Toshiba PA3893U-1CAM Camileo S30 User manual

GMAA00272011
11/10
English/Español
CAMILEO™ S30
User’s Guide

2
5.375 x 8.375 ver 2.3
Regulatory Information
FCC Information
Product Name: Camcorder
Model number: CAMILEO™ S30
FCC notice “Declaration of Conformity Information”
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
❖Reorient or relocate the receiving antenna.
❖Increase the separation between the equipment and receiver.
❖Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
❖Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications made to this equipment, not expressly approved
by TOSHIBA or parties authorized by TOSHIBA could void the user’s
authority to operate the equipment.

3
5.375 x 8.375 ver 2.3
FCC Conditions
This equipment has been tested and found to comply with Part 15 of the FCC
Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that
may cause undesired operation.
Contact
Safety Instructions
1Do not drop, puncture or disassemble the camcorder; otherwise the
warranty will be voided.
2Avoid all contact with water, and dry hands before using.
3Do not expose the camcorder to high temperature or leave it in direct
sunlight. Doing so may damage the camcorder.
4Use the camcorder with care. Avoid pressing hard on the camcorder body.
5For your own safety, avoid using the camcorder when there is a storm or
lightning.
6Do not use batteries of different specifications. Doing so may lead to the
potential for serious damage.
7Remove the battery during long periods between usage, as a deteriorated
battery may affect the functionality of the camcorder.
8Remove the battery if it shows signs of leaking or distortion.
9Use only the accessories supplied by the manufacturer.
10 Keep the camcorder out of the reach of infants.
11 Risk of explosion if battery is replaced by an incorrect type.
Address: TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Telephone: [phone]

4
5.375 x 8.375 ver 2.3
12 Dispose of used batteries according to the instructions.
About the battery pack
❖Use only batteries recommended by TOSHIBA as replacements. The
battery pack is lithium ion batteries, which can explode if not replaced,
used, handled or disposed of properly. Dispose of the battery as required by
local ordinances or regulations.
❖Charge the battery pack only in an ambient temperature between 5 and 35
degrees Celsius. Otherwise, the electrolyte solution might leak, battery pack
performance might deteriorate and the battery life might be shortened.
❖Never install or remove the battery pack without first turning off the power
and disconnecting the AC adaptor.
❖Only use the supplied AC adaptor or USB cable, or an optional Toshiba
battery charger to charge the battery pack. Never attempt to charge the
battery pack with any other charger.
Safety icons
This manual contains safety instructions that must be observed to avoid potential
hazards that could result in personal injuries, damage to your equipment, or loss
of data. These safety cautions have been classified according to the seriousness of
the risk, and icons highlight these instructions as follows:
Indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderate injury.
Indicates a potentially hazardous situation which, if not avoided, may result
in property damage.
Provides important information.
NOTE

5
5.375 x 8.375 ver 2.3
Additional Information
© Copyright 2010 TOSHIBA CORPORATION. All rights reserved. TOSHIBA
reserves the right to make technical changes. TOSHIBA assumes no liability for
damages incurred directly or indirectly from errors, omissions or discrepancies
between this product and the documentation.
Trademarks
CAMILEO is a trademark of Toshiba America Information Systems, Inc. and/or
Toshiba Corporation.
Adobe is either a registered trademark or trademark of Adobe Systems
Incorporated in the United States and/or other countries.
ArcSoft and MediaImpression are registered trademarks of ArcSoft, Inc.
Facebook is a registered trademark of Facebook Inc.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC.
Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the United States and other
countries.
Microsoft, Windows, and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
Picasa is a trademark of Google Inc.
Secure Digital and SD are trademarks of SD Card Association.
YouTube and the YouTube logo are registered trademarks of Google, Inc.
All other brand and product names are trademarks or registered trademarks of
their respective companies.

6
5.375 x 8.375 ver 2.3
Contents
Chapter 1: Getting to Know Your Camcorder.............................9
Overview ..................................................................9
Check the Components.....................................10
System Requirements.......................................10
Front/Side views ...............................................11
Rear view..........................................................12
Underside view .................................................12
Chapter 2: Getting Started......................................................... 13
Loading the battery.................................................13
Charging the battery .........................................14
Inserting and removing an SD™ Card (optional).....19
Protecting data on an SD™ Card.......................20
Turning the camcorder on and getting started .......20
Turning off the camcorder ......................................20
Chapter 3: Record Mode........................................................... 21
Button functions .....................................................21
LCD touch screen information ................................22
Notification icons..............................................22
Touch function icons ........................................24

7
Contents
5.375 x 8.375 ver 2.3
Video recording ......................................................25
Photo recording......................................................26
Taking close up photos/videos................................26
Using digital zoom ..................................................26
Menu options/operations........................................27
Video Setting options........................................28
Photo setting options........................................32
Photo Effects ....................................................36
Deleting files .....................................................39
Chapter 4: Playback Mode........................................................ 41
Button functions .....................................................41
LCD touch screen information ................................42
Notification icons..............................................42
Touch function icons ........................................43
Playback mode operations......................................44
Video Playback..................................................45
Photo Playback .................................................45
Delete a file in Playback mode ..........................46
Chapter 5: Camcorder Settings................................................ 47
Settings Menu.........................................................47
Sound ...............................................................48
TV .....................................................................48
Language ..........................................................49
Time Setting......................................................49
Format ..............................................................50
Default Setting ..................................................50
Chapter 6: Viewing Photos and
Videos on TV..................................................... 52
Connecting to a high-definition 16:9 (wide) TV.......52
Connecting to a non-high-definition 4:3 TV ...........53

8Contents
5.375 x 8.375 ver 2.3
Chapter 7: Viewing Photos and
Videos on a Computer...................................... 54
Installing bundled software.....................................54
Transferring photos or videos to a computer..........55
Chapter 8: Uploading Video Files to the Internet..................... 56
CAMILEO UPLOADER..............................................56
ArcSoft MediaImpression .......................................60
Chapter 9: Specifications........................................................... 63
Operating Environment Conditions .........................64
Chapter 10: Troubleshooting..................................................... 65
Chapter 11: Other Information.................................................. 67
Toshiba Support .....................................................67
Before you call ..................................................67
Contacting Toshiba .................................................68
Toshiba’s technical support Web site................68
Toshiba voice contact .......................................68
Warranty.................................................................69
Online Warranty Information.............................69
Warranty Service ..............................................69

9
Chapter 1
Getting to Know Your
Camcorder
Overview
Your Toshiba camcorder comes equipped with a 8 Mega Pixel
sensor that can record H.264 format videos. This format allows for
extended video recording with less memory.
Other features of your CAMILEO™S30 camcorder are:
❖High quality images up to 16 mega-pixels
❖Color LCD touch screen for easy viewing of photos and videos
❖Video recording at an HD resolution of 1920 x1080
❖HDTV connectivity via an HDMI™cable
❖Easy playback of recorded high-definition videos on wide
screen HDTV
❖Built-in CAMILEO UPLOADER, allowing you to upload videos
captured by the camcorder to the Internet more effortlessly
❖ISO and white balance can be set to automatic or manually
adjusted
❖16x digital zoom
❖Various effect options, such as Time Lapse and Slow Motion

10 Getting to Know Your Camcorder
Overview
❖Built-in memory allowing you to take photos and to record
videos without a memory card
A portion of the built-in memory is used for Firmware to operate the
camcorder.
❖Memory card slot allowing users to increase storage capacity
Check the Components
Unpack the box and make sure all listed items below are included:
(Sample Illustration) Components
*Preinstalled in the camcorder
Be sure to remove the protective film on the lens before using.
System Requirements
❖Microsoft®Windows®XP/Windows Vista®/Windows®7
❖Intel®Pentium®IV, 2.4 GHz or above
❖512 MB RAM
❖CD-ROM Drive
❖1 GB free HDD space
❖Available USB 2.0 port
❖16-bit color display
NOTE
Camcorder USB cable AV cable
Quick Start
Guide
CD-ROM
(Software,
User’s Manual, and
Cleaning cloth Hand Nylon case Mini
HDMI™ cable AC adaptor
Lithium-ion
Rechargeable
battery*
tripodstrap
Warranty information)
NOTE

11
Getting to Know Your Camcorder
Overview
The LCD touch screen is manufactured using extremely high-
precision technology. However, some tiny black and/or bright dots
(white, red, blue or green) may appear on the LCD touch screen.
These dots are a normal result of the manufacturing process, and do
not affect the recording.
Front/Side views
(Sample Illustration) Front view
NOTE
Switch between Macro
SD™ Card cover
Macro switch
Lens
NOTE: Remove the
Microphone
LED light
mode and Normal
protective film from
the lens before use.
mode.
Switch between Video mode and Photo
Power
Speaker
Battery
Mode button
mode.
Internet Upload button
In Playback mode, press to select the file
you wish to upload to a Web site.
When the camcorder is connected to the
computer, press to launch the CAMILEO
UPLOADER application automatically.
button
cover

12 Getting to Know Your Camcorder
Overview
Rear view
(Sample Illustration) Rear view
For more detailed operational instruction, please see “Record
Mode” on page 21 and “Playback Mode” on page 41.
Underside view
(Sample Illustration) Underside view
Video mode indicator light
Tele button
Wide button
TV port
Record button
In Video Record mode, press to
Press to pause recording.
Pause button
Mini USB 2.0 port
Hand strap hook
Photo mode indicator light
HDMI™ port
Zoom out and Volume decrease.
record a video, press again to
stop. In Photo Record mode,
press to take photos.
Press it again, to continue
Zoom in, and Volume increase.
recording. LED light button
Hand strap hook
Mini tripod socket

13
Chapter 2
Getting Started
Loading the battery
The battery comes pre-installed in the camcorder, however you
must remove the protective film on the battery before use.
To properly connect the battery:
1Flip open the LCD touch screen and slide the battery cover off.
2Remove the battery.
3Pull off the protective film.
(Sample Illustration) Removing the protective film
4Reinsert the battery, making sure it is lined-up with the correct
polarity marks.
Protective film
Li-ion battery

14 Getting Started
Loading the battery
(Sample Illustration) Inserting the battery pack
5Close the battery cover.
Charging the battery
You must use the supplied AC adaptor or the USB cable to charge
your camcorder before use. Turn off the camcorder. A blinking light
will indicate active charging and a solid light indicates that charging
is complete. In AC charging mode, the light will turn off
automatically after 3~5 minutes.
(Sample Illustration) Charging the battery
Polarity marks
Li-ion battery
Battery cover

15
Getting Started
Loading the battery
Handling of the battery pack
❖Never attempt to dispose of a battery pack by burning or by
throwing it into a fire, and never allow exposure to a heating
apparatus (e.g., microwave oven). Heat can cause a battery pack
to explode and/or release caustic liquid, both which may
possibly cause serious injury.
❖Never attempt to disassemble, tamper with or repair a battery
pack. The battery pack could overheat and ignite. Leakage of the
caustic alkaline solution or other electrolytic substances could
cause fire, possibly resulting in death or serious injury.
❖Never short-circuit the battery pack by either accidentally or
intentionally bringing the battery terminals in contact with
another conductive object. This could cause serious injury or a
fire, and could also damage the battery pack and product.
Always wrap the battery pack in plastic (or place it in a plastic
bag) whenever transporting it, to avoid exposing the terminals to
another conductive object which could result in serious injury.
Always cover the metal terminals with insulating tape when
disposing of the battery pack, to prevent accidental short-
circuiting which could result in serious injury.

16 Getting Started
Loading the battery
❖Never drive a nail or any other sharp object into the battery pack,
hit battery pack with a hammer or other object or step on it.
Doing so could cause a fire or explosion possibly resulting in
serious injury.
❖Never charge the battery pack by a method other than as
instructed. Doing so could cause a fire or explosion possibly
resulting in serious injury.
❖Never connect the battery pack to a plug socket or a car cigarette
plug socket. The battery pack could rupture or ignite causing a
fire or explosion possibly resulting in serious injury.
❖Never allow a battery pack to become wet. A wet battery pack will
overheat or ignite causing rupture or fire, possibly resulting in
death or serious injury.
❖Never store a battery pack in an area of high humidity. This could
cause a fire or explosion possibly resulting in serious injury.
❖Never expose a battery pack to abnormal shock, vibration or
pressure. Never use a battery pack which has been exposed to
abnormal shock even if the appearance is normal. The battery
pack’s internal protective device could fail, causing it to overheat
or ignite resulting in caustic liquid leakage, or explosion or fire,
possibly resulting in death or serious injury.
❖Never subject a battery pack to heat, and never store it or use it
near a heat source. The battery pack could ignite or explode
when heated or burned, possibly resulting in death or serious
injury. Subjecting a battery pack to heat could also cause caustic
liquid to leak. It can also cause failure, malfunction, or loss of
stored data.
Use of correct battery pack
❖Always use the battery pack supplied. Other battery packs have
different voltage and terminal polarities. Use of non-conforming
battery packs could generate smoke or cause fire or rupture,
possibly resulting in serious injury.

17
Getting Started
Loading the battery
Battery safety
❖Never allow caustic electrolyte fluid leaked from the battery pack
to contact your eyes, body or clothing.
Use appropriate protective gloves when handling a damaged
battery.
If caustic electrolyte fluid from the battery pack should contact
your eyes, immediately wash your eyes with large amounts of
running water and obtain prompt medical attention, to help
prevent permanent eye damage.
If electrolyte fluid should contact any part of your body,
immediately wash it off under running water to help prevent skin
rashes.
If electrolyte fluid should contact your clothes, promptly remove
them to help prevent the electrolyte fluid from contacting your
body, possibly resulting in serious injury.
Battery pack warning indicators
❖Always immediately turn the power off and disconnect the power
cable/cord plug from the plug socket and stop using the battery
pack if you observe any of the following conditions:
❖Offensive or unusual odor
❖Excessive heat
❖Discoloration
❖Deformation, cracks or leaks
❖Smoke
❖Other unusual event during use, such as abnormal sound
In such an event, carefully and immediately remove the battery
pack from the product. In some instances, you might have to
wait for the product to cool down before removing the battery
pack, in order to avoid any possible minor injury due to heat
exposure. Do not turn on the product’s power again until an
authorized Toshiba service provider has checked it for safety.
Continued use could cause a fire or rupture possibly resulting in
serious injury or product failure including but not limited to the
loss of data.

18 Getting Started
Loading the battery
Disposal of used battery packs
❖Always dispose of used battery packs in compliance with all
applicable laws and regulations. Put insulating tape, such as
cellophane tape, on the electrode during transportation to avoid
a possible short circuit, fire or electric shock. Failure to do so
could possibly result in serious injury.
Inserting the battery pack
❖When installing a battery pack or before moving the product,
always make sure the battery pack is inserted correctly and
securely. If the battery falls out, while you are carrying the
product, you could be injured or the battery pack could be
damaged.
Do not use an impaired or exhausted battery pack
❖Never continue to use a battery pack after its recharging
capability has become impaired, or after the warning message
indicating that the battery pack power is exhausted has been
displayed.
Continued use of an exhausted or impaired battery pack could
result in the loss of data or damage to the product.
Handling of the battery pack
❖Never attempt to install batteries in reverse polarity.
❖Make sure the battery is securely installed in the product before
attempting to charge the battery pack.
❖Improper installation could generate smoke or fire, or cause the
battery pack to rupture.
NOTE

19
Getting Started
Inserting and removing an SD™ Card (optional)
❖The battery pack is lithium ion batteries, which can explode if not
replaced, used, handled or disposed of properly. Dispose of the
battery as required by local ordinances or regulations. Use only
batteries recommended by TOSHIBA as replacements.
❖Charge the battery pack only in an ambient temperature between
5 and 35 degrees Celsius. Otherwise, the electrolyte solution
might leak, battery pack performance might deteriorate and the
battery life might be shortened.
❖Never install or remove the battery pack without first turning off
the power and disconnecting the AC adaptor.
Inserting and removing an SD™ Card (optional)
An SD™ Card must be purchased separately.
Your camcorder comes with internal memory that allows you to
store photos and videos. You can expand the memory capacity by
using an optional SD/SDHC/SDXC memory card.
1Open the SD™ Card cover.
2Insert the SD™ Card into the slot until it locks into place, as
shown below.
(Sample Illustration) Inserting and removing an SD™ Card
When a memory card is inserted, videos and photos are saved to the
card rather than the built-in memory.
NOTE
SD™ Card
SD™ Card cover
To remove the SD™ Card press
inward to release it. When the
card pops out, grasp it and pull
it straight out.
NOTE

20 Getting Started
Turning the camcorder on and getting started
Protecting data on an SD™ Card
Photos or videos cannot be recorded on an SD™ Card when the
card is locked (read only), however photos and videos can be
viewed.
Make sure the lock is in the writeable position before recording
photos and videos as shown below.
(Sample Illustration) Protecting data on an SD™ Card
Turning the camcorder on and getting started
To turn on the camcorder, either:
❖Flip the LCD touch screen outward to turn on the camcorder
automatically.
❖Or press the Power button for approximately one second to turn
it on.
To record videos: Press the Mode ( ) button or touch the
onscreen ( ) icon to switch to Video Record mode. Press the
Record ()button to begin recording. The Video Record mode
LED Indicator ( ) glows.
To take a photo: Press the Mode ( ) button or touch the onscreen
( ) icon to switch to Photo Record mode. Press the Record button
to take a photo. The Photo mode LED Indicator ( ) glows.
Turning off the camcorder
To turn off the camcorder: You can either press the Power ()
button for one second, or you can place the LCD touch screen back
to its original position.
Write-protectedWriteable
position position
