Owner’s Manual
Model Number
RM 16 INT’L UK
Power Conditioners
Audio / Video Power Isolation Units
International Rack Mount / Standalone
Description
International 16A
United Kingdom
Output
Connector
6 outlets
(UK panel mount
socket)
Input
230/240V
™

Important Safety Instructions
CAUTION!
CAUTION!
CAUTION!
CAUTION!
CAUTION!
CAUTION!
To reduce the risk of electric shock and fire, do not remove the cover of this device. There
are no user serviceable parts inside. Please refer all servicing to licensed service technicians.
The international symbol of a lightning bolt inside a triangle is intended to alert the user to
uninsulated “dangerous voltage” within the device’s enclosure. The international symbol of an
exclamation point inside a triangle is intended to alert the user to the presence of important
operating, maintenance and servicing information in the manual accompanying the device.
To prevent electrical shock, match wide blade of plug to wide slot, fully insert.
To reduce the risk of electrical shock, do not expose this equipment to rain or moisture.
To reduce the risk of electrical shock, ensure the voltage selector switch is selected to the
appropriate supply voltage.
To reduce the risk of electrical shock, ensure the fuses are replaced with the appropriate
fuse according to the unit markings.
1. Read Instructions—All safety and operating instructions
should be read before operating the device.
2. Retain Instructions—The safety and operating
instructions should be retained for future reference.
3. Heed Warnings—All warnings on the device and in the
operating instructions should be adhered to.
4. Follow Instructions—All operating and safety instructions
should be followed.
5. Water & Moisture—The device should never be used in,
on or near water for risk of fatal shock.
6. Carts & Stands—The device should only be used on carts
or stands recommended by the manufacturer.
7. Ventilation—The device should always be located in such
a way that it maintains proper ventilation. It should never
be placed in a built-in installation or anywhere that may
impede the flow of air through its ventilation slots.
8. Heat—Never locate the device near heat sources such as
radiators, floor registers, stoves or other heat-generating
devices.
9. Power Cord Protection—Power cables should be routed
so they are not likely to be stepped on or crushed by items
placed on them or against them. Special attention should
be paid to areas where the plug enters a socket or fused
strip and where the cord exits the device.
10. Cleaning—The device should be cleaned in accordance
with manufacturer’s instructions.
11. Periods Of Non-Use—The device should be unplugged
when not being used for extended periods.
12. Dangerous Entry—Care should be taken that no foreign
objects or liquids fall or are spilled inside the device.
13. Damage Requiring Service—The device should be
serviced by licensed technicians when:
• The plug or power supply cord has been damaged.
• Objects have fallen or liquid has spilled inside the device.
• The device has been exposed to moisture.
• The device does not appear to be operating properly or
exhibits a marked change in performance.
• The device has been dropped or the enclosure becomes
damaged.
14. Service—The device should always be serviced by
licensed technicians. Only replacement parts specified by
the manufacturer should be used. The use of unauthorized
substitutions may result in fire, shock, or other hazards.
15. Do not position the equipment so that it is difficult to
operate the disconnecting device (power cord).
16. If the equipment is used in a manner not specified by
the manufacturer, the protection provided by the
equipment may be impaired.
17. Units in this series are heavier than 32 kg
(.5 lb). Use safe practices when lifting.
CAUTION
³32 kg (70.5 lb) ³55 kg (121.2 lb)
www.TorusPower.com
Owner’s Manual Audio / Video Power Isolation Units International UK Rack Mount / Standalone 03/09Power Conditioners
™

Torus Power PIUs (Power Isolation Units) combine the best
surge suppression with unique toroidal transformer
technologies from PLITRON to provide the ultimate in AC
power conditioning and protection for sensitive audio and
video equipment applications.
PIUs use ZeroSurge patented series-mode surge removal
filters to absorb dangerous voltage surges and safely dissipate
them without using failure-prone MOVs (metal oxide
varistors). Also, unlike MOV-based protection, voltage surges
are not shunted to ground.
Isolation is combined with proven proprietary technologies
from PLITRON in the over-sized toroidal transformer. NBT
works as a low pass filter using the controlled leakage
inductance and capacitances within the transformer to cancel
common mode and differential mode noise. LoNo technology
has been used for years by high-end audio companies who
demand silent transformers. Imin technology reduces inrush
currents. UST provides additional common mode filtering
using a highly efficient faraday screen.
Low-impedance output with balanced high-power primary
input provides the most unconstrained, yet protected, energy
source available to your equipment.
â
Description
Please keep the original shipping box and all packing material.
This will ensure the PIU is protected in future transport.
In the unlikely event you have a problem and must return it for
service you must use the proper packing material.
Ship the PIU only in the original packing material, as the unit is
not insurable by carriers otherwise.
Shipping Carton & Packing Material
Torus Power PIUs are extremely efficient devices, however,
they are also very high-power devices, and must be
adequately cooled.
Do not install the PIU directly above heat-generating
equipment.
Maintain at least 15cm behind the PIU for adequate wiring
space.
PIUs have ventilation slots on the base, side panels and the
cover. Maintain at least 2.5cm distance from each of these
surfaces to anything else. Should your installation conditions
be constricted, additional forced air-cooling may be
necessary.
Placement & Ventilation
Torus Power products are warranted to be free from
manufacturing defects for a minimum of five years from the
original date of sale. This includes parts, labour and return
shipping to the first registered owner and all subsequent
registered owners. Warranty coverage is extended to
applicable products registered or having proof-of-purchase
(sales invoice, etc.).
In the event of a defect or malfunction, Torus Power will
remedy the problem by repair or replacement, as we deem
necessary, to restore the product to full performance.
This warranty is considered void if the defect, malfunction or
failure of the product or any component part was caused by
damage (not resulting from a defect or malfunction) or abuse
while in the possession of the customer. Failure to fully comply
with Torus Power operating instructions, voids the warranty.
Warranty
www.TorusPower.com
Owner’s Manual Audio / Video Power Isolation Units International UK Rack Mount / Standalone 03/09Power Conditioners
™

The front panel power switch is also
a circuit breaker.
When the breaker trips, the switch
returns to its “off” position.
Front Panel Layout Circuit Protection
Torus PIUs will shut-down if internal
unit temperature reaches excessive
levels.
Thermal Protection
Electrical Specifications
Input Voltage
Nominal
240VAC230/
Range +/- 10% voltage
47-53Hz
Model Number
RM 16 INT’L UK
International 16A - UK
Model Number RM 16 INT’L UK
Input
Current
Limiting
16A Circuit Breaker
Front Panel
Input Current
Rating
16A
½ cycle
160A
Load Current Capability
1 second
96A
10 seconds
32A
www.TorusPower.com
Owner’s Manual Audio / Video Power Isolation Units International UK Rack Mount / Standalone 03/09Power Conditioners
™
Rear Panel Layout
The six 13A outlets are protected by
the input circuit breaker on the front
panel.
Output Circuit
Protection
13A/250V
UK Panel Mount
Socket
Ground Stud
IEC 16A AC Inlet
International 16A - UK
Model Number RM 16 INT’L UK
Mechanical Specifications
Input (Inlet)
Connector
(Rear Panel)
IEC 16A
Output
Connector
(Rear Panel)
6 outlets
(UK panel mount
socket)
Weight
54 kg
Size, mm
(wxdxh)
483 x 457 x 178
Model Number
RM 16 INT’L UK
Input Power Switch / Circuit Breaker

Torus Power products are marketed
worldwide through Bryston Limited.
For sales contact
[email protected]
www.bryston.ca
03/09
™
Specifications subject to change without notice.
© Torus Power 2008
ZeroSurge is a registered trademark of Zero Surge Inc.
www.TorusPower.com
Torus Power
#8 601 Magnetic Drive
Toronto, ON M3J 3J2
Canada
416-667-8473
