MULTIFUNCTIONAL DIGITAL COLOR SYSTEMS /
MULTIFUNCTIONAL DIGITAL SYSTEMS
High Security Mode
Management Guide

©2012 - 2015 TOSHIBA TEC CORPORATION All rights reserved
Under the copyright laws, this manual cannot be reproduced in any form without prior written permission of TTEC.

Preface 1
Preface
Thank you for purchasing Toshiba Multifunctional Digital Systems.
This manual explains about the conditions and settings for using the Multifunctional Digital Systems which
complies with IEEE Std 2600.1TM-2009.
Read this manual carefully before using your Multifunctional Digital Systems under the high security mode.
For the security precautions on operating the equipment complying with IEEE Std 2600.1TM-2009, refer to
“Security Precautions” in the “Safety Information”.
Keep this manual within easy reach and use it to maintain the equipment complying with IEEE Std 2600.1TM-
2009.
If you find any evidence of the suspicious opening of received cartons or you are not sure how it has been
packed, contact your sales representative.
How to read this manual
Symbols in this manual
In this manual, some important items are marked with the symbols shown below. Be sure to read these items
before using this equipment.
Other than the above, this manual also marks information that may be useful for the operation of this
equipment with the following signs:
Model and series names in this manual
In this manual, each model name is replaced with the series name as shown below.
Indicates a potentially hazardous situation which, if not avoided, could result in death,
serious injury, or serious damage, or fire in the equipment or surrounding assets.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury, partial damage to the equipment or surrounding assets, or loss of data.
Indicates information to which you should pay attention when operating the equipment.
Describes handy information that is useful to know when operating the equipment.
Pages describing items related to what you are currently doing. See these pages as
required.
Model name Series name in this manual
e-STUDIO2050C/2550C e-STUDIO2550C Series
e-STUDIO2555C/3055C/3555C/4555C/5055C
e-STUDIO2555CSE/3055CSE/3555CSE/4555CSE/5055CSE
e-STUDIO5055C Series
e-STUDIO287CS/347CS/407CS
e-STUDIO287CSL/347CSL
e-STUDIO407CS Series
e-STUDIO477S/527S
e-STUDIO477SL
e-STUDIO527S Series
e-STUDIO5560C/6560C/6570C e-STUDIO6570C Series
e-STUDIO207L/257/307/357/457/507 e-STUDIO507 Series
e-STUDIO557/657/757/857 e-STUDIO857 Series

2 Preface
Explanation for control panel and touch panel
Illustrations for the control panel and the touch panel shown in this manual are those of the
e-STUDIO4540C Series.
The shape and location of some buttons on the control panel and the dimension of the touch panel of the
other models differ depending on the model, however, the names and functions of the buttons and parts
are the same.
The details on the touch panel menus may differ depending on the operating environment such as whether
options are installed.
The illustration screens used in this manual are for paper in the A/B format. If you use paper in the LT
format, the display or the order of buttons in the illustrations may differ from that of your equipment.
Options
For the available options, refer to "Options" in the Quick Start Guide for your equipment.
Trademarks
The official name of Windows Vista is Microsoft Windows Vista Operating System.
The official name of Windows 7 is Microsoft Windows 7 Operating System.
The official name of Windows 8 is Microsoft Windows 8 Operating System.
The official name of Windows Server 2003 is Microsoft Windows Server 2003 Operating System.
The official name of Windows Server 2008 is Microsoft Windows Server 2008 Operating System.
The official name of Windows Server 2012 is Microsoft Windows Server 2012 Operating System.
Microsoft, Windows, Windows NT, and the brand names and product names of other Microsoft products
are trademarks of Microsoft Corporation in the US and other countries.
Apple, AppleTalk, Macintosh, Mac, Mac OS, Safari, iPhone, iPod touch, and TrueType are trademarks of
Apple Inc. in the US and other countries.
AirPrint, AirPrint logo, and iPad are trademarks of Apple Inc.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under
license.
Adobe, Acrobat, Reader, and PostScript are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
Mozilla, Firefox and the Firefox logo are trademarks or registered trademarks of Mozilla Foundation in the
U.S. and other countries.
IBM, AT and AIX are trademarks of International Business Machines Corporation.
NOVELL, NetWare, and NDS are trademarks of Novell, Inc.
TopAccess is a trademark of Toshiba Tec Corporation.
Other company and product names given in this manual or displayed in this software may be the
trademarks of their respective companies.

CONTENTS 3
CONTENTS
Preface....................................................................................................................................... 1
How to read this manual........................................................................................................ 1
Chapter 1 THE HIGH SECURITY MODE
Precautions on Using the High Security Mode...................................................................... 6
Confirmation of the mode ...................................................................................................... 7
Operational conditions........................................................................................................... 8
Chapter 2 UNIQUE FUNCTIONS
Temporary Password ............................................................................................................. 12
Conditions when a temporary password is used ................................................................. 12
Operation by a user when a temporary password is used .................................................. 12
HOLD (FAX)............................................................................................................................. 13
Chapter 3 THE INITIAL VALUES
Precautions on the Initial Values .......................................................................................... 16
Logging in............................................................................................................................ 16
Initial value list ..................................................................................................................... 16

4 CONTENTS

1.THE HIGH SECURITY MODE
Precautions on Using the High Security Mode ..................................................................... 6
Confirmation of the mode .......................................................................................................................................7
Operational conditions............................................................................................................................................8

1 THE HIGH SECURITY MODE
6 Precautions on Using the High Security Mode
Precautions on Using the High Security Mode
This operation mode protects customers’ important information against unauthorized access to the equipment
and leakage.
The following are the security functions when you operate the equipment complying with IEEE Std 2600.1TM-
2009.
User Authentication Setting function
Role Management function
Encryption function of data to be written in HDD *1
Log collecting and browsing function
Overwriting function of the specified data in HDD when jobs are completed or the power is turned ON
Communication function with SSL*2 or TLS
Integrity Check function
Management functions such as:
Log, Passwords, User, Password Policy, Date & Time, Auto Clear, Session Timer, Enable/disable of
SSL*2/LTS
*1 The function to encrypt the data to be written in the HDD for the e-STUDIO5560C/6560C/6570C, e-STUDIO207L/257/307/357/457/
507 and e-STUDIO557/657/757/857 series are not subject to the assessment of ISO/IEC15408.
*2 Only TLS is supported in the e-STUDIO5560C/6560C/6570C, e-STUDIO207L/257/307/357/457/507 and e-STUDIO557/657/757/857
series.
The ISO/IEC 15408 certification is applied or will be to the models operating with the following OS and
browser combination as well as running in the English or Japanese mode.
OS: Windows XP
Browser: Internet Explorer 8
MFP:
e-STUDIO2050C/2550C
e-STUDIO2555C/3055C/3555C/4555C/5055C
e-STUDIO2555CSE/3055CSE/3555CSE/4555CSE/5055CSE
OS: Windows 7
Browser: Internet Explorer 9
MFP:
e-STUDIO5560C/6560C/6570C*
e-STUDIO207L/257/307/357/457/507*
e-STUDIO557/657/757/857*
* Certification pending (as of March, 2015)
To operate the equipment complying with IEEE Std 2600.1TM-2009 under the high security mode,
configurations according to the use environment, such as data or protocol encryption setting and setting for
the connection only to the authorized server or client PC, are required.
Pay attention that if the conditions given in this manual are not met, you may not be able to operate the
equipment complying with IEEE Std 2600.1TM-2009.
For details of each security function and how to set the related items, refer to the TopAccess Guide.
The optional Hard Disk Kit (GE-1220) is required when e-STUDIO2050C/2550C with no hard disk is to
be used in the high security mode.

1.THE HIGH SECURITY MODE
Precautions on Using the High Security Mode 7
1 THE HIGH SECURITY MODE
Confirmation of the mode
When this equipment is operated under the high security mode, is displayed on the touch panel of the
equipment.
The HDD inside the equipment which is operated under the high security mode is encrypted. Moreover,
the Data Overwrite Option (GP-1070) is installed in such equipment.
To confirm that each function is operating, check the display at the top right of the [Counter] screen on
the touch panel of the equipment.
When the Data Overwrite Enabler is installed, the hard disk space temporarily used during the job
process will be used for another job after the data are overwritten when the user is logging out.
The HDD is encrypted. The icon is displayed.
The HDD has been encrypted if this equipment is operated
under the high security mode.
The Data Overwrite Enabler is
operating properly. The icon showing that the Data Overwrite Enabler is
correctly operating is displayed.
The version of the system which is running is displayed.
The system version to be displayed differs depending on the
equipment which is used.
e-STUDIO2550C Series: SYS V4.0
e-STUDIO5055C Series: SYS V4.0
e-STUDIO6570C Series: SYS V3.0 *
e-STUDIO507 Series: SYS V3.0 *
e-STUDIO857 Series: SYS V3.0 *
e-STUIDO407CS Series: SYS V2.0
e-STUDIO527S Series: SYS V2.0
e-STUDIO307LP: SYS V2.0
* ISO/IEC15408 certification accession version

1 THE HIGH SECURITY MODE
8 Precautions on Using the High Security Mode
Operational conditions
Follow the operating guidance above, otherwise your confidential information will not be protected
from leakage or unauthorized access to this equipment.
Be sure to set [MFP Local Authentication] for [Authentication Method] in the [User Management]
screen. If [Windows Domain Authentication] or [LDAP Authentication] is set for user authentication,
the equipment will not be covered by IEEE Std 2600.1TM-2009.
When connecting the equipment from any of e-Filing BackUp/Restore Utility, File Downloader, TWAIN
Driver or AddressBook Viewer, enter an ID and password to log in. The password input is displayed in
the blank symbols. In addition, you will be locked out if the password is input incorrectly a certain
number of times.
Manually select [FULL] and perform the integrity check at the time of installation and during use
periodically.
* For details of the integrity check, refer to the MFP Management Guide/User’s Manual Advanced Guide.
Do not change the communication settings of the equipment from the initial values. Communication
via a network can be protected by SSL if no such changes are made.
Set to OFF [MEMORY TX] under [USER FUNCTIONS] - [ADMIN] - [LIST/REPORT] - [REPORT SETTING]
- [COMM. REPORT].
In any of the following cases, contact your service technician.
If the icon showing that the HDD is encrypted ( ) is not displayed.
If the icon showing that the Data Overwrite Enabler is operating properly ( ) is not displayed.
The displayed system version differs from the actual one.
When SNMPV3 is used, be sure to set "General User" in the [Permission Level] box during the
creation of the SNMP V3 user information in the following menu:
[Administration] tab page -> [Setup] menu -> [Network] submenu -> [SNMP] -> [Create SNMP V3 User
Information] screen
In the High Security Mode, the following functions cannot be used.
Interrupt copy
Network Fax
AddressBook Viewer
File Downloader
TWAIN Driver
e-Filing BackUp/Restore Utility
Scheduled printing
Storing to e-Filing from a printer driver*
* The function can be selected; however, an error occurs and the job is deleted. As a result, printing is not performed. When a job
is deleted, it is recorded in the error log. Confirm it in the [Logs] tab on TopAccess or [JOB STATUS] - [LOG] - [PRINT] in the
equipment.
Disabling log authentication
The automatic log-in function in the client software which comes with this equipment is not available.
Be sure to enter the user name and password when using client software.

1.THE HIGH SECURITY MODE
Precautions on Using the High Security Mode 9
1 THE HIGH SECURITY MODE
Any data sent to this equipment, such as a Fax and Internet Fax printed or received from a printer
driver*, can be outputted only when a user with the printing privilege is logged in.
* Use IPP SSL to communicate with this equipment.
When IPP printing is performed, use the port created by entering “https://[IP address]:[SSL port
number]/Print” into the URL field.
(e.g.: https://192.168.1.2:443/Print)
* For details, refer to [IPP printing] under [Installing the Printer Drivers] - [Other Installations] in the Software installation guide.
When importing the data such as address book, be sure to use the data exported from this equipment.
Do not use any applications which need a setting change of the [ODCA] sub menu in the [Setup] menu
on the [Administration] tab under TopAccess.
Do not enable [Use Password Authentication for Print Job] when printing is performed from this
equipment with any of these printer drivers; Universal Printer 2, Universal PS3 and Universal XPS.
To operate this equipment securely, be sure to set the following items:
Perform the setting correctly referring to Initial value list (P. 1 6 ) .
Select [Disable] in [Enable Raw TCP] and [Enable LPD] in the [Print Service] submenu.
Use the encrypted PDF format when saving or sending a file and the encryption level shall be 128 bit AES.
Specify a reliable remote PC for the saving destination of the scan data.
Do not use PUBLIC BOX in e-Filing since no password can be set.
Do not use MFP LOCAL since no password can be set.
When printing a Report by InternetFax, do not select “Print 1st page image” so that no copy of the original
will be added.
Administrators must regularly export and store the logs.
Select [Disable] in [Twain Scanning].
Select [Disable] in [Enable SLP].
Select [Disable] in [Web Services Print].
Select [Disable] in [SMB Server Protocol].
Select [Disable] in [Enable Bonjour].
Select [Disable] in [Enable FTP Server].
An administrator should explain to users that the high security mode is operating in this equipment
as well as the following items so that they will keep to them appropriately.
Printing should be performed by using the printer driver settings of IPP print.
Specify a reliable remote PC for the saving destination of the scan data.
Do not use a shared folder in e-Filing.
Do not use any local folder of this equipment.

2.UNIQUE FUNCTIONS
Temporary Password ............................................................................................................. 12
Conditions when a temporary password is used..................................................................................................12
Operation by a user when a temporary password is used ...................................................................................12
HOLD (FAX)............................................................................................................................. 13

2 UNIQUE FUNCTIONS
12 Temporary Password
Temporary Password
In the high security mode, a password, tentatively assigned by an administrator to allow a user access, is
treated as a temporary one. To use the equipment, you need to register your password after accessing it with
the temporary one.
The security level is insufficient if you continue to use the temporary password. Register your password as
soon as possible.
Conditions when a temporary password is used
A user temporary password is used in the following cases:
For the first time to log in to the equipment after being registered by an administrator.
When an administrator resets the user’s password.
When the user information password imported by an administrator is plain text.
When an administrator resets users' passwords, they must be so notified and prompted to change them to
ones of their own choosing.
To prevent user information exported from an equipment from being altered, it is hashed. If you change the
password for the exported user information, plain text is used for the password.
Operation by a user when a temporary password is used
If your password can be registered when accessing.
Registering your password on the control panel
Enter the user name and a temporary password in the User Authentication menu. When you press [OK] in
the confirmation screen for the temporary password, the password entry screen appears. Enter the
temporary password in [OLD PASSWORD]. Enter your new password in [NEW PASSWORD] and
[RETYPE NEW PASSWORD], and then press [OK]. The new password is registered and you can log in to
the equipment.
Registering your password in TopAccess
When you access the equipment from TopAccess, the log-in screen appears. Enter the user name and a
temporary password in the log-in screen, and then press [Login]. When the registration screen appears,
enter your new password in [NEW PASSWORD] and [RETYPE NEW PASSWORD], and then press
[SAVE]. The new password is registered and you can log in to TopAccess.
If you cannot register a new password when accessing the equipment.
In the following utilities, an error occurs when you try to log in to the equipment with a temporary password.
Therefore a new password cannot be registered either. Before using these utilities, register a new password
on the control panel or in TopAccess.
Remote Scan driver
e-Filing Web Utility

2 UNIQUE FUNCTIONS
HOLD (FAX) 13
HOLD (FAX)
In the high security mode, when an email to which a FAX, Internet FAX or image is received, it is not
automatically output. These jobs are stored in the [HOLD (FAX)] queue and only a user having the [Fax
Received Print] privilege can print the job.
If a job is in the [HOLD (FAX)] queue, the MEMORY RX lamp blinks.
Printing a job in the HOLD (FAX) queue
1
Log in to the equipment as a user having the [Fax Received Print] privilege.
3
Select [HOLD (FAX)].
All jobs in the [HOLD (FAX)] queue are displayed.
2
Press the [PRINT] button on the control panel.

2 UNIQUE FUNCTIONS
14 HOLD (FAX)
4
Select the desired job or [SELECT ALL], and then press [PRINT].
The job that has been output is deleted from the [HOLD (FAX)] queue.

3.THE INITIAL VALUES
Precautions on the Initial Values .......................................................................................... 16
Logging in.............................................................................................................................................................16
Initial value list ......................................................................................................................................................16

3 THE INITIAL VALUES
16 Precautions on the Initial Values
Precautions on the Initial Values
To securely operate the equipment, the initial and selectable values in the equipment under the high security
mode may differ from those under the normal security mode. This manual only explains about the initial
values and setting items which are different from those under the normal security mode.
To operate equipment complying with IEEE Std 2600.1TM-2009, be sure to change the initial values for the
high security mode listed in this chapter following the instructions described in the remarks column at the start
of use and keep them unchanged.
For the initial and setting values in the normal security mode, refer to the TopAccess Guide and MFP
Management Guide.
To reset all settings by performing “Initialization” of this equipment, back up the setting of this
equipment and customers’ data before initializing. For details, refer to the TopAccess Guide and MFP
Management Guide.
Logging in
The [User Management] and [Administration] tabs in TopAccess are displayed by logging in as a user with
the administrator privilege. Open TopAccess, click “Login” on the top right, and then enter the user name
and password to log in.
Be sure to log in the [ADMIN] tab in the [USER FUNCTIONS] mode of the equipment as a user with the
Administrator privilege.
Initial value list
[Administration] Tab
[Setup] Menu
[General] Sub Menu
* The value can be changed in the [ADMIN] tab in the [User Function] mode in the touch panel of the equipment.
Item Initial value for the high
security mode Remarks
Functions
Save as FTP Disable
Network iFax Disable
Network Fax Disable
Web Services Scan Disable
Twain Scanning Enable The initial value is the same as that of in the
Normal Security Mode; however, be sure to
set to OFF.
Restriction on Address Book Operation by Administrator
Can be operated by Administrator only
Energy Save
Auto Clear * 45 Seconds The initial value is the same as in the Normal
Security Mode; however, OFF cannot be
selected.

3.THE INITIAL VALUES
Precautions on the Initial Values 17
3 THE INITIAL VALUES
[Network] Sub Menu
* The value can be changed in the [ADMIN] tab in the [User Function] mode in the touch panel of the equipment.
Item Initial value for the high
security mode Remarks
HTTP Network Service
Enable SSL* Enable
SMTP Client
Enable SSL Verify with imported CA
certification(s)
The secure setting is "Verify with imported CA
certification(s)" or "Accept all certificates
without CA".
Authentication AUTO Be sure to confirm that one of "CRAM-MD5",
"Digest-MD5", "Kerberos" or "NTLM (IWA)" is
applied to your use environment.
SMTP Server
Enable SMTP Server Disable
POP3 Network Service
Enable SSL Verify with imported CA
certification(s)
FTP Client
Enable SSL Verify with imported CA
certification(s)
FTP Server
Enable FTP Server Enable Although [Enable] is set by default in the same
manner as the normal security mode, be sure
to set it to [Disable]
Enable SSL Enable
SNMP Network Service
Enable SNMP V1/V2 Disable
Enable SNMP V3 Enable
Web Services Setting
Enable SSL Enable
Web Services Print Enable Although [Enable] is set by default in the same
manner as the normal security mode, be sure
to set it to [Disable].
Web Services Scan Disable
SLP Session
Enable SLP Enable Although [Enable] is set by default in the same
manner as the normal security mode, be sure
to set it to [Disable].
SMB Session
SMB Server Protocol Enable Although [Enable] is set by default in the same
manner as the normal security mode, be sure
to set it to [Disable].
Bonjour
Enable Bonjour Enable Although [Enable] is set by default in the same
manner as the normal security mode, be sure
to set it to [Disable].

3 THE INITIAL VALUES
18 Precautions on the Initial Values
[Printer] Sub Menu
[Print Service] Sub Menu
[ODCA] Sub Menu
[Security] Menu
[Authentication] Sub Menu
Item Initial value for the high
security mode Remarks
General Setting
Restriction for Print
Job
Only Hold
Item Initial value for the high
security mode Remarks
IPP Print
Enable SSL Enable
FTP Print
Enable FTP Printing Disable
Raw TCP Print
Enable Raw TCP Enable Although [Enable] is set by default in the same
manner as the normal security mode, be sure
to set it to [Disable].
LPD Print
Enable LPD Enable Although [Enable] is set by default in the same
manner as the normal security mode, be sure
to set it to [Disable].
Item Initial value for the high
security mode Remarks
Network
Enable Port Disable
Item Initial value for the high
security mode Remarks
User Authentication Setting
User Authentication Enable You cannot change the setting to "Disable".
Authentication Type MFP Local
Authentication
Enable Guest User No check mark (Disable) The initial value is the same as in the Normal
Security Mode; however, it cannot be set to
"Enable".
PIN Code Authentication Disable Do not change the setting to “Enable”.
Use Password
Authentication for Print
Job
Disable Do not change the setting to “Enable”.
