cord:
Length:
IEC C13
5 15P, Straight Blade, 2 pole,
3-wire grounding, 15A 125V
3 x 14AWG
2.5 m
Model Number AVR 15 RK,
AVR15CSandAVR15CB
Rear Panel Layout of North American Models
20A Medical Outlet
Power Inlet
Accessory
Ground Stud
15A Medical Outlet
Ethernet
RS232
12V Trigger
12V Fault
Rubber Mounting Feet
(may be removed if rack
mounting)
Single 15A, Model Number AVR 15 RK,
AVR15CSandAVR15CB
Single 20A, Model Number AVR 20 RK,
AVR20CSandAVR20CB
Balanced 20A, Model Number AVR 20 BAL RK,
AVR 20 BAL CS and AVR 20 BAL CB
20A Medical Outlet
Suggested Receptacles for Installation
Page 13
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Mechanical Specifications International Models
Height includes rubber mounting feet.
Input (Inlet) Connector
(Rear Panel)
IEC 320-C20
IEC 320-C14
IEC 320-C14
IEC 320-C20
IEC 320-C14
IEC 320-C14
IEC 320-C20
IEC 320-C14
IEC 320-C14
Output Connector
(Rear Panel)
6 outlets
(13A/250V UK
Socket)
5 outlets
(13A/250V UK
Socket)
3 outlets
(13A/250V UK
Socket)
8 outlets
(16A/250V Ivory
Continental European Socket)
5 outlets
(16A/250V Ivory
Continental European Socket)
4 outlets
(16A/250V Ivory
Continental European Socket)
5 outlets
(20A/250V Interpower
Socket AUS)
5 outlets
(10A/250V Interpower
Socket AUS)
3 outlets
(10A/250V Interpower
Socket AUS)
Weight
56 kg
55 kg
35 kg
34 kg
20 kg
19 kg
56 kg
55 kg
35 kg
34 kg
20 kg
19 kg
56 kg
55 kg
35 kg
34 kg
20 kg
19 kg
Size, mm
(wxdxh)
483 x 662 x 203
432 x 633 x 206
483 x 565 x 159
432 x 556 x 162
483 x 489 x 102
432 x 480 x 105
483 x 662 x 203
432 x 633 x 206
483 x 565 x 159
432 x 556 x 162
483 x 489 x 102
432 x 480 x 105
483 x 662 x 203
432 x 633 x 206
483 x 565 x 159
432 x 556 x 162
483 x 489 x 102
432 x 480 x 105
Model Number
AVR16UKRK
AVR16UKCB
AVR16UKCS
AVR8UKRK
AVR8UKCB
AVR8UKCS
AVR4UKRK
AVR4UKCB
AVR4UKCS
AVR16CERK
AVR16CECB
AVR16CECS
AVR8CERK
AVR8CECB
AVR8CECS
AVR4CERK
AVR4CECB
AVR4CECS
AVR16AUSRK
AVR16AUSCB
AVR16AUSCS
AVR 8 AUS RK
AVR 8 AUS CB
AVR 8 AUS CS
AVR 4 AUS RK
AVR 4 AUS CB
AVR 4 AUS CS
Electrical Specifications International Models
Input Voltage
Nominal
20VAC3
Range +/- 10% voltage
47-53Hz
230VAC
Range +/- 10% voltage
47-53Hz
240VAC
Range +/- 10% voltage
47-53Hz
Model Number
AVR16UKRK
AVR16UKCB
AVR16UKCS
AVR8UKRK
AVR8UKCB
AVR8UKCS
AVR4UKRK
AVR4UKCB
AVR4UKCS
AVR16CERK
AVR16CECB
AVR16CECS
AVR8CERK
AVR8CECB
AVR8CECS
AVR4CERK
AVR4CECB
AVR4CECS
AVR16AUSRK
AVR16AUSCB
AVR16AUSCS
AVR 8 AUS RK
AVR 8 AUS CB
AVR 8 AUS CS
AVR 4 AUS RK
AVR 4 AUS CB
AVR 4 AUS CS
Input Current
Limiting
16A Circuit Breaker
Front Panel
8A Circuit Breaker
Front Panel
4A Circuit Breaker
Front Panel
16A Circuit Breaker
Front Panel
8A Circuit Breaker
Front Panel
4A Circuit Breaker
Front Panel
16A Circuit Breaker
Front Panel
8A Circuit Breaker
Front Panel
4A Circuit Breaker
Front Panel
Input Current
Rating
16A
8A
4A
16A
8A
4A
16A
8A
4A
½ cycle
160A
80A
80A
160A
80A
80A
160A
80A
80A
Load Current Capability
1 second
96A
46A
20A
96A
46A
20A
96A
46A
20A
10 seconds
32A
16A
10A
32A
16A
10A
32A
16A
10A
Page 14
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Rear Panel Layout of International Models
16A/250V Ivory Continental European Socket
Power Inlet (IEC320-C14)
Accessory
Ground Stud
10A/250V Interpower Socket AUS
RS232
12V Trigger
12V Fault
Rubber Mounting Feet
(may be removed if rack
mounting)
Australian 8A, Model Number
, S and BAVR 8 AUS RK AVR 8 AUS C AVR 8 AUS C
Continental Europe
CE AVR 8 CE C AVR 8 CE C
8A, Model Number
AVR 8 RK, S and B
United Kingdom 8A, Model Number
AVR 8 UK RK, S and BAVR8UKC AVR8UKC
Ethernet
Australian 4A, Model Numbers
AVR 4 AUS RK, S and BAVR4AUSC AVR4AUSC
Continental Europe
CE AVR4CEC AVR4CEC
4A, Model Numbers
AVR 4 RK, S and B
United Kingdom 4A, Model Numbers
AVR 4 UK RK, S and BAVR4UKC AVR4UKC
Australian 16A, Model Number
AVR 16 AUS RK, S and BAVR 16 AUS C AVR 16 AUS C
Continental Europe
CE AVR16CEC AVR16CEC
16A, Model Number
AVR 16 RK, S and B
United Kingdom 16A, Model Number
AVR 16 UK RK, S and BAVR16UKC AVR16UKC
10A/250V Interpower Socket AUS
13A/250V UK Socket16A/250V Ivory Continental European Socket
13A/250V UK Socket
16A/250V Ivory Continental European Socket 13A/250V UK Socket
20A/250V Interpower Socket AUS
Page 15
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
Power Inlet (IEC320-C20)
REV.04/19/2012

Home Automation Interface
Serial Port Settings
9600 baud
8 data bits
No parity
Commands are terminated with the carriage return character (13 decimal).
Command Description Response
“C0<CR>” Turn off power “OK<CR>”
“C1<CR>” Turn on power “OK<CR>”
Other
commands
Not supported “ERROR<CR>
Torus Power products are warranted to be free from
manufacturing defects for five years from the original date of
sale. This includes parts, labour and return shipping to the
first registered owner and all subsequent registered owners.
Warranty coverage is extended to applicable products
registered or having proof-of-purchase (sales invoice, etc.).
In the event of a defect or malfunction, Torus Power will
remedy the problem by repair or replacement, as we deem
necessary, to restore the product to full performance.
This warranty is considered void if the defect, malfunction or
failure of the product or any component part was caused by
damage (not resulting from a defect or malfunction) or abuse
while in the possession of the customer. Failure to fully comply
with Torus Power operating instructions, voids the warranty.
Warranty
Page 16
www.TorusPower.com
Owner’s Manual AVR Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12Power Conditioners
™
REV.04/19/2012

Specifications subject to change without notice.
© Torus Power 2012
www.TorusPower.com
04/12
Torus Power
#8 601 Magnetic Drive
Toronto, ON M3J 3J2
Canada
416-667-9914
™
Torus Power products are
marketed worldwide through
Plitron Manufacturing Inc.
Phone: [phone]
Toll free: 1-800-754-8766
Fax: [phone]
For sales contact:
[email protected]
Technical inquiries:
[email protected]
Phone: [phone]
REV.04/19/2012
